长三角地区土壤中有机氯农药残留量及其分布特征
Residues and distribution of organochlorine pesticides in soils in Yangtze River Delta region
-
摘要: 为了解长三角地区的有机氯农药的残留状况及空间分布特征，本研究选取南京、上海、吴江以及启东作为试验区域，采用加速溶剂萃取技术（ASE）和EPA 8081a-有机氯气相色谱法对该区域34个采样点的土壤样品进行检测.结果表明，该区域普遍检测出有机氯农药的残留，且表层土壤为主要残留层，随着深度增加，有机氯农药的残留量逐渐减少.表层土壤中，∑OCPs残留量介于ND-157.66 μg·kg-1之间.其中DDTs的检出率为91%，残留范围为ND-119.85 μg·kg-1，均值为7.6 μg·kg-1，占∑OCPs的81%.HCHs和六氯苯的检出率分别为60%、44%，残留范围分别为ND-15.79 μg·kg-1、ND-22.02 μg·kg-1.有机氯农药类别中主要的残留物为p，p'-DDE，占OCPs残留总量的45%以上，（DDD+DDE）/DDTs>0.5的样点约占样点数的88%.受试点均未检测到七氯、艾氏剂、环氧七氯、氯丹、狄氏剂、异狄氏剂等组分.对于农业区不同利用类型区域，表层土壤中∑OCPs残留均值为：农业区树林、水果林（5.37 μg·kg-1） >农业区菜地（3.93 μg·kg-1） >农业区农田（2.98 μg·kg-1） >农业区稻田（2.48 μg·kg-1）.对于不同功能区表层土壤中∑OCPs残留均值为：江滩沉积物（37.92 μg·kg-1） >农业区（7.99 μg·kg-1） >工业区（5.03 μg·kg-1）.本次调查对该地区的污染水平做出初步评价，所得数据可为该地区的生态环境建设及生态风险评价提供理论依据.Abstract: In order to investigate the residues and distribution of organochlorine pesticides in the soils in Yangtze River Delta region, soil samples were collected from 34 sampling sites in the test area (Nanjing, Shanghai, Wujiang and Qidong). The samples were treated by Accelerated Solvent Extraction and then analyzed by gas chromatography. The results showed that the residues of organochlorine pesticides were all detected in the test area, and the topsoil was the major residual layer. The residues of organochlorine pesticides gradually decreased with the increase of the soil depth. In topsoil, the residual quantity of total OCPs lied between N.D. and 157.66 μg·kg-1. And in these OCPs, the detection rate of DDTs, HCHs and HCB was 91%, 60% and 44% respectively, and the residual concentration ranged from N.D. to 119.85 μg·kg-1, N.D. to 15.79 μg·kg-1 and N.D. to 22.02 μg·kg-1 respectively. The mean residual concentration of DDTs was 7.6 μg·kg-1, which accounted for 81% of the total OCPs residues. The proportion of p,p'-DDE in total OCPs was more than 45%, and the sampling sites with the value (DDD+DDE)/DDTs > 0.5 accounted for 88% of all the sampling sites, which indicated p,p'-DDE was the main residues in the soils investigated in the test area. However, heptachlor, aldrin, heptachlor epoxide, chlordane, dieldrin and endrin were not detected. In addition, the mean residual quality of total OCPs in top soil in different types of agricultural regions followed the pattern of woodland and fruit land (5.37 μg·kg-1) > vegetable land (3.93 μg·kg-1) > farmland (2.98 μg·kg-1) > rice field(2.48 μg·kg-1), while the mean residual concentration of total OCPs in top soil in different function areas followed the pattern of riverbank sediment (37.92 μg·kg-1) > agricultural area (7.99 μg·kg-1) > industrial district(5.03 μg·kg-1). This survey could provide a preliminary assessment of the organochlorine pesticides pollutions in Yangtze River Delta region, and the results can lay a theoretical basis for the ecological environment construction and ecological risk assessment of this region.
-
-
[1] 刘继凤.持久性有机污染物的危害及防治对策[J]. 环境科学与管理,2007,32(1):65-67. LIU J F. The harm and the countermeasure for prevention of POPs[J]. Environmental Science and Management,2007,32(1):65-67(in Chinese).
[2] 张燕平,邱树毅. 持久性有机污染物(POPs)及其生态毒性[J]. 广东化工,2009,36(10):119-120 ,118. ZHANGYP,QIU S Y, Persistent organic pollutants (POPs) and the eco-toxicity[J].Guangdong Chemical Industry, 2009,36(10):119-120,118(in Chinese).
[3] [4] 王春辉,吴绍华,周生路,等. 典型土壤持久性有机污染物空间分布特征及环境行为研究进展[J]. 环境化学,2014,33(11):1828-1840. WANG C H,WU S H,ZHOU S L, et al. A review on spatial distribution and environmental behaviorof typical persistent organic pollutants in soil[J]. Environmental Chemistry,2014,33(11):1828-1840(in Chinese).
[5] HARNER T, WIDEMAN J.L, JANTUNEN L.M.M, et al, Residues of organochlorine pesticides in Alabama soils[J]. Environmental Pollution, 1999,106(3):323-332. [6] 胡春华,周文斌,易纯,等. 环鄱阳湖区蔬菜地土壤中有机氯农药分布特征及生态风险评价[J]. 农业环境科学学报,2011,30(3):487-491. HU C H,ZHOU W B,YI C, et al. Distribution and eco-risk evaluation of organochlorine pesticides in vegetable soil in the area around Poyang lake, China[J].Journal of Agro-Environment Science,2011,30(3):487-491(in Chinese).
