活性炭柱中砂垫层在微污染水源水处理工艺中的应用

,

downloadPDF

上一篇

下一篇

刘阳, 张燕. 活性炭柱中砂垫层在微污染水源水处理工艺中的应用[J]. 环境工程学报, 2012, 6(11): 3822-3826.
引用本文: 刘阳, 张燕. 活性炭柱中砂垫层在微污染水源水处理工艺中的应用[J]. 环境工程学报, 2012, 6(11): 3822-3826.
shu
Liu Yang, Zhang Yan. Application of sand layer in activate-carbon filter for micro-polluted source water treatment processes[J]. Chinese Journal of Environmental Engineering, 2012, 6(11): 3822-3826.
Citation: Liu Yang, Zhang Yan. Application of sand layer in activate-carbon filter for micro-polluted source water treatment processes[J]. Chinese Journal of Environmental Engineering, 2012, 6(11): 3822-3826.
shu

活性炭柱中砂垫层在微污染水源水处理工艺中的应用

  • 1.

    浙江大学土木工程学系,杭州 310058

  • 基金项目:

    国家"水体污染控制与治理"科技重大专项(2008ZX07421-003)

  • 中图分类号: X524

Application of sand layer in activate-carbon filter for micro-polluted source water treatment processes

  • 1.

    Department of Civil Engineering, Zhejiang University, Hangzhou 310058, China

  • Fund Project:

