光纤传导可见光降解亚甲基蓝

,

downloadPDF

上一篇

下一篇

储金宇, 仲蕾. 光纤传导可见光降解亚甲基蓝[J]. 环境工程学报, 2013, 7(3): 1035-1039.
引用本文: 储金宇, 仲蕾. 光纤传导可见光降解亚甲基蓝[J]. 环境工程学报, 2013, 7(3): 1035-1039.
shu
Chu Jinyu, Zhong Lei. Photocatalytic degradation of methylene blue via side-glowing optical fiber under visible light[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 1035-1039.
Citation: Chu Jinyu, Zhong Lei. Photocatalytic degradation of methylene blue via side-glowing optical fiber under visible light[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 1035-1039.
shu

光纤传导可见光降解亚甲基蓝

  • 1.

    江苏大学环境学院,城市水资源与水环境国家重点实验室江苏大学研究中心,镇江 212013

  • 基金项目:

  • 中图分类号: X703

Photocatalytic degradation of methylene blue via side-glowing optical fiber under visible light

  • 1.

    Branch Center of State Key Laboratory of Urban Water Resource and Environment, School of Environment, Jiangsu University, Zhenjiang 212013, China

  • Fund Project:

  • 摘要: 针对浓度大、色度高的印染废水难以处理的情况,选用加入光纤的光催化体系进行研究。采用溶胶凝胶法制备了Ag+/TiO2粉体光催化剂,用固体紫外可见光谱、X射线衍射对其进行表征。选用亚甲基蓝溶液作为目标降解物,评价了Ag+/TiO2在可见光下的光催化活性。分别考察了加入石英芯侧光光纤与塑料侧光光纤反应体系下,催化剂量、光纤数量、光照强度和pH值等因素对亚甲基蓝降解实验的影响。结果表明,选用20 mg/L的亚甲基蓝,采用催化剂量为11.67 g/L,500根侧光光纤,300 W的外部光源,pH值约为11时,光催化降解效果最佳,均能达到90%以上。
    Abstract: The photocatalytic system of side-glowing optical fibers (SOFs) was used to treat dyeing wastewater with high concentration and chroma. In this study, methylene blue (MB) was chosen as goal degradant. Ag+/TiO2 powder was prepared by sol-gel method, and characterized by ultraviolet visible spectroscopy of solid diffuse reflectance (UV-Vis DRS), X-ray diffraction (XRD). Ag+/TiO2 catalytic activity under the visible light irradiation was evaluated. The authors investigated different reaction conditions between quartz core and plastic side-glowing optical fiber system. The impact factors include the dosage of catalyst, quantity of optical fiber, illumination intensity, and pH and so on. The changes of MB degradation efficiency was discussed. The results show that the MB was degraded by more than 90% within 8 h under the conditions that the dosage of Ag+/TiO2 was 11.67 g/L, initial concentration of MB was 20 mg/L, the quality of SOFs was 500, pH was about 11 and the external light source was 300 W.
  • 加载中
  • [1] 蔡铁军, 吕晓萌, 邓谦, 等.复合催化剂PWn/TiO2光催化降解甲醛反应的研究.环境科学学报,2005,25(5):618-622Cai Tiejun, Lü Xiaomeng, Deng Qian, et al. Study on the photodegradation of formaldehyde with PWn/TiO2 composite catalysts. Acta Scientiae Circumstantiae, 2005, 25(5): 618-622 (in Chinese)
    [2] 邓谦, 吕晓萌, 蔡铁军, 等.磷钨酸表面修饰TiO2光催化降解空气污染物.中国环境科学, 2005,25(3):375-379Deng Qian, Lü Xiaomeng, Cai Tiejun, et al. Photocatalytic degradation of air pollutant over TiO2 modified with phosphatotungstic acid. China Environmental Science, 2005, 25(3): 375-379 (in Chinese)
    [3] 孙奉玉, 吴鸣, 李文钊,等.二氧化钛表面光学特性与催化活性的关系.催化学报,1998,19(2):121-124Sun Fengyu, Wu Ming, Li Wenzhao, et al. Relationship between optical surface properties and photocatalytic activity of titanium dioxide. Chinese Journal of Catalysis, 1998, 19(2): 121-124 (in Chinese)
