微藻对无机汞和甲基汞的吸附和吸收特性
Adsorption and absorption characteristics of inorganic mercury and methylmercury by microalgae
-
摘要: 本文选取蛋白核小球藻和斜生栅藻两种微藻作为研究对象，将其接种于含有低浓度无机汞（0.1—2.0 μg·L-1）和甲基汞（5.0—100 ng·L-1）的培养基中，考察两种藻的耐受性及微藻对无机汞及甲基汞的吸附和吸收特性. 结果表明，在实验浓度范围内，0.1 μg·L-1的无机汞和5.0 ng·L-1的甲基汞即可抑制蛋白核小球藻和斜生栅藻的生长，抑制作用随汞浓度的升高而增强.超过60%的无机汞和70%的甲基汞在24 h内通过吸附和吸收快速转移到了微藻，只有少量汞化合物残留于培养基中，168 h后，两种藻对无机汞和甲基汞的最高去除率分别为99.75%和99.82%.单个微藻细胞对于无机汞和甲基汞的吸附和吸收均在24 h达到最大值，随培养时间的延长，细胞增殖产生的稀释效应导致单细胞吸附量和吸收量逐渐降低.实验中观察到了无机汞和甲基汞在微藻细胞表面吸附及内部吸收的转换.Abstract: In this study,two species of microalgae,Chlorella pyrenoidosa and Scenedesmus obliquus,were inoculated in culture media containing low concentrations of inorganic mercury (Hg2+) (0.1—2.0 μg·L-1) and methylmercury (MeHg) (5.0—100 ng·L-1) to investigate the inhibition effects and adsorption/absorption characteristics of Hg2+ and MeHg. The results showed that 0.1 μg·L-1 Hg2+ and 5.0 ng·L-1 MeHg inhibited the growth of microalgae,and the inhibitory effect was enhanced with the increase of Hg concentrations. Transport of Hg2+ and MeHg from the culture media to microalgae was a relatively fast process,with more than 60% Hg2+ and 70% MeHg being transported to microalgae within 24 hours,while only a small amount of mercury compounds remained in the medium. After 168 h,the highest removal rates of Hg2+ and MeHg by micoralgae were 99.75% and 99.82%,respectively. The amounts of adsorption and absorption of both Hg species by single microalgae cells reached the maxima at the 24 h time point,and then dropped because of the growth dilution effect resulted from the cell proliferation of microalgae. Conversion of Hg between adsorption and absorption forms was indicated by the opposite trends observed in the adsorption/absorption curves.
-
Key words:
- microalgae /
- inorganic mercury /
- methylmercury /
- adsorption /
- absorption
-
-
[1] 秦捷,赵文,张鹏. 环境汞污染对藻类的毒性效应及其影响因素[J]. 生物学杂志,2011,28(3):74-76. QIN J,ZHAO W,ZHANG P,et al. The environment mercury pollution toxicity effect to the alga and their influencing factors[J]. Journal of Biology,2011,28(3): 74-76 (in Chinese).
