好氧颗粒污泥动态膜生物反应器工艺参数及运行性能

,  ,  ,

downloadPDF

上一篇

下一篇

桂永馨, 黄天寅, 李文卫, 姚嘉. 好氧颗粒污泥动态膜生物反应器工艺参数及运行性能[J]. 环境工程学报, 2013, 7(7): 2596-2600.
引用本文: 桂永馨, 黄天寅, 李文卫, 姚嘉. 好氧颗粒污泥动态膜生物反应器工艺参数及运行性能[J]. 环境工程学报, 2013, 7(7): 2596-2600.
shu
Gui Yongxin, Huang Tianyin, Li Wenwei, Yao Jia. Operating process parameters and performance of aerobic granular sludge dynamic membrane bioreactor[J]. Chinese Journal of Environmental Engineering, 2013, 7(7): 2596-2600.
Citation: Gui Yongxin, Huang Tianyin, Li Wenwei, Yao Jia. Operating process parameters and performance of aerobic granular sludge dynamic membrane bioreactor[J]. Chinese Journal of Environmental Engineering, 2013, 7(7): 2596-2600.
shu

好氧颗粒污泥动态膜生物反应器工艺参数及运行性能

  • 1.

    苏州科技学院环境学院, 苏州 215011

  • 2.

    中国科学技术大学, 合肥 230026

  • 3.

    中国科学技术大学苏州研究院环境实验室, 苏州 215123

  • 基金项目:

    江苏省自然科学基金资助项目(2010256)

  • 中图分类号: X703

Operating process parameters and performance of aerobic granular sludge dynamic membrane bioreactor

  • 1.

    School of Environment, Suzhou University of Science and Technology, Suzhou 215011, China

  • 2.

    1. University of Science and Technology of China, Hefei 230026, China

  • 3.

    Advanced Lab for Environmental Research & Technology of USTC, Suzhou 215123, China

  • Fund Project:

  • 摘要: 以一体式尼龙筛网动态膜生物反应器(DMBR)为研究体系,与好氧颗粒污泥相结合,形成新的好氧颗粒污泥动态膜生物反应器(AGDMBR),探讨了在新工艺条件下对COD、氨氮的去除,以及出水浊度的变化,与活性污泥动态膜生物反应器(DMBR)做比较,研究了进水流量、曝气量等工艺运行参数与膜污染之间的关系,并对系统中污泥的EPS进行分析。结论表明,AGDMBR系统对COD和NH4+-N的平均去除率分别为91%和95%,出水浊度为6 NTU,处理效果均优于DMBR系统;AGDMBR系统在运行过程中膜污染速度随进水流量的增大而加快;曝气量为125~150 L/h时,膜通量持续时间最长; AGDMBR系统比DMBR系统在膜污染的延缓上具有明显的优势。
    Abstract: The treatment performances of an aerobic granular sludge membrane bioreactor, which combined aerobic granular sludge process with submerged nylon-mesh dynamic membrane bioreactor (DMBR), were investigated, and the influences of operating factors such as filtrate flow rate and aeration rate on membrane fouling were studied. In addition, an analysis of the extracellular polymeric substances (EPS) of sludge in the AGDMBR and the activated sludge control reactor was performed to investigate the fouling mechanism in different systems. The results showed that COD and NH4+-N average removal efficiencies of AGDMBR remained at 91% and 95%, respectively the effluent turbidity was 6 NTU, which were better than DMBR. Moreover, the membrane fouling rate increased significantly with the filtration flow rate, and the flux of the membrane remained longest when the aeration rate was 125~150 L/h for the AGDMBR. Lower membrane fouling was achieved in AGDMBR than in DMBR.
  • 加载中
  • [1] Fan Bin, Huang Xia. Characteristics of a self-forming dynamic membrane coupled with a bioreactor for municipal wastewater treatment. Environment Science and Technology,2002, 36(23): 5245-5251
    [2] 邱宪锋, 张建, 高宝玉, 等. 内循环动态膜生物反应器处理生活污水. 中国环境科学,2007, 27(2): 165-168 Qiu Xianfeng, Zhang Jian, Gao Baoyu, et al. The treatment of domestic wastewater by internally circulating dynamic membrane bio-reactor. China Enviromental Science,2007, 27(2): 165-168 (in Chinese)
    [3] Zhou J., Yang F. L., Meng F. G., et al. Comparison of membrane fouling during shortterm filtration of aerobic granular sludge and activated sludge. Journal of Environmental Sciences,2007, 19(11): 1281-1286
    [4] Tay J. H., Yang P., Zhuang W. Q., et al. Reactor performance and membrane filtration in aerobic granular sludge membrane bioreactor. Journal of Membrane Science,2007, 304(1-2): 24-32
    [5] 朱振中, 周艳, 李秀芬, 等. 好氧颗粒污泥膜生物反应器的运行特性. 环境科学,2006, 27(1): 57-62 Zhu Zhenzhong, Zhou Yan, Li Liufen, et al. Characteristics of aerobic granular sludge membrane bioreactor for wastewater treatment. Enviromental Science,2006, 27(1): 57-62 (in Chinese)
    [6] Li X. F., Gao F. S., Hua Z. Z., et al. Treatment of synthetic wastewater by a novel MBR with granular sludge developed for controlling membrane fouling. Separation and Purification Technology,2005, 46(1-2): 19-25
    [7] 王景峰, 王暄, 季民, 等. 好氧颗粒污泥膜生物反应器脱氮特性. 环境科学,2007, 28(3): 528-533 Wang Jingfeng, Wang Xuan, Ji Min, et al. Characteristics of nitrogen removal in aerobic granular sludge membrane bioreactor. Enviromental Science,2007, 28(3): 528-533 (in Chinese)
    [8] Dignac M. F., Urbain V., Rybacki D., et al. Chemical description of extracellular polymers:implication on activated sludge floc structure. Water Science and Technology. 1998, 38(8-9):45-53
    [9] Frolund B., Griebe T., Nielsen P. H. Enzymatic activity in the activated-sludge floc matrix. Applied Microbiology and Biotechnology,1995, 43(4):755-761
    [10] Raunkjar K., Hvitved-Jacobsen T., Nielsen P. H. Measurement of pools of protein, carbohydrate and lipid in domestic wastewater. Water Research,1994, 28(2): 251-261
    [11] 范彬, 黄霞, 文湘华, 等. 动态膜-生物反应器对城市污水的处理. 环境科学,2002, 23(6):51-56 Fan Bin, Huang Xia, Wen Xianghua, et al. A submerged Dynamic membrane bioreactor for domestic wastewater treatment. Enviromental Science,2002, 23(6):51-56 (in Chinese)
    [12] Rosenberger S., Evenblij H., Poele S.T., et al.The importance of liquid phase analyses to understand fouling in membrane assisted activated sludge processes-six case studies of different European research groups.Journal of Membrane Science,2005, 263(1-2):113-126
    [13] Drews A., Lee C., Kraume M. Membrane fouling-A review on the role of EPS. Desalination,2006, 200(1-3):186-188
    [14] 白琳, 杨凤林, 王秀, 等. 好氧硝化颗粒污泥膜生物反应器性能和膜污染研究. 环境工程学报,2009, 3(5): 817-824 Bai Lin, Yang Fenglin, Wang Xiu, et al.Performance and membrane fouling of aerobic nitrifying granule membrane bioreactor. Chinese Journal of Enviromental Engineering,2009, 3(5): 817-824 (in Chinese)
    [15] Adav S. S., Lee D. J., Lai J. Y. Effects of aeration intensity on formation of phenol-fed aerobic granules and extracellular polymeric sub stances. Applied Microbiology and Biotechnology,2007, 77(1): 175-182
    [16] De Kreuk M.K., Kishida N., van Loosdrecht M.C. Aerobic granular sludge-state of the art. Water Science and Technology,2007, 55(8-9): 75-81
    [17] Wang X. H., Zhang H. M., Yang F. L., et al. Improved stability and performance of aerobic granules under stepwise increased selection pressure. Enzyme and Microbial Technology,2007, 41(3): 205-211
    [18] Liu Y., Yang S. F., Tay J. H., et al. Cell hydrophobicity is a triggering force of biogranulation. Enzyme and Microbial Technology,2004, 34(5): 371-379
    [19] Liu Y. Q., Liu Y., Tay J. H. The effects of extracellular polymeric substances on the formation and stability of biogranules. Applied Microbiology and Biotechnology,2004, 65(2):143-148
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1922
  • HTML全文浏览数:  1103
  • PDF下载数:  814
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-05-21
  • 刊出日期:  2013-07-18
桂永馨, 黄天寅, 李文卫, 姚嘉. 好氧颗粒污泥动态膜生物反应器工艺参数及运行性能[J]. 环境工程学报, 2013, 7(7): 2596-2600.
引用本文: 桂永馨, 黄天寅, 李文卫, 姚嘉. 好氧颗粒污泥动态膜生物反应器工艺参数及运行性能[J]. 环境工程学报, 2013, 7(7): 2596-2600.
shu
Gui Yongxin, Huang Tianyin, Li Wenwei, Yao Jia. Operating process parameters and performance of aerobic granular sludge dynamic membrane bioreactor[J]. Chinese Journal of Environmental Engineering, 2013, 7(7): 2596-2600.
Citation: Gui Yongxin, Huang Tianyin, Li Wenwei, Yao Jia. Operating process parameters and performance of aerobic granular sludge dynamic membrane bioreactor[J]. Chinese Journal of Environmental Engineering, 2013, 7(7): 2596-2600.
shu

好氧颗粒污泥动态膜生物反应器工艺参数及运行性能

  • 1.  苏州科技学院环境学院, 苏州 215011
  • 2.  中国科学技术大学, 合肥 230026
  • 3.  中国科学技术大学苏州研究院环境实验室, 苏州 215123
  • 收稿日期:  2012-05-21
基金项目:

江苏省自然科学基金资助项目(2010256)

摘要: 以一体式尼龙筛网动态膜生物反应器(DMBR)为研究体系,与好氧颗粒污泥相结合,形成新的好氧颗粒污泥动态膜生物反应器(AGDMBR),探讨了在新工艺条件下对COD、氨氮的去除,以及出水浊度的变化,与活性污泥动态膜生物反应器(DMBR)做比较,研究了进水流量、曝气量等工艺运行参数与膜污染之间的关系,并对系统中污泥的EPS进行分析。结论表明,AGDMBR系统对COD和NH4+-N的平均去除率分别为91%和95%,出水浊度为6 NTU,处理效果均优于DMBR系统;AGDMBR系统在运行过程中膜污染速度随进水流量的增大而加快;曝气量为125~150 L/h时,膜通量持续时间最长; AGDMBR系统比DMBR系统在膜污染的延缓上具有明显的优势。
