碳素纤维生态基技术对城市黑臭水体的修复效果

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

梁益聪, 胡湛波, 涂玮灵, 陆晖, 蒋哲, 刘恺华. 碳素纤维生态基技术对城市黑臭水体的修复效果[J]. 环境工程学报, 2015, 9(2): 603-608. doi: 10.12030/j.cjee.20150216
引用本文: 梁益聪, 胡湛波, 涂玮灵, 陆晖, 蒋哲, 刘恺华. 碳素纤维生态基技术对城市黑臭水体的修复效果[J]. 环境工程学报, 2015, 9(2): 603-608. doi: 10.12030/j.cjee.20150216
shu
Liang Yicong, Hu Zhanbo, Tu Weiling, Lu Hui, Jiang Zhe, Liu Kaihua. Effectiveness of carbon fiber based biofilm carrier remediation technology on urban black-odorous water[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 603-608. doi: 10.12030/j.cjee.20150216
Citation: Liang Yicong, Hu Zhanbo, Tu Weiling, Lu Hui, Jiang Zhe, Liu Kaihua. Effectiveness of carbon fiber based biofilm carrier remediation technology on urban black-odorous water[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 603-608. doi: 10.12030/j.cjee.20150216
shu

碳素纤维生态基技术对城市黑臭水体的修复效果

  • 1.

    广西大学环境学院, 南宁 530004

  • 2.

    广西南方流域生态治理研究院, 南宁 530004

  • 基金项目:

    广西自然科学基金资助项目(2013GXNSFAA019278)

    南宁市科学研究与技术开发计划项目(20123112)

    南宁市环境保护专项资金(南财经[2012]308号)

  • 中图分类号: X703.1

Effectiveness of carbon fiber based biofilm carrier remediation technology on urban black-odorous water

  • 1.

    School of Environment, Guangxi University, Nanning 530004, China

  • 2.

    Guangxi Academy for Ecological Management of South Basin, Nanning 530004, China

  • Fund Project:

  • 摘要: 以碳素纤维(carbon fiber,CF)生态基为载体,处理南宁市朝阳溪黑臭河水,考察CF生态基在黑臭水体中的挂膜情况及其对污染物的去除效果。结果表明,CF生态基对污水中悬浮物有较强的吸附能力,在24 h内,CF实验组的浊度由原来的47.32 NTU降低为13.78 NTU;CF生态基生物亲和力强,易于挂膜,在黑臭水体中10 d内能形成较成熟的生物膜;在没有曝气情况下,CF生态基挂膜后对COD、TP、NH3-N和TN去除率分别达到76.00%、54.34%、90.73%和55.13%,是一种较有效的改善城市黑臭水体生态材料。
    Abstract: Carbon fiber (CF) was used as biofilm carrier to treat black-odorous water samples from Chaoyang Creek, Nanning. The biofilm culturing status and its remediation effectiveness on the removal of pollutants were investigated. The results showed that (1) there was a strong adsorption of the CF biofilm to the suspended substances in the polluted waters. The turbidity of the sample decreased from 47.32 to 13.78 NTU within 24 h; (2) CF had a good ecological compatibility and the mature biofilm was formed within 10 days in the black-odorous water; (3) without aeration, the removal rates of the COD, TP, NH3-N and TN in the sample were 76.0%, 54.34%, 90.73% and 55.13%, respectively. Therefore, CF is an effective ecological material to be used in the application for improving the quality of urban black-odorous water.
  • 加载中
  • [1] 郝晓明, 胡湛波, 刘成, 等. 南宁市竹排冲河道水体黑臭评价模型建立研究. 华东师范大学学报(自然科学版), 2011, (1): 163-171 Hao Xiaoming, Hu Zhanbo, Liu Cheng, et al. Development of black-odour prediction model for Nanning Zhupai Creek. Journal of East China Normal University (Natural Science), 2011, (1): 163-171 (in Chinese)
    [2] 温灼如, 张瑛玉, 洪陵成, 等. 苏州水网黑臭警报方案的研究. 环境科学, 1987, 8(4): 2-7, 94 Wen Zhuoru, Zhang Yingyu, Hong Lingcheng, et al. Study on alarming program of black-odour in Suzhou water nets. Environmental Science, 1987, 8(4): 2-7, 94 (in Chinese)
    [3] 马剑敏, 贺锋, 成水平, 等. 曝气和阿科蔓填料对月湖围隔中的水质改善作用. 环境科学与技术, 2010, 33(8): 114-119 Ma Jianmin, He Feng, Cheng Shuiping, et al. Improvement of water quality of yuehu lake using aeration assisted by aquamats. Environmental Science & Technology, 2010, 33(8): 114-119 (in Chinese)
    [4] Moss B. Engineering and biological approaches to the restoration from eutrophication of shallow lakes in which aquatic plant communities are important components. Hydrobiologia, 1990, 200-201(1): 367-377
    [5] 童敏, 李真, 黄民生, 等. 多功能人工水草生物膜处理黑臭河水研究. 水处理技术, 2011, 37(8): 112-116 Tong Min, Li Zhen, Huang Minsheng, et al. Study on treating malodorous black water by multi-fuctional eco-biofilm with artificial aquatic mat. Technology of Water Treatment, 2011, 37(8): 112-116 (in Chinese)
    [6] 郝桂玉, 黄民生, 徐亚同. 生物修复原理及其在黑臭水体治理中的应用. 净水技术, 2004, 23(2): 39-42 Hao Guiyu, Huang Minsheng, Xu Yatong. Theory of bioremediation and its application of treatment on malodorous black river. Water Purification Technology, 2004, 23(2): 39-42 (in Chinese)
    [7] 李兰, 索帮成, 常布辉, 等. 碳素纤维改性及其在富营养化水体中的挂膜实验. 中国农村水利水电, 2013, (3): 53-57 Li Lan, Suo Bangcheng, Chang Buhui, et al. Modification of carbon fiber and it's membrane hanging experiment in eutrophic water. China Rural Water and Hydropower, 2013, (3): 53-57 (in Chinese)
    [8] 姚理为. 碳素纤维在水质改善与生态修复领域的应用研究. 湘潭: 湘潭大学硕士学位论文, 2012 Yao Liwei. The applied research of carbon fiber in water improvement and ecological restoration. Xiangtan: Master Dissertation of Xiangtan University, 2012(in Chinese)
    [9] van der Hoek J. P., Hofman J. A. M. H., Graveland A. The use of biological activated carbon filtration for the removal of natural organic matter and organic micropollutants from water. Water Science and Technology, 1999, 40(9): 257-264
    [10] Matsumoto S., Ohtaki A., Hori K. Carbon fiber as an excellent support material for wastewater treatment biofilms. Environmental Science & Technology, 2012, 46(18): 10175-10181
    [11] Kojima A., Sato M., Yamada T. A large amounts adhesion of microorgan and water purification with carbon fiber. TANSO, 1999, 1999(187): 101-108
