多孔陶瓷滤料的亲油改性及其除油性能

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

马淞江, 吴年芬, 李方文, 杨娟, 付美玲, 贾海武. 多孔陶瓷滤料的亲油改性及其除油性能[J]. 环境工程学报, 2012, 6(10): 3470-3474.
引用本文: 马淞江, 吴年芬, 李方文, 杨娟, 付美玲, 贾海武. 多孔陶瓷滤料的亲油改性及其除油性能[J]. 环境工程学报, 2012, 6(10): 3470-3474.
shu
Ma Songjiang, Wu Nianfen, Li Fangwen, Yang Juan, Fu Meiling, Jia Haiwu. Lipophilic modification of porous ceramic filter media and its oil removal performance[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3470-3474.
Citation: Ma Songjiang, Wu Nianfen, Li Fangwen, Yang Juan, Fu Meiling, Jia Haiwu. Lipophilic modification of porous ceramic filter media and its oil removal performance[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3470-3474.
shu

多孔陶瓷滤料的亲油改性及其除油性能

  • 1.

    湖南科技大学化学化工学院, 湘潭 411201

  • 基金项目:

    国家自然科学基金资助项目(50978098)

  • 中图分类号: X703

Lipophilic modification of porous ceramic filter media and its oil removal performance

  • Fund Project:

  • 摘要: 研究了铝酸酯偶联剂对多孔陶瓷滤料的亲油改性及改性滤料的除油性能。用正交实验优化改性工艺,并对改性前后滤料用FTIR、SEM、密度、孔隙率及接触角等手段进行表征。结果表明:最佳改性工艺参数为铝酸酯偶联剂5%(改性液质量分数)、改性温度90℃、改性时间20 min和涂层次数1次。改性滤料FTIR图在2 920.95 cm-1和2 851.63 cm-1处出现了CH3、CH2等特征吸收峰,其密度和孔隙率减小,而对水的接触角明显增大,表明多孔陶瓷滤料亲油改性成功。用改性滤料处理模拟油田采出水,控制滤速15 m/h,20 min后采样测出水中油的浓度,其去油率由预处理65.18%增加到96.46%;穿透曲线的研究表明,原始、预处理及改性滤料运行时间分别为48、85和149 min,可见改性滤料的运行时间更长,其较原始与预处理滤料分别延长了101 min和64 min,且其去油率能持续45 min维持在90%以上。可见经亲油改性的多孔陶瓷滤料是一种良好的聚结除油材料。
    Abstract: The orthogonal experiment was used to optimize the modification process.Before and after modification,filter media were characterized by FTIR,SEM,density,porosity and contact angle.The results showed that the best modification parameters included aluminate coupling agent (5%),temperature (90℃),modification time (20 min) and coating times (one).Proofs of porous ceramic filter media successfully modified included the characteristic adsorption peaks of CH3 and CH2 in FTIR from modified filter media,reduction of the density and porosity and increase of the contact angle to water.At a speed of 15 m/h and after 20 min,and oil removal rate of modified filter increased from 96.46% to 65.18% compared with pretreatment filter.The breakthrough curves showed that the working times of original,pretreatment and modified filter media were 48,85 and 149 min,respectively,which implied that operation cycle of modified filter was 101 min and 64 min longer than those of original and pretreatment filter.The oil removal rate of 90% lasted for 45 min,which means that the modified filter is a good coalescence degreasing material.
  • 加载中
  • [1] Mehmet Cakmakce,Necati Kayaalp,Ismail Koyuncu.Desalination of produced water from oil production fields by membrane processes.Desalination,2008,222(1-3):176-186
    [2] Ibrahim Shariff,Wang Shaobin,Ang Ha Ming.Removal of emulsified oil from oily wastewater using agricultural waste barley straw.Biochemical Engineering Journal,2010,49(1):78-83
    [3] Dick R.M.Ultrafiltration for oily wastewater treatment.Lubrication Engineering,1982,38(4):219-222
    [4] Hanafy M.,Nabin H.J.Treatment of oily wastewater using dissolved air flotation technique.Energy Sources Part A:Recovery,Utilization and Environmental Effects,2007,29(2):143-159
    [5] Angel Cambiella,Enrique Ortea,Guillermo Rios,et al.Treatment of oil-in-water emulsions:Performance of a sawdust bed filter.Journal of Hazardous Materials,2006,131(1-3):195-199
    [6] Zhou Yanbo,Tang Xuanyi,Hu Xiaomeng.,et al.Emulsified oily wastewater treatment using a hybrid-modified resin and activated carbon system.Separation and Purification Technology,2006,63(2):400-406
    [7] 孙恩呈,商平,梁岩.用海泡石处理采油废水.化工环保,2008,28(1):59-62 Sun Encheng,Shang Ping,Liang Yan.Treatment of oil extraction wastewater using meerschaum.Environmental Protection of Chemical Industry,2008,28(1):59-62(in Chinese)
    [8] 郑敏,金晓英,王清萍,等.改性高岭土处理含油废水的实验研究.非金属矿,2009,32(5):59-61 Zheng Min,Jin Xiaoying,Wang Qingping,et al.Experimental study on treatment of oily wastewater by modified kaolin.Non-Metallic Mines,2009,32(5):59-61(in Chinese)
    [9] Angel Cambiella,Enrique Ortea,Guillermo Rios,et al.Treatment of oil-in-water emulsions:Performance of a sawdust bed filter.Journal of Hazardous Materials,2006,131(1-3):195-199
    [10] Deepa Mysore,Thiruvenkatachari Viraraghavan,Yee-Chung Jin.Treatment of oily waters using vermiculite.Water Research,2005,9(12):2643-2653
    [11] 陈雷,祁佩时,王鹤立.聚结除油性能及机理的探讨.中国环境科学,2002,22(1):16-19 Chen Lei,Qi Peishi,Wang Heli.Research on oil removal performance and mechanism of coalescence.China Environmental Science,2002,22(1):16-19(in Chinese)
    [12] 王艺,陈雷.聚结除油反应机理及其动力学分析.环境污染治理技术与设备,2006,7(1):59-63 Wang Yi,Chen Lei.Analysis of coalescence mechanism and coalescence reaction dynamics.Techniques and Equipment for Environmental Pollution Control,2006,7(1):59-63
    [13] Thirunavukkarasu O.S.,Viraraghavan T.,Subramanian K.S.Arsenic removal from drinking water using iron oxide-coated sand.Water,Air,and Soil Pollution,2003,142(1-4):95-111
    [14] Truesdail S.E.,Lukasik J.,Farrah S.R.,et al.Analysis of Bacterial deposition on metal (hydr)oxide-coated sand filter media.Journal of Colloid and Interface Science,1998,203(2):369-378
    [15] Lai C.H.,Lo S.L.,Chiang H.L.Adsorption/desorption properties of copper ions on the surface of iron-coated sand using BET and EDAX analyses.Chemosphere,2000,41(8):1249-1255
    [16] 王全喜,李双妹.偶联剂在非金属矿粉体改性 中的适用性.广东化工,2006,33(6):96-103 Wang Quanxi,Li Shuangmei.Application of coupling agent in nonmetal minerals powders modification.Guangdong Chemical Industry,2006,33(6):96-103(in Chinese)
    [17] 刘立华,刘会媛,刘冬莲.铝酸酯偶联剂改性纳米碳酸钙效果研究.化工矿物与加工,2005,34(3):4-6 Liu Lihua,Liu Huiyuan,Liu Donglian.Research on surface modification of nano-sized CaCO3 by aluminate coupling agent.Industrial Minerals & Processing,2005,34(3):4-6(in Chinese)
    [18] 莫伟,马少健,韩跃新,等.膨润土的铝酸脂表面改性研究.金属矿山,2008,(2):78-82 Mo Wei,Ma Shaojian,Han Yuexin,et al.Study on surface modification of bentonite by aluminate ester.Metal Mine,2008,(2):78-82(in Chinese)
    [19] 陈义春.陶瓷滤料表面改性及其预处理微污染水的试验研究.武汉:武汉理工大学硕士学位论文,2008 Chen Yichun.Surface modification of ceramics filters and experiment research in the pretreatment of light polluted water.Wuhan:Master's Degree Thesis of Wuhan University of Technology,2008(in Chinese)
    [20] 曾欣.滤料表面性质的研究—润湿接触角的测定.西北民族大学学报(自然科学版),2006,27(3):25-27 Zeng Xin.Measurement of filter agents' wetting contact angle by means of capillary rise.Journal of Northwest University for Nationalities (Natural Science),2006,27(3):25-27(in Chinese)
