不同铝系混凝剂处理印染废水

,  ,  ,

downloadPDF

上一篇

下一篇

郭玥, 杜磊, 李庆, 徐慧. 不同铝系混凝剂处理印染废水[J]. 环境工程学报, 2016, 10(4): 1847-1852. doi: 10.12030/j.cjee.20160442
引用本文: 郭玥, 杜磊, 李庆, 徐慧. 不同铝系混凝剂处理印染废水[J]. 环境工程学报, 2016, 10(4): 1847-1852. doi: 10.12030/j.cjee.20160442
shu
Guo Yue, Du Lei, Li Qing, Xu Hui. Coagulation process using different Al-based coagulants in treatment of dyeing wastewater[J]. Chinese Journal of Environmental Engineering, 2016, 10(4): 1847-1852. doi: 10.12030/j.cjee.20160442
Citation: Guo Yue, Du Lei, Li Qing, Xu Hui. Coagulation process using different Al-based coagulants in treatment of dyeing wastewater[J]. Chinese Journal of Environmental Engineering, 2016, 10(4): 1847-1852. doi: 10.12030/j.cjee.20160442
shu

不同铝系混凝剂处理印染废水

  • 1.

    华北电力科学研究院有限责任公司, 北京 100045

  • 2.

    中国科学院生态环境研究中心环境水质学国家重点实验室, 北京 100085

  • 基金项目:

  • 中图分类号: X703.1

Coagulation process using different Al-based coagulants in treatment of dyeing wastewater

  • 1.

    North China Electric Power Research Institute Co. Ltd., Beijing 100045, China

  • 2.

    State Key Laboratory of Environmental Aquatic Chemistry, Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences, Beijing 100085, China

  • Fund Project:

  • 摘要: 印染废水具有色度大、有机物含量高、水质变化大等特点,处理难度较大。对比了不同种类的混凝剂对印染废水的处理效果,结果表明,随着混凝剂投加量的增加,SS,色度和COD的去除率逐渐增大,当混凝剂的投加量达到80 mg/L时,4种混凝剂的混凝效果达到最优。Al13在最优投加量下SS的去除率达到92.47%,色度去除率达到88.49%,COD的去除率达到80.47%。不同pH值条件下的混凝实验结果表明,随着pH值的升高,混凝效果逐渐提高,在pH值处于6.0~9.0的范围内均具有良好的混凝效果。在沉降的初始阶段,随着沉降时间的延长,4种混凝剂的混凝效果逐渐提高;当沉降时间超过10 min后,混凝效果没有明显的提高。Al13形成絮体的沉降速度最快,11 min左右可以完成沉降,其他3种混凝剂需要在14 min左右完成沉降。
    Abstract: Dyeing water has the characteristics of high colority, high organic concentration, and large changes in water quality, so the treatment of the wastewater is difficult.The aim of this study was to investigate the coagulation performances using different coagulants (with different Al species) in the treatment of dyeing wastewater.The results with different coagulant dosages indicated that the removal efficiencies for SS, colority, and COD increased with increasing coagulant dosage, and the removal efficiencies were the highest when the coagulant dosage was 80 mg/L.The removal efficiencies for SS, colority, and COD reached 92.47%, 88.49%, and 80.47% under the optimal conditions using Al13 as coagulant.The results under different pH conditions indicated that the removal efficiency increased with increasing solution pH from 2.0 to 6.0, and the coagulation performed well when the solution pH was between 6.0 and 9.0.The removal efficiency increased with increasing sedimentation period, and the removal efficiency did not increase significantly after sedimentation for 10 min.The flocs formed by Al13 had the largest fractal dimension, and the sedimentation was complete in 11 min.The fractal dimensions for flocs formed by three other coagulants were smaller, and the sedimentation periods were longer (14 min).
  • 加载中
  • [1] 陈忻,袁毅桦,潘坚定,等.羧甲基壳聚糖和稀土联合使用处理印染废水.环境科学与技术,2010,33(1):154-158 Chen Xin,Yuan Yihua,Pan Jianding,et al.Treatment of printing and dyeing wastewater with both carboxymethyl chitosan and rare earth.Environmental Science & Technology,2010,33(1):154-158(in Chinese)
    [2] 梁威,胡洪营.印染废水生物强化处理技术研究进展.环境污染治理技术与设备,2004,5(1):8-11 Liang Wei,Hu Hongying.Research advances in biological enhancing treatment techniques for dyeing wastewater.Techniques and Equipment for Environmental Pollution Control,2004,5(1):8-11(in Chinese)
    [3] 姚晓亮,林金清,周峰,等.镁盐复合混凝剂应用于活性染料印染废水脱色的实验研究.环境污染治理技术与设备,2006,7(2):93-96 Yao Xiaoliang,Lin Jinqing,Zhou Feng,et al.Decoloration of reactive dye wastewater by blend coagulation.Techniques and Equipment for Environmental Pollution Control,2006,7(2):93-96(in Chinese)
    [4] 韦朝海,黄会静,任源,等.印染废水处理工程的新型生物流化床组合工艺技术分析.环境科学,2011,32(4):1048-1054 Wei Chaohai,Huang Huijing,Ren Yuan,et al.Analysis of novel style biological fluidized bed A/O combined process in dyeing wastewater treatment.Environmental Science,2011,32(4):1048-1054(in Chinese)
    [5] 赵雪,何瑾馨,展义臻.印染废水处理技术的研究进展.化学工业与工程技术,2009,30(2):38-43 Zhao Xue,He Jingxin,Zhan Yizhen.Research progress of the dyeing wastewater treatment technologies.Journal of Chemical Industry & Engineering,2009,30(2):38-43(in Chinese)
    [6] 韩长秀,曹梦,张宝贵.絮凝法在印染废水处理中的应用进展.工业水处理,2006,26(9):5-9 Han Changxiu,Cao Meng,Zhang Baogui.Progress of flocculation applied to dyeing wastewater treatment.Industrial Water Treatment,2006,26(9):5-9(in Chinese)
    [7] 李雅婕,王平.生物技术在印染废水处理工艺中的应用.工业水处理,2006,26(5):14-17 Li Yajie.Wang Ping,Application of biotechnology to the treatment process of printing and dyeing wastewater.Industrial Water Treatment,2006,26(5):14-17(in Chinese)
    [8] 徐绮坤,汪晓军.曝气生物滤池在印染废水处理中的应用.环境科学与技术,2010,33(6):177-180 Xu Qikun,Wang Xiaojun.Application of biological aerated filter process to treatment of dyeing and printing wastewater.Environmental Science & Technology,2010,33(6):177-180(in Chinese)
    [9] 韩月,卢徐节,陈方雨,等.印染废水处理技术现状研究.工业安全与环保,2008,34(7):12-14 Han Yue,Lu Xujie,Chen Fangyu,et al.Research on the present status of dyeing wastewater treatment technology.Industrial Safety and Environmental Protection,2008,34(7):12-14(in Chinese)
    [10] Xu Hui,Xiao Feng,Wang Dongsheng.Effects of Al2O3 and TiO2 on the coagulation process by Al2(SO4)3 (AS) and poly-aluminum chloride PACl in kaolin suspension.Separation and Purification Technology,2014,124:9-17
    [11] Xu Hui,Jiao Ruyuan,Xiao Feng,et al.Relative importance of hydrolyzed Al species (Ala,Alb,Alc) on residual Al and effects of nano-particles (Fe-surface modified TiO2 and Al2O3) on coagulation process.Colloids and Surfaces A:Physicochemical and Engineering Aspects,2014,446:139-150
    [12] Xu Hui,Jiao Ruyuan,Xiao Feng,et al.Effects of different coagulants in treatment of TiO2-humic acid water and the aggregate characterization in different conditions.Colloids and Surfaces A:Physicochemical and Engineering Aspects,2014,446:213-223
    [13] Xu H.,Jiang W.,Xiao F.,et al.The characteristics of flocs and zeta potential in nano-TiO2 system under different coagulation conditions.Colloids and Surfaces A:Physicochemical and Engineering Aspects,2014,452:181-188
    [14] Xu Hui,Xiao Feng,Wang Dongsheng,et al.Survey of treatment process in water treatment plant and the characteristics of flocs formed by two new coagulants.Colloids and Surfaces A:Physicochemical and Engineering Aspects,2014,456:211-221
    [15] 蔡晓,洪金德.聚铁处理印染废水实验研究.华侨大学学报(自然科学版),1998,19(2):189-192 Cai Xiao,Hong Jinde.Experimental study on the treatment of textile printing wastewater by polymerized ferric sulphate.Journal of Huaqiao University (Natural Science),1998,19(2):189-192(in Chinese)
    [16] 李硕文,陈扬,戴育红.聚硅酸硫酸铝制备及在染色废水处理中应用的研究.环境科学研究,1994,7(3):31-35 Li Shuowen,Chen Yang,Dai Yuhong.Study on preparation and application of polysilicic acid containing aluminium sulfate (PAAS).Research of Environmental Sciences,1994,7(3):31-35(in Chinese)
    [17] 郭雅妮,李海红,同帜.聚硅酸铝絮凝剂处理印染废水的研究.西北大学学报(自然科学版),2004,34(5):567-570 Guo Yani,Li Haihong,Tong Zhi.A study on treatment of printing and dyeing wastewater by poly-silicate aluminum flocculant.Journal of Northwest University (Natural Science Edition),2004,34(5):567-570(in Chinese)
    [18] 王燕,高宝玉,岳钦艳,等.聚合铝基复合絮凝剂脱色性能的初步研究.环境化学,2004,23(3):310-313 Wang Yan,Gao Baoyu,Yue Qinyan,et al.Preliminary study on decolorization property of composite flocculants by polyaluminum chloride and ploydimethyldiallylammonium chloride.Environmental Chemistry,2004,23(3):310-313(in Chinese)
    [19] 陈文松,韦朝海.Fenton氧化-混凝法处理印染废水的研究.工业水处理,2004,24(4):39-41 Chen Wensong,Wei Chaohai.Study on Fenton oxidation-coagulation process for the treatment of printing and dyeing wastewater.Industrial Water Treatment,2004,24(4):39-41(in Chinese)
    [20] Lu Jianhang, Liu Weiping, Zhanggang, Pan Chunxiu, Effects of dye molecular and coagulant characteristics on decolorization of dye wastewater, Industrial Water Treatment, 1999,19(4):28-30.
    [21] 隋智慧,刘安军.复合混凝剂的制备及其对印染废水的处理.纺织学报,2007,28(11):69-72 Sui Zhihui,Liu Anjun.Preparation of inorganic compound coagulant and its application in the treatment of dyeing effluent.Journal of Textile Research,2007,28(11):69-72(in Chinese)
