贵州丹寨排庭汞矿区土壤-玉米重金属含量及生态影响
Heavy Metal Contents of Soil-Maizes and Its Ecological Effects in Mercury Mining Area of Danzhai Paiting, Guizhou
-
摘要: 对丹寨排庭汞矿区土壤、玉米中重金属含量及玉米Se、Mo和Zn等有益元素富集机制进行分析。在排庭汞矿区周边采集样品，包括尾矿渣、土壤和玉米，用电感耦合等离子体质谱仪（ICP-MS）和电感耦合等离子体原子发射光谱仪（ICP-AES）测试样品元素含量，pH计测试土壤、矿渣的pH值。并结合土壤环境质量标准、农作物重金属限量标准、欧盟标准以及世界卫生组织和联合国粮农组织（WHO/FAO）标准对土壤、玉米中重金属污染状况进行评价。结果表明，汞矿区矿渣土壤As、Hg、Cu和Pb等含量超过贵州和中国土壤背景值，As、Hg等含量较高，分别为271 mg·kg-1和110.50 mg·kg-1。矿渣土种植的玉米富集Se、Mo和Zn元素，含量为11.55、0.81和72.3 mg·kg-1。综上所述，该矿区土壤已受到As、Hg污染，重金属污染引起的生态问题应给予重视，矿区内玉米富集Se、Mo和Zn元素，对矿区周边种植富Se、Mo和Zn元素的玉米具有重要意义。Abstract: The objective of this study is to investigate the concentrations of heavy metals in soil and maize from Paiting mercury mine area, Danzhai, Guizhou Province and to explore the enrichment mechanism of Se, Mo and Zn in maize. The tailing, soil, and maize were sampled from the mercury mine area. The elemental concentrations in these samples were analyzed using inductively coupled plasma-mass spectrometry (ICP-MS) and inductively coupled plasma-atomic emission spectrometry (ICP-AES), and the pH values of tailing and soil were measured using the pH meter. Further, the pollution levels of heavy metals in soil and maize were assessed on the basis of the soil environment quality standard, the crop heavy metal limit standard, and the standards of European Union (EU), World Health Organization (WHO), and Food and Agriculture Organization (FAO). Results showed that the concentrations of As, Hg, Cu and Pb in the planted matrix (i.e., soil with tailing) exceeded the corresponding background values of soil in Guizhou and China, indicating the high concentrations of As and Hg (271 and 110.50 mg·kg-1, respectively) in the planted matrix. The concentrations of Se, Mo and Zn in the maize were 11.55, 0.81 and 72.3 mg·kg-1, respectively, showing that the maize was rich in Se, Mo and Zn. Overall, the soil from the mercury mine area was contaminated by As and Hg, so that, the ecological concerns caused by heavy metals pollution should be attached importance. Moreover, the maize was Se-, Mo-, and Zn-enriched, which is of great significance to cultivate the corn enriched by Se, Mo and Zn around the mercury mining area.
