生物可降解络合剂[S,S]-乙二胺二琥珀酸改性蛭石和活性炭及其对Fe（Ⅱ）的吸附性能

史海波; 祝建中; 陈胜鲁; 吉栋梁; 曹阳; 陈冠寰

doi:10.7524/j.issn.0254-6108.2014.06.011

环境化学

, , , , ,

史海波, 祝建中, 陈胜鲁, 吉栋梁, 曹阳, 陈冠寰. 生物可降解络合剂[S,S]-乙二胺二琥珀酸改性蛭石和活性炭及其对Fe（Ⅱ）的吸附性能[J]. 环境化学, 2014, 33(6): 949-955. doi: 10.7524/j.issn.0254-6108.2014.06.011

引用本文:

SHI Haibo, ZHU Jianzhong, CHEN Shenglu, JI Dongliang, CAO Yang, CHEN Guanhuan. Biodegradable chelant EDDS([S,S]-ethylenediamine disuccinic acid) modified vermiculite and activated carbon and their adsorption performance for Fe(Ⅱ)[J]. Environmental Chemistry, 2014, 33(6): 949-955. doi: 10.7524/j.issn.0254-6108.2014.06.011

Citation:

SHI Haibo, ZHU Jianzhong, CHEN Shenglu, JI Dongliang, CAO Yang, CHEN Guanhuan. Biodegradable chelant EDDS([S,S]-ethylenediamine disuccinic acid) modified vermiculite and activated carbon and their adsorption performance for Fe(Ⅱ)[J]. Environmental Chemistry, 2014, 33(6): 949-955. doi: 10.7524/j.issn.0254-6108.2014.06.011

生物可降解络合剂[S,S]-乙二胺二琥珀酸改性蛭石和活性炭及其对Fe（Ⅱ）的吸附性能

1.
河海大学浅水湖泊综合治理与资源开发教育部重点实验室及河海大学环境学院, 南京, 210098
基金项目:
教育部留学人员回国启动基金（1061-51200312）；中央高校（河海大学）基本科研业务费专项资金（B11020157）；江苏水利科技项目基金（1061-51146012）；江苏科技项目基金（1061-51334512）资助.

Biodegradable chelant EDDS([S,S]-ethylenediamine disuccinic acid) modified vermiculite and activated carbon and their adsorption performance for Fe(Ⅱ)

1.
Key Laboratory of Integrated Regulation and Resource Development on Shallow Lake of Ministry of Education, College of Environment, Hohai University, Nanjing, 210098, China
Fund Project:

摘要: 提出将Fe（Ⅱ）离子吸附络合稳定于活性炭、蛭石表面，再与H2O2组成新的非均相Fenton反应体系，通过加热、煮沸、干燥等简单的物理方法成功地将螯合剂EDDS（[S，S]-乙二胺二琥珀酸）修饰到蛭石和活性炭表面，对蛭石和活性炭进行改性.主要研究了包括pH、温度、初始浓度、反应时间对材料吸附性能的影响.研究表明，在相同条件下EDDS改性可以提高活性炭和蛭石对Fe（Ⅱ）离子的吸附容量，溶液pH、温度、初始浓度对吸附有较大影响.吸附等温线的拟合结果表明，Fe（Ⅱ）离子在 EDDS 修饰的活性炭和蛭石上吸附行为符合 Langmuir 吸附，其饱和吸附量都有所提高，且具有较大的吸附系数，这是由于修饰在活性炭和蛭石表面的 EDDS 和金属离子形成强烈的络合作用所致.
- 蛭石 /
- 活性炭 /
- 改性 /
- Fe（Ⅱ） /
- 吸附
Abstract: In this paper, activated carbon and vermiculite were used to adsorb Fe (Ⅱ) ions, to form a heterogeneous Fenton reaction system with H2O2. Modified vermiculite and activated carbon were prepared by coating chelating agent EDDS onto their surface with the simple physical methods like heating, boiling, drying. In the study, the influence of pH, temperature, initial concentration and reaction time on the adsorption performance of the material for Fe(Ⅱ) were investigated. The results showed that EDDS improved Fe(Ⅱ) ion adsorption capacity of both activated carbon and vermiculite. And pH, temperature and the initial Fe(Ⅱ) concentration had a great influence on the adsorption capacity. Adsorption isotherm fitting results showed that adsorption behavior of the Fe(Ⅱ) ion on the modified activated carbon and vermiculite materials conformed to the Langmuir adsorption. The adsorption capacity was improved with a large adsorption coefficient, attributing to the strong complexing action of the metal ions with EDDS modified onto the surface of the activated carbon and vermiculite.
- vermiculite /
- activated carbon /
- modified /
- Fe(Ⅱ) /
- absorption

