硅酸镁/PES复合膜吸附材料的制备及其对亚甲基蓝的吸附

,  ,

downloadPDF

上一篇

下一篇

汪清, 毛丽莉, 王海增. 硅酸镁/PES复合膜吸附材料的制备及其对亚甲基蓝的吸附[J]. 环境工程学报, 2014, 8(10): 4296-4300.
引用本文: 汪清, 毛丽莉, 王海增. 硅酸镁/PES复合膜吸附材料的制备及其对亚甲基蓝的吸附[J]. 环境工程学报, 2014, 8(10): 4296-4300.
shu
Wang Qing, Mao Lili, Wang Haizeng. Preparation of magnesium silicate/PES composite membrane and its adsorption of methylene blue[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4296-4300.
Citation: Wang Qing, Mao Lili, Wang Haizeng. Preparation of magnesium silicate/PES composite membrane and its adsorption of methylene blue[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4296-4300.
shu

硅酸镁/PES复合膜吸附材料的制备及其对亚甲基蓝的吸附

  • 1.

    中国海洋大学化学化工学院 海洋化学工程与技术教育部重点实验室, 青岛 266100

  • 基金项目:

    教育部博士点专项基金资助项目（20090132110009）

  • 中图分类号: X52

Preparation of magnesium silicate/PES composite membrane and its adsorption of methylene blue

  • 1.

    Key Laboratory of Marine Chemistry Theory and Technology, Ministry of Education, College of Chemistry and Chemical Engineering Ocean University of China, Qingdao 266100, China

  • Fund Project:

  • 摘要: 采用共混法制备了硅酸镁/聚醚砜（PES）复合膜吸附材料，通过傅氏转换红外线光谱分析仪（FT-IR）和 扫描式电子显微镜（SEM）等手段对膜的结构进行表征，研究了复合膜的吸附性能、机械性能和热稳定性。考察了时间、溶液平衡浓度和pH等对亚甲基蓝吸附的影响。结果表明，综合机械性能和吸附性能考虑，硅酸镁含量为19%时的复合膜最佳。25℃条件下，对亚甲基蓝的吸附6 h达到平衡，最大吸附量为1.85 mg/cm2；25℃条件下，弱酸或碱性条件时有利于复合膜对亚甲基蓝的吸附。
    Abstract: The magnesium silicate /PES (polyethersulfones) composite membrane was prepared by blending method.The resulting membrane was characterized by FT-IR and SEM.Mechanical and thermal properties of the membrane were researched.Different factors affecting the adsorption behavior of methylene blue (MB),i.e.time,equilibrium concentration and pH were studied.Results showed that the optimal content of magnesium silicate in the composite membrane was 19%,taking mechanical and adsorptive properties into consideration.At 25℃,the adsorption process attained equilibrium in 6 h and the maximal adsorption capacity was 1.85 mg/cm2,it was favorable for the adsorption of MB under weak acidic or alkaline conditions.
  • 加载中
  • [1] 张蓓蓓,李华明,刘海龙,等.四钛酸钾晶须对亚甲基蓝吸附性能研究.环境科学与技术,2011,34(9):40-43 Zhang Beibei,Li Huaming,Liu Hailong,et al.Adsorption of characteristics of methylene blue onto K2Ti4O9 whiskers.Environmental Science & Technology,2011,34(9):40-43(in Chinese)
    [2] 廖钦洪,刘庆业,蒙冕武,等.稻壳基活性炭的制备及其对亚甲基蓝吸附的研究.环境工程学报,2011,5(11):2447-2452 Liao Qinhong,Liu Qingye,Meng Mianwu,et al.Study on preparation of rice husk-based activated carbon and its adsorption of methylene blue.Chinese Journal of Environmental Engineering,2011,5(11):2447-2452(in Chinese)
    [3] 宋锦,田秀君.光催化降解亚甲基蓝的影响因素及动力学研究.环境科学导刊,2007,26(4):11-14 Song Jin,Tian Xiujun.Study on kinetics and affection factors of methylene blue degradation by photochemical catalysis.Environmental Science Survey,2007,26(4):11-14(in Chinese)
    [4] 储金宇,万翔,李宁,等.复合型CoO/TiO2光催化剂降解亚甲基蓝动力学研究.环境工程学报,2011,5(12):2773-2777 Chu Jinyu,Wan Xiang,Li Ning,et al.Research on kinetics of photocatalytic degradation of methylene blue(MB)by using CoO/TiO2 as composite photocatalyst.Chinese Journal of Environmental Engineering,2011,5(12):2773-2777(in Chinese)
    [5] 张旭,陈胜,孙德智.印染废水生物法处理技术研究进展.长春工业大学学报(自然科学版),2009,30(1):26-32 Zhang Xu,Chen Sheng,Sun Dezhi.Researches in biological treatment technologes for the dyeing waste water.Journal of Changchun University of Technology (Natural Science Edition),2009,30(1):26-32(in Chinese)
    [6] 刘振荣,李红,王军,等.TiO2催化超声降解亚甲基蓝溶液.化学研究,2005,16(1):69-71 Liu Zhenrong,Li Hong,Wang Jun,et al.Ultrasonic degradation of methylene blue catalyzed by TiO2.Chemical Research,2005,16 (1):69-71(in Chinese)
    [7] Khattri S.D.,Singh M.K.Removal of malachite green from dye wastewater using neem sawdust by adsorption.Journal of Hazardous Materials,2009,167(1-3):1089-1094
    [8] 姚超,刘敏,李为民,等.凹凸棒石/氧化锌纳米复合材料对亚甲基蓝的吸附性能.环境科学学报,2010,30(6):1211-1219 Yao Chao,Liu Min,Li Weimin,et al.Adsorption capability of methylene blue by attapulgite /zinc oxide nanocomposites.Acta Scientiae Circumstaniae,2010,30(6):1211-1219(in Chinese)
    [9] Zhu P.Y.,Wang H.Z.,Sun B.W.,et al.Adsorption of fluoride from aqueous solution by magnesia-amended silicon dioxide granules.Journal of Chemical Technology and Biotechnology,2009,84(10):1449-1455
    [10] zdemir Y.,Dogˇan M.,Alkan M.Adsorption of cationic dyes from aqueous solutions by sepiolite.Microporous and Mesoporous Materials,2006,96(1):419-427