-
Key words:
- heavy metals /
- maize /
- mercury mining area /
- beneficial elements /
- Paiting
-
-
胡国成, 张丽娟, 齐剑英, 等. 贵州万山汞矿周边土壤重金属污染特征及风险评价[J]. 生态环境学报, 2015, 24(5):879-885 Hu G C, Zhang L J, Qi J Y, et al. Contaminant characteristics and risk assessment of heavy metals in soils from Wanshan mercury mine area, Guizhou Province[J]. Ecology and Environmental Sciences, 2015, 24(5):879-885(in Chinese)
包正铎, 王建旭, 冯新斌, 等. 贵州万山汞矿区污染土壤中汞的形态分布特征[J]. 生态学杂志, 2011, 30(5):907-913 Bao Z D, Wang J X, Feng X B, et al. Distribution of mercury speciation in polluted soils of Wanshan mercury mining area in Guizhou[J]. Chinese Journal of Ecology, 2011, 30(5):907-913(in Chinese)
喻子恒, 黄国培, 张华, 等. 贵州丹寨金汞矿区稻田土壤重金属分布特征及其污染评估[J]. 生态学杂志, 2017, 36(8):2296-2301 Yu Z H, Huang G P, Zhang H, et al. Distribution and pollution assessment of heavy metals in paddy soil in Danzhai Au-Hg mining area, Guizhou, China[J]. Chinese Journal of Ecology, 2017, 36(8):2296-2301(in Chinese)
仇广乐, 冯新斌, 王少锋, 等. 贵州汞矿矿区不同位置土壤中总汞和甲基汞污染特征的研究[J]. 环境科学, 2006, 27(3):3550-3555 Qiu G L, Feng X B, Wang S F, et al. Total mercury and methylmercury in soils collected from Guizhou Hg-mined areas[J]. Environmental Science, 2006, 27(3):3550-3555(in Chinese)
仇广乐. 贵州省典型汞矿地区汞的环境地球化学研究[D]. 贵阳:中国科学院研究生院, 2005:23-65 Qiu G L. Environmental geochemistry of mercury in typical Hg-mined area, Guizhou Province[D]. Guiyang:Graduate School of Chinese Academy of Sciences, 2005:23 -65(in Chinese)
尹德良, 何天容, 安艳玲, 等. 万山汞矿区居民食用大米的汞暴露风险评估[J]. 安全与环境学报, 2016, 16(3):330-337 Yin D L, He T R, An Y L, et al. Mercury exposure and its health assessment for the residents in Wanshan mercury-mining areas via the rice consumption[J]. Journal of Safety and Environment, 2016, 16(3):330-337(in Chinese)
Yin R S, Zhang W, Sun G Y, et al. Mercury risk in poultry in the Wanshan mercury mine, China[J]. Environmental Pollution, 2017, 230:810-816 李葆华, 李雯霞, 顾雪祥, 等. 贵州丹寨汞矿田甲烷包裹体研究及其地质意义[J]. 地学前缘, 2013, 20(1):55-63 Li B H, Li W X, Gu X X, et al. A study of methane inclusion of the Danzhai mercury ore field in Guizhou Province and its geological significance[J]. Earth Science Frontiers, 2013, 20(1):55-63(in Chinese)
孙雪城, 王建旭, 冯新斌. 贵州丹寨金汞矿区尾渣和水土中汞砷分布特征及潜在风险[J]. 生态毒理学报, 2014, 9(6):1173-1180 Sun X C, Wang J X, Feng X B. Distribution and potential environmental risk of mercury and arsenic in slag, soil and water of Danzhai mercury mining area, Guizhou Province, China[J]. Asian Journal of Ecotoxicology, 2014, 9(6):1173-1180(in Chinese)
夏勇, 吴学益, 贾蓉芬, 等. 丹寨汞金矿床成矿构造地球化学模拟实验[J]. 大地构造与成矿学, 1994, 18(2):117-125 Xia Y, Wu X Y, Jia R F, et al. Geochemical simulation experiment of metallogenic structure of Danzhai mercury-gold deposit[J]. Geotectonica et Metallogenia, 1994, 18(2):117-125(in Chinese)
李德鹏, 杨瑞东, 陈军, 等. 贵州丹寨排庭金汞矿床地质地球化学特征[J]. 地质论评, 2019, 65(5):1153-1169 Li D P, Yang R D, Chen J, et al. Geological and geochemical characteristics of the Paiting gold-mercury deposit in Danzhai, Guizhou[J]. Geological Review, 2019, 65(5):1153-1169(in Chinese)
