ZnIn2S4光催化降解水中痕量药物卡马西平的特性

,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

谭娜, 卜龙利, 高波, 刘嘉栋, 冯奇奇, 孟海龙, 何克博. ZnIn2S4光催化降解水中痕量药物卡马西平的特性[J]. 环境工程学报, 2017, 11(1): 223-229. doi: 10.12030/j.cjee.201508197
引用本文: 谭娜, 卜龙利, 高波, 刘嘉栋, 冯奇奇, 孟海龙, 何克博. ZnIn2S4光催化降解水中痕量药物卡马西平的特性[J]. 环境工程学报, 2017, 11(1): 223-229. doi: 10.12030/j.cjee.201508197
shu
TAN Na, BO Longli, GAO Bo, LIU Jiadong, FENG Qiqi, MENG Hailong, HE Kebo. Characteristics of photocatalytic degradation by ZnIn2S4 for trace pharmaceutical carbamazepine in aqueous solution[J]. Chinese Journal of Environmental Engineering, 2017, 11(1): 223-229. doi: 10.12030/j.cjee.201508197
Citation: TAN Na, BO Longli, GAO Bo, LIU Jiadong, FENG Qiqi, MENG Hailong, HE Kebo. Characteristics of photocatalytic degradation by ZnIn2S4 for trace pharmaceutical carbamazepine in aqueous solution[J]. Chinese Journal of Environmental Engineering, 2017, 11(1): 223-229. doi: 10.12030/j.cjee.201508197
shu

ZnIn2S4光催化降解水中痕量药物卡马西平的特性

  • 1.

    西安建筑科技大学环境与市政工程学院, 西安, 710055

  • 基金项目:

    西安建筑科技大学创新团队项目

  • 中图分类号: X703.1

Characteristics of photocatalytic degradation by ZnIn2S4 for trace pharmaceutical carbamazepine in aqueous solution

  • 1.

    School of Environmental and Municipal Engineering, Xi'an University of Architecture and Technology, Xi'an 710055, China

  • Fund Project:

