Vis/Co-TiO2/KHSO5体系Fenton-光催化协同降解苯酚

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

陈晴空, 谢志刚, 吉芳英, 郭倩, 刘亭役, 徐璇. Vis/Co-TiO2/KHSO5体系Fenton-光催化协同降解苯酚[J]. 环境工程学报, 2014, 8(5): 1749-1754.
引用本文: 陈晴空, 谢志刚, 吉芳英, 郭倩, 刘亭役, 徐璇. Vis/Co-TiO2/KHSO5体系Fenton-光催化协同降解苯酚[J]. 环境工程学报, 2014, 8(5): 1749-1754.
shu
Chen Qingkong, Xie Zhigang, Ji Fangying, Guo Qian, Liu Tingyi, Xu Xuan. Synergistic effect of Fenton-photocatalysis through degradation of phenol by Vis/Co-TiO2/KHSO5 reaction system[J]. Chinese Journal of Environmental Engineering, 2014, 8(5): 1749-1754.
Citation: Chen Qingkong, Xie Zhigang, Ji Fangying, Guo Qian, Liu Tingyi, Xu Xuan. Synergistic effect of Fenton-photocatalysis through degradation of phenol by Vis/Co-TiO2/KHSO5 reaction system[J]. Chinese Journal of Environmental Engineering, 2014, 8(5): 1749-1754.
shu

Vis/Co-TiO2/KHSO5体系Fenton-光催化协同降解苯酚

  • 1.

    重庆大学三峡库区生态环境教育部重点实验室, 重庆 400045

  • 2.

    重庆文理学院材料与化工学院, 重庆 402160

  • 3.

    林同棪国际工程咨询(中国)有限公司, 重庆 401121

  • 基金项目:

    国家自然科学基金资助项目（51108483）

    中央高校基本科研业务费专项资金项目（CDJXS12210002）

    教育部科技创新工程重大项目培育资金项目（708071）

    重庆市自然科学基金资助项目（cstcjjA20002）

  • 中图分类号: X703

Synergistic effect of Fenton-photocatalysis through degradation of phenol by Vis/Co-TiO2/KHSO5 reaction system

  • 1.

    Key Laboratory of Three Gorges Reservoir Region's Eco-Environment, Ministry of Education, Chongqing University, Chongqing 400045, China

  • 2.

    College of Materials and Chemical Engineering, Chongqing University of Arts and Sciences, Chongqing 402160, China

  • 3.

    T. Y. Lin International Engineering Consulting (China) Co. Ltd., Chongqing 401121, China

  • Fund Project:

  • 摘要: 通过溶胶-凝胶法制备了同时具有可见光（Vis）光催化和Fenton催化双重活性的Co-TiO2催化剂。通过对比Vis/Co-TiO2/KHSO5、Co-TiO2/KHSO5和Vis/Co-TiO2 3种体系对苯酚的降解效果，Vis/Co-TiO2/KHSO5表现出明显的Fenton-光催化协同作用。进一步研究pH值、KHSO5与苯酚摩尔比（nKHSO5：nC6H6O）和Co-TiO2投加量（mCo-TiO2）对Fenton-光催化协同降解苯酚效果的影响。结果表明，pH=6.9、nKHSO5：nC6H6O=10：1、mCo-TiO2=1.0 g/L时，降解率达100%。最后，结合XRD、XPS和UV-DRS等手段和催化活性实验数据分析了Vis/Co-TiO2/KHSO5体系的催化机理。
    Abstract: The Co-TiO2 catalyst, which has both Fenton and visible light phocatalytic activities, was prepared by the sol-gel method. Its catalytic activities were measured by the degradation of phenol through comparative experiments of Vis/Co-TiO2/KHSO5, Co-TiO2/KHSO5 and Vis/Co-TiO2 reaction systems. The Vis/Co-TiO2/KHSO5 process represented the obvious synergistic effect of Fenton and photocatalysis, and the results showed that when the pH=6.9, nKHSO5:nC6H6O=10:1 and mCo-TiO2=1.0 g/L, the degradation rate of phenol reached 100%. Finally, the catalytic mechanism was also studied through XRD, UV-DRS, XPS and phenol degradation tests.
  • 加载中
  • [1] 吴忠标. 环境催化原理及应用. 北京: 化学工业出版社, 2006
    [2] Riga A., Soutsas K., Ntampegliotis K., et al. Effect of system parameters and of inorganic salts on the decolorization and degradation of Procion Hexl dyes. Comparison of H2O2/UV, Fenton, UV/Fenton, TiO2/UV and TiO2/UV/H2O2 processes. Desalination, 2007, 211 (1-3): 72-86
    [3] Selvam K., Muruganandham M., Sobana N., et al. Enhancement of UV-assisted photo-Fenton degradation of reactive orange 4 using TiO2-P25 nanoparticles. Sep. Purif. Technol., 2007, 54 (2): 241-247
    [4] Cong Y. Q., Li Z., Zhang Y., et al. Synthesis of α-Fe2O3/TiO2 nanotube arrays for photoelectro-Fenton degradation of phenol. Chem. Eng. J., 2012, 191: 356-363
    [5] Anipsitakis G. P., Dionysiou D. D., Gonzalez M. A. Cobalt-mediated activation of peroxymonosulfate and sulfate radical attack on phenolic compounds. Implications of chloride ions. Environ. Sci. & Technol., 2006, 40 (3): 1000-1007
    [6] Chan K. H., Chu W. Degradation of atrazine by cobalt-mediated activation of peroxymonosulfate: Different cobalt counteranions in homogenous process and cobalt oxide catalysts in photolytic heterogeneous process. Water Res., 2009, 43 (9): 2513-2521
    [7] 宋林云, 吴玉程, 李云, 等. 介孔Co-TiO2 的制备及其光催化性能研究. 功能材料, 2008, 39 (1): 32-35 Song Y. L., Wu Y. C., Li Y., et al. Preparation and photocatalystic activity of the mesoporous Co2+ doping nanometer TiO2. Journal of Functional Materials, 2008, 39 (1): 32-35 (in Chinese)
    [8] Le T. T., Akhtar M. S., Park D. M., et al. Water splitting on Rhodamine-B dye sensitized Co-doped TiO2 catalyst under visible light. Appl. Catal. B., 2012, 111-112: 397-401
    [9] Mi W. B., Jiang E. Y., Bai H. L. Structure, magnetic and optical properties of polycrystalline Co-doped TiO2 films. J. Magn. Magn. Mater., 2009, 321 (16): 2472-2476
    [10] Jayakumar O. D., Sudakar C., Persson C., et al. 1D Morphology stabilization and enhanced magnetic properties of Co:ZnO nanostructures on Co doping with Li: A template-free synthesis. Cryst. Growth Des., 2009, 9 (10): 4450-4455
    [11] Kim Y. D., Cooper S. L., Klein M. V., et al. Spectroscopic ellipsometry study of the diluted magnetic semiconductor system Zn (Mn, Fe, Co) Se. Phys. Rev. B., 1994, 49 (3): 1732-1742
    [12] Zayat M., Levy D. Blue CoAl2O4 particles prepared by the sol-gel and citrate-gel methods. Chem. Mater., 2000, 12 (9): 2763-2769
    [13] 刘春艳. 纳米光催化及光催化环境净化材料. 北京: 化学工业出版社, 2008
    [14] Ganesh I., Gupta A. K., Kumar P. P., et al. Preparation and characterization of Co-doped TiO2 materials for solar light induced current and photocatalytic applications. Mater. Chem. Phys., 2012, 135 (1): 220-234
    [15] Shi P. H., Su R. J., Wan F. Z., et al. Co3O4 nanocrystals on graphene oxide as a synergistic catalyst for degradation of Orange Ⅱ in water by advanced oxidation technology based on sulfate radicals. Appl. Catal. B., 2012, 123-124: 265-272
    [16] Huang W., Zuo Z. J., Han P. D., et al. XPS and XRD investigation of Co/Pd/TiO2 catalysts by different preparation methods. J. Electron. Spectrosc. Relat. Phenom., 2009, 173 (2-3): 88-95
    [17] Yang Q. J., Choi H., Dionysiou D. D. Nanocrystalline cobalt oxide immobilized on titanium dioxide nanoparticles for the heterogeneous activation of peroxymonosulfate. Appl. Catal. B., 2007, 74 (1-2): 170-178
    [18] Liang C. J., Wang Z. S., Bruell C. J. Influence of pH on persulfate oxidation of TCE at ambient temperatures. Chemosphere, 2007, 66 (1): 106-113
    [19] Rastogi A. Sulfate radical-based environmental friendly chemical oxidation processes for destruction of 2-Chlorobiphenyl (PCB) and Chlorophenols (CPs). Cincinnati, Ohio, United States: University of Cincinnati, 2008
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2706
  • HTML全文浏览数:  1110
  • PDF下载数:  1311
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-08-17
  • 刊出日期:  2014-05-06
陈晴空, 谢志刚, 吉芳英, 郭倩, 刘亭役, 徐璇. Vis/Co-TiO2/KHSO5体系Fenton-光催化协同降解苯酚[J]. 环境工程学报, 2014, 8(5): 1749-1754.
引用本文: 陈晴空, 谢志刚, 吉芳英, 郭倩, 刘亭役, 徐璇. Vis/Co-TiO2/KHSO5体系Fenton-光催化协同降解苯酚[J]. 环境工程学报, 2014, 8(5): 1749-1754.
shu
Chen Qingkong, Xie Zhigang, Ji Fangying, Guo Qian, Liu Tingyi, Xu Xuan. Synergistic effect of Fenton-photocatalysis through degradation of phenol by Vis/Co-TiO2/KHSO5 reaction system[J]. Chinese Journal of Environmental Engineering, 2014, 8(5): 1749-1754.
Citation: Chen Qingkong, Xie Zhigang, Ji Fangying, Guo Qian, Liu Tingyi, Xu Xuan. Synergistic effect of Fenton-photocatalysis through degradation of phenol by Vis/Co-TiO2/KHSO5 reaction system[J]. Chinese Journal of Environmental Engineering, 2014, 8(5): 1749-1754.
shu