[1]	Parra S, et al., Discoloration of azo-dyes at biocompatible pH-values through an Fe-histidine complex immobilized on Nafion via Fenton-like processes[J]. The Journal of Physical Chemistry B, 2004. 108(14): 4439-4448
[2]	KuŠić H, Koprivanac N, Selanec I. Fe-exchanged zeolite as the effective heterogeneous Fenton-type catalyst for the organic pollutant minimization: UV irradiation assistance[J]. Chemosphere, 2006. 65(1): 65-73
[3]	赵立谦.似芬顿试剂处理 TCE 污染源区的方法研究[D]. 北京: 中国地质大学硕士论文, 2009
[4]	李婷婷. 天然有机质对似芬顿试剂去除三氯乙烯的影响研究[D]. 北京: 中国地质大学硕士论文, 2012
[5]	Chen J, Yiacoumi S, Blaydes T G. Equilibrium and kinetic studies of copper adsorption by activated carbon[J]. Separations Technology, 1996. 6(2): 133-146
[6]	杨连珍, 梁霞, 王吟, 等.微波辅助 HNO₃ 改性竹炭对 Cu²⁺ 的吸附性能[J]. 环境化学, 2013, 32(3): 387-393
[7]	赵梅青, 马子川, 张立艳, 等.高锰酸钾改性对颗粒活性炭吸附 Cu²⁺ 的影响[J]. 金属矿山, 2008, 11: 110-113
[8]	戴清清, 宋绵新, 张宝述, 等.溶液 pH 值对不同粒径蛭石吸附 Cu²⁺, Pb²⁺ 的影响[J]. 矿业研究与开发, 2006, 3: 18
[9]	梁洪祥, 姚献东. 环境因素对蛭石吸附重金属钴离子的影响及机理[J]. 化学试剂, 2013, 35(6): 551-554
[10]	钟玉凤, 吴少林, 戴玉芬, 等. 有机螯合剂在环境保护中的应用[J]. 江西科学, 2007, 25(3): 351-354
[11]	李倩倩, 李义久, 相波.高分子鳌合剂在重金属废水处理中的应用[J]. 工业水处理, 2004, 24(7): 5-8
[12]	Zhang L, Zhu Z, Zhang R, et al.Extraction of copper from sewage sludge using biodegradable chelant EDDS[J]. Journal of Environmental Sciences, 2008, 20(8): 970-974
[13]	Koodyńska, D. Application of strongly basic anion exchangers for removal of heavy metal ions in the presence of green chelating agent[J]. Chemical Engineering Journal, 2011, 168(3): 994-1007
[14]	魏岚, 陈亚华, 钱猛, 等. 可降解螯合剂 EDDS 诱导植物修复重金属污染土壤的潜力[J]. 南京农业大学学报, 2006, 29(2): 33-38
[15]	钱猛, 沈振国, 魏岚.螯合剂 EDDS 和 EDTA 诱导海州香薷积累土壤重金属的比较研究[J]. 农业环境科学学报, 2006, 25(1): 113-118
[16]	Harris D C. Quantitative chemical analysis (5th ed)[M].New York: W H Freeman, 1999.
[17]	魏复盛. 国家环境保护总局与水和废水监测分析方法编委会, 水和废水监测分析方法. 北京: 中国环境科学出版社, 2002
[18]	张勇. 微波活性炭处理重金属废水研究[D]. 昆明: 昆明理工大学, 2007
[19]	Ma L Q, Rao G N. Chemical fractionation of cadmium, copper, nickel, and zinc in contaminated soils[J]. Journal of Environmental Quality, 1997, 26(1): 259-264
[20]	Adhikari T, Singh M V. Sorption characteristics of lead and cadmium in some soils of India[J]. Geoderma, 2003, 114(1): 81-92
[21]

