回流式无膜生物阴极微生物燃料电池脱氮

,  ,

downloadPDF

上一篇

下一篇

王龙, 赵庆良, 姜珺秋. 回流式无膜生物阴极微生物燃料电池脱氮[J]. 环境工程学报, 2014, 8(6): 2245-2250.
引用本文: 王龙, 赵庆良, 姜珺秋. 回流式无膜生物阴极微生物燃料电池脱氮[J]. 环境工程学报, 2014, 8(6): 2245-2250.
shu
Wang Long, Zhao Qinliang, Jiang Junqiu. Nitrogen removal effect by return flow membrane-less biological cathode microbial fuel cells[J]. Chinese Journal of Environmental Engineering, 2014, 8(6): 2245-2250.
Citation: Wang Long, Zhao Qinliang, Jiang Junqiu. Nitrogen removal effect by return flow membrane-less biological cathode microbial fuel cells[J]. Chinese Journal of Environmental Engineering, 2014, 8(6): 2245-2250.
shu

回流式无膜生物阴极微生物燃料电池脱氮

  • 1.

    哈尔滨工业大学市政环境工程学院, 哈尔滨 150090

  • 基金项目:

    国家自然科学基金资助项目（51378144）

  • 中图分类号: X703

Nitrogen removal effect by return flow membrane-less biological cathode microbial fuel cells

  • 1.

    School of Municipal and Environmental Engineering, Harbin Institute of Technology, Harbin 150090, China

  • Fund Project:

  • 摘要: 为有效提高脱氮效率、降低MFC运行成本，设计了一种新构型回流式无PEM膜的生物阴极微生物燃料电池，处理生活污水，回收电能。研究了该系统的启动情况及稳定运行时的污水脱氮效果和产电性能。结果表明，系统稳定运行后，输出电压0.53 V，反应器内阻406.8 Ω，最大功率密度201.9 mW/m3。连续进水、停留时间12 h、回流比为1及阴极连续曝气条件下，COD去除率85%以上，氨氮去除率93.94%，总氮去除率44.96%，总氮去除较作参比的A2/O系统提高8.17%。
    Abstract: Aiming at improving the efficiency of denitrification and reducing operating costs of MFCs, a new type of reflux PEM-less bio-cathode microbial fuel cells was designed for domestic sewage treatment and electrical energy recycle. Start-up of MFCs, sewage denitrification effects and electricity production performance under stable operation were studied. The results indicated that, the steadily operated system could provide stable output voltage of 0.53 V with internal resistance of 406.8 Ω, and the maximum power density reached to 201.9 mW/m3. It provided more than 85% COD removal efficiency, 93.94% NH3-N and 40.96% TN removal efficiency, while removal efficiency of TN increased by 8.17% compared with A2/O system under the conditions of continuous inflow,12 hours of HRT,reflux ratio equaling to 1 and continuous aeration in cathode chamber.
  • 加载中
  • [1] 张壮志,孙磊,常维山.水体富营养化中的氮素污染及生物防治技术研究现状.山西农业科学, 2008,36(6):13-15 Zhang Z.Z.,Sun L.,Chang W. S.Study status on the nitrogen pollution and biocontrol technology in water eutrophication. Shanxi Agricultural Sciences, 2008,36(6):13-15(in Chinese)
    [2] 王微微,高路,郭子洋.废水生物脱氮工艺综述.黑龙江水利科技, 2010, 38(1):127-128 Wang W. W., Gao L.,Guo Z. X.Wastewater biological nitrogen removal process of nitrogen. Heilongjiang Science and Technology of Water Conservancy, 2010,38(1):127-128(in Chinese)
    [3] Rabaey K., Verstraete W. Microbial fuel cells: Novel biotechnology for energy generation. Trends Biotechnol., 2005, 23(6): 291-298
    [4] Chaudhuri S. K., Lovley D. R. Electricity generation by direct oxidation of glucose in mediatorless microbial fuel cells. Nature Biotechnology, 2003, 21(10):1229-1232
    [5] Kim B. H., Ikeda T., Park H. S.,et al.Electrochemical activity of an Fe(Ⅲ)-reducing bacterium, Shewanella putrefaciens IR-1,in the presence of alternative electron acceptors.Biotechnology Techniques, 1999,13(7):475-478
    [6] Logan B. E., Regan J. M. Microbial fuel cells-challenges and applications. Environmental Science & Technology, 2006, 40(17):5172-5180
    [7] Fan Y. Z., Hu H. Q., Liu H.Enhanced coulombic efficiency and power density of air-cathode microbial fuel cells with an improved cell configuration. Power Sources, 2007,171(2):348-354
    [8] Rabaey K.Microbial fuel cells for simultaneous carbon and nitrogen removal.Water Res.,2009,42(12):3013-3024
    [9] Luo A. Removal of carbon, nitrogen,and phosphorus in pig manure by continuous and intermittent aeration at low redox potentials.Biosyst. Eng., 2002,82(2):209-215
    [10] Freguia S., Rabaey K.,Yuan Z. G.Sequential anodecathode configuration improves cathodic oxygen reduction and effluent quality of microbial fuel cell. Water Res., 2008, 42(6-7):1387-1396
    [11] Clauwaert P.,Rabaey K.,Aelterman P.Biological denitrification in microbial fuel cells.Environmental Science & Technology, 2007,41(9):3354-3360
    [12] Hu W. J., Niu C. G., Wang Y.,et al.Nitrogenous heterocyclic compounds degradation in the microbial fuel cells. Process Safety and Environmental Protection, 2011,89(2):133-140
    [13] Du Z. W., Li Q. H., Tong M., et al. Electricity generation using membraneless microbial fuel cell during wastewater treatment. Chinese Journal of Chemical Engineering, 2008,16(5): 772-777
    [14] Hernandez M. E., Newman D. K. Extracellular electron transfer. Cellular and Molecular Life Sciences, 2001, 58(11): 1562-1571
    [15] 国家环境保护总局. 水和废水监测分析方法(第4版). 北京: 中国环境科学出版社, 2002
    [16] 尤世界. 微生物燃料电池处理有机废水过程中的产电特性研究.哈尔滨:哈尔滨工业大学博士学位论文, 2008 YouS.J.Microbial fuel cell for electricity generation during organic waster treatment. Harbin: Doctoral Dissertation of Harbin Institute of Technology,2008 (in Chinese)
    [17] 王建芳,赵庆良,刘志刚.好氧-沉淀-厌氧工艺剩余污泥减量化的影响因素.中国环境科学, 2008,28(5):427-432 Wang J. F., Zhao Q.L., Liu Z.G.,et al.Influence factors of excess sludge reduction of the oxic-settling-anaerobic technique. China Environmental Science, 2008,28(5):427-432(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1711
  • HTML全文浏览数:  1078
  • PDF下载数:  919
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-05-23
  • 刊出日期:  2014-05-29
王龙, 赵庆良, 姜珺秋. 回流式无膜生物阴极微生物燃料电池脱氮[J]. 环境工程学报, 2014, 8(6): 2245-2250.
引用本文: 王龙, 赵庆良, 姜珺秋. 回流式无膜生物阴极微生物燃料电池脱氮[J]. 环境工程学报, 2014, 8(6): 2245-2250.
shu
Wang Long, Zhao Qinliang, Jiang Junqiu. Nitrogen removal effect by return flow membrane-less biological cathode microbial fuel cells[J]. Chinese Journal of Environmental Engineering, 2014, 8(6): 2245-2250.
Citation: Wang Long, Zhao Qinliang, Jiang Junqiu. Nitrogen removal effect by return flow membrane-less biological cathode microbial fuel cells[J]. Chinese Journal of Environmental Engineering, 2014, 8(6): 2245-2250.
shu

回流式无膜生物阴极微生物燃料电池脱氮

  • 1. 哈尔滨工业大学市政环境工程学院, 哈尔滨 150090
  • 收稿日期:  2013-05-23
基金项目:

国家自然科学基金资助项目（51378144）

摘要: 为有效提高脱氮效率、降低MFC运行成本，设计了一种新构型回流式无PEM膜的生物阴极微生物燃料电池，处理生活污水，回收电能。研究了该系统的启动情况及稳定运行时的污水脱氮效果和产电性能。结果表明，系统稳定运行后，输出电压0.53 V，反应器内阻406.8 Ω，最大功率密度201.9 mW/m3。连续进水、停留时间12 h、回流比为1及阴极连续曝气条件下，COD去除率85%以上，氨氮去除率93.94%，总氮去除率44.96%，总氮去除较作参比的A2/O系统提高8.17%。
