电絮凝处理煤层气产出水

,  ,  ,

downloadPDF

上一篇

下一篇

李向东, 冯启言, 宋均轲, 蔡娟. 电絮凝处理煤层气产出水[J]. 环境工程学报, 2012, 6(3): 744-748.
引用本文: 李向东, 冯启言, 宋均轲, 蔡娟. 电絮凝处理煤层气产出水[J]. 环境工程学报, 2012, 6(3): 744-748.
shu
Li Xiangdong, Feng Qiyan, Song Junke, Cai Juan. Treatment of water produced with coal-bed methane by electrocoagulation[J]. Chinese Journal of Environmental Engineering, 2012, 6(3): 744-748.
Citation: Li Xiangdong, Feng Qiyan, Song Junke, Cai Juan. Treatment of water produced with coal-bed methane by electrocoagulation[J]. Chinese Journal of Environmental Engineering, 2012, 6(3): 744-748.
shu

电絮凝处理煤层气产出水

  • 1.

    江苏省资源环境信息工程重点实验室， 徐州 221116； 2.中国矿业大学环境与测绘学院，徐州 221116

  • 基金项目:

    国家“大型油气田及煤层气开发”科技重大专项（2008ZX05039-003）

  • 中图分类号: X703

Treatment of water produced with coal-bed methane by electrocoagulation

  • 1.

    Jiangsu Key Laboratory of Resources and Environmental Information Engineering， Xuzhou 221116， China； 2. School of Environment Science and Spatial Informatics， China University of Mining and Technology， Xuzhou 221116， China

  • Fund Project:

  • 摘要: 采用电絮凝法处理煤层气产出水，通过铁和铝2种电极材料的处理效果的比较，选择铝电极进行实验，研究了电极间距、原水pH值以及电流密度等因素对电絮凝处理效果的影响。实验结果表明，电絮凝法对煤层气产出水的化学需氧量（COD）和固体悬浮物（SS）具有良好的去除效果，原水pH接近中性时处理效果较好，电絮凝处理过程中不需添加可溶性盐和改变pH值。实验中确定的电絮凝处理条件为:电极间距1 cm，电流密度30 A/m2，反应10 min后，出水的COD、SS分别为9.6 mg/L和8.5 mg/L，去除率分别达到75.1%和88.8%，出水pH为7.8，电能消耗为1.75 kWh/m3。
    Abstract: Electrocoagulation was applied to water produced with coal-bed methane treatment. Comparing aluminum and iron electrodes， the former one was selected in the electrocoagulation experiments. The effect of the operational parameters such as inter-electrode， the pH value and current density was investigated. The results showed that the electrocoagulation was an effective water treatment technique for water produced with coal-bed methane. The optimum working pH was found to be in the neutral condition， allowing water produced with coal-bed methane to be treated directly without adding soluble salts to the water and changing the pH of the solution. The appropriate experimental conditions for water produced with coal-bed methane treatment by electrocoagulation are quantified. Electrode distance is 1 cm. The current intensity is 30 A/m2. The COD and SS reach 9.6 mg/L and 8.5 mg/L after 10 min reaction， of which the removal efficiencies are about 75.1% and 88.8%， respectively. The pH value of effluent is 7.8. The power requirement is 1.75 kWh/m3. Experimental investigations show that the electrocoagulation is an effective water treatment technique for water produced with coal-bed methane.
  • 加载中
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2281
  • HTML全文浏览数:  1477
  • PDF下载数:  1815
  • 施引文献:  0
出版历程
  • 收稿日期:  2011-01-31
李向东, 冯启言, 宋均轲, 蔡娟. 电絮凝处理煤层气产出水[J]. 环境工程学报, 2012, 6(3): 744-748.
引用本文: 李向东, 冯启言, 宋均轲, 蔡娟. 电絮凝处理煤层气产出水[J]. 环境工程学报, 2012, 6(3): 744-748.
shu
Li Xiangdong, Feng Qiyan, Song Junke, Cai Juan. Treatment of water produced with coal-bed methane by electrocoagulation[J]. Chinese Journal of Environmental Engineering, 2012, 6(3): 744-748.
Citation: Li Xiangdong, Feng Qiyan, Song Junke, Cai Juan. Treatment of water produced with coal-bed methane by electrocoagulation[J]. Chinese Journal of Environmental Engineering, 2012, 6(3): 744-748.
shu

电絮凝处理煤层气产出水

  • 1. 江苏省资源环境信息工程重点实验室， 徐州 221116； 2.中国矿业大学环境与测绘学院，徐州 221116
  • 收稿日期:  2011-01-31
基金项目:

国家“大型油气田及煤层气开发”科技重大专项（2008ZX05039-003）

摘要: 采用电絮凝法处理煤层气产出水，通过铁和铝2种电极材料的处理效果的比较，选择铝电极进行实验，研究了电极间距、原水pH值以及电流密度等因素对电絮凝处理效果的影响。实验结果表明，电絮凝法对煤层气产出水的化学需氧量（COD）和固体悬浮物（SS）具有良好的去除效果，原水pH接近中性时处理效果较好，电絮凝处理过程中不需添加可溶性盐和改变pH值。实验中确定的电絮凝处理条件为:电极间距1 cm，电流密度30 A/m2，反应10 min后，出水的COD、SS分别为9.6 mg/L和8.5 mg/L，去除率分别达到75.1%和88.8%，出水pH为7.8，电能消耗为1.75 kWh/m3。