点击查看大图

计量

文章访问数: 1303
HTML全文浏览数: 1303
PDF下载数: 484
施引文献: 0

引用本文:

Citation:

SHI Haibo, ZHU Jianzhong, CHEN Shenglu, JI Dongliang, CAO Yang, CHEN Guanhuan. Biodegradable chelant EDDS([S,S]-ethylenediamine disuccinic acid) modified vermiculite and activated carbon and their adsorption performance for Fe(Ⅱ)[J]. Environmental Chemistry, 2014, 33(6): 949-955. doi: 10.7524/j.issn.0254-6108.2014.06.011

生物可降解络合剂[S,S]-乙二胺二琥珀酸改性蛭石和活性炭及其对Fe（Ⅱ）的吸附性能

1. 河海大学浅水湖泊综合治理与资源开发教育部重点实验室及河海大学环境学院, 南京, 210098

收稿日期: 2013-09-23

基金项目:

教育部留学人员回国启动基金（1061-51200312）；中央高校（河海大学）基本科研业务费专项资金（B11020157）；江苏水利科技项目基金（1061-51146012）；江苏科技项目基金（1061-51334512）资助.

关键词:

蛭石 /
活性炭 /
改性 /
Fe（Ⅱ） /
吸附

摘要: 提出将Fe（Ⅱ）离子吸附络合稳定于活性炭、蛭石表面，再与H2O2组成新的非均相Fenton反应体系，通过加热、煮沸、干燥等简单的物理方法成功地将螯合剂EDDS（[S，S]-乙二胺二琥珀酸）修饰到蛭石和活性炭表面，对蛭石和活性炭进行改性.主要研究了包括pH、温度、初始浓度、反应时间对材料吸附性能的影响.研究表明，在相同条件下EDDS改性可以提高活性炭和蛭石对Fe（Ⅱ）离子的吸附容量，溶液pH、温度、初始浓度对吸附有较大影响.吸附等温线的拟合结果表明，Fe（Ⅱ）离子在 EDDS 修饰的活性炭和蛭石上吸附行为符合 Langmuir 吸附，其饱和吸附量都有所提高，且具有较大的吸附系数，这是由于修饰在活性炭和蛭石表面的 EDDS 和金属离子形成强烈的络合作用所致.

English Abstract

Biodegradable chelant EDDS([S,S]-ethylenediamine disuccinic acid) modified vermiculite and activated carbon and their adsorption performance for Fe(Ⅱ)

1. Key Laboratory of Integrated Regulation and Resource Development on Shallow Lake of Ministry of Education, College of Environment, Hohai University, Nanjing, 210098, China

Received Date: 2013-09-23

Fund Project:

Keywords:

Abstract: In this paper, activated carbon and vermiculite were used to adsorb Fe (Ⅱ) ions, to form a heterogeneous Fenton reaction system with H2O2. Modified vermiculite and activated carbon were prepared by coating chelating agent EDDS onto their surface with the simple physical methods like heating, boiling, drying. In the study, the influence of pH, temperature, initial concentration and reaction time on the adsorption performance of the material for Fe(Ⅱ) were investigated. The results showed that EDDS improved Fe(Ⅱ) ion adsorption capacity of both activated carbon and vermiculite. And pH, temperature and the initial Fe(Ⅱ) concentration had a great influence on the adsorption capacity. Adsorption isotherm fitting results showed that adsorption behavior of the Fe(Ⅱ) ion on the modified activated carbon and vermiculite materials conformed to the Langmuir adsorption. The adsorption capacity was improved with a large adsorption coefficient, attributing to the strong complexing action of the metal ions with EDDS modified onto the surface of the activated carbon and vermiculite.