    [11] Kara M.,Yuzer H.,Sabah E.,et al.Adsorption of cobalt from aqueous solutions onto sepiolite.Water Research,2003,37(1):224-232
    [12] Ferrero F.Adsorption of methylene blue on magnesium silicate:Kinetics,equilibria and comparison with?浯慴杨湥敲琠楡捤?浯慲杢湥敮獴楳甮浊?獵楲汮楡捬愠瑯敦?湅慮湶潩瑲畯扮敭獥??呡桬攠??潩略牮瑣桥?匬攲猰猱椰漬渲′漨昳?琺栴收??栴椷渳攼獢敲￣?挱愳摝攠浃祯?潧映?匮捌椮攬湒捡敤獯?偺漠獍琮??潯捷瑬潥牲愠求??挮愬摥整洠楡捬??湯湬畹慭汥??敩敮瑯楲湧条?慩湣搠??据慯摣敯浭楰捯??潴湥映敭牥敭湢捲敡?潥湳??湯摲甠獧瑡牳椠慳汥??捲潡湴潩浯祮?慓湥摰?卲畡獴瑩慯楮渠慡扮汤攠??ひ???楣湡??桯楮渠敔獥散?nology,2007,55(3):281-291
    [13] Yu L.Y.,Shen H.M.,Xu Z.L.PVDF–TiO2 Composite hollow fiber ultrafiltration membranes prepared by TiO2 sol-gel method and blending method.Journal of Applied Polymer Science,2009,113(3):1763-1772
    [14] 艾晓莉,胡小玲.有机-无机杂化膜的研究进展.化学进展,2005,16(4):654-659 Ai Xiaoli,Hu Xiaoling.Study on organic-inorganic hybrid membranes.Progress in Chemistry,2005,16(4):654-659(in Chinese)
    [15] Rahimpour A.,Madaeni S.S.Polyethersulfone (PES)/cellulose acetate phthalate (CAP) blend ultrafiltration membranes:Preparation,morphology,performance and antifouling properties.Journal of Membrane Science,2007,305(1-2):299-312
    [16] Maximous N.,Nakhla G.,Wan W.,et al.Preparation,characterization and performance of Al2O3/PES membrane for wastewater filtration.Journal of Membrane Science,2009,341(1-2):67-75
    [17] 李传峰,邵怀启,钟顺和.有机无机杂化膜材料的制备技术.化学进展,2004,16(1):83-89 Li Cuanfeng,Shao Huaiqi,Zhong Shunhe.Preparation technology of organic-inorganic hybrid membrane.Progress in Chemistry,2004,16(1):83-89(in Chinese)
    [18] 王银叶,单杰,张春青.X分子筛-硅藻土复合吸附剂对废水中亚甲基蓝吸附性能的研究.工业水处理,2009,40(5):53-56 Wang Yinye,Shan Jie,Zhang Chuanqing.Adsorption performance of X zeolite-diatomite compound adsorbent to methylene blue in wastewater.Industrial Water Treatment,2009,40(5):53-56(in Chinese)
    [19] 赵文俞,张清杰,彭长琪,等.硅灰石分子结构的FTIR谱.硅酸盐学报,2006,34(9):1137-1139 Zhao Wenyu,Zhang Qingjie,Peng Changqi,et al.FTIR spectra for molecular structure of wollastonite.Journal of the Chinese Ceramic Society,2006,34 (9):1137-1139(in Chinese)
    [20] Brew D.R.M.,Glasser F.P.Synthesis and characterisation of magnesium silicate hydrate gels.Cement and Concrete Research,2005,35(1):85-98
    [21] 曹昌燕,魏芳,曲晋,等.磁性硅酸镁纳米管的合成及其性能研究//第四届中国科学院博士后学术年会暨工业经济与可持续发展学术会议论文集,2012 Cao Changyan,Wei Fang,Qu Jin,et al.Preparation and properties of
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1658
  • HTML全文浏览数:  1051
  • PDF下载数:  806
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-11-08
  • 刊出日期:  2014-09-28
汪清, 毛丽莉, 王海增. 硅酸镁/PES复合膜吸附材料的制备及其对亚甲基蓝的吸附[J]. 环境工程学报, 2014, 8(10): 4296-4300.
引用本文: 汪清, 毛丽莉, 王海增. 硅酸镁/PES复合膜吸附材料的制备及其对亚甲基蓝的吸附[J]. 环境工程学报, 2014, 8(10): 4296-4300.
shu
Wang Qing, Mao Lili, Wang Haizeng. Preparation of magnesium silicate/PES composite membrane and its adsorption of methylene blue[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4296-4300.
Citation: Wang Qing, Mao Lili, Wang Haizeng. Preparation of magnesium silicate/PES composite membrane and its adsorption of methylene blue[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4296-4300.
shu

硅酸镁/PES复合膜吸附材料的制备及其对亚甲基蓝的吸附

  • 1. 中国海洋大学化学化工学院 海洋化学工程与技术教育部重点实验室, 青岛 266100
  • 收稿日期:  2013-11-08
基金项目:

教育部博士点专项基金资助项目（20090132110009）

摘要: 采用共混法制备了硅酸镁/聚醚砜（PES）复合膜吸附材料，通过傅氏转换红外线光谱分析仪（FT-IR）和 扫描式电子显微镜（SEM）等手段对膜的结构进行表征，研究了复合膜的吸附性能、机械性能和热稳定性。考察了时间、溶液平衡浓度和pH等对亚甲基蓝吸附的影响。结果表明，综合机械性能和吸附性能考虑，硅酸镁含量为19%时的复合膜最佳。25℃条件下，对亚甲基蓝的吸附6 h达到平衡，最大吸附量为1.85 mg/cm2；25℃条件下，弱酸或碱性条件时有利于复合膜对亚甲基蓝的吸附。
