娄山河表层沉积物重金属赋存形态及风险评价
Speciation and risk assessment of heavy metals in surface sediments of the Loushan River
-
摘要: 测定了娄山河表层沉积物间隙水中重金属(Cu、As、Pb、Zn、Cr、Cd和Ni)的质量浓度,采用改正的BCR顺序提取法分析了沉积物中重金属的赋存形态,并分别基于美国水质基准(CCC、CMC)和风险评价编码法(RAC)、潜在生态风险指数法对间隙水和表层沉积物中重金属的毒性及生态风险进行评价.结果表明,娄山河表层沉积物间隙水中Cr、Pb可能对水生态系统产生急性或慢性毒性.沉积物中7种重金属的含量均高于土壤背景值,呈现累积效应.沉积物中As、Ni主要赋存于残渣态,Cu、Cr主要赋存于可氧化态和残渣态,Pb、Zn在多数点位以残渣态为主,Cd以酸可溶解态为主要赋存形态.除As外,其余重金属的可提取态含量高于残渣态,有较高的二次释放潜力.RAC的评价结果表明,表层沉积物中Cu、As、Pb和Cr处于无风险到低风险级,Zn、Ni处于低风险到高风险级,Cd以高风险和极高风险级为主,不同重金属RAC的平均值依次为Cd>Zn>Ni>Pb>Cu>As>Cr.潜在生态风险指数法的评价结果表明,Zn为低生态风险,其余重金属均存在点位处于中等及以上生态风险,RI值表明研究区采样点有中等到极强生态风险.Abstract: The concentrations of Cu, As, Pb, Zn, Cr, Cd and Ni were analyzed in interstitial water from Loushan River by ICP-MS. A modified BCR's sequential extraction procedure was used to investigate the fraction of the heavy metals in surface sediments. The aquatic toxicity of heavy metals in interstitial water was assessed by US Water Quality Criteria(CCC, CMC). Based on speciation of the heavy metals in the sediments, their ecological risk was assessed with the methods of risk assessment code(RAC) and potential ecological risk index. The results show that Cr and Pb pose acute or chronic toxicity for aquatic ecosystem in some sampling locations. Contents of the heavy metals in the sediments were higher than the background values of the local soils, indicating enrichment of the heavy metals. As and Ni were primarily in residual fractions, while Cu and Cr were mainly present in residual and oxidisable fractions. Although Pb and Zn exist mainly in residual fractions in the majority of the sampling locations, Cd exist mainly in acid soluble faction. The bio-available fractions of Cu, Pb, Zn, Cr, Cd and Ni were higher than the residual fractions in the sediments, indicating a high potential for secondary release. Based on the calculations with the RAC method, Cu, As, Pb and Cr pose an extremely low to low risk to the environment. Accordingly, Zn and Ni pose low to high risk, and Cd is mainly of high to extreme high risk to the environment. The potential ecological risk of the heavy metals in the sediments is in the order of Cd>Zn>Ni>Pb>Cu>As>Cr. Zn has low ecological risk, and the other heavy metals have medium to extremely high potential ecological risk at some sampling locations. The potential ecological risk Indices(RI) indicate the heavy metals in the sediments pose medium to extremely high potential ecological risks to the Loushan River.
-
Key words:
- Loushan River /
- interstitial water /
- surface sediments /
- heavy metals /
- speciation /
- risk assessment.
-
-
[1] 张彦, 卢学强, 刘红磊, 等. 渤海湾天津段表层沉积物重金属分布特征及其来源解析[J]. 环境科学研究, 2014, 27(6):608-614. ZHANG Y, LU X Q, LIU H L, et al. Distribution characteristics and source identification of heavy metals in surface sediments of Bohai Bay near Tianjin[J]. Research of Environmental Sciences, 2014, 27(6):608-614(in Chinese).
[2] CHEN C W, KAO C M, CHEN C F,et al. Distribution and accumulation of heavy metals in the sediments of Kaohsiung Harbor, Taiwan[J]. Chemosphere, 2007, 66(8):1431-1440. [3] MCCREADY S, BIRCH G F, LONG E R. Metallic and organic contaminants in sediments of Sydney Harbour, Australia and vicinity:A chemical dataset for evaluating sediment quality guidelines[J]. Environmental international, 2006, 32(4):455-465. [4] SALOMONS W, STIGLIANI W M. Biogeodynamics of pollutants in soils and sediments:risk assessment of delayed and non-linear responses[M]. Springer-Verlag, 1995, 331-343. [5] 曹会聪, 王金达, 张学林. 吉林黑土中Cd, Pb, As的空间分布及潜在生态风险[J]. 中国环境科学, 2007, 27(1):89-92. CAO H C, WANG J D, ZHANG X L. Spatial distribution and potential ecological risk of Cd, Pb, As in Jilin black soil[J]. China Environmental Science, 2007, 27(1):89-92(in Chinese).
