热镀锌厂酸洗废水及锌灰中锌回收

,  ,

downloadPDF

上一篇

下一篇

许玉东, 孙燕如, 郑雪琴. 热镀锌厂酸洗废水及锌灰中锌回收[J]. 环境工程学报, 2012, 6(12): 4487-4492.
引用本文: 许玉东, 孙燕如, 郑雪琴. 热镀锌厂酸洗废水及锌灰中锌回收[J]. 环境工程学报, 2012, 6(12): 4487-4492.
shu
Xu Yudong, Sun Yanru, Zheng Xueqin. Recovery of zinc from wastewater and zinc ash of zinc hot galvanizing plants[J]. Chinese Journal of Environmental Engineering, 2012, 6(12): 4487-4492.
Citation: Xu Yudong, Sun Yanru, Zheng Xueqin. Recovery of zinc from wastewater and zinc ash of zinc hot galvanizing plants[J]. Chinese Journal of Environmental Engineering, 2012, 6(12): 4487-4492.
shu

热镀锌厂酸洗废水及锌灰中锌回收

  • 1.

    福州大学环境与资源学院,福州 350108

  • 2.

    福建船政交通职业学院,福州 350007

  • 基金项目:

    福建省基本科研专项项目(2009R10023-4)

  • 中图分类号: X781.1

Recovery of zinc from wastewater and zinc ash of zinc hot galvanizing plants

  • 1.

    College of Environment and Resources, Fuzhou University, Fuzhou 350108, China

  • 2.

    Fujian Chuanzheng and Communications Technology College, Fuzhou 350007, China

  • Fund Project:

