酸析-活性炭纤维吸附预处理精制棉黑液

,  ,  ,

downloadPDF

上一篇

下一篇

赵旭, 赵泉林, 孟庆强, 叶正芳. 酸析-活性炭纤维吸附预处理精制棉黑液[J]. 环境工程学报, 2013, 7(3): 1017-1023.
引用本文: 赵旭, 赵泉林, 孟庆强, 叶正芳. 酸析-活性炭纤维吸附预处理精制棉黑液[J]. 环境工程学报, 2013, 7(3): 1017-1023.
shu
Zhao Xu, Zhao Quanlin, Meng Qingqiang, Ye Zhengfang. Pretreatment of black liquor from refined cotton production by acidification and adsorption using activated carbon fiber[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 1017-1023.
Citation: Zhao Xu, Zhao Quanlin, Meng Qingqiang, Ye Zhengfang. Pretreatment of black liquor from refined cotton production by acidification and adsorption using activated carbon fiber[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 1017-1023.
shu

酸析-活性炭纤维吸附预处理精制棉黑液

  • 1.

    北京大学环境工程系,水沙科学教育部重点实验室,北京 100871

  • 基金项目:

    北京大学大型仪器开放测试基金项目(0210218)

  • 中图分类号: X791

Pretreatment of black liquor from refined cotton production by acidification and adsorption using activated carbon fiber

  • 1.

    Key Laboratory of Water and Sediment Sciences, Ministry of Education, Department Environmental Engineering, Peking University, Beijing 100871, China

  • Fund Project:

  • 摘要: 采用酸析-活性炭纤维吸附工艺去除精制棉黑液中的有机物,先用酸析法去除木质素,再用活性炭纤维吸附黑液中的剩余有机物。采用紫外-可见(UV-vis)吸收光谱、傅立叶转换红外吸收光谱(FTIR)和明亮发光菌水质急性毒性法等手段分析处理前后的精制棉黑液。研究表明,黑液中主要有机成分为愈创基(G-)和羟苯基(H-)木质素。在pH为2.0,活性炭纤维用量为90 g/L,温度为40°C,吸附时间为5 h的条件下,COD去除率可以达到85%。活性炭纤维对酸析后精制棉黑液的吸附热力学符合Redlich-Peterson经验吸附模型,吸附动力学符合伪二级动力学模型,吸附为吸热过程。酸析-吸附过程使精制棉黑液急性毒性去除率达到95%以上,为后续生物法处理提供了有利条件。
    Abstract: Acidification and activated carbon fiber (ACF) adsorption were investigated for removal of organic pollutants from black liquor generated from refined cotton production. Acidification is to remove lignin, while ACF adsorption is to remove the remaining organic matters from black liquor. UV-vis spectroscopy, FTIR were used to evaluate the chemical changes of black liquor. The acute toxicity of black liquor before and after adsorption was evaluated by bacterial bioluminescence assays. The results indicated that the main organic components of black liquor are guaiacyl (G-) and hydroxyphenyl (H-) lignin. When pH=2.0 for acid precipitation, ACF dosage was 90 g/L, 85% of COD could be removed after 5 h of adsorption at 40°C. The adsorption process can be described by Redlich-Peterson isotherm model. The kinetic data followed the pseudo-second-order equation and the adsorption process was endothermic. After acidification and ACF adsorption, up to 95% of the acute toxicity of black liquor was removed, which may be favorable for further biological treatment.
  • 加载中
  • [1] 胡波,黎敏聪. UASB反应器处理精制棉废水的实验研究. 环境科技,2009,22(1):30-32 Hu B.,Li M.C. Experiment research on refined cotton wastewater treatment by UASB reactor. Environmental Science and Technology,2009,22(1):30-32(in Chinese)
    [2] 殷琨. 精制棉生产中污染物的综合治理. 江苏环境科技,2006,19(3):28-30 Yin K. Integrated treatment for pollutants from refined cotton production. Jiangsu Environmental Science and Technology,2006,19(3):28-30(in Chinese)
    [3] 邹士洋,杨腊梅,王胜智,等. 精制棉废水处理工程实践. 江苏环境科技,2005,18(2): 14-16 Zou S. Y.,Yang L. M.,Wang S. Z.,et al. Practice of refined cotton wastewater treatment. Jiangsu Environmental Science and Technology,2005,18(2):14-16(in Chinese)
    [4] 徐常新,陈毅坚. 造纸黑液的酸析处理. 玉溪师范学院学报,2001,17(3):72-73 Xu C. X.,Chen Y. J. Acid recovery treatment of black liquor from paper making. Journal of Yuxi Normal College,2001,17(3):72-73 (in Chinese)
    [5] 曾志勇,利锋. 精制棉废水处理工艺研究. 广东化工,2009,36(8):161-162 Zeng Z. Y.,Li F. The exploration of refined cotton wastewater treatment technology. Guangdong Chemistry,2010,36(8):161-162(in Chinese)
    [6] Mangun C. L.,Yue Z. R., Economy J. Adsorption of organic contaminants from water using tailored ACFs. Chemical Materials,2001,13(7):2356-2360
    [7] Mochida I.,Yoon S. H.,Qiao W. M. Catalysts in syntheses of carbon and carbon precursors. Journal of Brazil Chemistry and Society,2006,17(6):1059-1060
    [8] Saha B.B.,El-Sharkawy II,Chakraborty A.,et al. Study on an activated carbon fiber-ethanol adsorption chiller:Part I system description and modeling. International Journal of Refrigeration,2007,30(1):86-87
    [9] Saha B.B.,El-Sharkawy II,Chakraborty A.,et al. Study on an activated carbon fiber-ethanol adsorption chiller:Part II performance evaluation. International Journal of Refrigeration,2007,30(1):92-94
    [10] Brasquet C.,Subrenat E.,Le Cloirec P. Removal of phenolic compounds from aqueous solution by activated carbon cloths. Water Science Technology,1999,40(10/11):2012-2014
    [11] Soo-J I.P.,Kim Y. Mi. Adsorption behaviors of heavy metal ions onto electrochemical oxidized activated carbon fibers. Materials Science and Engineering:A,2005,391(1/2):121-123
    [12] 李颖,岳钦艳,高宝玉,等. 活性炭纤维对活性染料的吸附动力学研究. 环境科学,2007,28(11):2637-2641 Li Y.,Yue Q. Y.,Gao B. Y.,et al. Adsorption kinetics of reactive dyes on activated carbon fiber. Environmental Science,2007,28(11):2637-2641(in Chinese)
