银钛共负载型光催化材料降解甲基橙废水

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

徐荣, 葛骁, 郭海宁, 束正华, 封克, 王小治. 银钛共负载型光催化材料降解甲基橙废水[J]. 环境工程学报, 2014, 8(1): 150-156.
引用本文: 徐荣, 葛骁, 郭海宁, 束正华, 封克, 王小治. 银钛共负载型光催化材料降解甲基橙废水[J]. 环境工程学报, 2014, 8(1): 150-156.
shu
Xu Rong, Ge Xiao, Guo Haining, Shu Zhenghua, Feng Ke, Wang Xiaozhi. Photocatalytic degradation of methyl orange wastewater by co-deposited(Ag+-TiO2-EP) material[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 150-156.
Citation: Xu Rong, Ge Xiao, Guo Haining, Shu Zhenghua, Feng Ke, Wang Xiaozhi. Photocatalytic degradation of methyl orange wastewater by co-deposited(Ag+-TiO2-EP) material[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 150-156.
shu

银钛共负载型光催化材料降解甲基橙废水

  • 1.

    江苏省环境材料与环境工程重点实验室, 扬州大学环境科学与工程学院, 扬州

  • 基金项目:

    污染控制与资源化研究国家重点实验室开放课题（PCRRF11002）

    扬州市科技攻关项目（YZ2011111）

    扬州市环保科技项目（YHK1204）

  • 中图分类号: X703

Photocatalytic degradation of methyl orange wastewater by co-deposited(Ag+-TiO2-EP) material

  • Fund Project:

  • 摘要: 以膨胀珍珠岩为载体，采用溶胶凝胶法对其进行负载，制备出不同类型的光催化材料（TiO2-EP、Ag+-TiO2-EP），并在模拟日光条件下，研究其对甲基橙溶液的降解效果。结果表明，浸渍3次且担载0.04% Ag+的负载型TiO2光催化活性最高，在光催化剂用量为0.3 g，20 mL初始浓度为10 mg/L甲基橙溶液光照4 h后降解率可达81.6%，且甲基橙的光催化降解服从一级动力学方程。回收3次后仍有较强的活性，其2 h降解率为24.8%。
    Abstract: Different floating photocatalysts including TiO2-EP and Ag+-TiO2-EP were successfully synthesized by Sol-Gel method using tetrabutyl titanate as precursor and expanded perlite (EP) as support. Under simulative sunlight, the degradation rate of methyl orange by different photocatalysts, as well as the effect of different loading times, the dosage and the initial concentration of methyl orange were investigated. The results showed that Ag+-TiO2-EP which modified three times with Ag+-TiO2 (0.04% Ag+) had the highest photocatalyst ability. The degradation rate of the methyl orange solution (20 mL, 10 mg/L) which were decomposed by Ag+-TiO2-EP (0.3 g) in 4 h was 81.6%. The reaction of photocatalysis for methyl orange can be expressed as first-order kinetic mode within the concentration range of methyl orange between 5 mg/L and 15 mg/L. Ag+-TiO2-EP still had the relatively higher photocatalytic activity after three times recycling and the degradation rate of methyl orange was 24.8% within 2 h.
  • 加载中
  • [1] 刘梅红. 印染废水处理技术研究进展. 纺织学报, 2007, 28(1): 116-119+128 Liu M.H. Advances in dyeing and printing wastewater treatment technologies. Journal of Textile Research, 2007, 28(1): 116-119+128(in Chinese)
    [2] 侯文俊,余健. 印染废水处理技术的研究新进展. 化工环保, 2004, 24(z1): 105-107 Hou W.J., Yu J. New progress in research of the printing and dyeing wastewater treatment technology. Environmental Protection of Chemical Industry, 2004, 24(z1): 105-107(in Chinese)
    [3] 王成国,邓兵. 纳米TiO2光催化氧化处理直接耐晒翠蓝染色废液. 印染, 2004, 30(7): 10-12 Wang C.G., Deng B. Degradation of phthalocyanine dye by photocatalysis oxidation of nano TiO2. Dyeing and Finishing, 2004, 30(7): 10-12(in Chinese)
    [4] 于海霞,赵立杰,翟明翚, 等. TiO2光催化/电-Fenton法降解印染废水的研究. 齐齐哈尔大学学报(自然科学版), 2012, 28(3): 4-6+27 Yu H.X., Zhao L.J., Zhai M.H., et al. Study on the degradation of dyeing waste water by photocatalysis/electro-fenton. Journal of Qiqihar University(Natural Science Edition), 2012, 28(3): 4-6+27(in Chinese)
    [5] 张理元,刘钟馨,于晓龙, 等. Ag掺杂纳米二氧化钛的制备及光催化性能研究. 功能材料, 2010, 41(12): 2169-2173 Zhang L.Y., Liu Z.X., Yu X.L., et al. Preparation and photocatalytic property of Ag-doped TiO2。Journal of Functional Materials, 2010, 41(12): 2169-2173(in Chinese)
    [6] 景伟文,李君,康志强, 等. Ag掺杂改性TiO2催化降解水体中的邻苯二甲酸二甲酯. 环境科学技术, 2012, 35(7): 112-116 Jing Weiwen,Li Jun,Kang Zhiqiang,et al.Degradation of dimethyl phthalate in aqueous solution by Ag doping TiO2. Environmental Science & Technology, 2012, 35(7): 112-116(in Chinese)
    [7] Reddy M.P., Venugopal A., Subrahmanyam M. Hydroxyapatite-supported Ag-TiO2 as escherichia coli disinfection photocatalyst. Water Res., 2007, 41(2): 379-386
    [8] Skmen M., Candan F., SÜmer Z. Disinfection of E.coli by the Ag-TiO2/UV system: Lipidperoxidation. J. Photoch. and Photobio. A, 2001, 143(2-3): 241-244
    [9] 杨莹琴,陈慧娟. 膨润土负载掺铁氧化钛光降解苯酚. 光谱实验室, 2012, 29(3): 1506-1508 Yang Y.Q., Chen H.J. Photodegradation of phenol by bentonite loaded iron doped titanium oxide. Chinese Journal of Spectroscopy Laboratory, 2012, 29(3): 1506-1508(in Chinese)
    [10] 胡校冬,邓桦. 活性炭负载TiO2的制备及其光催化活性研究. 炭素技术, 2012, 31(3): 10-13 Hu X.D., Deng H.Preparation of activated carbon loaded TiO2 and its photocatalytic activity. Carbon Techniques, 2012, 31(3): 10-13(in Chinese)
    [11] Doˇ[]gan M.,Alkan M. Removal of methyl violet from aqueous solution by perlite. J. Colloid. and Interf. Sci., 2003, 267(1): 32-41
    [12] Chakir A.,Bessiere J.,Kacemi K.E.L., et al. A comparative study of the removal of trivalent chromium from aqueous solutions by bentonite and expanded perlite. J. Hazard. Mater., 2002, 95(1-2): 29-46
    [13] Hosseini S.N.,Borghei S.M.,Vossoughi M.,et al. Immobilization of TiO2 on perlite granules for photocatalytic degradation of phenol. Appl. Catal. B-Environ., 2007, 74(1-2): 53-62
    [14] 雍卫卫,王小治,高芡芡, 等. 纳米TiO2/EP光催化降解罗丹明B废水的研究. 环境工程学报, 2012, 6(1): 185-190 Yong W.W., Wang X.Z., Gao Q.Q., et al. Photocatalytic degradation of Rhodamine B by nanoTiO2-expanded pearlite. Chinese Journal of Environmental Engineering, 2012, 6(1): 185-190(in Chinese)
