吹脱法去除深度脱水污泥水中的氨氮

,  ,  ,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

周振, 胡大龙, 顾雨婷, 乔卫敏, 杜兴治, 李震, 蒋玲燕, 魏海娟, 吕燕. 吹脱法去除深度脱水污泥水中的氨氮[J]. 环境工程学报, 2015, 9(3): 1093-1097. doi: 10.12030/j.cjee.20150317
引用本文: 周振, 胡大龙, 顾雨婷, 乔卫敏, 杜兴治, 李震, 蒋玲燕, 魏海娟, 吕燕. 吹脱法去除深度脱水污泥水中的氨氮[J]. 环境工程学报, 2015, 9(3): 1093-1097. doi: 10.12030/j.cjee.20150317
shu
Zhou Zhen, Hu Dalong, Gu Yuting, Qiao Weimin, Du Xingzhi, Li Zhen, Jiang Lingyan, Wei Haijuan, Lü Yan. Ammonia removal by air stripping for reject water from advanced sludge dewatering process[J]. Chinese Journal of Environmental Engineering, 2015, 9(3): 1093-1097. doi: 10.12030/j.cjee.20150317
Citation: Zhou Zhen, Hu Dalong, Gu Yuting, Qiao Weimin, Du Xingzhi, Li Zhen, Jiang Lingyan, Wei Haijuan, Lü Yan. Ammonia removal by air stripping for reject water from advanced sludge dewatering process[J]. Chinese Journal of Environmental Engineering, 2015, 9(3): 1093-1097. doi: 10.12030/j.cjee.20150317
shu

吹脱法去除深度脱水污泥水中的氨氮

  • 1.

    上海电力学院环境与化学工程学院, 上海 200090

  • 2.

    上海城投污水处理有限公司, 上海 201203

  • 基金项目:

    国家高技术研究发展计划(863)项目(2012AA063403)

    上海市科委能力建设计划项目(12250500900)

  • 中图分类号: X703

Ammonia removal by air stripping for reject water from advanced sludge dewatering process

  • 1.

    College of Environmental and Chemical Engineering, Shanghai University of Electric Power, Shanghai 200090, China

  • 2.

    Shanghai Chentou Wastewater Treatment Co. Ltd., Shanghai 201203, China

  • Fund Project:

  • 摘要: 针对污水处理厂剩余污泥深度脱水污泥水高氨氮、高pH、高碱度的特点,考察了气水比、水温和吹脱时间对其氨氮吹脱效果的影响,分析了吹脱过程中污泥水pH下降和结垢问题。深度脱水污泥水高pH和高碱度的环境有利于氨氮吹脱的顺利进行,而提高气水比和温度均能改善吹脱效率。氨氮吹脱会造成污泥水pH下降,这有助于其后续处理。污泥水吹脱过程中还出现了Ca2+浓度下降和固体物质析出的现象,能谱分析结果显示析出物主要成分为CaCO3。
    Abstract: Reject water from advanced sludge dewatering process was characterized by high concentrations of ammonia nitrogen, high pH and high alkalinity. The effects of air-liquid ratio, temperature and stripping time on the removal of ammonia nitrogen from the reject water were investigated, and the phenomena of pH decrease and scaling during the stripping process were analyzed. High pH and high alkalinity of the reject water were conducive to the progress of stripping, while the increase of air-liquid ratio and temperature could both improve the stripping efficiency. Ammonia air stripping also results in the simultaneous decrease of pH and Ca2+ concentration. The decrease of pH was in favor of subsequent biological treatment of the reject water, while the latter decrease caused the precipitation of CaCO3 in the stripping equipment.
  • 加载中
  • [1] Tchobanoglous G., Burton F. L., Stensel H. D. Wastewater Engineering: Treatment and Reuse (4th ed.). New York: Metcalf & Eddy Incorporation, 2003
    [2] 陈柏校, 张辰, 王国华, 等. 污泥深度脱水工艺在杭州七格污水处理厂的应用. 中国给水排水, 2011, 27(8): 83-85 Chen Boxiao, Zhang Chen, Wang Guohua, et al. Application of advanced sludge dewatering process at Qige WWTP, Hangzhou. China Water & Wastewater, 2011, 27(8): 83-85(in Chinese)
    [3] 谢小青, 黄珍艺, 戴兰华, 等. 厦门城市污泥深度脱水处理及资源化利用研究. 中国给水排水, 2010, 26(5): 138-140 Xie Xiaoqing, Huang Zhenyi, Dai Lanhua, et al. Study on deep dewatering and recycling of municipal sludge in Xiamen. China Water & Wastewater, 2010, 26(5): 138-140(in Chinese)
    [4] 柯明勇. 集美污水处理厂污泥深度脱水技术探讨. 给水排水, 2011, 37(5): 40-43 Ke Mingyong. Probe into advanced sludge dewatering technology in Jimei wastewater treatment plant. Water & Wastewater Engineering, 2011, 37(5): 40-43(in Chinese)
    [5] 姚萌, 程国淡, 谢小青, 等. 城市污水厂污泥化学调理深度脱水机理. 环境工程学报, 2012, 6(8): 2787-2792 Yao Meng, Cheng Guodan, Xie Xiaoqing, et al. Mechanism of chemical conditioning for sludge dewatering in a municipal wastewater treatment plant. Chinese Journal of Environmental Engineering, 2012, 6(8): 2787-2792(in Chinese)
    [6] Ozturk I., Altinbas M., Koyuncu I., et al. Advanced physico-chemical treatment experiences on young municipal landfill leachates. Waste Management, 2003, 23(5): 441-446
    [7] Quan Xuejun, Wang Fuping, Zhao Qinghua, et al. Air stripping of ammonia in a water-sparged aerocyclone reactor. Journal of Hazardous Materials, 2009, 170(2-3): 983-988
    [8] 熊鸿斌, 谷良平, 张正. UASB-FEO-氨吹脱-CASS 工艺在垃圾渗滤液处理中的应用. 环境工程学报, 2010, 4(1): 39-43 Xiong Hongbin, Gu Liangping, Zhang Zheng. Application of UASB-FEO-ammonia stripping-CASS process in treatment of landfill leachate. Chinese Journal of Environmental Engineering, 2010, 4(1): 39-43(in Chinese)
    [9] Bonmatí A., Flotats X. Air stripping of ammonia from pig slurry: characterisation and feasibility as a pre- or post-treatment to mesophilic anaerobic digestion. Waste Management, 2003, 23(3): 261-272
    [10] Guštin S., Marinsek-Logar R. Effect of pH, temperature and air flow rate on the continuous ammonia stripping of the anaerobic digestion effluent. Process Safety and Environmental Protection, 2011, 89(1): 61-66
    [11] Zhang Lei, Lee Y. W., Jahng D. Ammonia stripping for enhanced biomethanization of piggery wastewater. Journal of Hazardous Materials, 2012, 199-200: 36-42