[2] WEBER J H. Review of possible paths for abiotic methylation of mercury (Ⅱ) in the aquatic environment[J]. Chemosphere,1993,26(11): 2063-2077. [3] CAMPBELL L M,NORSTROM R J,HOBSON K A,et al. Mercury and other trace elements in a pelagic Arctic marine food web (Northwater Polynya,Baffin Bay)[J]. Science of the Total Environment,2005,351-352: 247-263. [4] TSUI M T K,WANG W. Uptake and elimination routes of inorganic mercury and methylmercury in daphnia magna[J]. Environmental Science & Technology,2004,38(3): 808-816. [5] PICKHARDT P C,FISHER N S. Accumulation of inorganic and methylmercury by freshwater phytoplankton in two contrasting water bodies[J]. Environmental Science & Technology,2007,41(1): 125-131. [6] MILES C J,MOYE H A,PHLIPS E J,et al. Partitioning of monomethylmercury between freshwater algae and water[J]. Environmental Science & Technology,2001,35(21): 4277-4282. [7] HAMMERSCHMIDT C R,FINIGUERRA M B,WELLER R L,et al. Methylmercury accumulation in plankton on the continental margin of the northwest atlantic ocean[J]. Environmental Science & Technology,2013,47(8): 3671-3677. [8] MOREL F O M M,KRAEPIEL A M L,AMYOT M. The Chemical Cycle and Bioaccumulation of Mercury[J]. Annual Review of Ecology and Systematics,1998,29: 543-566. [9] 邓贵福. 三角褐指藻对汞的富集和转化机制[D]. 厦门:厦门大学,2011. DENG G F. Bioaccumulation and transformation mechanism of mercury by Phaeodactylum tricornutum[D]. Xiamen: Xiamen University,2011 (in Chinese). [10] 林毅雄,闫海,刘秀芬,等. 滇池铜绿微囊藻对重金属的富集和氨基酸含量的变化[J]. 环境污染治理技术与设备,2003,4(3):39-41. LIN Y X,YAN H,LIU X F,et al. The accumulaiton to heavy metals and the variation of amino acids in Microcystis aeruginosa kuitz in the Dianchi lake[J]. Techniques and Equipment for Environmental Pollution Control,2003,4(3): 39-41 (in Chinese).
[11] DENG G,ZHANG T,YANG L,et al. Studies of biouptake and transformation of mercury by a typical unicellular diatom Phaeodactylum tricornutum[J]. Chinese Science Bulletin,2013,58(2): 256-265. [12] 湖北省水生生物研究所第五室藻类应用组. 利用丝状绿藻处理含汞污水的试验[J]. 水生生物学集刊,1976,6(1):67-73. Section of Applied Phycology,Fifth Laboratory,Institute of Hydrobiology,Hubei Province. Studies on the treatment of mercury-containing wastewater with filamentous green algae[J]. Acta Hydrobiologica Sinica,1976,6(1): 67-73 (in Chinese).
[13] 史媛媛. 微藻法污水处理研究与进展[J]. 青海科技,2009,16(5):58-61. SHI Y Y. Research and development of microalgae wastewater treatment[J]. Qinghai Science and Technology, 2009,16(5): 58-61 (in Chinese).
[14] 姚茹,程丽华,徐新华,等. 微藻的高油脂化技术研究进展[J]. 化学进展,2010,22(6):1221-1232. YAO R,CHENG L H,XU X H,et al. Advances on technology of microalgal high-lipid production[J]. Progress in Chemistry,2010,22(6): 1221-1232 (in Chinese).
[15] [16] DIÉGUEZ M,QUEIMALINOS C P,GUEVARA S R,et al. Influence of dissolved organic matter character on mercury incorporation by planktonic organisms: An experimental study using oligotrophic water from Patagonian lakes[J]. Journal of Environmental Sciences,2013,25(10): 1980-1991. [17] LE FAUCHEUR S,PG C,C F,et al. Interactions between mercury and phytoplankton: Speciation,bioavailability,and internal handling[J]. Environmental Toxicology and Chemistry,2014,33(6): 1211-1224. [18] 石磊. 重金属对小球藻的毒性作用及小球藻对汞的吸附研究[D]. 沈阳:东北大学,2008. SHI L. Research on the toxicity of heavy metals on Chlorella sp. and the adsorption of Hg2+ by Chlorella sp.[D]. Shenyang: Northeastern University,2008 (in Chinese). [19] 陈必链,吴松刚. 钝顶螺旋藻对7种重金属的富集作用[J]. 福建师范大学学报(自然科学版),1999,15(1 ):86-90. CHEN B L,WU S G. Accumulation of 7 heavy metals in Spirulina platensis[J]. Journal of Fujian Teachers University (Natural Science),1990,15(1):86-90 (in Chinese).
