蜂窝状Ti0.14Mn0.86Ox/CH催化剂的制备及其低温NH3-SCR脱硝性能
Preparation and investigation of Ti0.14Mn0.86Ox/CH monolithic catalysts for low-temperature NH3-SCR
-
摘要: 采用自蔓延高温合成法（SHS）以堇青石蜂窝陶瓷（CH）为基体制备了一系列Ti1-yMnyOx/CH整体式催化剂，应用于柴油车尾气氮氧化物净化.考察了制备参数（钛锰比、涂覆次数、点燃温度）和工况条件（空速，水蒸气）对催化剂低温SCR（选择性催化还原）脱硝活性的影响，采用X射线荧光光谱仪（XRF）、场发射扫描电镜（FE-SEM）、X射线衍射（XRD）、X射线光电子能谱（XPS）、比表面积（BET）等表征手段对催化剂的结构和形貌进行表征.结果表明，在Ti：Mn=1：6（物质的量之比），一次涂覆，点燃温度为350℃条件下所制备的催化剂具有最佳的NH3-SCR脱硝活性，Ti0.14Mn0.86Ox/CH催化剂在空速为30000 h-1，氧气含量为3 vol%反应温度为150-250℃时反应条件为最优，催化剂在150℃以上具有良好的耐水性.Ti元素的添加提高了催化剂表面Mn4+/Mn3+比例，并使MnOx呈无定形态均匀分散在Ti0.14Mn0.86Ox/CH催化剂表面，提高催化剂的低温SCR活性.Abstract: Cordierite honeycomb ceramics (CH) as catalysts' carrier were prepared by self-propagating high-temperature syntheses method (SHS) to obtain a series of Ti1-yMnyOx/CH catalysts for diesel exhaust purification. The effects of the preparation parameters (Ti/Mn ratio in the combustion solution, times of coating, ignition temperature) and operation conditions (space velocity and H2O) on performance of the monolith catalysts for the NH3-SCR were also investigated. The catalysts were characterized by BET, XRF, XRD, FESEM and XPS. It was observed that the catalysts ignited at 350℃ once with Ti/Mn=1:6 in the combustion solution showed the optimal NH3-SCR activity when tested at 150-250℃ with NH3/NO ratio at 1, gaseous hourly space velocity(GHSV)=30000 h-1and 3vol% O2. The catalyst showed excellent H2O tolerance when temperature was above 150℃. Addlition of Ti in the combustion solution increased Mn4+/Mn3+ ratio and improved uniform distribution of amorphous MnOx on the surface of the catalysts, which are benefit for the NH3-SCR activity of the catalysts.
-
-
[1] 郑玉婴,汪谢. Mn基低温SCR脱硝催化剂的研究进展[J]. 功能材料,2014,45(11):11008-11012. ZHENG Y Y, WANG X. Research progress on Mn-based catalysts for low-temperature selective catalytic reduction of NOx[J]. Journal of Functional Materials, 2014, 11(45): 11008-11012(in Chinese).
[2] 王宁,杨海真,王峰. 柴油机机外净化技术发展现状及展望[J]. 环境污染与防治,2010,32(1):73-77. WANG N, YANG H Z, WANG F, Status and prospects of the external purification technology for diesel-powered vehicle[J]. Environmental Pollution and Control, 2010, 32(1): 73-77(in Chinese).
[3] SARACCO G, BADINI C, RUSSO N, et al. Development of catalysts based on pyrovanadates for soot combustion[J]. Applied Catalysis B:Environmental, 1999, 21: 233-242. [4] KĂSPAR J, FORNASIERO P, HICKEY N, Automotive catalytic converters: Current status and some perspectives[J].Catalysis Today, 2003, 77:419-449. [5] 刘清雅,刘振宇.蜂窝状堇青石基CuO/Al2O3 催化剂用于烟气同时脱硫脱硝的研究[J]. 燃料化学学报,2004,32(3):257-262. LIU Q Y, LIU Z Y. Honeycomb cordierite-based CuO/Al2O3 catalyst for simultaneous SO2 and NO removal from flue gas[J]. Journal of Fuel Chemistry and Technology, 2004, 32(3): 257-262(in Chinese).