  • 摘要: 分别采用蒸酸法、氨络合法和硫化沉淀法分离回收热镀锌厂酸洗废水及锌灰中锌铁。分别考察了酸洗废水中盐酸的逸出特性和氨浸法回收蒸馏渣中锌的效果;利用酸洗废水的酸度浸取锌灰中的锌并用氨络合法分离酸浸出液中锌铁;利用硫化物不同溶度积选择性沉淀酸浸出液中的锌,考察了Na2S加入量、曝气时间、反应溶液pH和反应时间的影响。研究结果表明硫酸的加入能提高盐酸的蒸发率但效果不明显,氨络合法难于有效分离锌铁,但硫化物沉淀法可较好地分离锌铁,铁回收率可达97.12%,锌沉淀率达到99.99%,所得沉淀物中ZnS纯度为68.51%。
    Abstract: Steamed acid process, ammonia complexation process and sulphide precipitation process were conducted to investigate separation and recovery of zinc and iron from wastewater and zinc ash of zinc hot galvanizing plants. Different HCl evaporation characterization, zinc extracting effect with ammonia leaching process, and using the acidity of wastewater to leach out zinc ash and then separating zinc and iron from acid leaching solution by ammonia complexation were performed, respectively. Selective precipitation of zinc with Na2S from acid leaching solution based on product solubility was employed under different conditions of Na2S dosage, aeration time, pH value and reaction time. It is found that addition of sulphuric acid can slightly promote the evaporation of HCl. Ammonia complexation could hardly separate zinc from iron. On the contrary, sulphide precipitation can isolate zinc and iron effectively. Under the optimal conditions, the recovery rate of iron, the precipitation rate of zinc and the purity of ZnS can reach 97.12%, 99.99% and 68.51%, respectively.
  • 加载中
  • [1] Cierpiszewski R., Miesiac I., Rosocka M. R., et al. Removal of zinc(Ⅱ)from spent hydrochloric acid solutions from zinc hot galvanizing plants. Industrial & Engineering Chemistry Research, 2002,41(3):598-603
    [2] 茆亮凯,张林生,陆继来,等.电镀含锌废水的纳滤-反渗透处理回用研究.水处理技术, 2011,37(3):105-107,111 Mao Liangkai, Zhang Linsheng, Lu Jilai, et al. A research on recycling of electroplating zinc wastewater by using nanofiltration and reverse osmosis membrane. Technology of Water Treatment, 2011,37(3):105-107,111(in Chinese)
    [3] 杜巧云.热镀锌灰渣的再利用.河南化工,1993,(11):25-26 Du Qiaoyun. Reuse of znic ash from zinc hot galvanizing plants. Henan Chemical Industry, 1993,(11):25-26(in Chinese)
    [4] Jha M. K., Kumar V., Singh R. J.Review of hydrometallurgical recovery of zinc from industrial wastes. Resources Conservation and Recycling, 2001,33(1):1-22
    [5] Kinoshitaa T., Yamaguchic K., Akita S., et al. Hydrometallurgical recovery of zinc from ashes of automobile tire wastes. Chemosphere,2005,59(8):1105-1111
    [6] 杨声海.Zn(Ⅱ)-NH3-NH4Cl-H2O体系制备高纯锌理论及应用.长沙:中南大学博士学位论文,2003 Yang Shenghai. Theory and application studies on preparing high purity zinc in th system of Zn(Ⅱ)-NH3-NH4Cl-H2O. Changsha: Doctoral Dissertation of Central South University, 2003(in Chinese)
    [7] 赵俊学,贺慧,马红周,等.不锈钢酸洗废水蒸酸研究.钢铁钒钛,2010,31(1):84-87 Zhao Junxue, He Hui, Ma Hongzhou, et al. Study on acid evaporation and valuable metal elements recovery in stainless steel pickling waste liquors. Iron Steel Vanadium Titanium, 2010,31(1):84-87(in Chinese)
    [8] 彭位华, 桂和荣. 国内铁氧体法处理重金属废水应用现状. 水处理技术, 2010,36(5):22-27 Peng Weihua, Gui Herone. Application status of ferrite process in treating industrial effluents of heavy metals in China. Technology of Water Treatment, 2010,36(5):22-27(in Chinese)
    [9] 曾媛,赵俊学,马红周,等.含重金属离子酸洗漂洗废水的处理与回收利用研究现状.湿法冶金,2010,29(4):238-241 Zeng Yuan, Zhao Junxue, Ma Hongzhou, et al.Treatment and recycle of heavy metal ions-containing pickling rinse wastewater. Hydrometallurgy of China, 2010,29(4):238-241(in Chinese)
    [10] Esposito G., Veeken A., Weijma J., et al. Use of biogenic sulfide for ZnS precipitation. Separation and Purification Technology, 2006,51(1):31-39
    [11] 大连工学院编.无机化学(上册).北京:人民教育出版社,1982
    [12] 李二平,闵小波,舒余德,等.Zn2+-S2--H2O系热力学平衡研究.环境科学与技术, 2010,33(3):1-3,8 Li Erping, Min Xiaobo, Shu Yude, et al. Thermodynamic equilibrium of Zn2+-S2--H2O system. Environmental Science & Technology, 2010,33(3):1-3,8(in Chinese)
    [13] Grootscholtena T., Keesmana K., Lensb P. Modelling and on-line estimation of zinc sulphide precipitation in a continuously stirred tank reactor. Separation and Purification Technology, 2008,63(3):654-660
    [14] Sampaio R. M. M., Timmers R. A., Kocks N., et al. Zn-Ni sulfide selective preciptitation: The role of supersaturation. Separation and Purification Technology, 2010,74(1):108-118