    [13] 李永贵,张海泉,张君. 活性炭纤维处理印染工业废水展望. 产业用纺织品,2001,6(1):19-23 Li Y. G.,Zhang H. Q.,Zhang J. Prospects for treatment of printing and dyeing wastewater by activated carbon fiber. Technical Textiles,2001,6(1):19-23(in Chinese)
    [14] Lee S.W. Application of activated carbon fiber(ACF)for arsenic removal in aqueous solution. Korean Journal of Chemical Engineering,2010,27(3):110-115
    [15] Kuramitz H.,Matsushita M.,Tanaka S. Electrochemica摬?慲捥瑭楯癶慡瑬攠摯?挠慢物扳潰湨??楯湬攠瑁椠换?獳瑥畤搠祯?愠湴摨?攠煡畮楯汤楩扣爠楰畯浬?業獥潲瑩桺敡牴浩?慮渠慵汳祩獮敧猠???桯敬浵潭獮瀠桴敹牰敥??ちひ???ㄠ?????????っ??扯牤?嬮㈠?嵡?剥敲搠汒楥捳桥?佲??倬攲琰攰爴猬漳游??????″??甲猳攳昸甼汢?愾摛猱漶牝瀠瑄楩潡湺?楆獬潯瑲桥敳爠浐???漮甬牌湥慹汶?漭晒?偭桯祳猠楒挮愬汇??桲敲浥楲獯琭牃祯?????????????づ???扬爮?孁??嵯??桴潩祯??????????偣潨牬瑯敲牯????????捲歯慭礠?????湵瑳爠慳灯慬牵瑴楩捯汮攠?摮楴景映畡獣楴潩湶?楴湥?猠楣湡杲汢敯?愠湦摩?浥畲氮琠楉?捤潵浳灴潲湩敡湬琠?慮捤椠摅?摧祩敮?慥摲獩潮牧瀠瑃楨潥湭?晳牴潲浹?睒慥獳瑥敡睲慣瑨攬爲‰漰渶琬漴‵挨愱爩戺漳渳???椳漶挼桢敲派楛挱愷汝??湯杭楥湺攠敖爮椬湌条??潥畣牨湩愠汍???????ぬ??ㄠ????ㄠ???????戠牡?孤㈠?嵤?卯畲湰?坩????兴畵?她??婦??乣楩????剥???摭獯潶牡灬琠極潳湩?潧映?潣牴杩慶湡楴捥?瀠潣污汲畢瑯慮渮琠獃?晥牭潯浳?捨潥歲楥測朲‰愰渷搬?瀹愨瀱攩爺洱愱欵椱渭朱?眵愸猼瑢敲眾慛琱攸牝猠?扯礠?戮漠瑓琮漬浃?慩獡桮???漮甠牃渮愠汓?潲晰??慯穮愠牳摴潵畤獩??愠瑯敦爠楡慣汩獤??べづ??????????????づ?ts. Adsorption,2001,7(1):139-147
    [16] Özacar M. �瘙塁engil . A. Adsorption of reactive dyes on calcined alunite from aqueous solutions. J. Hazard. Mater.,2003,B98(2):211-224
    [17] Özacar M. �瘙塁engil .A. Application of kinetic models to the sorption of disperse dyes onto alunite. Colloid. Surface. A.,2004,242(2):105-113
    [18] Rodriguez E.,Encinas A.,Masa F. J.,et al. Influence of resorcinol chemical oxidation on the removal of resulting organic carbon by activated carbon adsorption. Chemosphere,2008,70(2):1366-1374
    [19] 陈晓英,朱仙弟,梁华定,等. 活性炭纤维吸附邻硝基苯胺水溶液的研究. 应用化工,2010,(5):11-14 Chen X. Y.,Zhu X. D.,Liang H. D.,et al. Study on the adsorption of o-nitroaniline aqueous solution by activated carbon fiber. Applied Chemical Industry,2010,(5):11-14(in Chinese)
    [20] Ho Y. S.,Ofomaja A. E. Biosorption thermodynamics of cadmium on coconut copra meal as biosorbent. Biochemical Engineering Journal,2006,30(1):117-123
    [21] Langmuir I. The constitution and fundamental properties of solids and liquids. Journal of the American Chemical Society,1916,38(1):2221-2295
    [22] 张全兴,陈金龙,许昭怡,等. 树脂吸附法处理有毒有机化工废水及其资源化研究. 高分子通报,2005,4(1):116-121 Zhang Q. X.,Chen J. L.,Xu Z. Y. Application of polymeric resin adsorbent in organic chemical wastewater treatment and resources reuse. Polymer Bulletin,2005,4(1):116-121(in Chinese)
    [23] Mall I. D., Srivastava V. C., Agarwal N. K. Mishra I. M. Removal of congo red from aqueous solution by bagasse fly ash an
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1812
  • HTML全文浏览数:  945
  • PDF下载数:  1390
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-03-02
  • 刊出日期:  2013-03-18
赵旭, 赵泉林, 孟庆强, 叶正芳. 酸析-活性炭纤维吸附预处理精制棉黑液[J]. 环境工程学报, 2013, 7(3): 1017-1023.
引用本文: 赵旭, 赵泉林, 孟庆强, 叶正芳. 酸析-活性炭纤维吸附预处理精制棉黑液[J]. 环境工程学报, 2013, 7(3): 1017-1023.
shu
Zhao Xu, Zhao Quanlin, Meng Qingqiang, Ye Zhengfang. Pretreatment of black liquor from refined cotton production by acidification and adsorption using activated carbon fiber[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 1017-1023.
Citation: Zhao Xu, Zhao Quanlin, Meng Qingqiang, Ye Zhengfang. Pretreatment of black liquor from refined cotton production by acidification and adsorption using activated carbon fiber[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 1017-1023.
shu

酸析-活性炭纤维吸附预处理精制棉黑液

  • 1. 北京大学环境工程系,水沙科学教育部重点实验室,北京 100871
  • 收稿日期:  2012-03-02
基金项目:

北京大学大型仪器开放测试基金项目(0210218)

摘要: 采用酸析-活性炭纤维吸附工艺去除精制棉黑液中的有机物,先用酸析法去除木质素,再用活性炭纤维吸附黑液中的剩余有机物。采用紫外-可见(UV-vis)吸收光谱、傅立叶转换红外吸收光谱(FTIR)和明亮发光菌水质急性毒性法等手段分析处理前后的精制棉黑液。研究表明,黑液中主要有机成分为愈创基(G-)和羟苯基(H-)木质素。在pH为2.0,活性炭纤维用量为90 g/L,温度为40°C,吸附时间为5 h的条件下,COD去除率可以达到85%。活性炭纤维对酸析后精制棉黑液的吸附热力学符合Redlich-Peterson经验吸附模型,吸附动力学符合伪二级动力学模型,吸附为吸热过程。酸析-吸附过程使精制棉黑液急性毒性去除率达到95%以上,为后续生物法处理提供了有利条件。