[6] WANG J C, PENG Z L, CHEN Y, et al, In-situ hydrothermal synthesis of Cu-SSZ-13/cordierite for the catalytic removal of NOx from diesel vehicles by NH3[J]. Chemical Engineering Journal, 2015, 263: 9-19. [7] HUANG H F, JIN L L, LU H F, et al, Monolithic Cr-V/TiO2/cordierite catalysts prepared by in-situ precipitation and impregnation for low-temperature NH3-SCR reactions[J]. Catalysis communications, 2013, 34: 1-4. [8] 李伟,林涛,张秋林,等.整体式MnOx-CeO2/ZrO2-TiO2催化剂用于NH3 低温选择性催化还原NO[J]. 催化学报, 2009, 30(2): 104-110. LI W, LIN T, ZHANG Q L, et al, Low-temperature selective catalytic reduction of NO with NH3 over MnOx-CeO2/ZrO2-TiO2 monolith catalyst[J].Chinese Journal of Catalysis, 2009, 30(2):104-110(in Chinese).
[9] ROY S, Viswanath B, Hegde M S, et al. Low-temperature selective catalytic reduction of NO with NH3 over Ti0.9M0.1O2-δ(M) (Cr, Mn, Fe, Co, Cu)[J]. J Phys Chem C, 2008, 112: 6002-6012. [10] SIVA SANKAR REDDY PUTLURU, LEONHARD SCHILL, et.al, Mn/TiO2 and Mn-Fe/TiO2 catalysts synthesized by deposition precipitation-promising for selective catalytic reduction of NO with NH3 at low temperatures[J]. Applied Catalysis B: Environmental, 2015, 165: 628-635. [11] 沈伯雄,郭宾彬,史展亮,等.CeO2/ACF的低温SCR烟气脱硝性能研究[J]. 燃料化学学报, 2007, 35(1): 125-128. SHEN B X, GUO B S, SHI Z L, et al. Low temperature SCR of NO in flue gas on CeO2/ACF[J]. Journal of Fuel Chemistry and Technology, 2015, 35(1): 125-128(in Chinese).
[12] 王学海,李勇,刘忠生,等. NH3选择性还原NOx催化剂的制备及性能评价[J]. 化工环保,2011,31(6):549-552. WANG X H, LI Y, LIU Z S, et al. Preparation and performance evaluation of catalyst for selective catalytic reduction of NOx with NH3[J]. Envionmental Protection of Chemical Industry. 2011, 31(6): 549-552(in Chinese).
[13] 耿春香,柴倩倩,王陈珑,等. Mn-Fe-Ce/TiO2 低温脱硝催化剂的制备条件优化及其表征[J]. 化工进展,2014,33(4):921-924. GENG C X, CHAI Q Q, WANG C L, et al. Preparation optimization and characterization of low-temperature denitration catalyst Mn-Fe-Ce/TiO2[J]. Chemical Industry and Engineering Progress, 2014, 33(4): 921-924(in Chinese).
[14] 张信莉,王栋,彭建升,等.煅烧温度对Mn改性γ-Fe2O3催化剂结构及低温SCR脱硝活性的影响[J]. 燃料化学学报2015, 43(2):243-250. ZHXANG X L,WANG D, PENG J S, et al. Influence of calcination temperature on structural property of Mn doped γ-Fe2O3 catalysts and low-temperature SCR activity[J]. Journal of Fuel Chemistry and Technology. 2015,43(2): 243-250(in Chinese).