何金坪. 贵州省丹寨县四相厂汞金矿床地质特征及控矿因素[J]. 科技情报开发与经济, 2012, 22(12):140-143 He J P. Discussion on the geological characteristics and ore-controlling factors of Sixiangchang mercury gold deposit in Danzhai County of Guizhou Province[J]. Sci-Tech Information Development & Economy, 2012, 22(12):140-143(in Chinese)
林齐维, 李庆新, 瞿丽雅, 等. 丹寨汞矿冶炼厂土壤汞污染的初步研究[J]. 贵州环保科技, 1998, 4(2):23-26 , 31 Lin Q W, Li Q X, Qu L Y, et al. Preliminary study on soil mercury pollution in Danzhai mercury smelter[J]. Guizhou Environmental Protection Science and Technology, 1998, 4(2):23-26, 31(in Chinese)
丁振华, 王文华, 瞿丽雅, 等. 贵州万山汞矿区汞的环境污染及对生态系统的影响[J]. 环境科学, 2004, 25(2):111-114 Ding Z H, Wang W H, Qu L Y, et al. Mercury pollution and its ecosystem effects in Wanshan mercury miner area, Guizhou[J]. Environmental Science, 2004, 25(2):111-114(in Chinese)
余志, 陈凤, 张军方, 等. 锌冶炼区菜地土壤和蔬菜重金属污染状况及风险评价[J]. 中国环境科学, 2019, 39(5):2086-2094 Yu Z, Chen F, Zhang J F, et al. Contamination and risk of heavy metals in soils and vegetables from zinc smelting area[J]. China Environmental Science, 2019, 39(5):2086-2094(in Chinese)
Zhou H, Guo X Y. Soil heavy metal pollution evaluation around mine area with traditional and ecological assessment methods[J]. Journal of Geoscience and Environment Protection, 2015, 3(10):28-33 Li Z, Ma Z,van der Kuijp T J, et al. A review of soil heavy metal pollution from mines in China:Pollution and health risk assessment[J]. Science of the Total Environment, 2014, 468-469:843-853 牟明辉, 石杨程, 张晓晴, 等. 恩施富硒茶园土壤重金属和氟含量及风险评价[J]. 河南农业科学, 2016, 45(5):61-65 Mou M H, Shi Y C, Zhang X Q, et al.Contents and risk assessment of heavy metal and fluorine in selenium enriched tea garden soils in Enshi area[J]. Journal of Henan Agricultural Sciences, 2016, 45(5):61-65(in Chinese)
Qu C, Sun K, Wang S, et al. Monte carlo simulation-based health risk assessment of heavy metal soil pollution:A case study in the Qixia mining area, China[J]. Human and Ecological Risk Assessment, 2012, 18(4):733-750 Cao H B, Chen J J, Zhang J, et al. Heavy metals in rice and garden vegetables and their potential health risks to inhabitants in the vicinity of an industrial zone in Jiangsu, China[J]. Journal of Environmental Sciences, 2010, 22(11):1792-1799 Biester H, Scholz C. Determination of mercury binding forms in contaminated soils:Mercury pyrolysis versus sequential extractions[J]. Environmental Science & Technology, 1997, 31(1):233-239 Huang L, Liu L L, Zhang T, et al. An interventional study of rice for reducing cadmium exposure in a Chinese industrial town[J]. Environment International, 2019, 122:301-309 中华人民共和国生态环境部, 国家市场监督管理总局. GB 15618-2018土壤环境质量农用地土壤污染风险管控标准(试行)[S]. 北京:中华人民共和国生态环境部, 国家市场监督管理总局, 2018 Ministry of Ecology and Environment of the People's Republic of China, State Administration for Marketing Regulation of the People's Republic of China. GB 15618-2018 Soil Environmental Quality Risk Control Standard for Soil Contamination of Agricultural Land[S]. Beijing:Ministry of Ecology and Environment of the People's Republic of China, State Administration for Marketing Regulation of the People's Republic of China, 2018 (in Chinese)
