泥磷中温蒸馏提取黄磷装置改进效果的研究

,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

李志林, 江映翔, 李桂镇, 杨永珠, 陈金梦, 孙文灏, 李江燕. 泥磷中温蒸馏提取黄磷装置改进效果的研究[J]. 环境工程学报, 2013, 7(11): 4553-4558.
引用本文: 李志林, 江映翔, 李桂镇, 杨永珠, 陈金梦, 孙文灏, 李江燕. 泥磷中温蒸馏提取黄磷装置改进效果的研究[J]. 环境工程学报, 2013, 7(11): 4553-4558.
shu
Li Zhilin, Jiang Yingxiang, Li Guizhen, Yang Yongzhu, Chen Jinmeng, Sun Wenhao, Li Jiangyan. Study on device improvement effect of yellow phosphorus extraction from phosphorus sludge at moderate high temperature[J]. Chinese Journal of Environmental Engineering, 2013, 7(11): 4553-4558.
Citation: Li Zhilin, Jiang Yingxiang, Li Guizhen, Yang Yongzhu, Chen Jinmeng, Sun Wenhao, Li Jiangyan. Study on device improvement effect of yellow phosphorus extraction from phosphorus sludge at moderate high temperature[J]. Chinese Journal of Environmental Engineering, 2013, 7(11): 4553-4558.
shu

泥磷中温蒸馏提取黄磷装置改进效果的研究

  • 1.

    昆明理工大学环境科学与工程学院, 昆明 650000

  • 2.

    云南民族大学化学与生物技术学院, 昆明 650000

  • 基金项目:

    云南省科委资助项目(99067)

  • 中图分类号: X705

Study on device improvement effect of yellow phosphorus extraction from phosphorus sludge at moderate high temperature

  • 1.

    Faculty of Environmental Science and Engineering, Kunming University of Science and Technology, Kunming 650000, China

  • 2.

    Faculty of Chemistry and Biotechnology, Yunnan University of Nationalities, Kunming 650000, China

  • Fund Project:

  • 摘要: 针对泥磷中温蒸馏提取黄磷前期实验装置存在的问题,通过对装置的传动齿轮位置移动改进来达到受力平衡和采用机械密封与软填料密封组合的方式对旋转密封接头重新设计,同时检测改进后实验装置的气密性并进行了泥磷中温蒸馏提取黄磷实验。结果表明,在密封性检测实验中,改进后的实验装置3 h之后出现负压,比前期实验装置缩短0.5 h,冷凝器温度略有下降,压差与前期相比增加约100 mm水柱。黄磷提取实验中,改进的实验装置反应时间比前期缩短0.5 h,黄磷蒸馏温度下降,压差增大。最终黄磷的回收率为97.1%,比前期实验增加0.2%;纯度为99.95%,比前期实验提高0.01%,砷含量为0.009561%,比前期实验减少0.0019%,黄磷等级达到优等,实验装置的改进是有效的。
    Abstract: Analyzing the problems of former experimental device in yellow phosphorus extraction from phosphorus sludge at moderate high temperature, we redesigned rotating seal joint on two aspects: transmission gear position to achieve the device rotating balance and combination with mechanical seal and soft fill packing seal to enhance device joint sealing properties. At the same time, the air tightness property of the device was detected to test the improved experimental device and yellow phosphorus extraction experiment was done at moderate high temperature. The results indicated that in tightness test experiment, negative pressure of the improved experimental device appeared after three hour heating, which is 0.5 hours shorter than former experimental device. Condenser's inner temperature declined slightly and pressure difference increased approximately 100 mm water column compared with the former device. In yellow phosphorus extraction experiment, reaction time of the improved experimental device was 0.5 hours shorter than that of the former device. Therefore, distillation temperature of yellow phosphorus dropped and pressure difference increased. Final yellow phosphorus recovery rate is 97.1%, which is 0.2% higher than the previous experiment. Purity of yellow phosphorus is 99.95%, 0.01% higher than the previous experiment and arsenic concentration is 0.009561%, 0.0019% less than previous experiment. Excellence grade of yellow phosphorus concentrate indicated well efficiency of the improved experimental device.
  • 加载中
  • [1] 武汉化工原料厂.黄磷"三废"综合利用.资源节约和综合利用,1989,3(1):28-31 Chemicals factory in Wuhan. Comprehensive utilization of yellow phosphorus "three wastes". Resources Conservation and Comprehensive Utilization, 1989,3(1): 28-31 (in Chinese)
    [2] 李旺华.泥磷动态蒸馏工艺设计.江西化工,1999(4): 24-25 Li W.H. Process design of phosphorus sludge dynamic distillation. Jiangxi Chemical Industry, 1999(4): 24-25 (in Chinese)
    [3] 宋发志.从泥磷中回收黄磷.湖北化工,1996(3):38 Song F.Z. Yellow phosphorus recovery from the phosphorus sludge. Hubei Chemical Industry, 1996(3):38(in Chinese)
    [4] 刘康莲.泥磷中黄磷的提取方法研究.贵州化工, 2011, 36(4):19-21 Liu K.L.Study on extraction methods of Yellow phosphorus in phosphorus mud. Guizhou Chemical Industry, 2011,36(4):19-21(in Chinese)
    [5] 刘书勤,赵军.泥磷的综合利用.化工环保,1992,12(2):83-89 Liu S.Q., Zhao J. Phosphorus sludge comprehensive utilization. Chemical Industry Environmental Protection, 1992,12(2): 83-89(in Chinese)
    [6] 刘云根,江映翔,周平.泥磷中温真空提取黄磷的技术研究.云南化工,2005,32(2):12-14 Liu Y.G., Jiang Y.X., Zhou P. Extraction of yellow phosphorus from phosphorus slurry at mid-temperature and vacuum. Yunnan Chemical Industry, 2005,32(2):12-14 (in Chinese)
    [7] 罗忠新,王雷,杨春辉.石油化工釜用机械密封的失效分析与对策.聚氯乙烯,2000,(2):54-57 Luo Z.X., Wang L., Yang C.H. Mechanical seal failure analysis and countermeasures of petrochemical kettle. PVC, 2000,(2):54-57(in Chinese)
    [8] 韩金涛,江映翔,罗芳.泥磷中温提取黄磷研究.广西轻工业,2009,(11):91-92 Han J.T., Jiang Y.X., Luo F. Study on yellow phosphorus extraction from phosphorus sludge at moderate temperature.Guangxi Journal of Light Industry, 2009,(11): 91-92(in Chinese)
    [9] 付兴旺.浅谈化工设备机械密封的泄漏问题与对策.中国科技博览,2010,(15):215 Fu X.W. Problems and countermeasures on mechanical seal leakage of chemical equipment. China Science and Technology Expo, 2010,(15):215(in Chinese)
    [10] 胡黄卿.软填料密封常用材料及其选择.机械研究与应用,2004,17(1):34-37 Hu H.Q. Commonly used materials and their choice of soft packing seal. Mechanical Research & Application, 2004, 17 (1):34-37(in Chinese)
    [11] R. K. Miller, A. A. Pollock, D. J. Watts, et al. A reference standard for the development of acoustic emission pipeline leak detection techniques. NDT&E Internatioal, 1999. 1-8
    [12] 夏成洋,黄德镛,林友,等.泥磷回收制磷危险性分析与防治.无机盐工业,2007,39(11):44-46 Xia C.Y., Huang D.Y., Lin Y., et al. Risk analysis and prevention of yellow phosphorus production by recovery of phosphorous slurry. Inorganic Chemicals Industy, 2007, 39(11):44-46(in Chinese)
    [13] GB 11893-89.水质 总磷的测定 钼酸铵分光光度法
    [14] GB/T15555.3-1995.固体废物 砷的测定 二乙基二硫代氨基甲酸银分光光度法
    [15] 朱正德.对泄漏检测中全密封样件实施校准的探索与实践.组合机床与自动化加工技术,2000,(12):3-6 Zhu Z.D. Exploration and practice on implementation calibration of hermetically sealed sample in leak detection. Modular Machine Tool & Automatic Manufacturing Technique,2000,(12):3-6(in Chinese)
    [16] 王平艳,刘谋胜,刘永成,等.真空蒸馏制取低砷黄磷的研究.昆明理工大学学报(理工版),2003,28(2):12-13 Wang P.Y., Liu M.S., Liu Y.C., et al. Theoretical study on the process of low-arsenic yellow phosphorus produced by vacuum distillation. Journal of Kunming University of Science and Technology(Science and Technology), 2003,28(2):12-13(in Chinese)
    [17] GB7816-1998.工业黄磷