    [4] Chia-Hsin Li, yung-Hsu Heish, Wan-Ting Chiu, et al. Study on preparation and photocatalysis performance of Ag/TiO2 and Pt/TiO2 photocatalysis. Separation and Purification Technology, 2007,58(1): 148-151
    [5] 刘守新,曲振平,韩秀文,等. Ag担载对TiO2光催化活性的影响.催化学报,2004,25(2):133-137Liu Shouxin, Qu Zhenping, Han Xiuwen, et al. Effect of sliver deposition on photocatalytic activity of TiO2. Chinese Journal of Catalysis, 2004, 25(2): 133-137(in Chinese)
    [6] Xiao hong S. Li.,Glen E. Fryxell, Chongmin Wang, et al. The synthesis of Ag-doped mesoporous TiO2. Microporous and Mesoporous Materials, 2008, 111(1-3): 639-642
    [7] Pratap Reddy M., Venugopal A., Subrahmanyam M. Hydroxyapatite supported Ag-TiO2, as Escherichia coli disinfection photocatalyst. Water Research, 2007, 41(2): 379-386
    [8] Subramanian V., Wolf E. Kamat P. V. Semiconductor-metal composite nanostructure. To what extent do metal nanoparticles improve the photocatalytic activity of TiO2 films. Physical Chemistry B, 2001, 105(46): 11439-11446
    [9] Schwitzgebel J., Ekerdt J. G., Gerischer H., et al. Role of the oxygen molecule and of the photogenerated electron in TiO2-photocatalyzed air oxidation reactions. Physical Chemistry, 1995, 99(15):5633-5638
    [10] Zhi-Ming Dai, Gerald Burgeth, Francesco Parrino, et al. Visible light photocatalysis by a titania-rhodium(Ⅲ) complex. Journal of Organometallic Chemistry, 2009, 694(7-8): 1049-1054
    [11] Min Liang, Shiqun Sun, Shuchuan Peng, et al. Study on preparation and improvement of palygorskite-TiO2 as a photocatalytist. Journal of Hefei University of Technology (Nature Science), 2009,32(2): 145-149
    [12] Rajesh J.Tayade, Ramchandra G. Kulkarni, Raksh V. Jasra. Enhanced photocatalytic activity of TiO2-cated NaY and HY zeolites for the degradation od methylene blue in water. Industry Engineering Chemistry Research, 2007, 46(2): 369-376
    [13] Tsoukleris D. S., Maggos T., Vassilakos C., et al.Photocatalytic degradation of volatile organics on TiO2 embedded glass spherules. Catalysis Today, 2007, 129(1-2): 96-101
    [14] 黄徽, 杜玉扣, 戴兢陶, 等. TiO2/ACF 的制备及光催化降解四氯乙烯性能. 感光科学与光化学, 2007,25(2): 123-129Hui Huang, Yukou Du, Jingtao Dai, et al. Prepartation of TiO2/ACF catalysts and their photodegradation on thtrachloroethylene. Photographic Science and Photochemistry, 2007, 25(2):123-129 (in Chinese)
    [15] Hoffmann M. R., Martin S. T., Choi W., et al. Environmental applications of semiconductor photocatalysis. Chemistry Rev., 1995, 95(1): 69-96
    [16] jingjing Xu, Yanhui Ao, Degang Fu, et al. Photocatalytic activity on TiO2-coated side-glowing optical fiber reactor under solar light. Photochemistry and Photobiology A: Chemistry, 2008, 199(2-3):165-169
    [17] Fuxiang Zhang, Xiu Zhang, Jixin Chen, et al. Preparation and characterization of Ag/TiO2 nanoparticle catalyst and its photocatalytic activity. Chinese Journal of Catalysis, 2003,24(11): 877-880
    [18] Goswami D. Y. A review of engineering developments of aqueous phase solar photocatalytic detoxification and disinfection processes. Journal of Solar Energy Engineering, 1997,119(2): 101-107
