虚拟模板分子印迹微球的制备及其对水中微囊藻毒素的吸附性能

,  ,  ,  ,

downloadPDF

上一篇

下一篇

宋兴良, 王爱香, 刘晓泓, 黄怡, 石莉莉. 虚拟模板分子印迹微球的制备及其对水中微囊藻毒素的吸附性能[J]. 环境化学, 2016, 35(3): 451-459. doi: 10.7524/j.issn.0254-6108.2016.03.2015021301
引用本文: 宋兴良, 王爱香, 刘晓泓, 黄怡, 石莉莉. 虚拟模板分子印迹微球的制备及其对水中微囊藻毒素的吸附性能[J]. 环境化学, 2016, 35(3): 451-459. doi: 10.7524/j.issn.0254-6108.2016.03.2015021301
shu
SONG Xingliang, WANG Aixiang, LIU Xiaohong, HUANG Yi, SHI Lili. Preparation of analog-molecularly imprinted microspheres and their adsorbent performance for microcystin in aqueous solution[J]. Environmental Chemistry, 2016, 35(3): 451-459. doi: 10.7524/j.issn.0254-6108.2016.03.2015021301
Citation: SONG Xingliang, WANG Aixiang, LIU Xiaohong, HUANG Yi, SHI Lili. Preparation of analog-molecularly imprinted microspheres and their adsorbent performance for microcystin in aqueous solution[J]. Environmental Chemistry, 2016, 35(3): 451-459. doi: 10.7524/j.issn.0254-6108.2016.03.2015021301
shu

虚拟模板分子印迹微球的制备及其对水中微囊藻毒素的吸附性能

  • 1.

    临沂大学化学化工学院, 临沂, 276005

  • 基金项目:

    国家自然科学基金(21275068)资助.

Preparation of analog-molecularly imprinted microspheres and their adsorbent performance for microcystin in aqueous solution

  • 1.

    School of Chemistry & Chemical Engineering, Linyi University, Linyi, 276005, China

  • Fund Project: Supported by the National Natural Science Foundation of China (21275068).

  • 摘要: 本文以L-精氨酸为模板、丙烯酰胺(AM)为单体,N, N'-亚甲基双丙烯酰胺(MBA)为交联剂以及偶氮二异丁腈(AIBN)为引发剂,采用沉淀聚合法制备了微囊藻毒素分子印迹聚合物.采用量子化学密度泛函理论(DFT)模拟计算以确定模板分子(L-精氨酸)与功能单体(AM)的印迹比例,通过扫描电镜和红外吸收光谱对分子印迹聚合物微球进行表征,并利用平衡吸附实验考察了印迹微球对微囊藻毒素的吸附性能.结果表明,本虚拟模板法制备的印迹微球对MC-LR的吸附符合Langmuir模型,线性拟合得出MIPs的线性回归方程为Ce/Q=3.026×10-4+0.125(r=0.991),由此推导出对MC-LR的最大表观吸附量为80.3 μg·g-1.实验还表明,印迹聚合物对MC-LR和MC-RR的吸附比非印迹聚合物具有更好的选择性,MIPs对MC-LR的初始吸附速率为58.8 μg·g-1·min-1,大于非印迹聚合物的初始吸附速率19.6 μg·g-1·min-1,具有选择性富集水体中MC-LR和MC-RR等微囊藻毒素的应用前景.
    Abstract: Molecularly imprinted polymers for microcystins were synthesized by precipitation polymerization method using L-arginine as the template, acrylamide(AM) as monomer, N, N'-Methylenebisacrylamide as crosslinker and azodiisobutyronitrile as initiator. The imprinting ratio of L-arginine and acrylamide (AM) was calculated based on the Density Functional Theory (DFT) method, and the resulting composites were characterized by scanning electron microscopy (SEM) and Fourier transform infrared (FT-IR) analysis. The selectivity of the MIPs for the adsorption of microcystin-LR was demonstrated by equilibrium adsorption experiments.Results showed that the adsorption isotherms of analog-molecularly imprinted microspheres to MC-LR can be described by the Langmuir adsorption model, and the linear regression equation was fitted as Ce/Q=3.026×10-4+0.125 (r=0.991), and the apparent maximum adsorption capacity for MC-LR was 80.3 μg·g-1. It was proved that the MIPs had better molecular fragment recognition ability for MC-LR and MC-RR than for of NIPs. The imprinted microspheres showed rapid adsorption dynamic process because the initial adsorption rate of MIPs and NIPs to MC-LR were 58.8, 19.6 μg·g-1·min-1, respectively. This polymers can be used for selective extraction of[arginine]-microcystins in water using solid phase extraction method in future.
  • 加载中
  • [1] 梁丽丽, 弓爱君, 李红梅, 等.高效液相色谱法检测水体中微囊藻毒素[J]. 分析化学, 2010,38(5):740-742.