[15] WAN Y P, ZHAO W R, TANG Y, et al. Ni-Mn bi-metal oxide catalysts for the low temperature SCR removal of NO with NH3[J]. Applied Catalysis B: Environmental, 2014, 148-149: 114-122. [16] 朱霖. 新型锰铁系低温NH3-SCR催化剂性能及其反应机理研究[D]. 上海:上海交通大学硕士学位论文,2012. ZHU L. Studies on the performance and mechanism of the novel catalysts loaded with manganese and iron for low temperature NH3-SCR[D].Shanghai: Shanghai Jiao Tong University, 2012(in Chinese). [17] 张先龙,解程华,郭勇,等. 蜂窝式MnOx/PG-CH催化剂的制备及低温选择性催化还原法脱硝性能研究[J].环境化学,2015,34(4):614-626. ZHANG X L, XIE C H, GUO Y, et al. Preparation and performance of honeycomb MnOx/PG-CC catalysts for low temperature NO removal by SCR[J]. Environmental Chemistry, 2015, 34(4): 614-626(in Chinese)
[18] TANG X F, LI Y G, HUANG X M, et al. MnOx-CeO2 mixed oxide catalysts for complete oxidation of formaldehyde: Effect of preparation method and calcination temperature[J]. Applied Catalysis B: Environmental, 2006,62(3-4): 265-273. [19] KAPTEIJN F, SINGOREDJO L, ANDREINI A, et al. Activity and selectivity of pure manganses oxides in the selective catalytic reduction of nitric oxides with ammonia[J].Applied Catalysis B Environmental, 1994(3): 173-189. [20] KANG M, PARK E D, KIM J M, et al. Manganses oxide catalysts for NOx reduction with NH3 at low temperatures[J]. Applied Catalysis A: General, 2007, 327(2): 261-269. [21] 时博文. 凹凸棒石负载过渡金属氧化物低温SCR脱硝催化剂的制备与表征[D]. 合肥:合肥工业大学硕士学位论文,2012. SHI B W. Preparation and characterization of palygorskite supported transition metal oxides catalyst for low-temperature selected catalytic reduction of NO by NH3[D]. Hefei:Hefei University of Technology, 2012(in Chinese). [22] ZHOU C Q, DONG G J, GONG F, et al. Preparation and characterization of monolith catalysts loaded with copper and manganese for low-temperature NH3-SCR[J]. Journal of Fuel Chemistry and Technology, 2009,37(5): 588-594. [23] 张先龙,郭勇,张恒健,等. 助剂Fe添加对柱状MnOx/PG-AC催化剂低温选择性催化还原(SCR)性能影响[J]. 环境化学,2015,34(8):1535-1544. ZHANG X L, GUO Y, ZHANG H J, et al. Iron oxides as addtive over MnOx/PG-AC catalysts for low temperature selective catalytic reduction[J].Environmental Chemistry, 2015,34(8):1535-1544(in Chinese).
[24] 博琼. Mn/TiO2系列低温SCR脱硝催化剂制备及其反应机理研究[D]. 杭州:浙江大学博士学位论文,2008. FU Q. The Preparation of Mn/TiO2 series low-temperature SCR DeNOx catalysts and reaction mechanism[D]. Hangzhou: ZheJiang University, 2008(in Chinese). [25] JERY K. WIESLAW T. NOx emission from a two-stroke ship engine[J]. Applied Thermal Engineering, 2009, 29(11): 93-106. [26] ZHANG R R, LI Y H, ZHEN T L. Ammonia selective catalytic reduction of NO over Fe/Cu-SSZ-13[J]. RSC Advances, 2014, 4: 52130-52139. [27] SHEN B X, ZHANG X P, MA H Q, et al. A comparative study of Mn/CeO2, Mn/ZrO2 and Mn/Ce-ZrO2 for low temperature selective catalytic of NO with NH3 in the presence of SO2 and H2O[J]. Journal of Environmental Sciences,2013,25(4): 791-800. [28] Kijlstra W S, Danmen J C M L, van de Graaf J M., et al. Inhibiting and deactivating effects of water on the selective catalytic reduction of nitric oxide with ammonia over MnOx/Al2O3[J].Applied Catalysis B: Environmental, 1996,7(3/4):337-357. -
