利用钢渣制备多孔吸声材料的研究

,  ,  ,

downloadPDF

上一篇

下一篇

李鹏, 郭占成, 孙朋, 郭茂盛. 利用钢渣制备多孔吸声材料的研究[J]. 环境工程学报, 2014, 8(10): 4409-4414.
引用本文: 李鹏, 郭占成, 孙朋, 郭茂盛. 利用钢渣制备多孔吸声材料的研究[J]. 环境工程学报, 2014, 8(10): 4409-4414.
shu
Li Peng, Guo Zhancheng, Sun Peng, Guo Maosheng. Study on preparation of porous sound absorbing material using steel slag[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4409-4414.
Citation: Li Peng, Guo Zhancheng, Sun Peng, Guo Maosheng. Study on preparation of porous sound absorbing material using steel slag[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4409-4414.
shu

利用钢渣制备多孔吸声材料的研究

  • 1.

    北京科技大学钢铁冶金新技术国家重点实验室, 北京 100083

  • 基金项目:

    国家“863”高技术研究发展计划资助项目（2011AA06A105）

  • 中图分类号: TF09

Study on preparation of porous sound absorbing material using steel slag

  • 1.

    State Key Laboratory of Advanced Metallurgy, University of Science and Technology Beijing, Beijing 100083, China

  • Fund Project:

  • 摘要: 为促进钢渣的高附加值利用，研究了以钢渣为主要原料，以微硅粉为粘结剂，采用烧结成型的方法制备的多孔吸声材料的吸声性能及力学性能。结合X射线荧光分析、X射线衍射分析、热重分析、扫描电镜观察和化学分析等测试方法，对样品的化学组成、矿物组成、烧结制度、微观形貌和体积稳定性进行了分析。结果表明，利用钢渣制备的多孔吸声材料具有良好的吸声性能，材料的体积稳定性良好且在吸声性能最佳时的抗压强度为5.41 MPa，是一种适用于解决城市道路、高速路和铁路噪音污染问题的吸声材料。
    Abstract: In order to promote the recycling of steel slag with high value-added,we studied the sound absorption performance and mechanical property of the porous sound absorbing material which used steel slag as main raw material and micro-silica fume as caking agent.The material was prepared through the method of sintering.The chemical and mineral compositions,sintering schedule,microstructure and volume stability of the sintered sample were analyzed via X-ray fluorescence (XRF),X-ray diffraction (XRD),thermogravimetric analysis and differential thermal analysis (TG-DTA),scanning electronic microscopy (SEM) and chemical analysis.The results showed that the porous sound absorbing material we prepared has excellent sound absorption performance,the material has good volume stability and compressive strength of the material is 5.41 MPa as the best sound absorption performance of the material.The material can be applied to highways,urban roads and railways to solve noise pollution.
  • 加载中
  • [1] Han F.S.,Seiffert G.,Zhao Y.Y.,et al.Acoustic absorption behaviour of an open-celled aluminium foam.Journal of Physics D:Applied Physics,2003,36(3):294-302
    [2] Fouladi M.H.,Mohd Nor M.J.,Ayub M.,et al.Utilization of coir fiber in multilayer acoustic absorption panel.Applied Acoustics,2010,71(3):241-249
    [3] Kino N.A comparison of two acoustical methods for estimating parameters of glass fibre and melamine foam materials.Applied Acoustics,2012,73(6-7):590-603
    [4] Li Z.B.,Zhao S.Y.,Zhao X.G.,et al.Cementitious property modification of basic oxygen furnace steel slag.Construction and Building Materials,2013,48:575-579
    [5] 张朝晖,廖杰龙,巨建涛,等.钢渣处理工艺与国内外钢渣利用技术.钢铁研究学报,2013,25(7):1-4 Zhang Zhaohui,Liao Jielong,Ju Jiantao,et al.Treatment process and utilization technology of steel slag in China and abroad.Journal of Iron and Steel Research,2013,25(7):1-4(in Chinese)
    [6] 郭家林,赵俊学,黄敏.钢渣综合利用技术综述及建议.中国冶金,2009,19(2):35-38 Guo Jialin,Zhao Junxue,Huang Min.Technical summary and suggestions of comprehensive utilization of steel slag.China Metallurgy,2009,19(2):35-38(in Chinese)
    [7] Das B.,Prakash S.,Reddy P.S.R.,et al.An overview of utilization of slag and sludge from steel industries.Resources,Conservation and Recycling,2007,50(1):40-57
    [8] Tsakiridis P.E.,Papadimitriou G.D.,Tsivilis S.,et al.Utilization of steel slag for portland cement clinker production.Journal of Hazardous Materials,2008,152(2):805-811
    [9] Shen W.G.,Zhou M.K.,Ma W.,et al.Investigation on the application of steel slag-fly ash-phosphogypsum solidified material as road base material.Journal of Hazardous Materials,2009,162(1):99-104
    [10] Shih P.H.,Wu Z.Z.,Chiang H.L.Characteristics of bricks made from waste steel slag.Waste Management,2004,24(10):1043-1047
    [11] Wang G.G.,Wang Y.H.,Gao Z.L.Use of steel slag as a granular material:Volume expansion prediction and usability criteria.Journal of Hazardous Materials,2010,184(1-3):555-560
    [12] Waligora J.,Bulteel D.,Degrugilliers P.,et al.Chemical and mineralogical characterizations of LD converter steel slags:A multi-analytical techniques approach.Materials Characterization,2010,61(1):39-48
    [13] 张作顺,连芳,廖洪强,等.利用铁尾矿高温改性钢渣的性能.北京科技大学学报,2012,34(12):1379-1384 Zhang Zuoshun,Lian Fang,Liao Hongqiang,et al.Modifying the properties of steel slag by iron tailings at high temperature.Journal of University of Science and Technology Beijing,2012,34(12):1379-1384(in Chinese)
    [14] 赵海晋,余其俊,韦江雄,等.利用粉煤灰高温重构及稳定钢渣品质的研究.硅酸盐通报,2010,29(3):572-576 Zhao Haijin,Yu Qijun,Wei Jiangxiong,et al.Study on improvement of steel slag property with fly ash added at high temperature.Bulletin of the Chinese Ceramic Society,2010,29(3):572-576(in Chinese)
    [15] 邵钢,俞悟周.道路交通噪声等效频率的研究.声学技术,2009,28(5):201-202 Shao Gang,Yu Wuzhou.The equivalent frequency of road traffic noise.Technical Acoustics,2009,28(5):201-202(in Chinese)
    [16] 龚凯,刘林芽.客运列车声屏障的等效频率试验研究.噪声与振动控制,2011,4(5):117-120,152 Gong Kai,Liu Linya.Experimental study on sound barrier equivalent frequency of passenger trains.Noise and Vibration Control,2011,31(5):117-120,152(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1609
  • HTML全文浏览数:  982
  • PDF下载数:  784
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-10-28
  • 刊出日期:  2014-09-28
李鹏, 郭占成, 孙朋, 郭茂盛. 利用钢渣制备多孔吸声材料的研究[J]. 环境工程学报, 2014, 8(10): 4409-4414.
引用本文: 李鹏, 郭占成, 孙朋, 郭茂盛. 利用钢渣制备多孔吸声材料的研究[J]. 环境工程学报, 2014, 8(10): 4409-4414.
shu
Li Peng, Guo Zhancheng, Sun Peng, Guo Maosheng. Study on preparation of porous sound absorbing material using steel slag[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4409-4414.
Citation: Li Peng, Guo Zhancheng, Sun Peng, Guo Maosheng. Study on preparation of porous sound absorbing material using steel slag[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4409-4414.
shu

利用钢渣制备多孔吸声材料的研究

  • 1. 北京科技大学钢铁冶金新技术国家重点实验室, 北京 100083
  • 收稿日期:  2013-10-28
基金项目:

国家“863”高技术研究发展计划资助项目（2011AA06A105）

摘要: 为促进钢渣的高附加值利用，研究了以钢渣为主要原料，以微硅粉为粘结剂，采用烧结成型的方法制备的多孔吸声材料的吸声性能及力学性能。结合X射线荧光分析、X射线衍射分析、热重分析、扫描电镜观察和化学分析等测试方法，对样品的化学组成、矿物组成、烧结制度、微观形貌和体积稳定性进行了分析。结果表明，利用钢渣制备的多孔吸声材料具有良好的吸声性能，材料的体积稳定性良好且在吸声性能最佳时的抗压强度为5.41 MPa，是一种适用于解决城市道路、高速路和铁路噪音污染问题的吸声材料。