    [15] 胡华国,王玉萍,顾凌燕, 等. 活性炭负载N掺杂TiO2光催化剂的制备及其可见光催化活性研究. 南京师大学报(自然科学版), 2010, 33(1): 52-58 Hu G.H., Wang Y.P., Gu L.Y., et al. Preparation of nitrogen-doped TiO2/activated carbon and photocatalytic activity under visible light. Journal of Nanjing Normal University(Natural Science Edition), 2010, 33(1): 52-58(in Chinese)
    [16] 李晓平,徐宝琨,刘国范, 等. 纳米TiO2光催化降解水中有机污染物的研究与发展. 功能材料, 1999, 30(3): 19-22+5 Li X.P.,Xu B.K., Liu G.F., et al. The research and development of photocatalytic degradation of organic contaminant over nanosized TiO2 in water. Journal of Functional Materials, 1999, 30(3): 19-22+5(in Chinese)
    [17] Natalie S.,Anna E.,Olga R.. Synthesis and characterization of photocatalytic porous Fe3+/TiO2 layers on glass. J. Sol-Gel Sci. Techn., 2001, 22 (1-2): 109-113
    [18] 曹怀宝,卢园,王剑波, 等. 沸石负载TiO2的光催化性能. 工业催化, 2007, 15(8): 40-43 Cao H.B., Lu Y., Wang J.B. Photocatalytic properties of titania supported on zeolite. Industrial Catalysis, 2007,15(8): 40-43(in Chinese)
    [19] 严新,吴俊,陈华, 等. TiO2光催化降解甲基橙废水性能研究. 合肥工业大学学报(自然科学版), 2011, 34(3): 429-432 Yan X., Wu J., Chen H., et al. Photocatalytic degradation property of TiO2 in treating methyl orange wastewater. Journal of Hefei University of Technology(Natural Science),2011, 34(3): 429-432(in Chinese)
    [20] 王怡中,符雁,汤鸿霄. 二氧化钛悬浆体系太阳光催化降解甲基橙研究. 环境科学学报, 1999, 19(1): 63-67 Wang Y.Z., Fu Y., Tang H.X. Solar photocatalytic oxidation of methyl orange with TiO2 suspension. Acta Scientiae Circumstantiae, 1999, 19(1): 63-67 (in Chinese)
    [21] 侯新刚,薛彩红,哈敏. Ag+掺杂TiO2纳米粉体制备及光催化性能研究. 粉末冶金技术, 2008, 26(4): 291-295 Hou X.G., Xue C.H., Ha M. Preparation of TiO2 nanoparticles doped with Ag+ and study on its photocatalytic performance.Powder Metallurgy Technology, 2008, 26(4): 291-295(in Chinese)
    [22] 尤先锋,陈锋,张金龙. 银促进的TiO2光催化降解甲基橙. 催化学报, 2006, 27(3): 270-274 You X.F., Chen F., Zhang J.L. Photocatalytic degradation of methyl orange on TiO2 promoted by silver.Chinese Journal of Catalysis, 2006, 27(3): 270-274(in Chinese)
    [23] Lee M.S., Hong S.S., Mohseni M. Synthesis of photocatalytic nanosized TiO2-Ag particles with sol-gel method using reduction agent. J. Mol. Catal. A-Chem., 2005, 242(1-2): 135-140
    [24] 许晶晶,朱平武,赵丽, 等. Ag/TiO2中空纳米纤维光催化材料的制备及表征. 化学学报, 2011, 69(5): 585-590 Xu J.J., Zhu P.W., Zhao L., et al. Preparation and characterization of Ag/TiO2 hollow nano-fiber photocatalytic material. Acta Chimica Sinica, 2011, 69(5): 585-590(in Chinese)
    [25] Sung-Suh H. M.,Choi J. R.,Hah H. J., et al. Comparison of Ag deposition effects on the photocatalytic activity of nanoparticulate TiO2 under visible and UV light irradiation. J.Photoch. and Photobio. A,2004, 163 (1-2): 37-44
    [26] 王九思,蒲艳玲,李玉金, 等. 负载型TiO2光催化氧化降解甲基橙的实验研究. 甘肃科学学报, 2006, 18(3): 120-122 Wang J.S., Pu Y.L., Li Y.J., et al. Study on photocatalytic degradation of methyl orange with immobilized titanium dioxide. Journal of Gansu Sciences, 2006, 18(3): 120-122( in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1658
  • HTML全文浏览数:  894
  • PDF下载数:  816
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-03-06
  • 刊出日期:  2014-01-03
徐荣, 葛骁, 郭海宁, 束正华, 封克, 王小治. 银钛共负载型光催化材料降解甲基橙废水[J]. 环境工程学报, 2014, 8(1): 150-156.
引用本文: 徐荣, 葛骁, 郭海宁, 束正华, 封克, 王小治. 银钛共负载型光催化材料降解甲基橙废水[J]. 环境工程学报, 2014, 8(1): 150-156.
shu
Xu Rong, Ge Xiao, Guo Haining, Shu Zhenghua, Feng Ke, Wang Xiaozhi. Photocatalytic degradation of methyl orange wastewater by co-deposited(Ag+-TiO2-EP) material[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 150-156.
Citation: Xu Rong, Ge Xiao, Guo Haining, Shu Zhenghua, Feng Ke, Wang Xiaozhi. Photocatalytic degradation of methyl orange wastewater by co-deposited(Ag+-TiO2-EP) material[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 150-156.
shu

银钛共负载型光催化材料降解甲基橙废水

  • 1. 江苏省环境材料与环境工程重点实验室, 扬州大学环境科学与工程学院, 扬州
  • 收稿日期:  2013-03-06
基金项目:

污染控制与资源化研究国家重点实验室开放课题（PCRRF11002）

扬州市科技攻关项目（YZ2011111）

扬州市环保科技项目（YHK1204）

摘要: 以膨胀珍珠岩为载体，采用溶胶凝胶法对其进行负载，制备出不同类型的光催化材料（TiO2-EP、Ag+-TiO2-EP），并在模拟日光条件下，研究其对甲基橙溶液的降解效果。结果表明，浸渍3次且担载0.04% Ag+的负载型TiO2光催化活性最高，在光催化剂用量为0.3 g，20 mL初始浓度为10 mg/L甲基橙溶液光照4 h后降解率可达81.6%，且甲基橙的光催化降解服从一级动力学方程。回收3次后仍有较强的活性，其2 h降解率为24.8%。