  • 摘要: 以嘉兴市某水厂沉后水为进水进行实验,研究炭砂滤池对污染物的去除性能,以及炭砂滤池取代活性炭+砂滤池的可能性,探讨了短流程工艺的适用性。结果表明,炭砂滤池能有效去除水中的浊度、氨氮、CODMn和铁、锰等污染物,与活性炭柱相比,炭砂滤池在降低出水浊度和水中颗粒数方面具有一定优势,即砂垫层对控制出水浊度和保障微生物安全能够起到积极作用。在实验条件下,增加活性炭层厚度或者降低滤速,在一定程度上有利于提高对CODMn的去除率。在设计滤速为9~10 m/h,CODMnMn<3 mg/L。
    Abstract: The experiments were carried out with the settled water of a Jiaxing water work as influent. The pollutants removal efficiency of sand/carbon filter, the possibility of using sand/carbon filter to replace activated carbon filter plus sand filter and the applicability of this short process technology were discussed. The results show that sand/carbon filter can remove turbidity, NH4+-N, CODMn ,Fe and Mn, effectively. Compared with single active carbon filter, sand/carbon filter has advantages on reducing effluent turbidity and lessening effluent particle counts. It shows that the sand layer plays a positive role on the controlling the turbidity and guaranteeing microbial safety. Under the experimental conditions, to increase thickness of carbon layer or reduce filtration velocity to some extent can improve the removal efficiency of CODMn. When filtration velocity is 9~10 m/h and sand/carbon influent CODMnMn<3 mg/L.
  • 加载中
  • [1] 潘碌亭.中国微污染水源水处理技术研究现状与进展.工业水处理,2006,26(6):6-10 Pan Luting.Progress of treatment technology of water from micro-polluted water sources in China.Industrial Water Treatment, 2006,26(6):6-10(in Chinese)
    [2] 吴舜泽,夏青,刘鸿亮.中国流域水污染分析.环境科学与技术,2000,23(2):1-6
    [3] 崔玉川,傅涛.我国城市给水发展现状与特点.中国给水排水,1999,15(2):53-54
    [4] 王占生,刘文君.微污染水源饮用水处理.北京:中国工业出版社,1999
    [5] 张燕,王志奇,陈英旭.微污染水源水的控制技术.环境污染与防治,2001,23(2):69-71 Zhang Yan,Chen Yingxu.Treatment method of micro-polluted water resource.Environmental Pollution & Control,2001,23(2):69-71(in Chinese)
    [6] 商静宇.生物活性炭技术在水处理中的应用研究.能源与环境,2009,(5):50-52
    [7] 沈渊玮,陆善忠.活性炭在水处理中的应用.工业水处理,2007,27(4):13-16 Shen Yuanwei,Lu Shanzhong.Application of active carbon to water treatment.Industrial Water Treatment, 2007,27(4):13-16(in Chinese)
    [8] 陈艺韵,陆少鸣.GAC-石英砂滤池处理高氨氮原水的生产研究.环境科学与技术,2010,33(6):45-48 Chen Yiyun, Lu Shaoming.GAC/Quartz-sand duel media filter for treating raw water with high NH3-N concentration.Environmental Science & Technology,2010,33(6):45-48(in Chinese)
    [9] 朱昊,张林生.微污染水生物活性炭处理技术应用及展望.农业环境科学学报,2006,25(增刊):382-384
    [10] 许嘉炯,雷挺,沈裘昌,等.嘉兴南郊水厂微污染河网水集成净水处理工艺选择与设计.城镇给排水,2008,9(34):9-14
    [11] 王广智,李伟光,王锐,等.炭砂滤池在松花江污染应急处理中的应用特性.给水排水,2007,33(8):11-15 Wang Guangzhi,Li Weiguang,Wang Rui,et al.Study on emergent application of combined activated carbon and sand filter in the Songhua River pollution accident.Water & Wastewater Engineering, 2007,33(8):11-15(in Chinese)
    [12] Scholz M., Martin R.J. Ecological equilibrium on biological activated carbon. Water Sci.Technol.,1997,31(12):2959-2968
    [13] 段蕾.臭氧-炭砂滤池对滦河水深度处理中试研究.哈尔滨:哈尔滨工业大学博士学位论文,2007 Duan Lei.Study on the pilot-scale ozone-sand/carbon filter for advanced treatment of water in Luanhe river.Harbin:Doctor Dissertation of Harbin Institute of Technology, 2007(in Chinese)
    [14] 李伟光,王广智,何文杰,等.IBAC技术中石英砂垫层的工艺条件研究.哈尔滨工业大学学报,2007,39(8):1236-1240 Li Weiguang,Wang Guangzhi,He Wenjie,et al.Study on technologic condition of sand in immobilized biological active carbon purification technology.Journal of Harbin institute of Technology,2007,39(8):1236-1240(in Chinese)
    [15] Lechevallier M. W., William D. N. Examining relationships between particle counts and giardia. Cryptosporidium and Turbidity.J.AWWA,1992,84(12):54-60
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2224
  • HTML全文浏览数:  996
  • PDF下载数:  2519
  • 施引文献:  0
出版历程
  • 收稿日期:  2011-09-27
  • 刊出日期:  2012-11-09
刘阳, 张燕. 活性炭柱中砂垫层在微污染水源水处理工艺中的应用[J]. 环境工程学报, 2012, 6(11): 3822-3826.
引用本文: 刘阳, 张燕. 活性炭柱中砂垫层在微污染水源水处理工艺中的应用[J]. 环境工程学报, 2012, 6(11): 3822-3826.
shu
Liu Yang, Zhang Yan. Application of sand layer in activate-carbon filter for micro-polluted source water treatment processes[J]. Chinese Journal of Environmental Engineering, 2012, 6(11): 3822-3826.
Citation: Liu Yang, Zhang Yan. Application of sand layer in activate-carbon filter for micro-polluted source water treatment processes[J]. Chinese Journal of Environmental Engineering, 2012, 6(11): 3822-3826.
shu

活性炭柱中砂垫层在微污染水源水处理工艺中的应用

  • 1. 浙江大学土木工程学系,杭州 310058
  • 收稿日期:  2011-09-27
基金项目:

国家"水体污染控制与治理"科技重大专项(2008ZX07421-003)

摘要: 以嘉兴市某水厂沉后水为进水进行实验,研究炭砂滤池对污染物的去除性能,以及炭砂滤池取代活性炭+砂滤池的可能性,探讨了短流程工艺的适用性。结果表明,炭砂滤池能有效去除水中的浊度、氨氮、CODMn和铁、锰等污染物,与活性炭柱相比,炭砂滤池在降低出水浊度和水中颗粒数方面具有一定优势,即砂垫层对控制出水浊度和保障微生物安全能够起到积极作用。在实验条件下,增加活性炭层厚度或者降低滤速,在一定程度上有利于提高对CODMn的去除率。在设计滤速为9~10 m/h,CODMnMn<3 mg/L。