[20] 阎海鱼,冯新斌,商立海,等. 天然水体中痕量汞的形态分析方法研究[J]. 分析测试学报,2003,22(5):10-13. YAN H Y,FENG X B,SHANG L H,et al. Speciation analysis of ultra trace levels of mercury in natural waters[J]. Journal of Instrumental Analysis,2003,22(5): 10-13 (in Chinese).
[21] 杜青平,黄彩娜,贾晓珊,等. 1,2,4-三氯苯对3种海洋微藻的毒性效应[J]. 生态环境,2007,16(2):352-357. DU Q P,HUANG C N,JIA X S,et al. The toxic effects of 1,2,4-trichlorobenzene on three kinds of ocean tiny algae[J]. Ecology and Environment,2007,16(2): 352-357 (in Chinese).
[22] 杨州,孔繁翔,史小丽,等. 萼花臂尾轮虫培养滤液对铜绿微囊藻、斜生栅藻和小球藻群体形成及生长的影响[J]. 应用生态学报,2005,16(6):1138-1141. YANG Z,KONG F X,SHI X L,et al. Effects of Brachionus calyciflorus culture media filtrate on Microcystis aeruginosa,Scenedesmus obliquus and Chlorella vulgaris colony formation and growth[J]. Chinese Journal of Applied Ecology,2005,16(6): 1138-1141 (in Chinese).
[23] MA J,ZHENG R,XU L,et al. Differential sensitivity of two green algae,scenedesmus obliquus and Chlorella pyrenoidosa,to 12 pesticides[J]. Ecotoxicology and Environmental Safety,2002,52(1): 57-61. [24] 孔维宝,华绍烽,宋昊,等. 利用微藻生产生物柴油的研究进展[J]. 中国油脂,2010,35(8):51-56. KONG W B,HUA S F,SONG H,et al. Progress on biodiesel production using microalgae[J]. China Oils and Fats,2010,35(8): 51-56 (in Chinese).
[25] 杜勇,杜雨润,朱绍萍,等. 微藻在环境修复中的研究进展[J]. 环境科学与技术,2014,37(S2):316-320. DU Y,DU Y R,ZHU S P,et al. Research progress of microalgae in environmental remediation[J]. Environmental Science & Technology,2014,37(120): 316-320 (in Chinese).
[26] [27] 张玉玺,马红军. 藻类生物燃料的发展与环境保护[J]. 当代化工,2013,42(12):1711-1714. ZHANG Y X,MA H J. Algae biofuel development and environmental protection[J]. Contemporary Chemical Industry,2013,42(12): 1711-1714 (in Chinese).
[28] 牟文,熊丽,胡芹芹,等. HgCl2对斜生栅藻(Scenedesmus obliquus)生理生化特性的影响[J]. 生态毒理学报,2009,4(6):854-859. MOU W,XIONG L,HU Q Q,et al. Effects of HgCl2 on physiological and biochemical characteristics of Scenedesmus obliquus[J]. Asian Journal of Ecotoxicology,2009,4(6): 854-859 (in Chinese).
[29] GOUVEIA L,OLIVEIRA A C. Microalgae as a raw material for biofuels production[J]. Journal of Industrial Microbiology & Biotechnology,2009,36(2): 269-274. [30] 郭建东,杨宵宵,孙清荣,等. 产油微藻的筛选及油脂含量测定[J],中国油脂,2014,39(6):68-71. GUO J D,YANG X X,SUN Q R,et al. Screening of oleaginous microalgae and determination of its oil content[J]. China Oils and Fats,2014,39(6): 68-71 (in Chinese).
[31] 钟成华,周晓琴,苏翔,等. 利用市政污水培养产油微藻的研究[J]. 安全与环境学报,2014,14(6):157-160. ZHONG C H,ZHOU X Q,SU X,et al. On cultivating oil-containing microalgae by using urban sewage[J]. Journal of Safety and Environment,2014,14(6): 157-160 (in Chinese).
