杨喜, 崔慧霞, 郭彦霞, 薛芳斌, 程芳琴. 煤矸石中的铝、铁在高浓度盐酸中的浸出行为[J]. 环境工程学报, 2014, 8(8): 3403-3408.
引用本文: 杨喜, 崔慧霞, 郭彦霞, 薛芳斌, 程芳琴. 煤矸石中的铝、铁在高浓度盐酸中的浸出行为[J]. 环境工程学报, 2014, 8(8): 3403-3408.
shu
Yang Xi, Cui Huixia, Guo Yanxia, Xue Fangbin, Cheng Fangqin. Leaching behavior of alumina and ferric oxide in concentrated hydrochloric acid from coal gangue[J]. Chinese Journal of Environmental Engineering, 2014, 8(8): 3403-3408.
Citation: Yang Xi, Cui Huixia, Guo Yanxia, Xue Fangbin, Cheng Fangqin. Leaching behavior of alumina and ferric oxide in concentrated hydrochloric acid from coal gangue[J]. Chinese Journal of Environmental Engineering, 2014, 8(8): 3403-3408.
shu

煤矸石中的铝、铁在高浓度盐酸中的浸出行为

  • 1.

    山西大学资源与环境工程研究所, 国家环境保护煤炭废弃物资源化利用技术重点实验室, 太原 030006

  • 基金项目:

    国家“863”高技术研究发展计划项目（2011AA06A103）

  • 中图分类号: X752

Leaching behavior of alumina and ferric oxide in concentrated hydrochloric acid from coal gangue

  • 1.

    State Environmental Protection Key Laboratory of Efficient Utilization Technology of Coal Waste Resources, Institute of Resources and Environmental Engineering, Shanxi University, Taiyuan 030006, China

  • Fund Project:

  • 摘要: 考察了煤矸石中Al2O3和Fe2O3在不同浓度盐酸中的浸出行为，着重探讨了Al2O3和Fe2O3在高浓度盐酸中的溶出规律。通过与文献中AlCl3和FeCl3在不同浓度盐酸中的溶解度数据对照，发现煤矸石中Al2O3的溶出率受AlCl3溶解度的影响显著，而Fe2O3的溶出则基本不受FeCl3溶解度影响。进一步的研究结果表明，在高浓度盐酸中，煤矸石中Al2O3的溶出率显著降低，高浓度的盐酸不影响Fe2O3的溶出。当煤矸石的煅烧温度为700℃、酸浸温度为33℃时，酸浸固液比为1：1（g/mL），利用37%的高浓度盐酸酸浸，Fe2O3和Al2O3的溶出率分别为48.7%和7.3%，可实现煤矸石中铁铝的有效分离。
    Abstract: The leaching behavior of Al2O3 and Fe2O3 in the concentrated hydrochloric acid from coal gangue was investigated. By comparison with the solubility of AlCl3 and FeCl3 in literatures, it is found that the dissolution of Al2O3 from coal gangue was seriously affected by the solubility of AlCl3 while that of Fe2O3 not by the solubility of FeCl3. The further study showed that the dissolution of Al2O3 in concentrated HCl decreased significantly, while the dissolution of Fe2O3, was little affected by the concentration of HCl. Therefore, the concentrated HCl was used to leach Fe2O3. The results showed that the dissolution of Fe2O3 could reach about 48.7% only with 7.3% loss of Al2O3 at the calcination activation temperature of 700℃, the leaching temperature of 33℃ and a solid to liquid ratio of 1:1 for coal gangue.
  • 加载中
  • [1] Querol X., Izquierdo M., Monfort E., et al. Environmental characterization of burnt coal gangue banks at Yangquan, Shanxi Province, China. International Journal of Coal Geology, 2008,75 (2): 93-104
    [2] Bian Z., Dong J., Lei S., et al. The impact of disposal and treatment of coal mining wastes on environment and farmland. Environmental Geology, 2009, 58(3):625-634
    [3] Wang X.,Zhao B.,Zhang C.,et al. Paste-like self-flowing transportation backfilling technology based on coal gangue. Mining Science and Technology, 2009,19(2):137-143
    [4] Li H., Sun H., Tie X., et al. Dissolution properties of calcined gangue. Journal of University of Science and Technology Beijing, Mineral, Metallurgy, Material, 2006, 13(6): 570-576
    [5] Cheng F., Cui L., Miller J., et al. Aluminum leaching from calcined coal waste using hydrochloric acid solution. Mineral Processing & Extractive Metall. Rev., 2012, 33(6): 391-403
    [6] Qiao X., Si P., Yu J. A Systematic investigation into the extraction of aluminum from coal spoil through kaolinite. Environmental Science & Technology, 2008, 42(22): 8541-8546
    [7] 程芳琴, 崔莉, 张红, 等. 煤矸石中氧化铝溶出的实验研究. 环境工程学报,2007,1(11): 99-103 Cheng F. Q., Cui L., Zhang H., et al. Study on aluminum oxide extracted from coal gangue. Chiese Journal of Environmental Engineering, 2007,1(11): 99-103 (in Chinese)
    [8] Uslu T., Atalayü. Microwave heating of coal for enhanced magnetic removal of pyrite. Fuel Processing Technology, 2004, 85(1): 21-29
    [9] 祖占良,杜玉成,罗家珂,等. 煤矸石选择性磁种分选工艺应用研究. 矿产综合利用,1998,(3):1-4 Zu Z. L., Du Y. C., Luo J. K., et al. Study on application of selective magnetic seeding separation process in coal gangue. Multipurpose Utilization of Mineral Resources, 1998,(3):1-4 (in Chinese)
    [10] 孔德顺, 李志, 艾德春, 等. 高铁高砂煤矸石合成 4A 沸石分子筛. 光谱实验室, 2011, 28(2): 787-791 Kong D. S., Li Z., Ai D. C., et al. Synthesis of 4A zeolites molecular sieve from coal gangue with high contents of iron and silica. Chinese Journal of Spectroscopy Laboratory, 2011, 28(2): 787-791 (in Chinese)
    [11] 孔德顺, 吴红, 艾德春, 等. 煤矸石酸浸除铁及废液利用的实验研究. 应用化工, 2010, 39(10): 1482-1484 Kong D. S.,Wu H.,Ai D. C.,et al. Research on theiron removalfrom gangueby acid leaching and theutilization of waste liquid. Applied Chemical Industry, 2010, 39(10): 1482-1484 (in Chinese)
    [12] 薛茹君,吴玉程,陈晓玲. 煤系高岭土制取高纯氧化铝—萃取除铁. 矿物学报,2009, 29(2): 164-168 Xue R. J., Wu Y. C., Chen X. L. Preparation of ultra-pure and ultra-fine alumia from kaolinite in coal measures—Extraction separation of FeⅢ. Acta Mineralogica Sinica, 2009, 29(2): 164-168 (in Chinese)
    [13] Chen J., Yu S., Liu H., et al. New mixed solvent systems for the extraction and separation of ferric iron in sulphate solutions. Hydrometallurgy, 1992, 30(1): 401-416
    [14] 姜力夫, 程秀莉, 张蕊, 等. 煤矸石合成 4A 沸石过程中除铁方法的研究. 山东化工, 2002, 31(6): 5-6 Jiang L. F., Cheng X. L., Zhang R., et al. Investigation on methods of removing Fe Ⅲ in the synthesis of 4A zeolite from coal gangue. Shandong Chemistry Industry, 2002, 31(6): 5-6 (in Chinese)
    [15] 朱国才, 时文中, 池汝安. 氯化铵焙烧法从氟碳铈矿提取稀土的研究进展. 中国稀土学报, 2002, 20(2):136-141 Zhu G. C., Shi W. Z., Chi R. A. Progress on recovery of rare earth from bastnasite with NH4Cl roasting treatment. Journal of the Chinese Rare Earth Society, 2002, 20(2):136-141 (in Chinese)
    [16] 黄念东, 夏畅斌. 某高岭土细尾矿酸浸除铁的研究. 矿产综合利用, 2000, (3): 9-11 Huang N. D.,Xia C. B. Leaching of kaolin fine tailings for removing iron oxides with oxalic acid. Multipurpose Utilization of Mineral Resources, 2000, (3): 9-11 (in Chinese)
    [17] Brown R., Daut G., Mrazek R. Solubility and activity of aluminum chloride in aqueous hydrochloric acid solutions. United States, Bureau of Mines, Investigative Report, 1979, 8379: 1-17
    [18] Guo Y., Li Y., Cheng F., et al. Role of additives in improved thermal activation of coal fly ash for alumina extraction. Fuel Processing Technology, 2013, 110 (6): 114-121
    [19] 刘海龙, 韩红光, 崔莉, 等. 粒度对煤矸石活化效率的影响. 环境科学与技术, 2009, 32(6): 45-48 Liu H. L., Han H. G., Cui L., et al. Key affecting factors on coal gangue activation. Enviromental Science & Technology, 2009, 32(6): 45-48 (in Chinese)
    [20] 崔慧霞. 煤矸石制备结晶氯化铝过程中的关键工艺研究. 太原:山西大学硕士学位论文,2013 Cui H.X. Research on the key technology in the process of the preparation of crystalline aluminum chloride from coal gangue. Taiyuan: Master Dissertation of Shanxi University, 2013 (in Chinese)