Vis/Co-TiO2/KHSO5体系Fenton-光催化协同降解苯酚

  • 1. 重庆大学三峡库区生态环境教育部重点实验室, 重庆 400045
  • 2. 重庆文理学院材料与化工学院, 重庆 402160
  • 3. 林同棪国际工程咨询(中国)有限公司, 重庆 401121
  • 收稿日期:  2013-08-17
基金项目:

国家自然科学基金资助项目（51108483）

中央高校基本科研业务费专项资金项目（CDJXS12210002）

教育部科技创新工程重大项目培育资金项目（708071）

重庆市自然科学基金资助项目（cstcjjA20002）

摘要: 通过溶胶-凝胶法制备了同时具有可见光（Vis）光催化和Fenton催化双重活性的Co-TiO2催化剂。通过对比Vis/Co-TiO2/KHSO5、Co-TiO2/KHSO5和Vis/Co-TiO2 3种体系对苯酚的降解效果，Vis/Co-TiO2/KHSO5表现出明显的Fenton-光催化协同作用。进一步研究pH值、KHSO5与苯酚摩尔比（nKHSO5：nC6H6O）和Co-TiO2投加量（mCo-TiO2）对Fenton-光催化协同降解苯酚效果的影响。结果表明，pH=6.9、nKHSO5：nC6H6O=10：1、mCo-TiO2=1.0 g/L时，降解率达100%。最后，结合XRD、XPS和UV-DRS等手段和催化活性实验数据分析了Vis/Co-TiO2/KHSO5体系的催化机理。