[32] 周群英,高廷耀. 环境工程微生物学[M]. 北京: 高等教育出版社,2000. ZHOU Q Y,GAO T Y. Environmental Engineering Microbiology[M]. Beijing: Higher Education Press,2000 (in Chinese). [33] 程柳,毛宇翔,麻冰涓,等. 汞在小浪底水库的赋存形态及其时空变化[J]. 环境科学,2015,36(1):121-129. CHENG L,MAO Y X,MA B J,et al. Speciation and spatial-temporal variation of mercury in the Xiaolangdi Reservoir[J]. Environmental Science,2015,36(1): 121-129 (in Chinese).
[34] ZHONG H,WANG W. Controls of dissolved organic matter and chloride on mercury uptake by a marine diatom[J]. Environmental Science & Technology,2009,43(23): 8998-9003. [35] 索乾善,毛宇翔,张飞鹏,等. 小浪底水库鱼体汞的污染现状[J]. 环境化学,2013,32(11):2030-2036. SUO Q S,MAO Y X,ZHANG P F,et al. Mercury contents in the muscle tissue of fish species in Xiaolangdi Reservoir[J]. Environmental Chemistry,2013,32(11): 2030-2036 (in Chinese).
[36] 蒋红梅,冯新斌,梁琏,等. 蒸馏-乙基化GC-CVAFS法测定天然水体中的甲基汞[J]. 中国环境科学,2004,24(5):568-571. JIANG H M,FENG X B,LIANG L,et al. Determination of methyl mercury in waters by distillation-GC-CVAFS technique[J]. China Environmental Science,2004,24(5): 568-571 (in Chinese).
[37] 顾昱晓,孟梅,邵俊娟,等. 在线吹扫捕集-气相色谱-原子荧光光谱法测定土壤中甲基汞[J]. 分析化学,2013,41(11):1754-1757. GU Y X,MENG M,SHAO J J,et al. Determination of methylmercury in soil samples with online purge and trap gas chromatography-atomic fluorescence spectrometry[J]. Chinese Journal of Analytical Chemistry,2013,41(11): 1754-1757 (in Chinese).
[38] 梁英,王帅. 重金属对微藻胁迫的研究现状及前景[J]. 海洋湖沼通报,2009(4):72-82. LIANG Y,WANG S. Current status and prospect of studies on microalgae stress by heavy metals[J]. Transactions of Oceanology and Limnology,2009 (4): 72-82 (in Chinese).
[39] 况琪军,夏宜琤,惠阳. 重金属对藻类的致毒效应[J]. 水生生物学报,1996,20(3):277-283. KUANG Q J,XIA Y Z,HUI Y. Toxic effects of heavy metals on algae[J]. Acta Hydrobiologica Sinica,1996,20(3): 277-283 (in Chinese).
[40] Fujita M,Hashizume K. Status of uptake of mercury by the fresh water diatom,synedra ulna[J]. Water Research,1974,9: 889-894. [41] 潘进芬,林荣根. 海洋微藻吸附重金属的机理研究[J]. 海洋科学,2000,24(2):31-34. PAN J F,LIN R G. Studies on heavy metal adsorption by marine algae[J]. Marine Sciences,2000,24(2): 31-34 (in Chinese).
[42] 刘瑞霞,汤鸿霄,劳伟雄. 重金属的生物吸附机理及吸附平衡模式研究[J]. 化学进展,2002,14(2):87-92. LIU R X,TANG H X,LAO W X. Advances in biosorption mechanism and equilibrium modeling for heavy metals on biomaterials[J]. Progress in Chemistry,2002,14(2): 87-92 (in Chinese).
[43] 王沛芳,王文娜,王蓉,等. 汞对水生生物的毒性效应研究进展[J]. 安全与环境学报,2014,14(2):282-288. WANG P F,WANG W N,WANG R,et al. Research progress of the toxic effect of mercury on aquatic organisms[J]. Journal of Safety and Environment,2014,14(2): 282-288 (in Chinese).
-
