基于物种敏感度分布及相平衡理论的汾河流域磺胺类抗生素生态风险阈值研究
Study on Ecological Risk Threshold of Sulfonamides Antibiotics in Fenhe River Basin Based on Species Sensitivity Analysis and Phase Equilibrium Theory
-
摘要: 磺胺素类抗生素(SAs)广泛应用于医疗、畜禽养殖等领域。但过量的SAs通过多种方式最终进入流域水体和沉积物中，对流域生态系统带来潜在的风险。预测无效应浓度(PNEC)可以作为评估污染物潜在生态风险的阈值，因此确定水体和沉积物中SAs的PNEC是风险评估的关键。本研究以黄河支流——汾河流域为研究区，通过采集水体和沉积物的样品，发现水体中SAs的磺胺甲恶唑(SMX)含量最高，均值为73.6 ng·L-1，而磺胺醋酰(SAAM)检出率最高，高达100%。沉积物中仅检出了2种SAs类抗生素，为磺胺醋酰(SAAM)和磺胺喹恶啉(SQX)，但检出频率却高达100%。基于物种敏感度分布(SSD)得到水体中SAs的生态风险阈值为3.40~440 μg·L-1。在此基础上，基于水-沉积物密度、体积比等参数，采用相平衡理论(EqP)进一步得到了沉积物中SAs的生态风险阈值为0.065~75.5 mg·kg-1。基于确定的生态风险阈值，对汾河流域SAs现状进行风险评估，结果表明仅水体中的甲氧苄啶(TMP)的风险商(RQ)均值为0.014，存在一定的低风险，但超标概率仅为8%，而其他类别在水体和沉积物中RQ均低于0.01，均无显著风险。
-
关键词:
- 磺胺类抗生素(SAs) /
- 预测无效应浓度(PNEC) /
- 物种敏感度分布(SSD) /
- 相平衡理论(EqP) /
- 生态风险阈值
Abstract: Sulfonamide antibiotics (SAs) are widely used in medical treatment, livestock and poultry breeding, aquaculture and other fields. However, excessive use of SAs enters the water and sediment of watershed through domestic sewage, surface runoff, and so on, resulting in potential risks for the ecosystem. Predicted no effect concentration (PNEC) can be regarded as the threshold for assessing the potential ecological risk of pollutants, therefore calculating the PNEC of SAs in water and sediment is the key to assess the ecological risk. In this study, through collecting samples of water and sediment in Fenhe River Basin, a tributary of the Yellow River, the results showed that the concentrations of sulfamethoxazole (SMX) in water were the highest, with an average of 73.6 ng·L-1, and the detection rate of sulfacetamide (SAAM) was the highest, with 100% detection rate. However, only two types of SAs, SAAM and sulfaquinoxaline (SQX), were detected in the sediments, with detection frequency as high as 100%. Based on species sensitivity analysis (SSD), the ecological risk threshold for SAs in water was obtained, ranging from 3.40 to 440 μg·L-1. Then, combined the density, volume ratio and other parameters of water and sediment, the ecological risk threshold of SAs in the sediment was also obtained using the method phase equilibrium theory (EqP), and the results were 0.065~75.5 mg·kg-1. Based on the ecological risk threshold of SAs in water and sediment in the Fenhe River Basin, the ecological risk was further assessed. The results showed that the average risk quotient (RQ) of trimethoprim (TMP) in water was 0.014, which could result in low risk with the probability of exceeding the threshold being only 8%. The RQ values of the other were all less than 0.01, indicating insignificant risk. -
-
Seyoum M M, Obayomi O, Bernstein N, et al. The dissemination of antibiotics and their corresponding resistance genes in treated effluent-soil-crops continuum, and the effect of barriers[J]. The Science of the Total Environment, 2022, 807(Pt 2): 151525 Grossman Z, del Torso S, Hadjipanayis A, et al. Antibiotic prescribing for upper respiratory infections: European primary paediatricians' knowledge, attitudes and practice[J]. Acta Paediatrica, 2012, 101(9): 935-940 Zhang Z B, Duan Y P, Zhang Z J, et al. Multimedia fate model and risk assessment of typical antibiotics in the integrated demonstration zone of the Yangtze River Delta, China[J]. The Science of the Total Environment, 2022, 805: 150258 Liang X M, Chen B W, Nie X P, et al. The distribution and partitioning of common antibiotics in water and sediment of the Pearl River Estuary, South China[J]. Chemosphere, 2013, 92(11): 1410-1416 Dong D M, Zhang L W, Liu S, et al. Antibiotics in water and sediments from Liao River in Jilin Province, China: Occurrence, distribution, and risk assessment[J]. Environmental Earth Sciences, 2016, 75(16): 1202 Na G S, Fang X D, Cai Y Q, et al. Occurrence, distribution, and bioaccumulation of antibiotics in coastal environment of