投菌强化序批式反应器(SBR)脱氮除磷效果及微生物种属分析

,  ,  ,  ,

downloadPDF

上一篇

下一篇

陈晶, 周新程, 陈萍, 邓文, 张文艺. 投菌强化序批式反应器(SBR)脱氮除磷效果及微生物种属分析[J]. 环境化学, 2016, 35(10): 2183-2190. doi: 10.7524/j.issn.0254-6108.2016.10.2016021502
引用本文: 陈晶, 周新程, 陈萍, 邓文, 张文艺. 投菌强化序批式反应器(SBR)脱氮除磷效果及微生物种属分析[J]. 环境化学, 2016, 35(10): 2183-2190. doi: 10.7524/j.issn.0254-6108.2016.10.2016021502
shu
CHEN Jing, ZHOU Xincheng, CHEN Ping, DENG Wen, ZHANG Wenyi. Enhanced nitrogen and phosphorus removal with addition of microbes in sequencing batch reactor and analysis of microbial specie[J]. Environmental Chemistry, 2016, 35(10): 2183-2190. doi: 10.7524/j.issn.0254-6108.2016.10.2016021502
Citation: CHEN Jing, ZHOU Xincheng, CHEN Ping, DENG Wen, ZHANG Wenyi. Enhanced nitrogen and phosphorus removal with addition of microbes in sequencing batch reactor and analysis of microbial specie[J]. Environmental Chemistry, 2016, 35(10): 2183-2190. doi: 10.7524/j.issn.0254-6108.2016.10.2016021502
shu

投菌强化序批式反应器(SBR)脱氮除磷效果及微生物种属分析

  • 1.

    常州大学环境与安全工程学院, 常州, 213164

  • 基金项目:

    国家“水体污染控制与治理”科技重大专项（2012zx07301-001），国家自然科学基金（41571471），常州市和武进区科技支撑项目（CE20155061，WS201521）资助.

Enhanced nitrogen and phosphorus removal with addition of microbes in sequencing batch reactor and analysis of microbial specie

  • 1.

    School of Environment & Safety Engineering, Changzhou University, Changzhou, 213164, China

  • Fund Project: Supported by The National Major Science & Technology Program for Water Pollution Control and Management(2012zx07301-001),the National Natural Science Foundation of China(41571471),Science and Technology Project of Changzhou City and Wujin District(CE20155061, WS201521).

  • 摘要: 为揭示投加具有反硝化聚磷能力的恶臭假单胞菌（B8）强化序批式反应器（SBR）除污特性和微生物种属，将B8菌液和干粉菌剂分别引入SBR，构成液态型DNPAOs-SBR污水处理系统A和干粉型DNPAOs-SBR污水处理系统B，以不接菌的SBR污水处理系统C为对照，分别考察了在厌氧-缺氧条件下运行的各反应器除污效果.结果表明，各SBR（A、B、C）对COD去除率均达到90%以上；第49-77天时A系统、B系统和C系统NO3-平均去除率分别为61.62%、68.58%和26.72%；第62-77天时A系统、B系统和C系统TP平均去除率分别为53.66%、55.45%和46.61%；投菌强化系统在缺氧段对TP降解过程符合一阶指数衰减动力学模式，在第71天时，A号吸磷动力学系数KP为1.2584，B号吸磷动力学系数KP为2.0379；对SBR内活性污泥菌种16S rDNA测序及GenBank BLAST，A系统和B系统中占优势菌种依次是溶血不动杆菌、恶臭假单胞菌和粪产碱菌，而未投菌C系统占优势菌类依次是溶血不动杆菌、粪产碱菌和产碱假单胞菌，表明投加的B8菌在液态型DNPAOs-SBR污水处理系统和干粉型DNPAOs-SBR污水处理系统内得到生长富集，从而成为优势菌群.
    Abstract: This paper aimed to investigate the performance and microbial community of denitrifying polyphosphate accumulating bacteria (Pseudomonas putida B8) in the sequencing batch reactor (SBR) system. B8 bacterial liquid and B8 bacteria powder were introduced into SBR respectively to construct new type DNPAOs-SBR sewage disposal systems (liquid type A and dry powder type B), with a traditional SBR (type C) as contrast. The performance of these three reactors under anaerobic-anoxic conditions was investigated. The results showed that the chemical oxygen demand (COD) removal of all SBR reactors was above 90%, while the mean removal rates of nitrate in A, B and C reactors during 49-77 days were 61.62%, 68.58% and 26.72%, respectively. In addition, the mean removal rates of total phosphorus (TP) in A, B and C reactors during 62-77 days were 53.66%, 55.45% and 46.61%, respectively. The kinetics of TP removal under anoxic conditions in A and B reactors followed the first-order exponential decay model, with the kinetic constants 1.2584 and 2.0379 at 71 day, respectively. The polyphosphate accumulating microbial species in SBR were also analyzed, and the dominant bacteria were Actinetobacter haemolyticus, Pseudomonas putida and Alcaligenes faecalis in the system A and B, while the dominant bacteria were Actinetobacter haemolyticus, Alcaligenes faecalis and Pseudomonas alcaligenes in the control group. The denitrifying polyphosphate accumulating microorganism B8 put in the DNPAOs-SBR systems (A and B reactors) grew well.
  • 加载中
  • [1] LIU Y, MAITE P J, YUAN Z G. The effect of free nitrous acid on key anaerobic processes in enhanced biological phosphorus removal systems[J]. Bioresource Technology,2013,130:382-389.
    [2] KAPAGIANNIDIS A G, ZAFIRIADIS I, AIVASIDIS A. Comparison between aerobic and anoxic metabolism of denitrifying-EBPR sludge: Effect of biomass poly-hydroxyalkanoates content[J]. New Biotechnology, 2013,30(2):227-236.
    [3] 马放, 杨菲菲, 李昂,等. 1株高效反硝化聚磷菌的生物学特性研究[J]. 环境科学,2011,32(9):2711-2715.

