秸秆黑碳的制备及吸附特性

谢永; 高志凤; 王红艳; 卓馨; 郑文雷; 刘超

环境工程学报

秸秆黑碳的制备及吸附特性

, , , , ,

谢永, 高志凤, 王红艳, 卓馨, 郑文雷, 刘超. 秸秆黑碳的制备及吸附特性[J]. 环境工程学报, 2013, 7(8): 2968-2972.

引用本文:

谢永, 高志凤, 王红艳, 卓馨, 郑文雷, 刘超. 秸秆黑碳的制备及吸附特性[J]. 环境工程学报, 2013, 7(8): 2968-2972.

Xie Yong, Gao Zhifeng, Wang Hongyan, Zhuo Xin, Zheng Wenlei, Liu Chao. Adsorption characteristics and preparation of straw black carbon[J]. Chinese Journal of Environmental Engineering, 2013, 7(8): 2968-2972.

Citation:

Xie Yong, Gao Zhifeng, Wang Hongyan, Zhuo Xin, Zheng Wenlei, Liu Chao. Adsorption characteristics and preparation of straw black carbon[J]. Chinese Journal of Environmental Engineering, 2013, 7(8): 2968-2972.

秸秆黑碳的制备及吸附特性

1.
宿州学院自旋电子与纳米材料安徽省重点实验室, 宿州 234000
2.
宿州学院化学与生命科学院, 宿州 234000
3.
安徽富博医药化工股份有限公司, 蚌埠 233030
基金项目:
安徽省高等学校省级自然科学研究项目(KJ2011B179,KJ2012A268)

自旋电子与纳米材料安徽省重点实验室开放课题资助(2011YKF02,2011YKF01)

安徽省教育厅自然科学研究重点项目(KJ2011A260)
中图分类号: X703.1

Adsorption characteristics and preparation of straw black carbon

1.
Anhui Province Key Laboratory of Spinning and Nano, Suzhou University, Suzhou 234000, China
2.
School of Chemistry and Life Science, Suzhou University, Suzhou 234000, China
3.
Anhui Fubore Pharmaceutical & Chemical Co. Ltd., Bengbu 233030, China
Fund Project:

摘要: 基于前期实验确定在氮气保护3种温度(550、650和750℃)制备秸秆黑碳,并用XRD、SEM对其结构、形貌进行了表征,研究它对吡唑酮废水中铵盐吸附去除效果。结果表明,650℃秸秆黑碳改变了晶体的有序度和结晶度,断面微孔道分布疏松均匀规则,具有较大的比表面积,而且有一定数量的纳米级黑碳颗粒;它的吸附特性优于750℃和550℃的秸秆黑碳,吸附率最高为95.31%;650℃秸秆黑碳最佳吸附工艺:吸附温度和饱和时间分别为35℃和4 h,吸附振荡频率为100 r/min。秸秆黑碳的吸附速率快、适用条件宽是处理铵盐废水的良好材料。
- 氮气保护 /
- 秸秆黑碳 /
- 吸附 /
- SEM /
- 吡唑酮废水 /
- 铵盐
Abstract: On the basis of the previous experiment, black carbon was made from wheat straw with three different temperatures (550, 650, 750℃) under the nitrogen protection. Their particle sizes, structures, and morphologies were also tested by X-ray diffraction (XRD), and scanning electron microscopy (SEM), aiming to examine the effect of removing the ammonia nitrogen in pyrazolone wastewater. The experiments show that the sequence and crystallization degree of the crystal were changed by straw black carbon at 650℃. Micropore volume was distributed on the duct loosely, uniformly and regularly. Specific surface area was larger than the other. There was a certain number of nanoscale black carbon particles. The adsorptive characteristic of straw black at 650℃ was better than that at 750℃ and 550℃. The highest adsorption rate was 95.31%. The optimum conditions for absorptive power of straw black carbon at 650℃ are as the follows: the adsorptive temperature of 35℃; the adsorptive time of 4 h ; and the oscillation frequency of 100 r/min. With faster adsorption rate and wider applicability, straw black carbon at 650℃ is a good material to treat ammonia nitrogen wastewater.
- nitrogen protect /
- straw black carbon /
- adsorption /
- SEM /
- pyrazolone wastewater /
- aminium salt