  • 摘要: 采用水热合成法制备光催化剂ZnIn2S4，考察其光催化降解水中痕量医药类物质卡马西平的特性。研究表明，卡马西平初始浓度100 μg·L-1、溶液pH 5~9、ZnIn2S4投加量50 mg·L-1与碘镓灯（350~450 nm）光照反应3 h后，卡马西平的去除率为90%。动力学分析表明，卡马西平的光催化降解符合一级反应动力学，添加催化剂时的反应速率常数是不加催化剂的2.85倍，催化剂明显提高了降解反应速率。催化剂循环使用2个周期后，卡马西平的去除率由90%降至70%并保持稳定，表明催化剂结构趋稳后仍具有较高的催化活性。羟基自由基（·OH）实验证实了卡马西平降解过程中·OH为主要活性物种，但卡马西平的矿化率却只有3%，由于反应后的溶液呈酸性，因此推测光催化过程中卡马西平与·OH作用后大都转化为酸性中间产物而未被彻底氧化。
    Abstract: Visible-light-driven catalyst ZnIn2S4 was synthesized via a hydrothermal method, and its photocatalytic activity for trace pharmaceutical carbamazepine (CBZ) in aqueous solution was investigated subsequently through a batch reactor. The research showed that the removal efficacy of CBZ reached 90% under irradiation by an iodine-gallium lamp for 3 h at a wavelength of 350 to 450 nm. Other reaction conditions were an initial CBZ concentration of 100 μg·L-1, solution pH of 5 to 9, and catalyst dosage of 50 mg·L-1. Reaction kinetics analysis indicated that the photocatalytic degradation of CBZ was in accord with first-order kinetics, and the reaction rate constant with the catalyst was 2.85 times higher than that without the catalyst. Therefore, ZnIn2S4 improved the reaction rate significantly. The stability of the catalyst was investigated and the results showed that the removal rate of CBZ decreased from 90% to 70% after the catalyst was recycled two times, and then the removal of CBZ remained constant and the catalyst displayed high catalytic activity and a stable structure. Trapping experiments indicated that free hydroxyl radical (·OH) plays an important role in CBZ decomposition; however, mineralization of CBZ was only 3%. After illumination, the reaction solution was acidic, which implied that most of the CBZ degraded into acid intermediates instead of CO2 and H2O while reacting with ·OH.
  • 加载中
  • [1] ZHANG Yongjun, GEIBEN S U, GAL C. Carbamazepine and diclofenac:Removal in wastewater treatment plants and occurrence in water bodies[J]. Chemosphere, 2008, 73(8):1151-1161
    [2] ZHANG Zhongbo, HU Jiangyong. Selective removal of estrogenic compounds by molecular imprinted polymer (MIP)[J]. Water Research, 2008, 42(15):4101-4108
    [3] ALONSO S G, CATALÁ M, MAROTO R R, et al. Pollution by psychoactive pharmaceuticals in the rivers of Madrid metropolitan area (Spain)[J]. Environmental International, 2010, 36(2):195-201
    [4] TERNES T A. Occurrence of drugs in German sewage treatment plants and rivers[J]. Water Research, 1998, 32(11):3245-3260
    [5] LI Zhihua, ZLABEK V, VELISEK J, et al. Acute toxicity of carbamazepine to juvenile rainbow trout (Oncorhynchus mykiss):Effects on antioxidant responses, hematological parameters and hepatic EROD[J]. Ecotoxicology and Environmental Safety, 2011, 74(3):319-327
    [6] JARVIS A L, BERNOT M J, BERNOT R J. Relationships between the psychiatric drug carbamazepine and freshwater macroinvertebrate community structure[J]. Science of the Total Environment, 2014, 496:499-509
    [7] CHEN Huihui, ZHA Jinmiao, Liang Xuefang, et al. Effects of the human antiepileptic drug carbamazepine on the behavior, biomarkers, and heat shock proteins in the Asian clam Corbicula fluminea[J]. Aquatic Toxicology, 2014, 155:1-8
    [8] BU Qingwei, WANG Bin, HUANG Jun, et al. Pharmaceuticals and personal care products in the aquatic environment in China:A review[J]. Journal of Hazardous Materials, 2013, 262:189-211
    [9] 杨林, 薛罡, 刘亚男. 卡马西平降解菌的筛选分离及其降解机理[J]. 环境工程学报, 2012, 6(5):1559-1564
    [10] 唐玉霖, 高乃云, 庞维海, 等. 药物和个人护理用品在水环境中的现状与去除研究[J]. 给水排水, 2008, 34(5):116-121
    [11] RAO Y F, CHU W, WANG Y R. Photocatalytic oxidation of carbamazepine in triclinic-WO3 suspension:Role of alcohol and sulfate radicals in the degradation pathway[J]. Applied Catalysis A:General, 2013, 468:240-249
    [12] XU Jian, LI Lei, GUO Changsheng, et al. Photocatalytic degradation of carbamazepine by tailored BiPO4:Efficiency, intermediates and pathway[J]. Applied Catalysis B:Environmental, 2013, 130-131:285- 292
    [13] SHEN Shaohua, ZHAO Liang, ZHOU Zhaohui, et al. Enhanced photocatalytic hydrogen evolution over Cu-doped ZnIn2S4 under visible light irradiation[J]. The Journal of Physical Chemistry C, 2008, 112(41):16148-16155
    [14] CHAI Bo, PENG Tianyou, ZENG Peng, et al. Template-free hydrothermal synthesis of ZnIn2S4 floriated microsphere as an efficient photocatalyst for H2 production under visible-light irradiation[J]. The Journal of Physical Chemistry C, 2011, 115(13):6149-6155
    [15] LEI Zhibin, YOU Wansheng, LIU Meiying, et al. Photocatalytic water reduction under visible light on a novel ZnIn2S4 catalyst synthesized by hydrothermal method[J]. Chemical Communications, 2003(17):2142-2143
    [16] CHEN Zhixin, LI Danzhen, ZHANG Wenjuan, et al. Photocatalytic degradation of dyes by ZnIn2S4 microspheres under visible light irradiation[J]. The Journal of Physical Chemistry C, 2009, 113(11):4433-4440
    [17] GAO Bo, LIU Lifen, LIU Jiadong, et al. Photocatalytic degradation of 2, 4, 6-tribromophenol on Fe2O3 or FeOOH doped ZnIn2S4 heterostructure:Insight into degradation mechanism[J]. Applied Catalysis B:Environmental, 2014, 147:929-939
    [18] 杨照荣, 崔长征, 李炳智, 等. 热激活过硫酸盐降解卡马西平和奥卡西平复合污染的研究[J]. 环境科学学报, 2013, 33(1):98-104
    [19] HIRAKAWA T, NOSAKA Y. Properties of O2·- and OH· formed in TiO2 aqueous suspensions by photocatalytic reaction and the influence of H2O2 and some ions[J]. Langmuir, 2002, 18(8):3247-3254
    [20] 陈卫, 赵磊, 许航, 等. TiO2/AC光催化剂对卡马西平的降解特性[J]. 土木建筑与环境工程, 2012, 34(5):126-131
    [21] HAROUNE L, SALAUN M, MÉNARD A, et al. Photocatalytic degradation of carbamazepine and three derivatives using TiO2 and ZnO:Effect of pH, ionic strength, and natural organic matter[J]. Science of the Total Environment, 2014, 475:16-22
    [22] DENG Jing, SHAO Yisheng, GAO Naiyun, et al. Degradation of the antiepileptic drug carbamazepine upon different UV-based advanced oxidation processes in water[J]. Chemical Engineering Journal, 2013, 222:150-158
    [23] 刘玉燕. 氧化镓光催化降解邻苯二甲酸二甲酯(DMP)及动力学研究[D]. 青岛:青岛理工大学, 2013
    [24] JIANG Yuping. The influence of different pH values and high concentrations of Na2SO4 and NaCl on the photocatalytic oxidation (PCO) of methylene blue (MB) by aqueous suspension of nano-sized TiO2[J]. Advanced Materials Research, 2012, 490-495:3892-3896
    [25] HU Xianluo, YU J C, GONG Jingming, et al. Rapid mass production of hierarchically porous ZnIn2S4 submicrospheres via a microwave solvothermal process[J]. Crystal Growth & Design, 2007, 7(12):2444-2448
    [26] FANG Fang, CHEN Ling, CHEN Yubiao, et al. Synthesis and photocatalysis of ZnIn2S4 nano/micropeony[J]. The Journal of Physical Chemistry C, 2010, 114(6):2393-2397
    [27] 彭绍琴, 丁敏, 易婷, 等. 污染物甲胺为电子给体可见光下Pt/ZnIn2S4光催化制氢[J]. 分子催化, 2014, 28(5):466-473
