Fenton法处理垃圾渗滤液MBR-NF浓缩液

,  ,

downloadPDF

上一篇

下一篇

许玉东, 范良鑫, 黄友福. Fenton法处理垃圾渗滤液MBR-NF浓缩液[J]. 环境工程学报, 2014, 8(9): 3711-3717.
引用本文: 许玉东, 范良鑫, 黄友福. Fenton法处理垃圾渗滤液MBR-NF浓缩液[J]. 环境工程学报, 2014, 8(9): 3711-3717.
shu
Xu Yudong, Fan Liangxin, Huang Youfu. Treatment of MBR-NF concentrate of landfill leachate by Fenton process[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3711-3717.
Citation: Xu Yudong, Fan Liangxin, Huang Youfu. Treatment of MBR-NF concentrate of landfill leachate by Fenton process[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3711-3717.
shu

Fenton法处理垃圾渗滤液MBR-NF浓缩液

  • 1.

    福州大学环境与资源学院, 福州 350108

  • 基金项目:

    福建省科技计划重点项目（2009H0024）

    福建省自然科学基金项目（2012J01205）

  • 中图分类号: X705

Treatment of MBR-NF concentrate of landfill leachate by Fenton process

  • 1.

    College of Environment and Resources, Fuzhou University, Fuzhou 350108, China

  • Fund Project:

  • 摘要: 采用Fenton法处理MBR-NF浓缩液，考察了FeSO4·7H2O投加量、n（H2O2）/n（Fe2+）投加比、初始pH对渗滤液MBR-NF浓缩液处理效果的影响，并在最佳实验条件下，探讨浓缩液富里酸（FA）、亲水性有机物（HyI）组分在Fenton氧化前后组成的变化。研究结果表明，在FeSO4·7H2O投加量为0.055 mol/L、n（H2O2）/n（Fe2+）投加比为4、初始pH为7.58时，对COD、腐植酸（UV254）、色度（CN）的去除率分别为79.6%、93.7%和97.8%。Fenton氧化后，浓缩液中有机物组分含量发生了较大变化，腐植酸含量下降，HyI成为渗滤液溶解性有机物主要成分。紫外-可见光谱表明，Fenton法对FA去除效果较好，而对HyI氧化效果较差；傅立叶红外光谱显示，经Fenton氧化后，FA的结构发生了明显变化，而HyI则变化不明显。
    Abstract: The laboratory-scale experiments were conducted to investigate treatment performance of MBR-NF concentrate of landfill leachate by Fenton process. The affecting factors of dosage of FeSO4·7H2O, H2O2/ Fe2+ ratio (molar basis) and initial pH value on removal efficency were optimised. Meanwhile, the changes of compositions of fulvic acid (FA) and hydrophilic organic matter (HyI) fractions in the concentrate during Fenton process were discussed under the optimal conditions. The results showed that the optimal operating conditions were as follows: FeSO4·7H2O dosage of 0.055 mol/L, n(H2O2)/n(Fe2+) ratio of 4 and initial pH of 7.58. Under these conditions, the removal efficencies of COD, UV254, and CN reached 79.6%, 93.7% and 97.8%, respectively. During Fenton process, the organic composition of the concentrate varied significantly. The content of humic substances (HS) decreased, and the HyI fraction shifted the dominating composition of dissolved organic matter. The UV spectra demonstrated that Fenton oxidation had a high removal efficency for FA,while less effective for HyI. Fourier-transform infrared spectra exhibited the significant changes of FA structure, while few in HyI.
  • 加载中
  • [1] Zhang L.,Li A. M.,Lu Y. F.,et al. Characterization and removal of dissolved organic matter (DOM) from landfill leachate rejected by nanofiltration. Waste Management,2009,29(3):1035-1040
    [2] 叶少帆,吴志超,王志伟,等. Fenton法处理垃圾渗滤液过程中有机物分子质量分布和荧光特性.环境科学研究,2010,23(8):1049-1054 Ye Shaofan,Wu Zhichao,Wang Zhiwei,et al. Fluorescent characteristics and molecular weight distribution of organic substances in the course of treating landfill leachate by Fenton oxidation. Research of Environmental Sciences,2010,23(8):1049-1054(in Chinese)
    [3] 郭劲松,陈鹏,方芳,等. Fenton试剂对垃圾渗滤液中有机物的去除特性研究.中国给水排水,2008,24(3):88-91 Guo Jinsong,Chen Peng,Fang Fang,et al. Study on removal characteristics of organic matter in landifll leachate by Fenton reagent. China Water & Wastewater, 2008,24(3):88-91(in Chinese)
    [4] Umar M., Aziz H. A., Yusoff M. S. Trends in the use of Fenton, electro-Fenton and photo-Fenton for the treatment of landfill leachate. Waste Management, 2010,30(11):2113-2121
    [5] Ramírez-Sosa D. R., Castillo-Borges E. R., Méndez-Novelo R. I., et al. Determination of organic compounds in landfill leachates treated by Fenton-adsorption. Waste Management, 2013,33(2): 390-395
    [6] 詹德明,汪晓军,刘智颖,等.新型Fenton工艺对垃圾渗滤液MBR出水预处理研究.水处理技术, 2013,39(7):112-115 Zhan Deming,Wang Xiaojun,Liu Zhiying, et al. The research on pretreatment of the landfill leachate MBR effluent by a new Fenton process. Technology of Water Treatment, 2013,39(7):112-115(in Chinese)
    [7] Zhou M. H., Tan Q. Q., Wang Q., et al. Degradation of organics in reverse osmosis concentrate by electro-Fenton process. Journal of Hazardous Materials, 2012,215-216:287-293
    [8] Wang Y. J.,Li X. Y.,Zhen L. M.,et al. Electro-Fenton treatment of concentrates generated in nanofiltration of biologically pretreated landfill leachate.Journal of Hazardous Materials,2012,229-230:115-121
    [9] 徐蘇士,汪诚文,王迪,等. UV-Fenton工艺对垃圾渗滤液纳滤浓缩液的处理效果及影响因素研究.环境工程技术学报,2013,3(1):65-70 Xu Sushi,Wang Chengwen,Wang Di, et al. Study on UV-Fenton treatment of concentrated water from nanofiltration of bio-treated landfill leachate. Journal of Environmental Engineering Technology, 2013,3(1):65-70(in Chinese)
    [10] 覃芳慧,叶秀雅,吴彦瑜,等. Fenton-双泥SBR工艺深度处理难降解反渗透浓缩液.环境工程学报,2011,5(4):721-725 Qin Fanghui,Ye Xiuya,Wu Yanyu, et al. Intensive treatment of biorecalcitrant concentrated leachate effluent of reverse osmosis (RO) by Fenton-two sludge SBR system. Chinese Journal of Environmental Engineering,2011,5(4):721-725(in Chinese)
    [11] He P. J.,Xue J. F.,Shao L. M.,et al. Dissolved organic matter(DOM)in recycled leachate of bioreactor landfill. Water Research,2006,40(7):1465-1473
    [12] Wu Y. Y., Zhou S. Q., Qin F. H., et al. Removal of humic substances from landfill leachate by Fenton oxidation and coagulation. Process Safety and Environmental Protection,2010,88(4):276-284
    [13] Tizaoui C.,Bouselmi L.,Mansouri L.,et al. Landfill leachate treatment with ozone and ozone/hydrogen peroxide systems. Journal of Hazardous Materials, 2007,140(12):316-324
    [14] Daphne H.,Manuel C.,Chin P. H. Optimizing the treatment of landfilll leachate by conventional Fenton and photo-Fenton processes. Science of the Total Environment,2009,407(11):3473-3481
    [15] Neyens E.,Baeyens J. A review of classic Fenton oxidation as an advanced oxidation technique. Journal of Hazard Materias,2003,98(1-3):33-50
    [16] Crittenden J. C.,Hu S., Hand D. W.,et al. A kinetic model for H2O2/UV process in a completely mixed batch reactor. Water Research,1999,33(10):2315-2328
    [17] 杨雅琴. Fenton-A/O法处理垃圾渗滤液的实验研究.重庆:重庆大学硕士学位论文,2010 Yang Yaqin,Experimental study on treatment of landfill leachate with Fenton method and A/O method. Chongqing: Master's Degree Thesis of Chongqing University,2010(in Chinese)
    [18] Kim S. M., Geissen S. U.,AlfonsV. M. Landfill leachate treatment by aphotoassisted Fenton reaction.Wat.Sci.Tech.,1997,35(4):239-248
    [19] 徐苏云,何品晶,唐琼瑶,等. Fenton法处理类长填龄渗滤液的氧化和絮凝作用.环境科学研究,2008,21(4):20-24 Xu Suyun,He Pinjing,Tang Qiongyao,et al. Roles of oxidation and coagulation during Fenton treatment of mature leachate. Research of Environmental Sciences,2008,21(4):20-24(in Chinese)
    [20] 刘智萍,郭劲松,姜佩言,等. Fenton对渗滤液中DOM及其组分的去除特性研究.水处理技术,2010,36(2):64-67 Liu Zhiping,Guo Jinsong,Jiang Peiyan,et al. Study on the DOM and fractions characteristic of landfill leachate by the Fenton reagent. Technology of Water Treatment,2010,36(2):64-67(in Chinese)
    [21] Chin Y. P.,Aiken G.,O'Loughlin E., Molecular weight, polydispersity and spectroscopic properties of aquatic humic substances. Environmental Science & Technology,1994,28(11):1853-1858
    [22] Korshin G. V.,Li C. W.,Benjamin M. M. Monitoring the properties of natural organic matter through UV spectroscopy:A consistent theory. Water Research,1997,31(7):1787-1795
    [23] 郭瑾,马军. 松花江水中天然有机物的提取分离与特性表征.环境科学,2005,26(5):77-84 Guo Jin,Ma Jun. Characterization of isolated fractions of NOM from Songhua river. Environmental Science,2005,26(5):77-84(in Chinese)
    [24] Kanokkantapong V.,Marhaba T. F.,Panyap-inyophol B. FTIR evaluation of functional groups in-volved in the formation of haloacetic acids during the chlorination of raw water. Journal of Hazardous Material,2006,136(2):188-196
    [25] Lin C.,Lin T.,Hao O. Effect of humic substance characterization on UF performance. Water Research,2000,34(4):1097-1106
