羟胺促进臭氧氧化降解阿特拉津
Ozonation of atrazine enhanced by hydroxylamine
-
摘要: 臭氧（O3）能有效氧化去除废水中的微量有机污染物，但其较高的成本限制了在我国废水处理中的应用.因此，开发新型的O3高级氧化技术以提高O3的利用率，已成为亟待解决的问题.本研究发现，羟胺（NH2OH）可大幅提高连续流O3氧化去除农药阿特拉津（ATZ）的效率.与单独臭氧氧化体系相比，当[NH2OH]0：[O3]s（摩尔浓度比）=0.25时，反应3 min时的ATZ去除率（[O3]s：[ATZ]0=10，pH 7.0）由37.9%提高至83.8%.当[NH2OH]0：[O3]s=0.25-0.75时，反应前3 min内的加速程度随NH2OH初始浓度的升高而降低，随后在0.75比例下的加速程度升高，这与[NH2OH]：[O3]s在反应过程中的持续降低及二级氧化剂生成的变化有关.二级氧化剂的生成种类和浓度主要受[NH2OH]0：[O3]s影响，有羟基自由基生成.反应3 min后，在0.25比例下二级氧化剂主要通过攻击ATZ的烷基等含碳基团加速其降解，0.75比例下二级氧化剂对含氯基团的攻击加剧.本研究将为利用NH2OH开发新型的O3高级氧化技术提供依据.Abstract: Ozone (O3) is effective for the removal of micropollutants in wastewater, while its relatively high cost limited the application for wastewater treatment in China. Therefore, there is an urgent need to develop new O3-based advanced oxidation processes (AOPs) to improve its utilization efficiency. This study found that hydroxylamine (NH2OH) could significantly enhance the degradation of atrazine (ATZ) by continuous ozonation treatment. Compared to ozonation alone, at a molar ratio of[NH2OH]0:[O3]s=0.25, the removal efficacy of ATZ at a reaction time of 3 min increased from 37.9% to 83.8% ([O3]s:[ATZ]0=10, pH 7.0). At[NH2OH]0:[O3]s=0.25-0.75, the degree of acceleration decreased with an increase in the initial NH2OH concentration within the first 3 min, and then the acceleration became stronger at[NH2OH]0:[O3]s=0.75, which arose from the continuous decrease in the[NH2OH]:[O3]s ratio during the reaction and the varied formation of secondary oxidants. The formed species and concentration of secondary oxidants were mainly affected by the[NH2OH]0:[O3]s ratio, and hydroxyl radicals were formed. After a reaction time of 3 min, the secondary oxidants mainly enhanced the degradation of ATZ through attacking its carbon-based groups (e.g., alkyl) at[NH2OH]0:[O3]s=0.25, whereas the attack of the secondary oxidants on chlorine-bearing groups of ATZ became stronger at[NH2OH]0:[O3]s=0.75. This study will provide a basis for developing new O3-based AOPs by using NH2OH.
-
Key words:
- ozone /
- atrazine /
- degradation /
- hydroxylamine /
- enhancement
-
-
[1] 叶新强, 鲁岩, 张恒. 除草剂阿特拉津的使用与危害[J]. 环境科学与管理, 2006, 31(8):95-97. YE X Q, LU Y, ZHANG H. The usage and permiciousness of the herbicide atrazine[J]. Environmental Science and Management, 2006, 31(8):95-97(in Chinese).
[2] 刘延湘, 张旭, 邓凤霞. 叶绿素光敏化降解水中阿特拉津[J]. 环境化学, 2015, 34(9):1748-1751. LIU Y X, ZHANG X, DENG F X. Chlorophyll photosensitized degradation of atrazine in water[J]. Environmental Chemistry, 2015, 34(9):1748-1751(in Chinese).