[1]	Dickens A. F., Gelinas Y., Masiello C. A., et al. Reburial of fossil organic carbon in marine sediments. Nature, 2004,427(6972):336-339
[2]	Gelinas Y., Prentice K. M., Baldock J. A., et al. An improved thermal oxidation method for the quantification of soot/graphitic black carbon in sediments and soils. Environmental Science and Technology, 2001,35(17):3519-3525
[3]	Watson A. Y., Valberg P. A. Carbon black and soot: two different substances. American Industrial Hygiene Association, 2001,62(2):218-228(in Chinese)
[4]	韩永明, 曹军骥. 环境中的黑碳及其全球生物地球化学循环. 海洋地质与第四纪地质, 2005,25(1):125-132 Han Y. M., Cao J. J. Black carbon in the environments and its global biogeochemical cycle. Marine Geology and Quaternary Geology, 2005,25(1):125-132(in Chinese)
[5]	韩宏华,陆建飞. 农作物秸秆焚烧污染治理的政策分析. 生态经济,2009,(12):172-174 Han Honghua, Lu Jianfei. A police analysis on crop straw burning pollution control. Ecological economy, 2009,(12):172-174(in Chinese)
[6]	Nigam J. N. Ethanol production from wheat straw hemicellulose hydrolysate by Pichia stipitis. Journal of Biotechnology, 2001,87(1):17-27
[7]	Islam M. N., Ani F. N. Techno-economics of rice husk pyrolysis,conversion with catalytic treatment to produce liquid fuel. Bioresource Technology, 2000,7(1):67-75
[8]	何娇,孔火良,韩进,等.秸秆生物质环境材料的制备及对水中多环芳烃的处理性能. 环境科学,2011,32(1):135-139 He Jiao, Kong Huoliang, Han Jin, et al. Preparation method of stalk environmental biomaterial and its sorption ability for polycyclic aromatic hydrocarbons in water. Environmental Science, 2011,32(1):135-139(in Chinese)
[9]	冯利,陈中兰,杨显俊,等.改性小麦秸秆纤维素球对苯酚吸附性能研究.分析科学学报,2010,26(4):451-454 Feng Li, Chen Zhonglan, Yang Xianjun,et al.Study on adsorption performance of modified wheat straw cellulose sphere for phenol. Journal of Analytical Science, 2010,26(4):451-454(in Chinese)
[10]	刘光全,张华,吴百春.改性花生壳粉对钙离子的吸附特性研究.环境工程学报,2011,5(12):2733-2738 Liu Guangquan, Zhang Hua, Wu Baichun. Study on adsorption characteristics of calcium ions on modified peanut shell. Chinese Journal of Environmental Engineering, 2011,5(12):2733-2738(in Chinese)
[11]	陈永,周柳江,洪玉珍,等.椰壳纤维基高比表面积中孔活性炭的制备.新型活性炭,2010,25(2):151-155 Chen Yong, Zhou Liujiang, Hong Yuzhen,et al.Preparation of high-surface-area activated carbon from coconut shell fibers. New Carbon Materials, 2010,25(2):151-155(in Chinese)
[12]	Manju G. N., Raji C., Anirudhan T. S. Evaluation of coconut husk carbon for the removal of arsenic from water. Water Research, 1998,32(10):3062-3070
[13]	王炳祥,刘玮炜,胡宏纹.1,3,5-三芳基吡唑类化合物合成的新方法.高等学校化学报,2003,24(4):648-650 Wang Bingxiang, Liu Weiwei,Hu Hongwen.A novel method for the synthesis of 1,3,5-triarylpyrazoles.Chemical Journal of Chinese Universities, 2003,24(4):648-650(in Chinese)
[14]	刘健,李哲.氨氮废水处理技术和发展.矿冶工程,2007,27(4):54-60 Liu Jian, Li Zhe. The treatment technology of ammonia nitrogen wastewater and its development. Mining and Metallurgical Engineering, 2007,27(4):54-60(in Chinese)
[15]	谢永,高志凤,周宝忠,等.炭化秸秆与改性粉煤灰联合吸附吡唑酮废水中铵盐. 水处理技术,2012,38(3):16-18 Xie Yong, Gao Zhifeng, Zhou Baozhong, et al. Fly ash-modified and wheat straw of charring united adsorption of ammonium sulfate from wastewater of pyrazolone. Technology of Water Treatment, 2012,38(3):16-18(in Chinese)
[16]	谢永,高志凤,周宝忠,等. 林可霉素菌(lincolnensis)对吡唑酮废液中硫酸铵的利用研究. 环境工程学报,2012,6(5):1576-1580 Xie Yong, Gao Zhifeng, Zhou Baozhong, et al. Study on utilization of pyrazolone wastewater by Streptomyces lincolnensis.Chinese Journal of Environmental Engineering, 2012,6(5):1576-1580
[17]	朱检. 生化实验.上海:上海科学技术出版社,1980
[18]	肖刚,刘继驰,金宝升,等.稻类秸秆高温炭化焦炭的特征研究.燃烧科学与技术,2010,16(1):1-4 Xiao Gang, Liu Jichi, Jin Baosheng, et al. Characteristics of rice straw and hull charcoal by high-temperature carbonization. Journal of Combustion Science and Technology, 2010,16(1):1-4(in Chinese)
[19]	Yan R., Liang D. T.,Tsen L., et al. Bench-scale experimental evaluation of carbon performance on mercury vapour adsorption. Fuel, 2004,83(17):2401-2409
[20]	Skodras G., Diamantopoulou I., Zabaniotou A., et al. Enhanced mercury adsorption in activated carbons from biomass materials and waste tires. Fuel Processing Technology, 2007,88(8):749-758