中华人民共和国农业部. NY 861-2004粮食(含谷物、豆类、薯类)及制品中铅、铬、镉、汞、硒、砷、铜、锌等八种元素限量[S]. 北京:中华人民共和国农业部, 2005 Ministry of Agriculture of the People's Republic of China. NY 861-2004 Limit of Eight Elements in Cereals, Legume, Tubes and Its Products[S]. Beijing:Ministry of Agriculture of the People's Republic of China, 2005 (in Chinese)
杨惟薇, 刘敏, 曹美珠, 等. 不同玉米品种对重金属铅镉的富集和转运能力[J]. 生态与农村环境学报, 2014, 30(6):774-779 Yang W W, Liu M, Cao M Z, et al. Accumulation and transfer of lead (Pb) and cadmium (Cd) on different species of maize[J]. Journal of Ecology and Rural Environment, 2014, 30(6):774-779(in Chinese)
李静, 依艳丽, 李亮亮, 等. 几种重金属(Cd、Pb、Cu、Zn)在玉米植株不同器官中的分布特征[J]. 中国农学通报, 2006, 22(4):244-247 Li J, Yi Y L, Li L L, et al. Distribution of heavy metal (Cd, Pb, Cu, Zn) in different organs of maize[J]. Chinese Agricultural Science Bulletin, 2006, 22(4):244-247(in Chinese)
中华人民共和国国家卫生和计划生育委员会, 国家食品药品监督管理总局. GB 2762-2017食品安全国家标准食品中污染物限量[S]. 北京:中华人民共和国国家卫生和计划生育委员会, 国家食品药品监督管理总局, 2017 中华人民共和国卫生部. GB 15199-1994食品中铜限量卫生标准[S]. 北京:中华人民共和国卫生部, 1994 Ministry of Health of the People's Republic of China. GB 15199-1994 Tolerance Limit of Copper in Foods[S]. Beijing:Ministry of Health of the People's Republic of China, 1994 (in Chinese)
中华人民共和国卫生部. GB 13106-1991食品中锌限量卫生标准[S]. 北京:中华人民共和国卫生部, 1991 Ministry of Health of the People's Republic of China. GB 13106-1991 Tolerance Limit of Zinc in Foods[S]. Beijing:Ministry of Health of the People's Republic of China, 1991 (in Chinese)
European Community (EC). Commission Regulation (EC):No.629/2008[S]. Brussels:the European Union, 2008 王世玉, 吴文勇, 刘菲, 等. 典型污灌区土壤与作物中重金属健康风险评估[J]. 中国环境科学, 2018, 38(4):1550-1560 Wang S Y, Wu W Y, Liu F, et al. Assessment of human health risks of heavy metals in the typical sewage irrigation areas[J]. China Environmental Science, 2018, 38(4):1550-1560(in Chinese)
窦韦强, 安毅, 秦莉, 等. 土壤pH对汞迁移转化的影响研究进展[J]. 农业资源与环境学报, 2019, 36(1):1-8 Dou W Q, An Y, Qin L, et al. Research progress on effects of soil pH on migration and transformation of mercury[J]. Journal of Agricultural Resources and Environment, 2019, 36(1):1-8(in Chinese)
Nakamaru Y M, Altansuvd J. Speciation and bioavailability of selenium and antimony in non-flooded and wetland soils:A review[J]. Chemosphere, 2014, 111:366-371 Antoniadis V, Levizou E, Shaheen S M, et al. Trace elements in the soil-plant interface:Phytoavailability, translocation, and phytoremediation-A review[J]. Earth Science Reviews, 2017, 171:621-645 Li J, Peng Q, Liang D L, et al. Effects of aging on the fraction distribution and bioavailability of selenium in three different soils[J]. Chemosphere, 2016, 144:2351-2359 Wang C, Ji J F, Zhu F H. Characterizing Se transfer in the soil-crop systems under field condition[J]. Plant and Soil, 2017, 415(1-2):535-548 Wang D, Dinh Q T, Thu T T A, et al. Effect of selenium-enriched organic material amendment on selenium fraction transformation and bioavailability in soil[J]. Chemosphere, 2018, 199:417-426 刘洋, 潘国浩, 赵永强, 等. 滨海滩涂不同围垦年代垦区农作物重金属累积特征及其与氮、磷的关系[J]. 生态毒理学报, 2018, 13(6):186-201 Liu Y, Pan G H, Zhao Y Q, et al. Heavy metal accumulation in crops and its relationships with nitrogen and phosphorus in different-age reclaimed farmlands in tidal flat area[J]. Asian Journal of Ecotoxicology, 2018, 13(6):186-201(in Chinese)
