消毒剂和溶解氧对管网铁释放影响的中试研究

,  ,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

鲁智礼, 王刚亮, 石宝友, 孙慧芳, 徐硕, 顾军农, 李玉仙, 王东升. 消毒剂和溶解氧对管网铁释放影响的中试研究[J]. 环境工程学报, 2014, 8(4): 1410-1416.
引用本文: 鲁智礼, 王刚亮, 石宝友, 孙慧芳, 徐硕, 顾军农, 李玉仙, 王东升. 消毒剂和溶解氧对管网铁释放影响的中试研究[J]. 环境工程学报, 2014, 8(4): 1410-1416.
shu
Lu Zhili, Wang Gangliang, Shi Baoyou, Sun Huifang, Xu Shuo, Gu Junnong, Li Yuxian, Wang Dongsheng. Pilot study on effects of disinfectant and dissolved oxygen on iron release in distribution system[J]. Chinese Journal of Environmental Engineering, 2014, 8(4): 1410-1416.
Citation: Lu Zhili, Wang Gangliang, Shi Baoyou, Sun Huifang, Xu Shuo, Gu Junnong, Li Yuxian, Wang Dongsheng. Pilot study on effects of disinfectant and dissolved oxygen on iron release in distribution system[J]. Chinese Journal of Environmental Engineering, 2014, 8(4): 1410-1416.
shu

消毒剂和溶解氧对管网铁释放影响的中试研究

  • 1.

    华北水利水电大学环境与市政工程学院, 郑州 450011

  • 2.

    中国科学院生态环境研究中心环境水质学国家重点实验室, 北京 100085

  • 3.

    北京市自来水集团有限责任公司, 北京 100031

  • 基金项目:

    国家“水体污染控制与治理”科技重大专项（2012ZX-07404-002，2012ZX07408-002）

    国家自然科学基金资助项目（51178450）

  • 中图分类号: TU991.33

Pilot study on effects of disinfectant and dissolved oxygen on iron release in distribution system

  • 1.

    School of Environmental and Municipal Engineering, North China University of Water Resources and Electric Power, Zhengzhou 450011, China

  • 2.

    State Key Laboratory of Environmental Aquatic Chemistry, Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences, Beijing 100085, China

  • 3.

    Beijing Water Works Group, Beijing 100031, China

  • Fund Project:

  • 摘要: 针对南水北调中线水源地丹江口水库水调入受水区城市后，可能引起管网铁腐蚀产物释放的问题，从北方某受水区城市的实际管网中挖取了原通地下水的3个地点的铸铁管道，在丹江口搭建了中试模拟系统，开展水源切换以及消毒剂和溶解氧对管网铁释放影响的中试研究。结果表明，实验管道管垢较薄且稳定性较差，在水源切换初期有"黄水"现象发生；增加进水硫酸根浓度，管网系统出水总铁浓度和浊度均有所增加；在0.3~3.6 mg/L的范围内改变进水自由氯浓度对实验系统铁释放的影响没有明显的规律；但进水氯胺浓度从1.3 mg/L增加到2.0 mg/L时，YS系统的铁释放有所升高；进水溶解氧浓度从8 mg/L增加到15 mg/L时，实验系统的铁释放都有明显的降低，但再增加到20 mg/L时，铁释放反而有所升高。
    Abstract: Water source switch to Danjiangkou reservoir (the middle route source area of the South-to-North Water Diversion Project in China) water might cause increased iron release in distribution systems of water receiving areas.Cast iron pipes transporting groundwater were harvested from three sites of existing distribution system of a northern city,and pipe-loop distribution systems were established in Danjiangkou.Pilot study was conducted to observe the outcomes of source water switch,and the effects of different disinfectants and dissolved oxygen concentration on iron release behaviors were investigated.Results show that the corrosion scales on the test pipes are relatively thin and less stable; at the early stage of water source switch,apparent "red water" occurs.The effluent iron concentration and turbidity increase accordingly with the increase of sulfate concentration.The change of iron release with free chlorine concentration change in the range of 0.3~3.6 mg/L has no clear trend.While iron release of YS system increases significantly as chloramine concentration is raised from 1.3 to 2.0 mg/L. When dissolved oxygen increases from 8 mg/L to 15 mg/L,iron release decreases significantly,but further increase of dissolved oxygen to 20 mg/L results in iron release increase.
  • 加载中
  • [1] Edwards M.Controlling corrosion in drinking water distribution systems:A grand challenge for 21st century.Water Science & Technology, 2004, 49(2):1-8
    [2] 张晓健, 牛璋彬.给水管网中铁稳定性问题及其研究进展.中国给水排水, 2006, 22(2):13-16 Zhang X.J., Niu Z.B.Progress in the study of the iron stability problem in drinking water distribution system.China Water & Wastewater, 2006, 22(2):13-16(in Chinese)
    [3] Vreeburg J.H., Boxall J.B.Discolouration in potable water distribution systems:A review.Water Research, 2007, 41(3):519-529
    [4] Reiber S., Poulsom S., Perry S.A.L., et al.A general framework for corrosion control based on utility experience.Denver:AWWA Research Foundation, 1997
    [5] 王洋, 张晓健, 陈超, 等.水源切换引起给水管网黄水问题原因分析.环境科学, 2009, 30(12):3555-3561 Wang Y., Zhang X.J., Chen C., et al.Case study of red water phenomenon in drinking water distribution systems caused by water source switch.Environmental Science, 2009, 30(12):3555-3561(in Chinese)
    [6] 石宝友, 李涛, 顾军农, 等.北方某市水源更换过程中管网黄水产生机制的探讨.供水技术, 2010, 4(4):12-15 Shi B.Y., Li T., Gu J.N., et al.Mechanism of distribution system red water occurred during the source water switch in a city of north China.Water Technology, 2010, 4(4):12-15(in Chinese)
    [7] 石宝友, 鲁智礼, 徐硕, 等.丹江口水源对北方某市管网铁释放影响的研究.中国给水排水, 2013, 29(11):33-39 Shi B.Y., Lu Z.L., Xu S., et al.Effect of Danjiangkou reservoir water source on iron release in water distribution system of a northern Chinese city.China Water & Wastewater, 2013, 29(11):33-39(in Chinese)
    [8] 鲁智礼, 徐硕, 石宝友, 等.水源切换对管网铁释放影响的中试模拟研究.给水排水, 2013, 39(5):146-150 Lu Z.L., Xu S., Shi B.Y., et al.Pilot study on the effect of source water switch on iron release in drinking water distribution systems.Water & Wastewater Engineering, 2013, 39(5):146-150(in Chinese)
    [9] 杨帆, 石宝友, 王东升, 等.水质化学组分变化对管道铁释放及管垢特征的影响.中国给水排水, 2012, 28(23):59-64 Yang F., Shi B.Y., Wang D.S., et al.Effect of water chemistry changes on iron release and corrosion scale properties of old cast iron pipes.China Water & Wastewater, 2012, 28(23):59-64(in Chinese)
    [10] 米子龙, 张晓健, 陈超, 等.硫酸根和碱度变化对管网铁释放的影响.中国给水排水, 2012, 28(1):31-34 Mi Z.L., Zhang X.J., Chen Chao, et al.Influence of sulphate and alkalinity change on iron release in drinking water distribution system.China Water & Wastewater, 2012, 28(1):31-34
    [11] Sarin P., Snoeyink V.L., Lytle D., et al.Iron corrosion scales:Model for scale growth, iron release, and colored water formation.Journal of Environmental Engineering, 2004, 130(4):364-373
    [12] Yang F., Shi B.Y., Gu J.N., et al.Morphological and physicochemical characteristics of iron corrosion scales formed under different water source histories in a drinking water distribution system.Water Research, 2012, 46(16):5423-5433
    [13] Sontheimer H., Koile W., Snoeyink V.L.The siderite model of the formation of corrosion-resistant scales.Journal AWWA, 1981, 73(11):572-579
    [14] Frateur I., Deslouis C., Kiene L., et al.Free chlorine consumption induced by cast iron corrosion in drinking water distribution systems.Water Research, 1999, 33(8):1781-1790
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2241
  • HTML全文浏览数:  1519
  • PDF下载数:  771
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-05-12
  • 刊出日期:  2014-03-28
鲁智礼, 王刚亮, 石宝友, 孙慧芳, 徐硕, 顾军农, 李玉仙, 王东升. 消毒剂和溶解氧对管网铁释放影响的中试研究[J]. 环境工程学报, 2014, 8(4): 1410-1416.
引用本文: 鲁智礼, 王刚亮, 石宝友, 孙慧芳, 徐硕, 顾军农, 李玉仙, 王东升. 消毒剂和溶解氧对管网铁释放影响的中试研究[J]. 环境工程学报, 2014, 8(4): 1410-1416.
shu
Lu Zhili, Wang Gangliang, Shi Baoyou, Sun Huifang, Xu Shuo, Gu Junnong, Li Yuxian, Wang Dongsheng. Pilot study on effects of disinfectant and dissolved oxygen on iron release in distribution system[J]. Chinese Journal of Environmental Engineering, 2014, 8(4): 1410-1416.
Citation: Lu Zhili, Wang Gangliang, Shi Baoyou, Sun Huifang, Xu Shuo, Gu Junnong, Li Yuxian, Wang Dongsheng. Pilot study on effects of disinfectant and dissolved oxygen on iron release in distribution system[J]. Chinese Journal of Environmental Engineering, 2014, 8(4): 1410-1416.
shu

消毒剂和溶解氧对管网铁释放影响的中试研究

  • 1.  华北水利水电大学环境与市政工程学院, 郑州 450011
  • 2.  中国科学院生态环境研究中心环境水质学国家重点实验室, 北京 100085
  • 3.  北京市自来水集团有限责任公司, 北京 100031
  • 收稿日期:  2013-05-12
基金项目:

国家“水体污染控制与治理”科技重大专项（2012ZX-07404-002，2012ZX07408-002）

国家自然科学基金资助项目（51178450）

摘要: 针对南水北调中线水源地丹江口水库水调入受水区城市后，可能引起管网铁腐蚀产物释放的问题，从北方某受水区城市的实际管网中挖取了原通地下水的3个地点的铸铁管道，在丹江口搭建了中试模拟系统，开展水源切换以及消毒剂和溶解氧对管网铁释放影响的中试研究。结果表明，实验管道管垢较薄且稳定性较差，在水源切换初期有"黄水"现象发生；增加进水硫酸根浓度，管网系统出水总铁浓度和浊度均有所增加；在0.3~3.6 mg/L的范围内改变进水自由氯浓度对实验系统铁释放的影响没有明显的规律；但进水氯胺浓度从1.3 mg/L增加到2.0 mg/L时，YS系统的铁释放有所升高；进水溶解氧浓度从8 mg/L增加到15 mg/L时，实验系统的铁释放都有明显的降低，但再增加到20 mg/L时，铁释放反而有所升高。
