人工湿地组合工艺对太湖三山岛农村生活污水的脱氮效果

,  ,  ,  ,

downloadPDF

上一篇

下一篇

王学华, 张娜, 苏祥, 沈耀良, 陈骏. 人工湿地组合工艺对太湖三山岛农村生活污水的脱氮效果[J]. 环境工程学报, 2014, 8(10): 4313-4318.
引用本文: 王学华, 张娜, 苏祥, 沈耀良, 陈骏. 人工湿地组合工艺对太湖三山岛农村生活污水的脱氮效果[J]. 环境工程学报, 2014, 8(10): 4313-4318.
shu
Wang Xuehua, Zhang Na, Su Xiang, Shen Yaoliang, Chen Jun. Effect of a combined constructed wetland process in removing nitrogen from rural domestic sewage in Sanshan Island, Taihu Lake[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4313-4318.
Citation: Wang Xuehua, Zhang Na, Su Xiang, Shen Yaoliang, Chen Jun. Effect of a combined constructed wetland process in removing nitrogen from rural domestic sewage in Sanshan Island, Taihu Lake[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4313-4318.
shu

人工湿地组合工艺对太湖三山岛农村生活污水的脱氮效果

  • 1.

    苏州科技学院环境科学与工程学院, 苏州 215009

  • 2.

    苏州科太环境技术有限公司, 苏州 215011

  • 基金项目:

    苏州市科技局科技支撑计划项目（SS0903）

  • 中图分类号: X703

Effect of a combined constructed wetland process in removing nitrogen from rural domestic sewage in Sanshan Island, Taihu Lake

  • Fund Project:

  • 摘要: 针对太湖三山岛农村生活污水分布面广而分散和水质水量不稳定，以及三级处理费用高等问题，提出了人工湿地组合工艺。以设计规模为1 000 m3/d、处理生活污水的工艺系统为对象，探讨了氮元素在系统中的去除效果、途径及其一级去除速率常数。结果表明，该工艺对NH4+-N去除效果较好，出水NH4+-N平均达到地表水Ⅲ类，TN平均接近地表水Ⅴ类；潜流人工湿地、好氧生态塘C、兼性生态塘A和表流人工湿地D对氮的去除量分别占组合工艺去除总量的52.05%、18.65%、16.65%和12.65%；组合工艺对NH4+-N和TN的平均一级去除速率常数分比别为（14.47±2.01）和（25.91±4.99）m/a。
    Abstract: To solve the problems of quality and quantity instability of decentralized rural domestic sewage in Sanshan island,Taihu lake,as well as the high cost of tertiary treatment,we put forward a combined constructed wetland process.The system with design capacity of 1000 m3/d was studied,for treating domestic sewage.The removal effect,removal pathway and first removal rate constant of nitrogen in the whole system were also explored.The results showed that this combined process performed well on NH4+-N.The effluent NH4+-N could meet grade Ⅲ averagely according to the China environmental quality standards for surface water; the effluent TN approached grade V.The partial N removal amounts in subsurface flow constructed wetland,aerobic ecological pond C,facultative pond A and surface flow constructed wetland D made up 52.05 %,18.65 %,16.65 % and 12.65 % of total N removal by the combined process.The average first removal rate constants for TN and NH4+-N were (14.47±2.01) and (25.91±4.99) m/a,respectively.
  • 加载中
  • [1] 季兵,陈季华.人工湿地系统处理上海崇明高浊度富营养化水体的研究.北京大学学报(自然科学版),2010,46(3):407-412 Ji Bing,Chen Jihua.Study on using constructed wetland systems for rural high turbid and eutrophic water treatment in chongming of Shanghai.Acta Scientiarum Naturalium Universitatis Pekinensis,2010,46(3):407-412(in Chinese)
    [2] Masters B.The ability of vegetated floating Islands to improve water quality in natural and constructed wetlands:A review.Water Practice and Technology,2012,7(1):1-9
    [3] Liu W.,Cui L.H.,Zhou Y.P.,et al.Removal of total phosphorus from septic tank effluent by the hybrid constructed wetland system.Procedia Environmental Sciences,2011,10:2102-2107
    [4] 唐晶,吕锡武,吴琦平,等.生物、生态组合技术处理农村生活污水研究.中国给水排水,2008,24(17):1-4 Tang Jing,Lv Xiwu,Wu Qiping,et al.Study on bio-ecological combined process for treatment of rural domestic sewage.China Water and Wastewater,2008,24(17):1-4(in Chinese)
    [5] 杨汉新,王文祥,蒋雄,等.鹤山市某城镇污水处理厂脱氮除磷工艺改造实践.中国给水排水,2008,24(18):83-86 Yang Hanxin,Wang Wenxiang,Jing Xiong,et al.Reconstruction practice of nitrogen and phosphorus removal process in a wastewater treatment plant of He Shan city.China Water & Wastewater,2008,24(18):83-86(in Chinese)
    [6] 何蓉,周琪,张军.表面流人工湿地处理生活污水的研究.生态环境,2004,13(2):180-181 He Rong,Zhou Qi,Zhang Jun.Treating domestic sewage by the free-water surface constructed wetlands.Ecology and Environment,2004,13(2):180-181(in Chinese)
    [7] 杨敦,周琪.人工湿地脱氮技术的机理及应用.中国给水排水,2003,19(1):23-24 Yang Dun,Zhou Qi.The mechanism and application of artificial wetland nitrogen removal technology.China Water & Wastewater,2003,19(1):23-24(in Chinese)
    [8] Haberl R.,Perfler R.,Mayer H.Constructed wetland in Europe.Water Science and Technology,1995,32(3):305-315
    [9] 张迎颖,丁为民,陈秀娟,等.复合垂直流人工湿地的脱氮机理及影响因素分析.环境工程,2009,27(5):36-40 Zhang Yinying,Ding Weimin,Chen Xiujuan,et al.Analysis of nitrogen removal mechansim and influence factors in integrated vertical flow constructed wetland.Environmental Engineering,2009,27(5):36-40(in Chinese)
    [10] Comín F.A.,Romero J.A.,Astorga V.,et al.Nitrogen removal and cycling in restored wetlands used as filters of nutrients for agricultural runoff.Water Science and Technology,1997,35(5):255-261
    [11] Saeed T.,Sun G.Z.A review on nitrogen and organics removal mechanisms in subsurface flow constructed wetlands:dependency on environmental parameters,operating conditions and supporting media.Journal of Environmental Management,2012,112:429-488
