强化循环厌氧反应器处理印染废水的中试启动研究

,  ,  ,

downloadPDF

上一篇

下一篇

杨波, 毕深涛, 李方, 田晴. 强化循环厌氧反应器处理印染废水的中试启动研究[J]. 环境工程学报, 2014, 8(10): 4273-4279.
引用本文: 杨波, 毕深涛, 李方, 田晴. 强化循环厌氧反应器处理印染废水的中试启动研究[J]. 环境工程学报, 2014, 8(10): 4273-4279.
shu
Yang Bo, Bi Shentao, Li Fang, Tian Qing. Study on pilot-scale start-up characters of strengthen circulation anaerobic reactor for treating printing and dyeing wastewater[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4273-4279.
Citation: Yang Bo, Bi Shentao, Li Fang, Tian Qing. Study on pilot-scale start-up characters of strengthen circulation anaerobic reactor for treating printing and dyeing wastewater[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4273-4279.
shu

强化循环厌氧反应器处理印染废水的中试启动研究

  • 1.

    东华大学环境科学与工程学院, 上海 201620

  • 基金项目:

    上海市自然科学基金资助项目（13ZR1401000）

  • 中图分类号: X703.3

Study on pilot-scale start-up characters of strengthen circulation anaerobic reactor for treating printing and dyeing wastewater

  • 1.

    College of Environmental Science & Engineering, Donghua University, Shanghai 201620, China

  • Fund Project:

  • 摘要: 应用自主研制的强化循环厌氧反应器（SCAR）中试规模处理实际印染废水，研究反应器的启动特性。反应器接种厌氧颗粒污泥后启动运行83 d，形成连续内循环并实现了对印染废水处理的高效稳定运行。在进水COD浓度1 000~3 650 mg/L、系统容积负荷0.7~6.4 kg/（m3·d）条件下，废水COD和色度平均去除率分别达到55%和73%。反应器内较高浓度的NH4+-N保证了系统pH的稳定性，350~600 mg/L的NH4+-N浓度没有对强化循环厌氧反应器产生抑制作用，系统内也没有出现VFA（以乙酸计）积累。启动过程中，厌氧颗粒污泥的粒径增大、沉降性能变好。启动实验完成时，反应器内微生物的脱氢酶活性（以TF计）和辅酶F420浓度分别为3.4973 mg/（g·h）和0.1872 μmol/g。
    Abstract: The start-up characters of treating real printing and dyeing wastewater by a self-made pilot-scale strengthen circulation anaerobic reactor were investigated in the experiment.Seeded with anaerobic granular sludge,the reactor started by using real printing and dyeing wastewater as influent with COD concentration of 1 000~3 650 mg/L.Within the 83 days start-up running,the reactor reached a state with high efficiency and formed a continuous internal circulation.The results showed that the average removal rates of COD and chroma were up to 55% and 73%,respectively while the system volume loading rate was 0.7~6.4 kg/(m3·d).It proved that 350~600 mg/L of NH4+-N had no inhibition to the strengthen circulation anaerobic reactor and ensured the stability of the pH value of the system and VFA with acetic acid expression also didn't accumulate in the system.During the start-up,the size of anaerobic granular sludge particle increased and the sludge sedimentation performance became better.At the end of the start-up,the values of dehydrogenase activity (DHA) with TF expression and the coenzyme F420 concentration were 3.4973 mg/ (g·h) and 0.1872 μmol/g,respectively.
  • 加载中
  • [1] Habets L.H.A.,Engelear A.J.H.H.,Groeneveld N.Anaerobic treatment of inuline effluent in an internal circulation.Water Science and Technology,1997,35(10):189-197
    [2] Wu J.,Zhang J.B.,Jiang Y.,et al.Impacts of hydrodynamic conditions on sludge digestion in internal circulation anaerobic reactor.Process Biochemistry,2012,47(11):1627-1632
    [3] Cui P.Y.,Zhou X.F.,Zhang Y.L.The feasibility study of cotton pulp wastewater treatment with IC anaerobic reactor.Procedia Environmental Sciences,2011,11(Part B):686-692
    [4] Deng L.W.,Zheng P.,Chen Z.A.Anaerobic digestion and post-treatment of swine wastewater using IC-SBR process with bypass of raw wastewater.Process Biochemistry,2006,41(4):965-969
    [5] 胡纪萃.废水厌氧生物处理理论与技术.北京:中国建筑工业出版社,2003:213-219
    [6] 郭方峥,刘伟京,涂勇,等.IC反应器处理废纸造纸废水的运行参数.环境科学研究,2011,24(3):325-331 Guo Fangzheng,Liu Weijing,Tu Yong,et al.Operating parameters of IC reactor treating OCC wastewater.Research of Environmental Sciences,2011,24(3):325-331(in Chinese)
    [7] Pereboom J.H.F.,Vereijken T.L.F.M.Methanogenic granule development in full scale internal circulation reactors.Water Science and Technology,1994,30(8):9-21
    [8] Frijters C.T.M.J,Vos R.H.,Scheffer G.,et al.Decolorizing and detoxifying textile wastewater,containing both soluble and insoluble dyes,in a full scale combined anaerobic/aerobic system.Water Research,2006,40(6):1249-1257
    [9] Fang C.,O-Thong S.,Boe K.,et al.Comparison of UASB and EGSB reactors performance,for treatment of raw and deoiled palm oil mill effluent (POME).Journal of Hazardous Materials,2011,189(1-2):229-234
    [10] 李津,左剑恶,邢薇.EGSB反应器在20℃下处理啤酒废水的工艺及微生物学研究.环境科学,2008,29(4):990-995 Li Jing,Zuo Jiane,Xing Wei.Performance and microbial characteristics of an egsb reactor treating brewery wastewater under 20℃.Environmental Science,2008,29(4):990-995(in Chinese)
    [11] Liu J.Y.,Luo J.H.,Zhou J.Z.,et al.Inhibitory effect of high-strength ammonia nitrogen on bio-treatment of landfill leachate using EGSB reactor under mesophilic and atmospheric conditions.Bioresource Technology,2012,113:239-243
    [12] Puyol D.,Mohedano A.F.,Sanz J.L.,et al.Comparison of UASB and EGSB performance on the anaerobic biodegradation of 2,4-dichlorophenol.Chemosphere,2009,76(9):1192-1198
    [13] Senthilkumar M.,Gnanapragasam G.,Arutchelvan V.,et al.Treatment of textile dyeing wastewater using two-phase pilot plant UASB reactor with sago wastewater as co-substrate.Chemical Engineering Journal,2011,166(1):10-14