[7] CORONA-CRUZ A, GOLD-BOUCHOT G, GUTIERREZ-ROJAS M, et al. Anaerobic-aerobic biodegradation of DDT (dichlorodiphenyl trichloroethane)in soils[J].Bull Environ Contam Toxicol, 1999, 63:219-225. [8] FEIDIEKER D, KAMPFER P, DOTT W. Field-scale investigations on the biodegradation of chlorinated aromatic compounds and HCH in the subsurface environment[J]. J Contam Hydrol, 1995, 19(2):145-169. [9] 张元标,林辉.厦门海域表层沉积物中DDTs、HCHs和PCBs的含量及其分布[J].台湾海峡,2004,23(4):423-427. ZHANG Y B,LIN H. Concentrations and distributions of DDTs, HCHs and PCBs in surface sediments of Xiamen sea areas[J].Journal of Oceanography in Taiwan Strait,2004,23(4):423-427(in Chinese).
[10] 安琼,董元华,王辉,等.南京地区土壤中有机氯农药残留及其分布特征[J]. 环境科学学报,2005,25(4):470-474. AN Q,DONG Y H,WANG H,et al. Residues and distribution character of organochlorine pesticides in soils in Nanjing area[J].Acta Scientiae Circumstantiae,2005,25(4):470-474(in Chinese).
[11] 安琼,董元华,王辉,等. 苏南农田土壤有机氯农药残留规律[J]. 土壤学报,2004,41(3):414-419. AN Q,DONG Y H,WANG H, et al. Organochlorine pesticides residues in cultivated soils, in the south of Jiangsu,China[J].Acta Pedologica Sinica,2004,41(3):414-419(in Chinese).
[12] LU M, ZENG DC, LIAO Y, et al, Distribution and characterization of organochlorine pesticides and polycyclic aromatic hydrocarbons in surface sediment from Poyang Lake China[J]. Science of the Total Environment, 2012, 433:491-497. [13] 陈敏,陈莉,黄平.乌鲁木齐地区土壤中有机氯农药残留特征及来源分析[J].中国环境科学,2014,34(7):1838-1846. CHEN M,CHEN L,HUANG P. Residues and possible sources of organochlorine pesticides in surface soil of Urumqi[J]. China Environmental Science,2014,34(7):1838-1846(in Chinese).
[14] WANG T Y, LU Y L, ZHANG H, et al, Contamination of persistent organic pollutants (POPs) and relevant management in China[J]Environment International, 2005,31(6):813-821. [15] MANZ M, WENZE K D, DIETZE U, et al. Persistent organic pollutants in agricultural soils of central Germany[J].The Science of the Total Environment,2001,277(1-3):187-198. [16] MIGLIORANZA K S B, AIZPU N DE MORENO J E, MORENO V J, et al. Fate of organochlorine pesticides in soils and terrestrial biota of"Los Padres" pond watershed, Argentina[J].Environmental Pollution,1999,105(1):91-99. [17] FALANDYSZ J, BRUDNOWSKA B, KAWANO M, et al. Polychlorinated biphenyls and organochlorine pesticides in soils from the southern part of poland[J].Arch Environ Contam Toxicol, 2001, 40:173-178. [18] 方杰.浙江沿海沉积物和海洋生物中持久性有机污染物及重金属的分析与研究[D].杭州:浙江大学,2007. FANG J. Persistent organic pollutants and heavy metals in surface sediments and marine organisms from coastal area of Zhejiang Province[D].Hangzhou:Zhejiang University,2007(in Chinese). [19] 杨华云.长江三角洲毗邻海域有机氯农药和多氯联苯的研究[D]杭州:浙江工业大学,2011. YANG H Y. Study on organochlorine pesticides and polychlorinated biphenyls in Yangtze River delta and adjacent sea[D].Hangzhou:Zhejiang University of Technology,2011(in Chinese). [20] 张颖,摆亚军,徐福留,等. 河北水库及湖泊沉积物中DDT农药的残留特征与风险评估[J]. 环境科学学报,2006,26(4):626-631. ZHANG Y,BAI Y J,XU F L, et al. DDTs residues in sediments from Hebei lakes and reservoirs and their risk evaluation[J].Acta Scientiae Circumstantiae,2006,26(4):626-631(in Chinese).
[21] 赵炳梓,张佳宝,周凌云,等.黄淮海地区典型农业土壤中六六六(HCH)和滴滴涕(DDT)的残留量研究Ⅰ.表层残留量及其异构体组成[J]. 土壤学报,2005, 42(5):761-768. ZHAO B Z,ZHANG J B,ZHOU L Y, et al. Residues of HCH and DDT in typical agricultural soils of HUANG-HUAI-HAI PLAIN, China. Ⅰ.Residues in surface soils and their isomeric composition[J].Acta Pedologica Sinica,2005,42(5):761-768(in Chinese).
[22] 张红艳,高如泰,江树人,等.北京市农田土壤中有机氯农药残留的空间分析[J].中国农业科学,2006,39(7):1403-1410. ZHANG H Y,GAO R T,JIANG S R, et al. Spatial variability of organochlorine pesticides (DDTs and HCHs) in surface soils of farmland in Beijing, China[J].Scientia Agricultura Sinica,2006,39(7):1403-1410(in Chinese).
[23] BARRON M G, ASHUROVA Z J, KUKANIEV M A, et al. Residues of organochlorine pesticides in surface soil and raw foods from rural areas of the Republic of Tajikistan[J]. Environmental Pollution, 2017, 224:494-502. -