    [12] 姚理为, 余辉, 田学达, 等. 碳素纤维对富营养化水体的水质改善与对藻类群落结构的影响. 环境科学研究, 2012, 25(8): 890-896 Yao Liwei, Yu Hui, Tian Xueda, et al. Impacts of carbon fiber on eutrophic water quality improvement and its algal community structure. Research of Environmental Sciences, 2012, 25(8): 890-896 (in Chinese)
    [13] 国家环保局. 水和废水监测分析方法(第4版). 北京: 中国环境科学出版社, 2002
    [14] 田伟君, 翟金波. 生物膜技术在污染河道治理中的应用. 环境保护, 2003, 31(8): 19-21 Tian Weijun, Qu Jinbo. Application of biomembrance technique in river pollution control. Environmental Protection, 2003, 31(8): 19-21 (in Chinese)
    [15] 海景, 黄尚东, 程江, 等. 水处理用塑料生物膜载体改性研究进展. 合成材料老化与应用, 2006, 35(4): 41-45 Hai Jing, Huang Shangdong, Cheng Jiang, et al. Advances in modification of plastic biofilm carriers for biodegradation of waste water. Synthetic Materials Aging and Application, 2006, 35(4): 41-45 (in Chinese)
    [16] 徐亚同. 活性污泥的培养、驯化和生物膜的挂膜. 水工业市场, 2012, (4): 71-73 Xu Yatong. Domestication, culture of activated sludge and hanging of membrane. Water-Industry Market, 2012, (4): 71-73 (in Chinese)
    [17] 岳舜琳. 生物氧化在给水处理中的应用. 中国给水排水, 1996, 12(4): 17-20 Yue Shunlin. Application of biological oxidation in water treatment. China Water & Wastewater, 1996, 12(4): 17-20 (in Chinese)
    [18] 吴永红, 方涛, 丘昌强, 等. 藻-菌生物膜法改善富营养化水体水质的效果. 环境科学, 2005, 26(1): 84-89 Wu Yonghong, Fang Tao, Qiu Changqiang, et al. Method of algae-bacterium biofilm to improve water quality in eutrophic waters. Environmental Science, 2005, 26(1): 84-89 (in Chinese)
    [19] Chapman D. Water Quality Assessments - A Guide to Use of Biota, Sediments and Water in Environmental Monitoring (2nd ed). London: E & Fn Spon, 1996
    [20] 张丽萍, 袁文权, 张锡辉. 底泥污染物释放动力学研究. 环境污染治理技术与设备, 2003, 4(2): 22-26 Zhang Liping, Yuan Wenquan, Zhang Xihui. Kinetics of pollutants release from sediments. Techniques and Equipment for Environmental Pollution Control, 2003, 4(2): 22-26 (in Chinese)
    [21] 刘晓海, 高云涛, 陈建国, 等. 人工曝气技术在河道污染治理中的应用. 云南环境科学, 2006, 25(1): 44-46 Liu Xiaohai, Gao Yuntao, Chen Jianguo, et al. Application on river course pollution treatment by artificial aeration technology. Yunnan Environmental Science, 2006, 25(1): 44-46 (in Chinese)
    [22] 肖羽堂, 许建华. 生物接触氧化法净化微污染原水的机理研究. 环境科学, 1999, 20(3): 86-89 Xiao Yutang, Xu Jianhua. Research on the mechanism of micropollutants removal in the raw water by biochemistry purification process. Environmental Science, 1999, 20(3): 86-89 (in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  3587
  • HTML全文浏览数:  1679
  • PDF下载数:  1277
  • 施引文献:  0
出版历程
  • 收稿日期:  2014-04-15
  • 刊出日期:  2015-02-07
梁益聪, 胡湛波, 涂玮灵, 陆晖, 蒋哲, 刘恺华. 碳素纤维生态基技术对城市黑臭水体的修复效果[J]. 环境工程学报, 2015, 9(2): 603-608. doi: 10.12030/j.cjee.20150216
引用本文: 梁益聪, 胡湛波, 涂玮灵, 陆晖, 蒋哲, 刘恺华. 碳素纤维生态基技术对城市黑臭水体的修复效果[J]. 环境工程学报, 2015, 9(2): 603-608. doi: 10.12030/j.cjee.20150216
shu
Liang Yicong, Hu Zhanbo, Tu Weiling, Lu Hui, Jiang Zhe, Liu Kaihua. Effectiveness of carbon fiber based biofilm carrier remediation technology on urban black-odorous water[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 603-608. doi: 10.12030/j.cjee.20150216
Citation: Liang Yicong, Hu Zhanbo, Tu Weiling, Lu Hui, Jiang Zhe, Liu Kaihua. Effectiveness of carbon fiber based biofilm carrier remediation technology on urban black-odorous water[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 603-608. doi: 10.12030/j.cjee.20150216
shu

碳素纤维生态基技术对城市黑臭水体的修复效果

  • 1.  广西大学环境学院, 南宁 530004
  • 2.  广西南方流域生态治理研究院, 南宁 530004
  • 收稿日期:  2014-04-15
基金项目:

广西自然科学基金资助项目(2013GXNSFAA019278)

南宁市科学研究与技术开发计划项目(20123112)

南宁市环境保护专项资金(南财经[2012]308号)

摘要: 以碳素纤维(carbon fiber,CF)生态基为载体,处理南宁市朝阳溪黑臭河水,考察CF生态基在黑臭水体中的挂膜情况及其对污染物的去除效果。结果表明,CF生态基对污水中悬浮物有较强的吸附能力,在24 h内,CF实验组的浊度由原来的47.32 NTU降低为13.78 NTU;CF生态基生物亲和力强,易于挂膜,在黑臭水体中10 d内能形成较成熟的生物膜;在没有曝气情况下,CF生态基挂膜后对COD、TP、NH3-N和TN去除率分别达到76.00%、54.34%、90.73%和55.13%,是一种较有效的改善城市黑臭水体生态材料。