[6] HUANG X F, HU J W, LI C X, et al. Heavy-metal pollution and potential ecological risk assessment of sediments from Baihua Lake, Guizhou, P.R. China[J]. International Journal of Environmental Health Research, 2009, 19(6):405-419. [7] LEWIS M A, DANIELS C B, MOORE J C, et al. Potential genotoxicity of wastewater-contaminated pore waters with comparison to sediment toxicity and macrobenthic community composition[J]. Environmental Toxicology, 2002, 17(1):63-73. [8] TALAUE-MCMANUS L, SMITH S V, BUDDEMEIER R W, et al. Biophysical and socio-economic assessments of the coastal zone:The LOICZ approach[J]. Ocean and Coastal Management, 2003, 46(3-4):323-333. [9] 袁浩, 王雨春, 顾尚义, 等. 黄河水系沉积物重金属赋存形态及污染特征[J]. 生态学杂志, 27(11):1966-1971. YUAN H, WANG Y C, GU S Y, et al. Chemical forms and pollution characteristics of heavy metals in Yellow River sediments[J]. Chinese Journal of Ecology, 2008 , 27(11):1966-1971(in Chinese).
[10] 董贺平, 邹建军, 李广雪, 等. 胶州湾西北部沉积物中重金属元素分布特征及评价[J]. 海洋地质动态, 2007, 23(8):4-9. Dong H P, ZOU J P, LI G X, et al. Distribution and evaluation of heavy metals in sediments in northwest of Jiaozhou bay[J]. Marine Geology Letters, 2007, 23(8):4-9(in Chinese).
[11] 张婧, 孙英兰. 胶州湾娄山河口海域制碱白泥治理方法初探[J]. 海洋湖沼通报, 2007, 3:120-126 ZHANG J, SUN Y L. Discussion on controlling method of soda wastemud in the Loushan River estuary, Jiaozhou Bay, Qingdao[J]. Transactions of Oceanology and Limnology, 2007 , 3:120-126(in Chinese).
[12] PARDO R, HELENA B A, CAZURROA C, et al. Application of two-and three-way principal component analysis to the interpretation of chemical fractionation results obtained by the use of the BCR procedure[J]. Analytica Chimica Acta, 2004, 523(1):125-132. [13] 王鸣宇, 张雷, 秦延文, 等. 湘江表层沉积物重金属的赋存形态及其环境影响因子分析[J]. 环境科学学报, 2011, 31(11):2447-2458. Wang M Y, Zhang L, Qin Y W, et al. Speciation of heavy metals in sediments from Xiang River and analysis of their environmental factors[J]. Acta Scientiae Circumstantiae, 2011, 31(11):2447-2458(in Chinese).
[14] 刘宗平. 环境重金属污染物的生物有效性[J]. 生态学报, 2005, 25(2):273-278. LIU Z P. The bioactivity of environment heavy metal pollutants in the vicinity of nonferrous metal smelters[J]. Acta Ecological Sinica, 2005, 25(2):273-278(in Chinese).
[15] HUANG H J, YUAN X Z, ZENG G, et al. Quantitative evaluation of heavy metals' pollution hazards in liquefaction residues of sewage sludge[J]. Bioresource Technology, 2011, 102(22):10346-10351. [16] HAKANSON L. An ecological risk index for aquatic pollution control. A sedimentological approach[J]. Water Research, 1980, 14(8):975-1001. [17] SARAEE K R E, ABDI M R, NAGHAVI K, et al. Distribution of heavy metals in surface sediments from the South China Sea ecosystem, Malaysia[J]. Environmental Monitoring and Assessment, 183(1-4):545-554. [18] 朱磊, 贾永刚, 潘玉英. 青岛北站规划区原场地表层土壤重金属污染研究[J]. 环境科学, 2013, 34(9):3663-3668. ZHU L, JIA Y G, PAN Y Y, et al. Study on pollution evaluation of heavy metal in surface soil of the original site of Qingdao north station[J]. Environmental Science, 2013, 34(9):3663-3668(in Chinese).
[19] 周家义, 潜琬英, 顾郁翘, 等. 海洋环境地球化学——Ⅳ. 胶州湾娄山河口海域铬迁移转化规律研究[J]. 环境科学学报, 1984, 4(2):165-178. ZHOU J Y, QIAN W Y, GU Y Q, et al. Marine environmental geochemisty——Ⅳ. Reduction of Cr(Ⅵ) to Cr(Ⅲ) and transfer of Chromium in Loushan estuary, Jiaozhou Bay[J]. Acta Science Circumstantiae, 1984, 4(2):165-178(in Chinese).