Dalian, China[J]. Marine Pollution Bulletin, 2013, 69(1-2): 233-237 Tolls J. Sorption of veterinary pharmaceuticals in soils: A review[J]. Environmental Science & Technology, 2001, 35(17): 3397-3406 Thiele-Bruhn S. Pharmaceutical antibiotic compounds in soils: A review[J]. Journal of Plant Nutrition and Soil Science, 2003, 166(2): 145-167 Marques R Z, Wistuba N, Brito J C M, et al. Crop irrigation (soybean, bean, and corn) with enrofloxacin-contaminated water leads to yield reductions and antibiotic accumulation[J]. Ecotoxicology and Environmental Safety, 2021, 216: 112193 Siedlewicz G, Białk-Bielińska A, Borecka M, et al. Presence, concentrations and risk assessment of selected antibiotic residues in sediments and near-bottom waters collected from the Polish coastal zone in the southern Baltic Sea: Summary of 3 years of studies[J]. Marine Pollution Bulletin, 2018, 129(2): 787-801 雷炳莉, 黄圣彪, 王子健. 生态风险评价理论和方法[J]. 化学进展, 2009, 21(Z1): 350-358 Lei B L, Huang S B, Wang Z J. Theories and methods of ecological risk assessment[J]. Progress in Chemistry, 2009, 21(Z1): 350-358(in Chinese)
李霁, 周俊丽, 曹莹, 等. 荧蒽的淡水沉积物预测无效应浓度推导及生态风险评价[J]. 环境化学, 2015, 34(4): 664-670 Li J, Zhou J L, Cao Y, et al. Derivation of predicted no effect concentration and ecological risk assessment of fluoranthene in freshwater sediment[J]. Environmental Chemistry, 2015, 34(4): 664-670(in Chinese)
Chen H, Liu S, Xu X R, et al. Antibiotics in the coastal environment of the Hailing Bay region, South China Sea: Spatial distribution, source analysis and ecological risks[J]. Marine Pollution Bulletin, 2015, 95(1): 365-373 Dyer S D, Versteeg D J, Belanger S E, et al. Comparison of species sensitivity distributions derived from interspecies correlation models to distributions used to derive water quality criteria[J]. Environmental Science & Technology, 2008, 42(8): 3076-3083 Monti G S, Filzmoser P, Deutsch R C. A robust approach to risk assessment based on species sensitivity distributions[J]. Risk Analysis: An Official Publication of the Society for Risk Analysis, 2018, 38(10): 2073-2086 Leung H W, Minh T B, Murphy M B, et al. Distribution, fate and risk assessment of antibiotics in sewage treatment plants in Hong Kong, South China[J]. Environment International, 2012, 42: 1-9 Staples C A, Woodburn K B, Klecka G M, et al. Comparison of four species sensitivity distribution methods to calculate predicted no effect concentrations for bisphenol A[J]. Human and Ecological Risk Assessment, 2008, 14(3): 455-478 Golet E M, Alder A C, Giger W. Environmental exposure and risk assessment of fluoroquinolone antibacterial agents in wastewater and river water of the Glatt Valley Watershed, Switzerland[J]. Environmental Science & Technology, 2002, 36(17): 3645-3651 Turkdogan F I, Yetilmezsoy K. Appraisal of potential environmental risks associated with human antibiotic consumption in Turkey[J]. Journal of Hazardous Materials, 2009, 166(1): 297-308 Hiki K, Iwasaki Y, Watanabe H, et al. Comparison of species sensitivity distributions for sediment-associated nonionic organic chemicals through equilibrium partitioning theory and spiked-sediment toxicity tests with invertebrates[J]. Environmental Toxicology and Chemistry, 2022, 41(2): 462-473 Hickey G L, Craig P S. Competing statistical methods for the fitting of normal species sensitivity distributions: Recommendations for practitioners[J]. Risk Analysis: An Official Publication of the Society for Risk Analysis, 2012, 32(7): 1232-1243 Hu Y, Yan X, Shen Y, et al. Antibiotics in surface water and sediments from Hanjiang River, Central China: Occurrence, behavior and risk assessment[J]. Ecotoxicology and Environmental Safety, 2018, 157: 150-158 Rico A, Oliveira R, McDonough S, et al. Use, fate and ecological risks of antibiotics applied in tilapia cage farming in Thailand[J]. Environmental Pollution, 