    [12] Vymazal J.Removal of nutrients in various types of constructed wetlands.Science of the Total Environment,2007,380(1-3):48-65
    [13] 刘树元,阎百兴,王莉霞.潜流人工湿地中植物对氮磷净化的影响.生态学报,2011,31(6):1538-1546 Liu Shuyuan,Yan Baixing,Wang Lixia.The effect of two wetland plants on nitrogen and phosphorus removal from the simulated paddy field runoff in two small-scale subsurface flow constructed wetlands.Acta Ecologica Sinica,2011,31(6):1538-1546
    [14] Liu X.,Huang S.L.,Tang T.F.Z.Growth characteristics and nutrient removal capability of plants in subsurface vertical flow constructed wetlands.Ecological Engineering,2012,44:189-198
    [15] 凌子微,仝欣楠,李亚红,等.处理低污染水的复合人工湿地脱氮过程.环境科学研究,2013,26(3):320-325 Ling Ziwei,Tong Xinnan,Li Yahong,et al.Study on nitrogen removal process of treatments for slightly contaminated water on hybrid constructed wetlands.Research of Environmental Sciences,2013,26(3):320-325(in Chinese)
    [16] 张晟,贺锋,成水平,等.八种不同工艺组合人工湿地系统除磷效果研究.长江流域资源与环境,2008,17(2):295-300 Zhang Sheng,He Feng,Cheng Shuiping,et al.On phosphorus removel efficiency in eight kinds of different combination systems of wetland.Resources and Environment in the Yangtze Basin,2008,17(2):295-300(in Chinese)
    [17] 沈耀良,王宝贞.废水生物处理新技术-理论与应用(第2版).北京:中国环境科学出版社,2006
    [18] Ko C.H.,Lee T.M.,Chang F.C.The correlations between system treatment efficiencies and aboveground emergent macrophyte nutrient removal for the Hsin-Hai Bridge phase II constructed wetland.Bioresource Technology,2011,102(9):5431-5437
    [19] 张嫒,张驰,郭旋,等.复合生态床的植物配置与净化效能研究.中国给水排水,2010,26(5):96-99 Zhang Yuan,Zhang Chi,Guo Xuan,et al.Arrangement and purification efficiency of plants in compound ecological bed.China Water & Wastewater,2011,26(5):96-99(in Chinese)
    [20] 尹振娟,杨扬,卢建,等.生物法-人工湿地组合工艺对小城镇混合污水氮素去除效果研究.生态环境学报,2010,19(5):1044-1049 Yin Zhenjuan,Yang Yang,Lu Jian,et al.Studies on the effects of the combined process of A/BCO-CW for treatment of small town mixed sewage.Ecology and Environmental Sciences,2010,19(5):1044-1049(in Chinese)
    [21] Kadlec R.H.The inadequacy of first-order treatment wetland models.Ecological Engineering,2000,15(1-2):105-119
    [22] 赵蓉,陈东宇,周少奇,等.k-C* 模型的人工湿地模拟研究.环境工程学报,2012,6(1):163-167 Zhao Rong,Chen Dongyu,Zhou Shaoqi,et al.Modeling of k-C* model for constructed wetland.Chinese Journal of Environmental Engineering,2012,6(1):163-167(in Chinese)
    [23] Kadlec R.H.Overview:Surface flow constructed wetlands.Water Science and Technology,1995,32(3):1-12
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1729
  • HTML全文浏览数:  1057
  • PDF下载数:  850
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-10-24
  • 刊出日期:  2014-09-28
王学华, 张娜, 苏祥, 沈耀良, 陈骏. 人工湿地组合工艺对太湖三山岛农村生活污水的脱氮效果[J]. 环境工程学报, 2014, 8(10): 4313-4318.
引用本文: 王学华, 张娜, 苏祥, 沈耀良, 陈骏. 人工湿地组合工艺对太湖三山岛农村生活污水的脱氮效果[J]. 环境工程学报, 2014, 8(10): 4313-4318.
shu
Wang Xuehua, Zhang Na, Su Xiang, Shen Yaoliang, Chen Jun. Effect of a combined constructed wetland process in removing nitrogen from rural domestic sewage in Sanshan Island, Taihu Lake[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4313-4318.
Citation: Wang Xuehua, Zhang Na, Su Xiang, Shen Yaoliang, Chen Jun. Effect of a combined constructed wetland process in removing nitrogen from rural domestic sewage in Sanshan Island, Taihu Lake[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4313-4318.
shu

人工湿地组合工艺对太湖三山岛农村生活污水的脱氮效果

  • 1. 苏州科技学院环境科学与工程学院, 苏州 215009
  • 2. 苏州科太环境技术有限公司, 苏州 215011
  • 收稿日期:  2013-10-24
基金项目:

苏州市科技局科技支撑计划项目（SS0903）

摘要: 针对太湖三山岛农村生活污水分布面广而分散和水质水量不稳定，以及三级处理费用高等问题，提出了人工湿地组合工艺。以设计规模为1 000 m3/d、处理生活污水的工艺系统为对象，探讨了氮元素在系统中的去除效果、途径及其一级去除速率常数。结果表明，该工艺对NH4+-N去除效果较好，出水NH4+-N平均达到地表水Ⅲ类，TN平均接近地表水Ⅴ类；潜流人工湿地、好氧生态塘C、兼性生态塘A和表流人工湿地D对氮的去除量分别占组合工艺去除总量的52.05%、18.65%、16.65%和12.65%；组合工艺对NH4+-N和TN的平均一级去除速率常数分比别为（14.47±2.01）和（25.91±4.99）m/a。
