汤爱萍, 万金保, 李爽. “控源-截污-资源化”模式处理面源污染[J]. 环境工程学报, 2014, 8(5): 1761-1768.
引用本文: 汤爱萍, 万金保, 李爽. “控源-截污-资源化”模式处理面源污染[J]. 环境工程学报, 2014, 8(5): 1761-1768.
shu
Tang Aiping, Wan Jinbao, Li Shuang. Integrated mode of source controlling-wastewater intercepting-recycling for rural non-point source pollution[J]. Chinese Journal of Environmental Engineering, 2014, 8(5): 1761-1768.
Citation: Tang Aiping, Wan Jinbao, Li Shuang. Integrated mode of source controlling-wastewater intercepting-recycling for rural non-point source pollution[J]. Chinese Journal of Environmental Engineering, 2014, 8(5): 1761-1768.
shu

“控源-截污-资源化”模式处理面源污染

  • 1.

    南昌大学环境与化学工程学院, 南昌 330031

  • 2.

    鄱阳湖环境与资源利用教育部重点实验室, 南昌 330029

  • 3.

    南昌航空大学环境与化学工程学院, 南昌 330063

  • 基金项目:

    江西省教育厅2012年度科技项目（GJJ12433）

    江西省科技计划项目（20122BBG70079）

    国家自然科学基金资助项目（41261097）

  • 中图分类号: X524

Integrated mode of source controlling-wastewater intercepting-recycling for rural non-point source pollution

  • 1.

    School of Environment and Chemical Engineering, Nanchang University, Nanchang 330031, China

  • 2.

    Key Laboratory of Poyang Lake Environment and Resource Utilization (Nanchang University), Ministry of Education, Nanchang 330029, China

  • 3.

    School of Environment and Chemical Engineering, Nanchang Hangkong University, Nanchang 330063, China

  • Fund Project:

  • 摘要: 针对农村面源污染的时空范围广，不确定性大，成分、过程复杂，难以控制的特点，同时考虑废物资源化的问题，提出了“控污-截污-资源化（再利用）”CIR模式，包括三方面：通过改变不良用水习惯及耕作方式等从源头上控制污染排放；利用植物缓冲带、自然塘、沟渠湿地和表面流湿地等达到截污的目的；将畜禽养殖废水及生活黑水集中处理，产生沼气，变废为宝，于湿地内种植经济类水生植物，兼性塘内水产养殖，最终实现废物资源化（再利用）。经过将近一年半的运行测试，测试结果表明，整个模式不仅除污效率高，而且可产生良好的经济效益。
    Abstract: The integrated mode of source controlling-sewage intercepting-recycling is suggested to solve the problems of rural non-point source pollution. The mode includes three processes: emissions control from the source via changing bad water-use habits and tillage methods; sewage interception by planting buffer zone, natural pond, ditch wetland and surface flow wetland; biogas produced by methane tank with livestock breeding wastewater and black water, together with economic hydrophyte planted in wetland and fishes cultured in the facultative pond so as to realize the waste resource recycling. The results of one and a half years test show that this mode has high pollutant removal efficiency and good economic benefit. It is worthwhile to popularize in the rural areas in the Poyang Lake watershed.
  • 加载中
  • [1] Arheimer B., Lidén R. Nitrogen and phosphorus concentrations from agricultural catchments-influence of spatial and temporal variables. Journal of Hydrology, 2000, 227(1):140-159
    [2] 万金保, 刘峰, 汤爱萍, 等. 小流域典型面源污染最佳管理措施(BMPs)研究.水土保持学报, 2010, 24(6): 181-184 Wan J. B., Liu F., Tang A. P., et al. Study on small watershed non-point source pollution best management practices. Journal of Soil Water Conservation, 2010, 24(6): 181-184(in Chinese)
    [3] 万金保, 兰新怡, 汤爱萍. 多级表面流人工湿地在鄱阳湖区农村面源污染控制中的应用. 水土保持通报, 2010, 30(5): 118-121 Wan J.B., Lan X.Y., Tang A.P., et al. Application of multi-surface flow constructed wetland to rural non-point source pollution control in poyang lake region. Bulletin of Soil and Water Conservation, 2010, 30(5): 118-121 (in Chinese)
    [4] 万金保, 余敏.江西农村面源污染现状及控制对策. 广东农业科学, 2010, (11):239-241 Wan J. B., Yu M. Pollution situation of rural non-point source and control countermeasures in Jiangxi. Guangdong Agricultural Sciences, 2010, (11):239-241 (in Chinese)
    [5] 焦平金, 许迪, 程先军.外加碳源对污水灌溉系统氮素迁移转化影响的实验研究. 水利学报, 2008, 39(3): 380-384 Jiao J. P., Xu D., Cheng X. J. Effect of additional organic carbon on nitrogen transport in waste water irrigation. Journal of Hydraulic Engineering, 2008, 39(3): 380-384 (in Chinese)
    [6] G.X.Xing, Z.L.Zhu. The environment consequences of ammonia altered nitrogen cycling resulting from industrial activity, agricultural production, and population growth in China. The Scientific World Journal, 2001, 1(S2): 70-80
    [7] Xing G.X., Zhu Z.L. Regional nitrogen budgets for China and its major watersheds. Biogeochemistry, 2002, 57-58(1): 405-427
    [8] 张文艺, 刘明元, 罗鑫, 等. 苏南水网地区表面流人工湿地示范工程. 中国农村水利水电. 2012, (2): 78-81 Zhang W. Y., Liu M. Y., Luo X. The project of surface flow constructed wetland in the south of Jiangsu Province. China Rural Water and Hydropower, 2012, (2): 78-81 (in Chinese)
    [9] 吴建强.不同坡度缓冲带滞缓径流及污染物去除定量化. 水科学进展, 2011, 22(1):112-117 Wu J. Q. Quantitative study of the damping effect of buffer strips with different slopes on runoff and pollutant removal efficiency. Advances in Water Science, 2011, 22(1):112-117 (in Chinese)
    [10] 李一平, 逄勇, 吕俊, 等. 水动力条件下底泥中氮磷释放通.湖泊科学, 2004, 16(4):318-324 Li Y. P., Pang Y., Lü J., et al. On the relation between the release rate of TN, TP from sediment and water velocity. Journal of Lake Science, 2004, 16(4):318-324 (in Chinese)
    [11] 蒋柏藩, 鲁如坤, 顾益初, 等. 南方水稻土中的磷酸铁对水稻磷素营养的意义. 土壤学报, 1963, 11(4): 361-369 Jiang B. P., Lu R. K., Gu Y. C., et al. The content of iron phosphates in the paddy soils of southern China and their significance to the phosphorus nutrition of rice plant. Acta Pedologica Sinica, 1963, 11(4): 361-369 (in Chinese)
    [12] 曹杰, 罗安程, 方照平, 等. 人工湿地对氮、磷的去除效率及其空间分布研究. 科技通报, 2009, 25(6): 848-853, 859 Cao J., Luo A. C., Fang Z. P., et al. Studies on nitrogen and phosphorous removal efficiency and spatial distribution in constructed wetland systems. Bulletin of Science and Technology, 2009, 25(6): 848-853, 859 (in Chinese)
    [13] Zhang Q., Volker R. E., Lockington D. A. Dispersion-based transport boundary condition in numerical modeling of density-dependent groundwater flow. Handbook and Proceedings of Water 99 Joint Congress, Brisbane, Australia: 6-8 July 1999, 2:785-790
    [14] 张奇.人工湖滨湿地磷素汇-源功能转换及理论解释. 湖泊科学, 2007, 19(1): 46-51 Zhang Q. Shift of phosphorus sink-source functions of constructed wetlands and a theoretical explanation. Journal of Lake Sciences, 2007, 19(1): 46-51(in Chinese)
    [15] 徐进, 张奇. 表流湖滨湿地磷素汇-源功能研究. 环境科学学报, 2007, 27(10): 1617-1622 Xu J., Zhang Q. Phosphorus sink-source function of a lakeside surface flow wetland. Acta Scientiae Circumstantiae, 2007, 27(10): 1617-1622 (in Chinese)
    [16] 郑仁宏, 邓仕槐, 李远伟, 等. 表面流人工湿地硝化和反硝化强度研究. 环境污染与防治, 2007, 29(1): 37-39 Zheng R. H., Deng S. H., Li Y. W., et al. Nitrification and denitrification in surface flow wetland. Environmental Pollution & Control, 2007, 29(1): 37-39 (in Chinese)
    [17] 钟成华, 李杰, 邓春光. 人工湿地废水处理中氮、磷去除机理研究. 重庆建筑大学学报, 2008, 30(4): 141-145 Zhong C. H., Li J., Deng C. G. Advances in the study of nitrogen and phosphorus removal mechanisms in constructed wetlands. Journal of Chongqing Jianzhu University, 2008, 30(4): 141-145 (in Chinese)
    [18] C. B. Craft. Dynamics of nitrogen and phosphorus retention during wetland ecosystem succession. Wetlands Ecology and Management, 1996, 4(3): 177-187
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2101
  • HTML全文浏览数:  1477
  • PDF下载数:  942
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-05-17
  • 刊出日期:  2014-05-06
汤爱萍, 万金保, 李爽. “控源-截污-资源化”模式处理面源污染[J]. 环境工程学报, 2014, 8(5): 1761-1768.
引用本文: 汤爱萍, 万金保, 李爽. “控源-截污-资源化”模式处理面源污染[J]. 环境工程学报, 2014, 8(5): 1761-1768.
shu
Tang Aiping, Wan Jinbao, Li Shuang. Integrated mode of source controlling-wastewater intercepting-recycling for rural non-point source pollution[J]. Chinese Journal of Environmental Engineering, 2014, 8(5): 1761-1768.
Citation: Tang Aiping, Wan Jinbao, Li Shuang. Integrated mode of source controlling-wastewater intercepting-recycling for rural non-point source pollution[J]. Chinese Journal of Environmental Engineering, 2014, 8(5): 1761-1768.
shu

“控源-截污-资源化”模式处理面源污染

  • 1.  南昌大学环境与化学工程学院, 南昌 330031
  • 2.  鄱阳湖环境与资源利用教育部重点实验室, 南昌 330029
  • 3.  南昌航空大学环境与化学工程学院, 南昌 330063
  • 收稿日期:  2013-05-17
基金项目:

江西省教育厅2012年度科技项目（GJJ12433）

江西省科技计划项目（20122BBG70079）

国家自然科学基金资助项目（41261097）

摘要: 针对农村面源污染的时空范围广，不确定性大，成分、过程复杂，难以控制的特点，同时考虑废物资源化的问题，提出了“控污-截污-资源化（再利用）”CIR模式，包括三方面：通过改变不良用水习惯及耕作方式等从源头上控制污染排放；利用植物缓冲带、自然塘、沟渠湿地和表面流湿地等达到截污的目的；将畜禽养殖废水及生活黑水集中处理，产生沼气，变废为宝，于湿地内种植经济类水生植物，兼性塘内水产养殖，最终实现废物资源化（再利用）。经过将近一年半的运行测试，测试结果表明，整个模式不仅除污效率高，而且可产生良好的经济效益。