    MA F, YANG F F, LI A, et al. Biological characteristics of denitrifying polyphosphate-accumulating organisms[J]. Environmental Science, 2011,32(9):2711-2715(in Chinese).

    [4] 刘立, 汤兵, 黄绍松,等. 反硝化聚磷菌快速富集、培养及其荧光原位杂交技术鉴别[J]. 环境科学,2013,34(7):2869-2875.

    LIU L, TANG B, HANG S S, et al. Rapid enrichment and cultivation of denitrifying phosphate-removal bacteria and its identification by fluorescence in situ hybridization technology[J]. Environmental Science, 2013,37(7):2869-2875(in Chinese).

    [5] TSUNEDA S, OHNO T, SOEJIMA K, et al. Simultaneous nitrogen and phosphorus removal using denitrifying phosphate-accumulating organisms in a sequencing batch reactor[J]. Biochemical Engineering Journal, 2006,27:191-196.
    [6] TSUNEDA S, MIYAUCHI R, OHNO T, et al. Characterization of denitrifying polyphosphate-accumulating organisms in activated sludge based on nitrite reductase gene[J]. Journal of Bioscience and Bioengineering, 2005,99(4):403-407.
    [7] CARVALHO G, LEMOS C P, OEHMEN A, et al. Denitrifying phosphorus removal: Linking the process performance with the microbial community structure[J]. Water Research, 2007,41(19):4383-4396.
    [8] LIU S L, LI J Z. Accumulation and isolation of simultaneous denitrifying polyphosphate-accumulating organisms in an improved sequencing batch reactor system at low temperature[J]. International Biodeterioration & Biodegradation, 2015,100:140-148.
    [9] SARIOGLU M. Biological phosphorus removal in a sequencing batch reactor by using pure culture[J]. Process Biochemistry, 2005,40(5):1599-1603.
    [10] WANG Y Y, GUO G, WANG H, et al. Long-term impact of anaerobic reaction time on the performance and granular characteristics of granular denitrifying biological phosphorus removal systems[J]. Water Research, 2013,47(14):5326-5337.
    [11] MIAO Z J, ZENG W, WANG S Y, et al. Effect of temperature on anoxic metabolism of nitrites to nitrous oxide by polyphosphate accumulating organisms[J]. Journal of Environmental Sciences, 2014,26(2):264-273.
    [12] WANG Y Y, ZHOU S, WANG H, et al. Comparison of endogenous metabolism during long-term anaerobic starvation of nitrite/nitrate cultivated denitrifying phosphorus removal sludges[J]. Water Research, 2015,68:374-386.
    [13] 潘杨, 阮文权, 黄勇, 等. 序批式活性污泥(SBR)转移工艺的除磷机制[J]. 环境化学,2015,34(7):1329-1334.

    PAN Y, RUAN E Q, HUANG Y, et al. Phosphorus removal mechanism of the sludge-shifting SBR process[J]. Environmental Chemistry, 2015,34(7):1329-1334(in Chinese).

    [14] 张文艺, 陈晶, 邓文, 等. 反硝化聚磷菌菌剂种子液制备条件及除磷机理[J]. 土木建筑与环境工程,2014,36(6):99-105.

    ZHANG W Y, CHEN J, DEN W, et al. Preparation of denitrifying phosphorus accumulating bacterial seed liquid and analysis of phosphorus removal mechanism[J]. Journal of Civil, Architectural & Environmental Engineering,2014,36(6):99-105(in Chinese).

    [15] CHAUDHRY V, NAUTIYAL C S. A high throughput method and culture medium for rapid screening of phosphate accumulating microorganisms[J].Bioresource Technology,2011,102(17):8057-8062.
    [16] 国家环境保护总局.水和废水检测分析方法(第4版)[M].北京:中国环境科学出版社,2002. State Environmental Protection Administration. Detection and analysis of water and wastewater (Fourth Edition)[M]. Beijing: China Environmental Science Press,2002(in Chinese).
    [17] ZHENG X L, SUN P D, HAN J Y, et al. Inhibitory factors affecting the process of enhanced biological phosphorus removal (EBPR)-A mini-review[J]. Process Biochemistry, 2014,49(12): 2207-2213.
    [18] 王建芳, 赵庆良, 张雁秋,等. 投加有效微生物强化SBR和SBBR除污效果的研究[J]. 中国给水排水,2007,23(9):56-59

    ,63. WANG J F, ZHAO Q L, ZHANG Y Q, et al. Study on enhanced contaminant removal efficiency by adding effective microorganisms into SBR and SBBR[J]. China Water & Wastewater,2007,23(9):56-59,63(in Chinese).

    [19] 贺纪正, 李晶, 郑袁明. 土壤生态系统微生物多样性-稳定性关系的思考[J]. 生物多样性,2013,21(4):411-420.

    HE J Z, LI J, ZHENG Y M. Thoughts on the microbial diversity-stability relationship in soil ecosystems[J]. Biodiversity Science,2013,21(4):411-420(in Chinese).