    LIANG L L, GONG A J, LI H M, et al. Determination of microcystins in aquatic environment with high performance liquid chromatography[J]. Chinese Journal of Analytical Chemistry, 2010,38(5):740-742(in Chinese).

    [2] 薛罡, 杨林, 龚清杰, 等. 高效液相色谱法测定水中微囊藻毒素[J].中国给水排水, 2009, 25(22):90-97.

    XUE G, YANG L,GONH Q J, et al. Determination of microcystin in water by high performance liquid chromatography[J]. China Water & Wastewater, 2009, 25(22):90-97(in Chinese).

    [3] 徐立红, 陈加平, 黄兆辉, 等. 用蛋白磷酸酶抑制法测定水体中的微囊藻毒素类物质[J].环境科学学报,1999,19(5):536-539.

    XU L H, CHEN J P, XU J M, et al. Use of protein phosphatase inhibition assay for measuring microcystin class compounds in aquatic system[J]. Acta Scientiae Circumstantiae, 1999,19(5):536-539(in Chinese).

    [4] 刘碧波,肖邦定,刘剑彤,等. 天然水体中痕量微囊藻毒素的高效液相色谱测定方法优化[J].分析化学, 2005, 33(11):1577-1579.

    LIU B B, XIAO B D, LIU J T, et al. The optmization of high performance liquid chromatographic method for analysis of trace microcystins in natural water bodies[J]. Chinese Journal of Analytical Chemistry, 2005, 33(11):1577-1579(in Chinese).

    [5] 毛敬英, 杨敏, 狄一安, 等. 高效液相色谱法检测水中5种微囊藻毒素[J]. 环境工程学报,2012, 6(11):3882-3888.

    MAO J Y, YANG M, DI Y A, et al. Detection of 5 variants microcystins in waters using high performance liquid chromatography[J]. Chinese Journal of Environmental Engineering, 2012, 6(11):3882-3888(in Chinese).

    [6] 肖付刚,赵晓联,汤坚,等. 免疫亲和层析-液质联用法检测蓝藻中的微囊藻毒素[J].分析化学,2009,37(3):369-372.

    XIAO F G, ZHAO X L,TANG J, et al. Determination of microcystins in cyanobacteria using immunoaffinity chromatography column and high performance liquid chromatography/mass spectrometry[J]. Chinese Journal of Analytical Chemistry, 2009,37(3):369-372(in Chinese).

    [7] VINOGRADOVA T,DANAHER M,BAXTER A,et al.Rapid surface plasmon resonance immunobiosensor assay for microcystin toxins in blue-green algae food supplements[J]. Talanta,2011,84(3):638-643.
    [8] 张明, 唐访良, 徐建芬, 等. 固相萃取-高效液相色谱法同时测定地表水中9种微囊藻毒素[J]. 环境化学,2013,32(6):1096-1097.

    ZHANG M, TANG F L, XU J F, et al. Simultaneous determination of 9 variants microcystins in surface water by solid phase extraction and high performance liquid chromatography[J]. Environmental Chemistry, 2013,32(6):1096-1097(in Chinese).

    [9] 赖家平,何锡文,郭洪声, 等. 分子印迹技术的回顾、现状与展望[J]. 分析化学, 2001, 29(7):836-844.

    LAI J P, HE X W, GUO H S, et al. A review on molecular imprinting technique[J]. Chinese Journal of Analytical Chemistry, 2001, 29(7):836-844(in Chinese).

    [10] 郭秀春,周文辉. 分子印迹技术研究进展[J].化学研究,2012,23(5):103-109.

    GUO X C, ZHOU W H. Research progress of molecular imprinting technology[J]. Chemical Research, 2012,23(5):103-109(in Chinese).

    [11] 雷秀兰,易翔,袁洋, 等. 罗丹明B分子印迹聚合物微球的合成及其在固相萃取中的应用[J].应用化学,2011, 28(5):531-536.

    LEI X L,YI X, YUAN Y, et al. Preparation of rhodamine b molecularly imprinted polymer microspheres and its application in solid phase extraction[J]. Chinese Journal of Applied Chemistry, 2011, 28(5):531-536(in Chinese).

    [12] 方继敏,李刚. MC-LR分子印迹聚合物的制备及富集分离性能研究[J].中国给水排水,2008, 28(1):40-47.