    [15] 杨声海,李英念,巨少华,等.用NH4Cl溶液浸出氧化锌矿石.湿法冶金, 2006,25(4):179-182 Yang Shenghai, Li Yingnian, Ju Shaohua, et al. Leaching of zinc oxide ore with ammonium chloride solution. Hydrometallurgy of China, 2006,25(4):179-182(in Chinese)
    [16] 王瑞祥,唐谟堂,刘维,等.NH3-NH4Cl-H2O体系浸出低品位氧化锌矿制取电锌.过程工程学报, 2008,8(1):219-222 Wang Ruiyang, Tang Motang, Liu Wei, et al. Leaching of low grade zinc oxide ore in NH3-NH4Cl-H2O system for production of electrolytic zinc. The Chinese Journal of Process Engineering, 2008,8(1):219-222(in Chinese)
    [17] Limpo J. L., Luis A., Cristina M. C. Hydrolysis of zinc chloride in aqueous ammonia calammonium chloridesolutions. Hydrometallurgy, 1995,38(3):235-243
    [18] 刘军坛.电镀废水处理技术的发展.化工时刊,1996,10(9):3-6,15 Liu Juntan. Development of treatment for electroplating wastewater. Chemical Industry Times, 1996,10(9):3-6,15(in Chinese)
    [19] 佟志芳,杨光华,李红超,等.氨浸出含锌烟尘制取活性氧化锌.化工环保,2009,29(6):534-537 Tong Zhifang, Yang Guanghua, Li Hongchao, et al. Preparation of activated zinc oxide from zinc dust by ammonia leaching process. Environmental Protection of Chemical Industry, 2009,29(6):534-537(in Chinese)
    [20] 唐忠德,韦世凡,姚毅.钢厂高浓度酸洗废水处理工程改造实例.工业水处理,2010,30(9):84-86 Tang Zhongde, Wei Shifan, Yao Yi. Reconstruction of the highly concentrated acid washing wastewater treatment project at a steel product factory. Industrial Water Treatment, 2010,30(9):84-86(in Chinese)
    [21] 王凯雄.水化学.北京:化学工业出版社, 2001
    [22] 贾建业,兰斌明,谢先德,等. 硫化物矿物溶解度与溶液pH值的关系. 长春科技大学学报, 2001,31(3):241-246 Jia Jianye, Lan Binming, Xie Xiande, et al. Relationship between solubility of sulfides and solution pH value. Journal of Changchun University of Science and Technology, 2001,31(3):241-246(in Chinese)
    [23] 曾懋华,黎载波,赵旭光,等.由高铁低锌萃铟废水制备锌精矿和铁红. 过程工程学报,2010,10(1):84-90 Zeng Maohua, Li Zaibo, Zhao Xuguang, et al. Recovery of zinc concentrate and preparation of iron red from high iron and low zinc wastewater from extraction of indium. The Chinese Journal of Process Engineering, 2010,10(1):84-90(in Chinese)
    [24] 王敏.纳米活性沉淀剂去除硫酸亚铁中的锌及重金属研究.湖北第二师范学院学报, 2008,25(8):37-38,129 Wang Min. Study on the nano activity of precipitant for removal of zinc and heavy metals in ferrous sulfate. Journal of Hubei University of Education, 2008,25(8):37-38,129(in Chinese)
    [25] Gharabaghi M., Irannajad M., Azadmehr A. R. Selective sulphide precipitation of heavy metals from acidic polymetallic aqueous solution by thioacetamide. Industrial & Engineering Chemistry Research, 2012,51(2):954-963
    [26] Liu Qing, Zhao Youcai, Zhao Guodong. Production of zinc and lead concentrates from lean oxidized zinc ores by alkaline leaching followed by two-step precipitation using sulfides. Hydrometallurgy,2011,110(1-4):79-84
    [27] Veeken A. H. M., Akoto L., Hulshoff Pol L. W., et al. Control of the sulfide (S2-) concentration for optimal zinc removal by sulfide precipitation in a continuously stirred tank reactor. Water Research, 2003,37(15):3709-3717
    [28] Lewis A. E. Review of metal sulphide precipitation. Hydrometallurgy, 2010,104(2):222-234
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2081
  • HTML全文浏览数:  1063
  • PDF下载数:  1904
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-05-20
  • 刊出日期:  2012-12-07
许玉东, 孙燕如, 郑雪琴. 热镀锌厂酸洗废水及锌灰中锌回收[J]. 环境工程学报, 2012, 6(12): 4487-4492.
引用本文: 许玉东, 孙燕如, 郑雪琴. 热镀锌厂酸洗废水及锌灰中锌回收[J]. 环境工程学报, 2012, 6(12): 4487-4492.
shu
Xu Yudong, Sun Yanru, Zheng Xueqin. Recovery of zinc from wastewater and zinc ash of zinc hot galvanizing plants[J]. Chinese Journal of Environmental Engineering, 2012, 6(12): 4487-4492.
Citation: Xu Yudong, Sun Yanru, Zheng Xueqin. Recovery of zinc from wastewater and zinc ash of zinc hot galvanizing plants[J]. Chinese Journal of Environmental Engineering, 2012, 6(12): 4487-4492.
shu

热镀锌厂酸洗废水及锌灰中锌回收

  • 1. 福州大学环境与资源学院,福州 350108
  • 2. 福建船政交通职业学院,福州 350007
  • 收稿日期:  2012-05-20
基金项目:

福建省基本科研专项项目(2009R10023-4)

摘要: 分别采用蒸酸法、氨络合法和硫化沉淀法分离回收热镀锌厂酸洗废水及锌灰中锌铁。分别考察了酸洗废水中盐酸的逸出特性和氨浸法回收蒸馏渣中锌的效果;利用酸洗废水的酸度浸取锌灰中的锌并用氨络合法分离酸浸出液中锌铁;利用硫化物不同溶度积选择性沉淀酸浸出液中的锌,考察了Na2S加入量、曝气时间、反应溶液pH和反应时间的影响。研究结果表明硫酸的加入能提高盐酸的蒸发率但效果不明显,氨络合法难于有效分离锌铁,但硫化物沉淀法可较好地分离锌铁,铁回收率可达97.12%,锌沉淀率达到99.99%,所得沉淀物中ZnS纯度为68.51%。