2014, 191: 8-16 Zhou L J, Li J, Zhang Y D, et al. Trends in the occurrence and risk assessment of antibiotics in shallow lakes in the lower-middle reaches of the Yangtze River Basin, China[J]. Ecotoxicology and Environmental Safety, 2019, 183: 109511 Di Toro D M, Zarba C S, Hansen D J, et al. Technical basis for establishing sediment quality criteria for nonionic organic chemicals using equilibrium partitioning[J]. Environmental Toxicology and Chemistry, 1991, 10(12): 1541-1583 Long E R. Ranges in chemical concentrations in sediments associated with adverse biological effects[J]. Marine Pollution Bulletin, 1992, 24(1): 38-45 Brock T C M, Belgers J D M, Boerwinkel M C, et al. Toxicity of sediment-bound lufenuron to benthic arthropods in laboratory bioassays[J]. Aquatic Toxicology, 2018, 198: 118-128 Xu J, Zhang Y, Zhou C B, et al. Distribution, sources and composition of antibiotics in sediment, overlying water and pore water from Taihu Lake, China[J]. The Science of the Total Environment, 2014, 497-498: 267-273 Yang J F, Ying G G, Zhao J L, et al. Simultaneous determination of four classes of antibiotics in sediments of the Pearl Rivers using RRLC-MS/MS[J]. Science of the Total Environment, 2010, 408(16): 3424-3432 Zhao S N, Liu X H, Cheng D M, et al. Temporal-spatial variation and partitioning prediction of antibiotics in surface water and sediments from the intertidal zones of the Yellow River Delta, China[J]. The Science of the Total Environment, 2016, 569-570: 1350-1358 Zhou L J, Ying G G, Zhao J L, et al. Trends in the occurrence of human and veterinary antibiotics in the sediments of the Yellow River, Hai River and Liao River in Northern China[J]. Environmental Pollution, 2011, 159(7): 1877-1885 汪银龙, 冯民权, 董向前. 汾河下游雨季硝酸盐污染源解析[J]. 环境科学, 2019, 40(9): 4033-4041 Wang Y L, Feng M Q, Dong X Q. Analysis of nitrate pollution sources in the rainy season of the lower Fenhe River[J]. Environmental Science, 2019, 40(9): 4033-4041(in Chinese)
王林芳, 党晋华, 刘利军, 等. 汾河上中游流域水环境中多环芳烃分布及分配[J]. 环境科学学报, 2017, 37(8): 2838-2845 Wang L F, Dang J H, Liu L J, et al. Distribution and components analysis of polycyclic aromatic hydrocarbons in upper middle of Fen River Basin[J]. Acta Scientiae Circumstantiae, 2017, 37(8): 2838-2845(in Chinese)
王林芳. 汾河流域典型抗生素污染特征及归趋研究[D]. 太原: 山西大学, 2021: 10-19 Wang L F. Pollution characteristics and fate of typical antibiotics in Fenhe River Basin[D]. Taiyuan: Shanxi University, 2021: 10 -19(in Chinese)
Menz J, Müller J, Olsson O, et al. Bioavailability of antibiotics at soil-water interfaces: A comparison of measured activities and equilibrium partitioning estimates[J]. Environmental Science & Technology, 2018, 52(11): 6555-6564 Cao L P, Liu R M, Wang L F, et al. Reliable and representative estimation of extrapolation model application in deriving water quality criteria for antibiotics[J]. Environmental Toxicology and Chemistry, 2023, 42(1): 191-204 Zhang L, Shen L, Qin S, et al. Quinolones antibiotics in the Baiyangdian Lake, China: Occurrence, distribution, predicted no-effect concentrations (PNECs) and ecological risks by three methods[J]. Environmental Pollution, 2020, 256: 113458 张国栋, 董文平, 刘晓晖, 等. 我国水环境中抗生素赋存、归趋及风险评估研究进展[J]. 环境化学, 2018, 37(7): 1491-1500 Zhang G D, Dong W P, Liu X H, et al. Occurrence, fate and risk assessment of antibiotics in water environment of China[J]. Environmental Chemistry, 2018, 37(7): 1491-1500(in Chinese)
De Laender F, De Schamphelaere K A, Vanrolleghem P A, et al. Do we have to incorporate ecological interactions in the sensitivity assessment of ecosystems? An examination of a theoretical assumption underlying species sensitivity distribution models[J]. Environment International, 2008, 34(3): 390-396 Travis C. Species sensitivity distributions in ecotoxicology[J]. Risk Analysis, 2003, 23(2): 425-426 周欣欣, 曲甍甍, 陈朗, 等. 物种敏感度分布(SSD)方法在农药环境风险评估中的应用[J]. 农药, 2017, 56(11): 786-790 Zhou X X, Qu M M, Chen L, et al. The application of species sensitivity distribution (SSD) method in environmental risk assessment of pesticide[J]. Agrochemicals, 2017, 56(11): 786-790(in Chinese)