    FANG J M, LI G. Study on Preparation of MC-LR molecularly imprinted polymers and their enrichment and separation performances[J]. China Water & Wastewater, 2008, 28(1):40-47(in Chinese).

    [13]
    [14] 赵硕,崔莉凤,黄振芳, 等. 溶胀聚合法制备微囊藻毒素分子印迹聚合物[J].化工进展, 2010,29:255-262. ZHAO S, CUI L F, HUANG Z F, et al. Preparation of microcystins molecularly imprinted polymer by swelling polymerization[J]. Chemical Industry and Engineering Progress, 2010

    ,29:255-262(in Chinese).

    [15] MBUKWA E A, MSAGATI T A M, MAMBA B B. Preparation of guanidinium terminus-molecularly imprinted polymers for selective recognition and solid-phase extraction (SPE) of[arginine]-microcystins[J]. Anal Bioanal Chem, 2013, 405:4253-4267.
    [16] LIU X J, LIU J Z, HUANG Y Y, et al. Determination of methotrexate in human serum by high-performance liquid chromatography combined with pseudo template molecularly imprinted polymer[J]. Journal of Chromatography A, 2009, 1216:7533-7538.
    [17] 王岩,刘俊渤,唐珊珊,等. 计算机辅助三聚氰胺分子印迹聚合物的制备[J]. 高等学校化学学报, 2015, 36(5), 945-954.

    WANG Y, LIU J B, TANG S S, et al. Preparation of melamine molecular imprinted polymer by computer aided design[J]. Chemical Journal of Chinese Universities, 2015, 36(5), 945-954(in Chinese).

  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1321
  • HTML全文浏览数:  1250
  • PDF下载数:  820
  • 施引文献:  0
出版历程
  • 收稿日期:  2015-02-13
  • 刊出日期:  2016-03-15
宋兴良, 王爱香, 刘晓泓, 黄怡, 石莉莉. 虚拟模板分子印迹微球的制备及其对水中微囊藻毒素的吸附性能[J]. 环境化学, 2016, 35(3): 451-459. doi: 10.7524/j.issn.0254-6108.2016.03.2015021301
引用本文: 宋兴良, 王爱香, 刘晓泓, 黄怡, 石莉莉. 虚拟模板分子印迹微球的制备及其对水中微囊藻毒素的吸附性能[J]. 环境化学, 2016, 35(3): 451-459. doi: 10.7524/j.issn.0254-6108.2016.03.2015021301
shu
SONG Xingliang, WANG Aixiang, LIU Xiaohong, HUANG Yi, SHI Lili. Preparation of analog-molecularly imprinted microspheres and their adsorbent performance for microcystin in aqueous solution[J]. Environmental Chemistry, 2016, 35(3): 451-459. doi: 10.7524/j.issn.0254-6108.2016.03.2015021301
Citation: SONG Xingliang, WANG Aixiang, LIU Xiaohong, HUANG Yi, SHI Lili. Preparation of analog-molecularly imprinted microspheres and their adsorbent performance for microcystin in aqueous solution[J]. Environmental Chemistry, 2016, 35(3): 451-459. doi: 10.7524/j.issn.0254-6108.2016.03.2015021301
shu

虚拟模板分子印迹微球的制备及其对水中微囊藻毒素的吸附性能

  • 1. 临沂大学化学化工学院, 临沂, 276005
  • 收稿日期:  2015-02-13
基金项目:

国家自然科学基金(21275068)资助.

摘要: 本文以L-精氨酸为模板、丙烯酰胺(AM)为单体,N, N'-亚甲基双丙烯酰胺(MBA)为交联剂以及偶氮二异丁腈(AIBN)为引发剂,采用沉淀聚合法制备了微囊藻毒素分子印迹聚合物.采用量子化学密度泛函理论(DFT)模拟计算以确定模板分子(L-精氨酸)与功能单体(AM)的印迹比例,通过扫描电镜和红外吸收光谱对分子印迹聚合物微球进行表征,并利用平衡吸附实验考察了印迹微球对微囊藻毒素的吸附性能.结果表明,本虚拟模板法制备的印迹微球对MC-LR的吸附符合Langmuir模型,线性拟合得出MIPs的线性回归方程为Ce/Q=3.026×10-4+0.125(r=0.991),由此推导出对MC-LR的最大表观吸附量为80.3 μg·g-1.实验还表明,印迹聚合物对MC-LR和MC-RR的吸附比非印迹聚合物具有更好的选择性,MIPs对MC-LR的初始吸附速率为58.8 μg·g-1·min-1,大于非印迹聚合物的初始吸附速率19.6 μg·g-1·min-1,具有选择性富集水体中MC-LR和MC-RR等微囊藻毒素的应用前景.