    [14] Gnanapragasam G.,Senthilkumar M.,Arutchelvan V.,et al.Bio-kinetic analysis on treatment of textile dye wastewater using anaerobic batch reactor.Bioresouure Technology,2011,102(2):627-632
    [15] etin D.,Dnmez G.Decolorization of reactive dyes by mixed cultures isolated from textile effluent under anaerobic conditions.Enzyme and Microbial Technology,2006,38(7):926-930
    [16] Türgay O.,Ersz G.,Atalay S.,et al.The treatment of azo dyes found in textile industry wastewater by anaerobic biological method and chemical oxidation.Separation and Purification Technology,2011,79(1):26-33
    [17] 国家环境保护总局.水和废水监测分析方法(第4版).北京:中国环境科学出版社,2002:105-280
    [18] 贺延龄.废水的厌氧生物处理.北京:中国轻工业出版社,1998:509-511
    [19] Serre-Wittling C.,Houot S.,Barriuso E.Soil enzymatic response to addition of municipal solid-waste compost.Biology and Fertility of Soils,1995,20(4):226-236
    [20] Liu H.,He Y.H.,Quan X.C.,et al.Enhancement of organic pollutant biodegradation by ultrasound irradiation in a biological activated carbon membrane reactor.Process Biochemistry,2005,40(9):3002-3007
    [21] Ebert S.,Rieger P.G.,Knackmuss H.J.Function of coenzyme F420 in aerobic catabolism of 2,4,6-trinitrophenol and 2,4-dinitrophenol by Nocardioides simplex FJ2-1.Journal of Bacteriology,1999,181(9):2669-2674
    [22] 梁耀开,邓毛程,梁磊.新型(IC)厌氧反应器处理酒厂废水的试验研究.中国酿造,2012,31(4):151-154 Liang Yaokai,Deng Maocheng,Liang Lei.Research of new (IC) anaerobic reactor treatment winery wastewater.China Brewing,2012,31(4):151-154(in Chinese)
    [23] 周莉莉,季民.IC反应器处理制药废水的颗粒污泥驯化和快速启动.中国环境科学,2010,30(6):758-762 Zhou Lili,Ji Min.Granular sludge acclimation and quick startup of pharmaceutical wastewater with an IC reactor.China Environmental Science,2010,30(6):758-762(in Chinese)
    [24] 刘伟京,许明,吴海锁,等.厌氧-好氧-混凝工艺处理印染废水中试研究.环境科学研究,2012,22(4):478-483 Liu Weijing,Xu Ming,Wu Haisuo,et al.Pilot-Scale Study on treatment of printing and dyeing wastewater.Research of Environmental Sciences,2012,22(4):478-483(in Chinese)
    [25] 付志敏,张玉高,王晓军.厌氧滤池处理纺织印染废水的中试研究.环境工程学报,2012,6(2):535-539 Fu Zhimin,Zhang Y.ugao,Wang Xiaojun.Pilot study on textile wastewater treatment by anaerobic filter reactor.Chinese Journal of Environmental Engineering,2012,6(2):535-539(in Chinese)
    [26] Ahring B.K.,Sandberg M.,Angelidaki I.Volatile fatty acids as indicators of process imbalance in anaerobic digestors.Applied Microbiology and Biotechnology,1995,43(3):559-565
    [27] Luangdilok W.,Panswad T.Effect of chemical structures of reactive dyes on color removal by an anaerobic-aerobic process.Water Science and Technology,2000,42(3-4):377-382
    [28] Bromley-Challenor K.C.A.,Knapp J.S.,Zhang Z.,et al.Decolorization of an azo dye by unacclimated activated sludge under anaerobic conditions.Water Research,2000,34(18):4410-4418
    [29] Zeshan,Karthikeyan O.P.,Visvanathan C.Effect of C/N ratio and ammonia-N accumulation in a pilot-scale thermophilic dry anaerobic digester.Bioresource Technology,2012,113:294-302
    [30] Liu Z.G.,Zhou X.F.,Zhang Y.L.,et al.Enhanced anaerobic treatment of CSTR-digested effluent from chicken manure:The effect of ammonia inhibition.Waste Management,2012,32(1):137-143
    [31] Siles J.A.,Brekelmans J.,Martín M.,et al.Impact of ammonia and sulphate concentration on thermophilic anaerobic digestion.Bioresource Technology,2010,101(23):9040-9048
    [32] Delafontaine M.J.,Naveau H.P.,Nyns E.J.Fluormetric monitoring of methanogenesis in anaerobic digestors.Biotechnology Letters,1979,1(2):71-74
    [33] 许敬亮,高勇生,陈立伟,等.运行负荷对酶制剂废水厌氧颗粒污泥形成的影响.环境科学学报,2005,25(3):379-384 Xu Jingliang,Gao Yongsheng,Chen Liwei,et al.Effects of organic load on the formation of anaerobic granular sludge for zymin wastewater treatment.Acta Scientiae Circumstantiae,2005,25(3):379-384(in Chinese)
    [34] Dong F.,Zhao Q.B.,Zhao J.B.,et al.Monitoring the restart-up of an upflow anaerobic sludge blanket (UASB) reactor for the treatment of a soybean processing wastewater.Bioresource Technology,2010,101(6):1722-1726