[3] REN J, JIANG K. Atrazine and its degradation products in surface and ground waters in Zhangjiakou District, China[J]. Chinese Science Bulletin, 2002, 47(19):1612-1616. [4] BETHSASS J, COLANGELO A. European Union bans atrazine, while the United States negotiates continued use[J]. International Journal of Occupational and Environmental Health, 2006, 12(3):260-267. [5] KÖCK-SCHULMEYER M, VILLAGRASA M, DE ALDA M L, et al. Occurrence and behavior of pesticides in wastewater treatment plants and their environmental impact[J]. Science of the Total Environment, 2013, 458-460:466-476. [6] HAYES T B, COLLINS A, LEE M, et al. Hermaphroditic, demasculinized frogs after exposure to the herbicide atrazine at low ecologically relevant doses[J]. Proceedings of the National Academy of Sciences of the United States of America, 2002, 99(8):5476-5480. [7] HAYES T B, KHOURY V, NARAYAN A, et al. Atrazine induces complete feminization and chemical castration in male African clawed frogs (Xenopus laevis)[J]. Proceedings of the National Academy of Sciences of the United States of America, 2010, 107(10):4612-4617. [8] JIANG H, ADAMS C. Treatability of chloro-s-triazines by conventional drinking water treatment technologies[J]. Water Research, 2006, 40(8):1657-1667. [9] 刘超, 强志民, 田芳, 等. 多类农药与紫外光、臭氧和高锰酸钾的反应活性研究[J]. 环境科学, 2009, 30(1):127-133. LIU C, QIANG Z M, TIAN F, et al. Reactivity of several classes of pesticides with UV, ozone and permanganate[J]. Environmental Science, 2009, 30(1):127-133(in Chinese).
[10] ADAMS C D, RANDTKE S J. Removal of atrazine from drinking water by ozonation[J]. American Water Works Association, 1992, 84(9):91-102. [11] WILDHABER Y S, MESTANKOVA H, SCHÄRER M, et al. Novel test procedure to evaluate the treatability of wastewater with ozone[J]. Water Research, 2015, 75:324-335. [12] Wastewater technology fact sheet-ozone disinfection[R]. United States Environmental Protection Agency, Office of Water, Washington, D.C., 1999. [13] MARCE M, DOMENJOUD B, ESPLUGAS S, et al. Ozonation treatment of urban primary and biotreated wastewaters:Impacts and modeling[J]. Chemical Engineering Journal, 2016, 283:768-777. [14] LEE M J, ZIMMERMANN-STEFFENS S G, AREY J S, et al. Development of prediction models for the reactivity of organic compounds with ozone in aqueous solution by quantum chemical calculations:The role of delocalized and localized molecular orbitals[J]. Environmental Science & Technology, 2015, 49(16):9925-9935. [15] DENISOVA T G, DENISOV E T. Reactivity of ozone as a hydrogen-atom acceptor in reactions with antioxidants[J]. Polymer Degradation and Stability, 1998, 60(2/3):345-350. [16] KHANCHANDANI S, SRIVASTAVA P K, KUMAR S, et al. Band gap engineering of ZnO using core/shell morphology with environmentally benign Ag2S sensitizer for efficient light harvesting and enhanced visible-light photocatalysis[J]. Inorganic Chemistry, 2014, 53(17), 8902-8912. [17] ZHANG J, ZHANG Y L, SHI Y N, et al. Acceleration of ozone decompostition and·OH generation by hydroxylamine[J]. Ozone:Science & Engineering, 2016, 38(2):150-155. [18] 曹杰. 臭氧/羟胺体系氧化效能研究[D]. 哈尔滨:哈尔滨工业大学, 2014. CAO J. Research on oxidation efficiency of ozone/hydroxylamine system[D]. Harbin:Harbin Institute of Technology, 2014(in Chinese). [19] MANDA S, NAKANISHI I, OHKUBO K, et al. Nitroxyl radicals:Electrochemical redox behavior and structure-activity relationships[J]. Organic & Biomolecular Chemistry, 2007, 5:3951-3955. [20] ADAMS C D, RANDTKE S J. Ozonation byproducts of atrazine in synthetic and natural waters[J]. Environmental Science & Technology, 1992, 26(11):2218-2227. [21] ACERO J L, STEMMLER K, VON GUNTEN U. Degradation kinetics of atrazine and its degradation products with ozone and OH radicals:A predictive tool for drinking water treatment[J]. Environmental Science & Technology, 2000, 34(4):591-597. -
