正渗透复合膜的制备及表征

,  ,  ,  ,

downloadPDF

上一篇

下一篇

宁静恒, 赵俊, 李玉平, 曹宏斌, 李海波. 正渗透复合膜的制备及表征[J]. 环境工程学报, 2014, 8(10): 4183-4190.
引用本文: 宁静恒, 赵俊, 李玉平, 曹宏斌, 李海波. 正渗透复合膜的制备及表征[J]. 环境工程学报, 2014, 8(10): 4183-4190.
shu
Ning Jingheng, Zhao Jun, Li Yuping, Cao Hongbin, Li Haibo. Fabrication and characterization of thin-film composite membrane for forward osmosis[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4183-4190.
Citation: Ning Jingheng, Zhao Jun, Li Yuping, Cao Hongbin, Li Haibo. Fabrication and characterization of thin-film composite membrane for forward osmosis[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4183-4190.
shu

正渗透复合膜的制备及表征

  • 1.

    长沙理工大学化学与生物工程学院, 长沙 410004

  • 2.

    中国科学院过程工程研究所绿色过程与工程重点实验室, 北京 100190

  • 基金项目:

    国家自然科学基金资助项目（21177130，21377130）

  • 中图分类号: X 703.1

Fabrication and characterization of thin-film composite membrane for forward osmosis

  • 1.

    College of Chemical and Biological Engineering, Changsha University of Science and Technology, Changsha 410004, China

  • 2.

    Laboratory of Green Process and Engineering, Institute of Process Engineering, Beijing 100190, China

  • Fund Project:

  • 摘要: 通过在聚砜铸膜液中加入混合添加剂氯化锂和聚乙烯吡咯烷酮（PVP），用相转移法制备出多孔支撑层，然后通过界面聚合制备聚酰胺正渗透复合膜，重点研究了添加剂和聚砜浓度对膜结构和性能的影响。结果表明，氯化锂使得膜支撑层指状孔更加均一，提高孔隙率，并降低海绵层的厚度，提高了水通量；PVP增强了膜的亲水性，并易于成膜，在保持截盐率的同时提高了水通量；随着聚砜浓度增大，支撑层孔隙率变小，海绵状孔层变厚，生成的聚酰胺层更加致密，加重过程内浓差极化，水通量降低。采用质量分数为9%聚砜同时添加氯化锂和PVP的膜支撑层结构均一，孔隙率较大（68.0%），表面亲水性较强（接触角48.5°），优于2种商用三醋酸纤维素正渗透膜的孔隙率（32.6%和25.4%）和接触角（76.5°和73.5°）；在正渗透过程中的自制膜水通量为21.9 L/（m2·h），均高于2种商用三醋酸纤维素正渗透膜（9.5和14.4 L/（m2·h））和文献报道的正渗透复合膜通量水平，并维持了一定的截盐率（盐通量为19.9 g/（m2·h）），表现出优异的正渗透性能。
    Abstract: Thin-film composite membranes for forward osmosis(TFC-FO) were synthesized by interfacial polymerization on top of the porous polysulfone(PSf) supporting layer films,which were prepared via phase inversion with addition of polyvinyl pyrrolidone(PVP) and lithium chloride(LiCl).The effects of PSf concentration and additives on the structure characteristics and forward osmosis performance were investigated thoroughly.The results indicate that the addition of LiCl makes the finger-like pore more uniform,reduces the thickness of sponge-like pore layer,and also promotes the porosity of supporting layer,resulting in high water flux in forward osmosis process.PVP increases the hydrophilicity of TFC-FO membrane and improves the property of membrane-formation.TFC-FO membranes with addition of PVP exhibit high water flux and low reverse salt flux.With PSf concentration increasing,the porosity of supporting layer decreases,the sponge-like pore layer thickens and polyamide active layer becomes dense,which can lead to more serious internal concentration polarization and lower water flux in FO process.The TFC-FO membrane with 9% PSf concentration and addition of PVP and LiCl exhibits more uniform,porous and hydrophilic characteristics(porosity 68.0%,contact angle 48.5°) than two commercial FO membranes(porosity 32.6% and 25.4%,contact angle 76.5° and 73.5°).Additionally,the fabricated membrane shows a high performance in FO process with low reverse salt-flux of 19.9 g/(m2·h) as well as high water-flux of 21.9 L/(m2·h),which is better than that of two commercial FO membranes(9.5 and 14.4 L/(m2·h)) and some reported TFC-FO membranes under similar testing conditions.
  • 加载中
  • [1] McGinnis R.L.,Elimelech M.Global challenges in energy and water supply:The promise of engineered osmosis.Environmental Science & Technology,2008,42(23):8625-8629
    [2] Shannon M.A.,Bohn P.W.,Elimelech M.,et al.Science and technology for water purification in the coming decades.Nature,2008,452(7185):301-310
    [3] Elimelech M.,Phillip W.A.The future of seawater desalination:Energy,technology,and the environment.Science,2011,333(6043):712-717
    [4] Cath T.,Childress A.,Elimelech M.Forward osmosis:Principles,applications,and recent developments.Journal of Membrane Science,2006,281(1-2):70-87
    [5] Achilli A.,Cath T.Y.,Marchand E.A.,et al.The forward osmosis membrane bioreactor:A low fouling alternative to MBR processes.Desalination,2009,239(1-3):10-21
    [6] McCutcheon J.R.,McGinnis R.L.,Elimelech M.A novel ammonia-carbon dioxide forward (direct) osmosis desalination process.Desalination,2005,174(1):1-11
    [7] Garcia-Castello E.M.,McCutcheon J.R.,Elimelech M.Performance evaluation of sucrose concentration using forward osmosis.Journal of Membrane Science,2009,338(1-2):61-66
    [8] Cornelissen E.R.,Harmsen D.,de Korte K.F.,et al.Membrane fouling and process performance of forward osmosis membranes on activated sludge.Journal of Membrane Science,2008,319(1):158-168
    [9] Dova M.I.,Petrotos K.B.,Lazarides H.N.On the direct osmotic concentration of liquid foods.Part I:Impact of process parameters on process performance.Journal of Food Engineering,2007,78(2):422-430
    [10] Petrotos K.B.,Lazarides H.N.Osmotic concentration of liquid foods.Journal of Food Engineering,2001,49(2-3):201-206
    [11] Zhao S.F.,Zou L.D.,Tang C.Y.,et al.Recent developments in forward osmosis:Opportunities and challenges.Journal of Membrane Science,2012,396:1-21
    [12] Wang R.,Shi L.,Tang C.Y.,et al.Characterization of novel forward osmosis hollow fiber membranes.Journal of Membrane Science,2010,355(1-2):158-167
    [13] McCutcheon J.R.,Elimelech M.Influence of concentrative and dilutive internal concentration polarization on flux behavior in forward osmosis.Journal of Membrane Science,2006,284(1-2):237-247
    [14] Zhang S.,Wang K.Y.,Chung T.S.,et al.Well-constructed cellulose acetate membranes for forward osmosis:Minimized internal concentration polarization with an ultra-thin selective layer.Journal of Membrane Science,2010,360(1-2):522-535
    [15] McCutcheon J.R.,McGinnis R.L.,Elimelech M.Desalination by ammonia-carbon dioxide forward osmosis:Influence of draw and feed solution concentrations on process performance.Journal of Membrane Science,2006,278(1-2):114-123
    [16] Mehta G.D.,Loeb S.Internal polarization in the porous substructure of a semipermeable membrane under pressure-retarded osmosis.Journal of Membrane Science,1979,4:261-265
    [17] Gray G.T.,McCutcheon J.R.,Elimelech M.Internal concentration polarization in forward osmosis:Role of membrane orientation.Desalination,2006,197(1-3):1-8
    [18] Mehta G.,Loeb S.Performance of Permasep B-9 and B-10 membranes in various osmotic regions and at high osmotic pressures.Journal of Membrane Science,1979,4:335-349
    [19] Setiawan L.,Wang R.,Li K.,et al.Fabrication of novel poly (amide-imide) forward osmosis hollow fiber membranes with a positively charged nanofiltration-like selective layer.Journal of Membrane Science,2011,369(1-2):196-205
    [20] Yip N.Y.,Tiraferri A.,Phillip W.A.,et al.High performance thin-film composite forward osmosis membrane.Environmental Science & Technology,2010,44(10):3812-3818
    [21] Wang K.Y.,Chung T.S.,Amy G.Developing thin-film-composite forward osmosis membranes on the PES/SPSf substrate through interfacial polymerization.Aiche Journal,2012,58(3):770-781
    [22] 时钧,袁权,高从堦.膜技术手册.北京:化学工业出版社,2001
    [23] Bokhorst H.,Altena F.,Smolders C.Formation of asymmetric cellulose acetate membranes.Desalination,1981,38:349-360
    [24] Hansen C.M.Hansen Solubility Parameters:A User’s Handbook.Boca Raton:CRC Press,2007
    [25] McCutcheon J.R.,Elimelech M.Modeling water flux in forward osmosis:Implications for improved membrane design.Aiche Journal,2007,53(7):1736-1744
    [26] McKelvey S.A.,Koros W.J.Phase separation,vitrification,and the manifestation of macrovoids in polymeric asymmetric membranes.Journal of Membrane Science,1996,112(1):29-39
    [27] Tang C.Y.,Kwon Y.N.,Leckie J.O.Effect of membrane chemistry and coating layer on physiochemical properties of thin film composite polyamide RO and NF membranes:II.Membrane physiochemical properties and their dependence on polyamide and coating layers.Desalination,2009,242(1-3):168-182
    [28] Widjojo N.,Chung T.S.,Weber M.,et al.The role of sulphonated polymer and macrovoid-free structure in the support layer for thin-film composite (TFC) forward osmosis (FO) membranes.Journal of Membrane Science,2011,383(1-2):214-223