董明明, 牟力言, 秦莉, 等. 物种敏感性分布法拟合函数的拟合优度评价[J]. 农业环境科学学报, 2021, 40(3): 544-551 Dong M M, Mu L Y, Qin L, et al. Evaluation of the goodness of fit of the species sensitivity distribution fitting function[J]. Journal of Agro-Environment Science, 2021, 40(3): 544-551(in Chinese)
雷炳莉, 文育, 王艺陪, 等. 不同评估方法得出的五氯酚的PNEC值的比较研究[J]. 环境科学, 2013, 34(6): 2335-2343 Lei B L, Wen Y, Wang Y P, et al. Comparison of aquatic predicted no-effect concentrations (PNECs) for pentachlorophenol derived from different assessment approaches[J]. Environmental Science, 2013, 34(6): 2335-2343(in Chinese)
Song C, Zhang C, Fan L M, et al. Occurrence of antibiotics and their impacts to primary productivity in fishponds around Tai Lake, China[J]. Chemosphere, 2016, 161: 127-135 Zhang Y X, Chen H Y, Jing L J, et al. Ecotoxicological risk assessment and source apportionment of antibiotics in the waters and sediments of a peri-urban river[J]. The Science of the Total Environment, 2020, 731: 139128 Wang L F, Li H, Dang J H, et al. Occurrence, distribution, and partitioning of antibiotics in surface water and sediment in a typical tributary of Yellow River, China[J]. Environmental Science and Pollution Research International, 2021, 28(22): 28207-28221 孙波, 周洪英, 吴洪丽, 等. 甲氧苄啶在家蚕体内的药代动力学研究[J]. 蚕业科学, 2014, 40(1): 59-63 Sun B, Zhou H Y, Wu H L, et al. A study on pharmacokinetics of trimethoprim inside silkworm body[J]. Acta Sericologica Sinica, 2014, 40(1): 59-63(in Chinese)
鞠晶. 磺胺间甲氧嘧啶在罗非鱼体内的药代动力学及残留规律[D]. 上海: 上海海洋大学, 2014: 1-3 Ju J. Pharmacokinetics and residue regularity of sulfamonomethoxine in tilapia[D]. Shanghai: Shanghai Ocean University, 2014: 1 -3(in Chinese)
Wang L F, Wang Y F, Li H, et al. Occurrence, source apportionment and source-specific risk assessment of antibiotics in a typical tributary of the Yellow River Basin[J]. Journal of Environmental Management, 2022, 305: 114382 Bai Y W, Meng W, Xu J, et al. Occurrence, distribution and bioaccumulation of antibiotics in the Liao River Basin in China[J]. Environmental Science Processes & Impacts, 2014, 16(3): 586-593 Kim S C, Carlson K. Temporal and spatial trends in the occurrence of human and veterinary antibiotics in aqueous and river sediment matrices[J]. Environmental Science & Technology, 2007, 41(1): 50-57 Managaki S, Murata A, Takada H, et al. Distribution of macrolides, sulfonamides, and trimethoprim in tropical waters: Ubiquitous occurrence of veterinary antibiotics in the Mekong Delta[J]. Environmental Science & Technology, 2007, 41(23): 8004-8010 Luo Y, Xu L, Rysz M, et al. Occurrence and transport of tetracycline, sulfonamide, quinolone, and macrolide antibiotics in the Haihe River Basin, China[J]. Environmental Science & Technology, 2011, 45(5): 1827-1833 Kümmerer K. Antibiotics in the aquatic environment： A review. Part Ⅰ[J]. Chemosphere, 2009, 75(4): 417-434 Li N, Zhang X B, Wu W, et al. Occurrence, seasonal variation and risk assessment of antibiotics in the reservoirs in North China[J]. Chemosphere, 2014, 111: 327-335 Marx C, Mühlbauer V, Krebs P, et al. Species-related risk assessment of antibiotics using the probability distribution of long-term toxicity data as weighting function: A case study[J]. Stochastic Environmental Research and Risk Assessment, 2015, 29(8): 2073-2085 Huo S L, Xi B D, Yu X J, et al. Application of equilibrium partitioning approach to derive sediment quality criteria for heavy metals in a shallow eutrophic lake, Lake Chaohu, China[J]. Environmental Earth Sciences, 2013, 69(7): 2275-2285 Xu J X. Grain-size characteristics of suspended sediment in the Yellow River, China[J]. Catena, 2000, 38(3): 243-263 -