王宁. 黑河中游绿洲农田土壤-玉米系统重金属的空间分布及其行为特征研究[D]. 兰州:兰州大学, 2014:12-34 Wang N. Study on spatial distribution and behavior characteristics of heavy metals in oasis arable soil-corn system from middle reaches of the Heihe River[D]. Lanzhou:Lanzhou University, 2014:12 -34(in Chinese)
Fu Z, Li W H, Zhang Q B, et al. Quantitative trait loci for mercury accumulation in maize (Zea mays L.) identified using a RIL population[J]. PLoS One, 2014, 9(9):e107243 Muhammad R, Shafaqat A, Muhammad F Q, et al. Use of maize (Zea mays L.) for phytomanagement of Cd-contaminated soils:A critical review[J]. Environmental Geochemistry and Health, 2017, 39(2):259-277 Qiu G L, Feng X B, Wang S F, et al. Mercury and methylmercury in riparian soil, sediments, mine-waste calcines, and moss from abandoned Hg mines in east Guizhou Province, southwestern China[J]. Applied Geochemistry, 2005, 20(3):627-638 Horvat M, Nolde N, Fajon V, et al. Total mercury, methylmercury and selenium in mercury polluted areas in the province Guizhou, China[J]. Science of the Total Environment, 2003, 304(1-3):231-256 Qiu G L, Feng X B, Wang S F, et al. Environmental contamination of mercury from Hg-mining areas in Wuchuan, northeastern Guizhou, China[J]. Environmental Pollution, 2006, 142(3):549-558 Qiu G L, Feng X B, Wang S F, et al. Mercury contaminations from historic mining to water, soil and vegetation in Lanmuchang, Guizhou, southwestern China[J]. Science of the Total Environment, 2006, 368(1):56-68 Li P, Feng X B, Shang L H, et al. Mercury pollution from artisanal mercury mining in Tongren, Guizhou, China[J]. Applied Geochemistry, 2008, 23(8):2055-2064 Gray J E, Hines M E, Higueras P L, et al. Mercury speciation and microbial transformations in mine wastes, stream sediments, and surface waters at the Almadén mining district, Spain[J]. Environmental Science & Technology, 2004, 38(16):4285-4292 Gnamus A, Byrne A R, Horvat M. Mercury in the soil-plant-deer-predator food chain of a temperate forest in Slovenia[J]. Environmental Science & Technology, 2000, 34(16):3337-3345 Bailey E A, Gray J E, Theodorakos P M. Mercury invegetation and soils at abandoned mercury mines in southwestern Alaska, USA[J]. Geochemistry:Exploration Environment Analysis, 2002, 2(3):275-285 Maramba N, Reyes J, Francisco-rivera A, et al. Environmental and human exposure assessment monitoring of communities near an abandoned mercury mine in the Philippines:A toxic legacy[J]. Journal of Environmental Management, 2006, 81(2):135-145 杨海, 李平, 仇广乐, 等. 世界汞矿地区汞污染研究进展[J]. 地球与环境, 2009, 37(1):80-85 Yang H, Li P, Qiu G L, et al. Mercury pollution in mercury mining areas throughout the world:An overview[J]. Earth and Environment, 2009, 37(1):80-85(in Chinese)
-