[20] 李玉. 胶州湾主要重金属和有机污染物的分布及特征研究[D]. 青岛:中国科学院海洋研究所, 2005. LI Y. Study on the distribution and characteristics of main heavy metals and organic pollutants of Jiaozhou Bay[D]. Qingdao:Institute of Oceanology, Chinese Academy of Sciences, 2005(in Chinese) [21] 王贵, 姚德. 胶州湾东岸表层沉积物重金属污染研究[J]. 内蒙古石油化工, 2005, 31(7):1-3. WANG G, YAO D. The assessment of heavy metal pollution for the sediments of Jiaozhou Bay[J]. Acta petrochemical industry of Neimenggu, 2005, 31(7):1-3(in Chinese).
[22] CHEN S Y, LIN J G. Bioleaching of heavy metals from sediment:significance of pH[J]. Chemosphere, 2001, 44(5):1093-1102. [23] 刘峰, 胡继伟, 吴迪, 等. 基于形态学分析红枫湖沉积物中重金属的分布特征及污染评价[J]. 环境化学, 2011, 30(2):440-446. HIU F, HU J W, WU D, et al. Speciation characteristics and risk assessment of heavy metals in sediments from Hongfeng Lake, Guizhou Province[J]. Environmental Chemistry, 2011, 30(2):440-446(in Chinese).
[24] 陈敬安, 万国江. 洱海沉积物重金属地球化学相及其污染历史研究[J]. 地质地球化学, 1998, 26(2):1-8. CHEN J A, WAN G J. Geochemical phases and pollution history of heavy metals in sediments of Lake Erhai[J]. Geology-Geochemistry, 1998, 26(2):1-8(in Chinese).
[25] 周怀东, 袁浩, 王雨春, 等. 长江水系沉积物中重金属的赋存形态[J]. 环境化学, 2008, 27(4):515-519. ZHOU H D, Y H, WANG C Y, et al. The chemical speciation of heavy metals in sediments from Yangze Basin[J]. Environmental Chemistry, 2008, 27(4):515-519(in Chinese).
[26] 陈春霄, 姜霞, 战玉柱, 等. 太湖表层沉积物中重金属形态分布及其潜在生态风险分析[J]. 中国环境科学, 2011, 31(11):1842-1848. CHEN C X, JIANG X, ZHAN Y Z, et al. Speciation distribution and potential ecological risk assessment of heavy metals in sediments of Taihu Lake[J]. China Environmental Science, 2011, 31(11):1842-1848(in Chinese).
[27] 田林锋, 胡继伟, 秦樊鑫, 等. 重金属元素在贵州红枫湖水体中的分布特征[J]. 中国环境科学, 2011, 31(3):481-489. TIAN L F, HU J W, QIN F X, et al. Distribution of heavy metal elements in the water body from Lake Hongfeng[J]. China Environmental Science, 2011, 31(3):481-489(in Chinese).
[28] 董丽华, 李亚男, 常素云, 等. 沉积物中重金属的形态分析及风险评价[J]. 天津大学学报, 2009, 42(12):1112-1117. DONG L H, LI Y N, CHANG S Y, ea al. Fraction distribution and risk assessment of heavy metals in sediments[J]. Journal of Tianjin University, 2009, 42(12):1112-1117(in Chinese).
[29] 赵建亮, 应光国, 魏东斌, 等. 水体和沉积物中毒害污染物的生态风险评价方法体系研究进展[J]. 生态毒理学报, 2011, 6(6):577-588. ZHAO J L, YING G G, WEI D B, et al. Ecological risk assessment methodology of toxic pollutants in surface water and sediments:A Review[J]. Asian Journal of Ecotoxicology, 2011, 6(6):577-588(in Chinese).
[30] LIU J L, LI Y L, ZHANG B, et al. Ecological risk of heavy metals in sediments of the Luan River source water[J]. Ecotoxicology, 2009, 18(6):748-758. [31] 李珊珊, 单保庆, 张洪. 滏阳河表层沉积物重金属的赋存形态研究[J]. 环境化学, 2013, 32(11):2016-2023. LI S S, SHAN B Q, ZHANG H. Heavy metal speciation in the surface sediments of Fuyang River[J]. Environmental Chemistry, 2013, 32(11):2016-2023.
[32] 方明, 吴友军, 刘红, 等. 长江口沉积物重金属的分布、来源及潜在生态风险评价[J]. 环境科学学报, 2013, 33(2):563-569. FANG M, WU Y J, LIU H, et al. Distribution, sources and ecological risk assessment of heavy metals in sediments of the Yangtze River estuary[J]. Acta Scientiae Circumstantiae, 2013, 33(2):563-569.
-