    [12] Alitalo A, Kyrö A, Aura E. Ammonia stripping of biologically treated liquid manure. Journal of Environmental Quality, 2012, 41(1): 273-280
    [13] De la Rubia M. á., Walker M., Heaven S., et al. Preliminary trials of in situ ammonia stripping from source segregated domestic food waste digestate using biogas: Effect of temperature and flow rate. Bioresource Technology, 2010, 101(24): 9486-9492
    [14] 国家环境保护总局. 水和废水监测分析方法 (第4版). 北京: 中国环境科学出版社, 2002
    [15] 孙华, 申哲民. 吹脱法去除氨氮的模型研究. 环境科学与技术, 2009, 32(8): 84-87 Sun Hua, Shen Zhemin. Model of air stripping of ammonia nitrogen. Enviromental Science & Technology, 2009, 32(8): 84-87(in Chinese)
    [16] 周振, 王罗春, 吴春华. 水化学. 北京: 冶金工业出版社, 2013
    [17] 周振, 胡大龙, 顾雨婷, 等. 浓缩脱水污泥水混凝预处理效果及混凝剂的选择. 环境工程学报, 2014, 8(11): 4575-4580 Zhou Zhen, Hu Dalong, Gu Yuting, et al. Coagulation pretreatment and coagulation selection on thickening and dewatering sludge water. Chinese Journal of Environmental Engineering, 2014, 8(11): 4575-4580(in Chinese)
    [18] 张树军, 韩晓宇, 张亮, 等. 污泥发酵同步消化液旁侧脱氮. 中国环境科学, 2011, 31(1): 19-24 Zhang Shujun, Han Xiaoyu, Zhang Liang, et al. Siding nitrogen removal from digestion liquid by simultaneous sludge fermentation and wastewater denitrification. China Environmental Science, 2011, 31(1): 19-24(in Chinese)
    [19] Budzianowski W., Koziol A. Stripping of ammonia from aqueous solutions in the presence of carbon dioxide: Effect of negative enhancement of mass transfer. Chemical Engineering Research and Design, 2005, 83(2): 196-204
    [20] Değermenci N., Ata O. N., Yildiz E. Ammonia removal by air stripping in a semi-batch jet loop reactor. Journal of Industrial and Engineering Chemistry, 2012, 18(1): 399-404
    [21] Segev R., Hasson D., Semiat R. Modeling CaCO3 precipitation in fluidized bed CO2 stripping desalination process. Desalination, 2013, 311: 192-197
    [22] Lee Y. W., Choi J. Y., Kim J. O., et al. Evaluation of UASB/CO2 stripping system for simultaneous removal of organics and calcium in linerboard wastewater. Environmental Progress & Sustainable Energy, 2011, 30(2): 187-195
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  3067
  • HTML全文浏览数:  2389
  • PDF下载数:  45
  • 施引文献:  0
出版历程
  • 收稿日期:  2014-03-01
  • 刊出日期:  2015-03-05
周振, 胡大龙, 顾雨婷, 乔卫敏, 杜兴治, 李震, 蒋玲燕, 魏海娟, 吕燕. 吹脱法去除深度脱水污泥水中的氨氮[J]. 环境工程学报, 2015, 9(3): 1093-1097. doi: 10.12030/j.cjee.20150317
引用本文: 周振, 胡大龙, 顾雨婷, 乔卫敏, 杜兴治, 李震, 蒋玲燕, 魏海娟, 吕燕. 吹脱法去除深度脱水污泥水中的氨氮[J]. 环境工程学报, 2015, 9(3): 1093-1097. doi: 10.12030/j.cjee.20150317
shu
Zhou Zhen, Hu Dalong, Gu Yuting, Qiao Weimin, Du Xingzhi, Li Zhen, Jiang Lingyan, Wei Haijuan, Lü Yan. Ammonia removal by air stripping for reject water from advanced sludge dewatering process[J]. Chinese Journal of Environmental Engineering, 2015, 9(3): 1093-1097. doi: 10.12030/j.cjee.20150317
Citation: Zhou Zhen, Hu Dalong, Gu Yuting, Qiao Weimin, Du Xingzhi, Li Zhen, Jiang Lingyan, Wei Haijuan, Lü Yan. Ammonia removal by air stripping for reject water from advanced sludge dewatering process[J]. Chinese Journal of Environmental Engineering, 2015, 9(3): 1093-1097. doi: 10.12030/j.cjee.20150317
shu

吹脱法去除深度脱水污泥水中的氨氮

  • 1. 上海电力学院环境与化学工程学院, 上海 200090
  • 2. 上海城投污水处理有限公司, 上海 201203
  • 收稿日期:  2014-03-01
基金项目:

国家高技术研究发展计划(863)项目(2012AA063403)

上海市科委能力建设计划项目(12250500900)

摘要: 针对污水处理厂剩余污泥深度脱水污泥水高氨氮、高pH、高碱度的特点,考察了气水比、水温和吹脱时间对其氨氮吹脱效果的影响,分析了吹脱过程中污泥水pH下降和结垢问题。深度脱水污泥水高pH和高碱度的环境有利于氨氮吹脱的顺利进行,而提高气水比和温度均能改善吹脱效率。氨氮吹脱会造成污泥水pH下降,这有助于其后续处理。污泥水吹脱过程中还出现了Ca2+浓度下降和固体物质析出的现象,能谱分析结果显示析出物主要成分为CaCO3。