点击查看大图

计量

文章访问数: 1982
HTML全文浏览数: 1002
PDF下载数: 1474
施引文献: 0

谢永, 高志凤, 王红艳, 卓馨, 郑文雷, 刘超. 秸秆黑碳的制备及吸附特性[J]. 环境工程学报, 2013, 7(8): 2968-2972.

引用本文:

谢永, 高志凤, 王红艳, 卓馨, 郑文雷, 刘超. 秸秆黑碳的制备及吸附特性[J]. 环境工程学报, 2013, 7(8): 2968-2972.

Citation:

秸秆黑碳的制备及吸附特性

1. 宿州学院自旋电子与纳米材料安徽省重点实验室, 宿州 234000
2. 宿州学院化学与生命科学院, 宿州 234000
3. 安徽富博医药化工股份有限公司, 蚌埠 233030

收稿日期: 2012-06-11

基金项目:

安徽省高等学校省级自然科学研究项目(KJ2011B179,KJ2012A268)

自旋电子与纳米材料安徽省重点实验室开放课题资助(2011YKF02,2011YKF01)

安徽省教育厅自然科学研究重点项目(KJ2011A260)

关键词:

摘要: 基于前期实验确定在氮气保护3种温度(550、650和750℃)制备秸秆黑碳,并用XRD、SEM对其结构、形貌进行了表征,研究它对吡唑酮废水中铵盐吸附去除效果。结果表明,650℃秸秆黑碳改变了晶体的有序度和结晶度,断面微孔道分布疏松均匀规则,具有较大的比表面积,而且有一定数量的纳米级黑碳颗粒;它的吸附特性优于750℃和550℃的秸秆黑碳,吸附率最高为95.31%;650℃秸秆黑碳最佳吸附工艺:吸附温度和饱和时间分别为35℃和4 h,吸附振荡频率为100 r/min。秸秆黑碳的吸附速率快、适用条件宽是处理铵盐废水的良好材料。

English Abstract

Adsorption characteristics and preparation of straw black carbon

1. Anhui Province Key Laboratory of Spinning and Nano, Suzhou University, Suzhou 234000, China
2. School of Chemistry and Life Science, Suzhou University, Suzhou 234000, China
3. Anhui Fubore Pharmaceutical & Chemical Co. Ltd., Bengbu 233030, China

Received Date: 2012-06-11

Fund Project:

Keywords:

Abstract: On the basis of the previous experiment, black carbon was made from wheat straw with three different temperatures (550, 650, 750℃) under the nitrogen protection. Their particle sizes, structures, and morphologies were also tested by X-ray diffraction (XRD), and scanning electron microscopy (SEM), aiming to examine the effect of removing the ammonia nitrogen in pyrazolone wastewater. The experiments show that the sequence and crystallization degree of the crystal were changed by straw black carbon at 650℃. Micropore volume was distributed on the duct loosely, uniformly and regularly. Specific surface area was larger than the other. There was a certain number of nanoscale black carbon particles. The adsorptive characteristic of straw black at 650℃ was better than that at 750℃ and 550℃. The highest adsorption rate was 95.31%. The optimum conditions for absorptive power of straw black carbon at 650℃ are as the follows: the adsorptive temperature of 35℃; the adsorptive time of 4 h ; and the oscillation frequency of 100 r/min. With faster adsorption rate and wider applicability, straw black carbon at 650℃ is a good material to treat ammonia nitrogen wastewater.
