废水中硝氮和COD浓度对AD-MFC脱氮产电性能的影响

,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

张吉强, 郑平, 何崭飞, 季军远, 张萌, 陈慧, 谢作甫. 废水中硝氮和COD浓度对AD-MFC脱氮产电性能的影响[J]. 环境工程学报, 2014, 8(10): 4508-4514.
引用本文: 张吉强, 郑平, 何崭飞, 季军远, 张萌, 陈慧, 谢作甫. 废水中硝氮和COD浓度对AD-MFC脱氮产电性能的影响[J]. 环境工程学报, 2014, 8(10): 4508-4514.
shu
Zhang Jiqiang, Zheng Ping, He Zhanfei, Ji Junyuan, Zhang Meng, Chen Hui, Xie Zuofu. Influence of nitrate and COD concentrations on nitrogen removal and power production performance of AD-MFC[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4508-4514.
Citation: Zhang Jiqiang, Zheng Ping, He Zhanfei, Ji Junyuan, Zhang Meng, Chen Hui, Xie Zuofu. Influence of nitrate and COD concentrations on nitrogen removal and power production performance of AD-MFC[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4508-4514.
shu

废水中硝氮和COD浓度对AD-MFC脱氮产电性能的影响

  • 1.

    浙江大学环境工程系, 杭州 310058

  • 2.

    中国海洋大学环境科学与工程学院, 青岛 266100

  • 3.

    浙江科技学院, 杭州 310023

  • 基金项目:

    国家自然科学基金资助项目（31070110）

    高等学校博士学科点专项科研基金资助项目（20110101110078）

    浙江省自然科学基金重点项目（Z5110094）

  • 中图分类号: X703.1

Influence of nitrate and COD concentrations on nitrogen removal and power production performance of AD-MFC

  • 1.

    Department of Environmental Engineering, Zhejiang University, Hangzhou 310058, China

  • 2.

    College of Environmental Science and Engineering, Ocean University of China, Qingdao 266100, China

  • 3.

    Zhejiang University of Science and Technology, Hangzhou 310023, China

  • Fund Project:

  • 摘要: 为探明废水中硝氮和COD浓度对阳极反硝化微生物燃料电池（AD-MFC）工作性能的影响，在批式操作下逐步提高进水浓度考察了AD-MFC反硝化速率和产电性能的变化，并以多个动力学模型对此过程进行拟合。结果表明，废水浓度可通过污染物降解速率来影响产电性能，硝氮浓度从50 mg/L升高至 2 000 mg/L时，反硝化速率和输出电压逐渐达到最大值（（1.26±0.01）kg N/（m3·d）和（1 016.75±4.74）mV），但硝氮浓度继续提高会抑制反硝化速率和产电性能。Han-Levenspiel模型可较好地表征AD-MFC的污染物降解和产电动力学行为，以该模型为基础建立了污染物去除速率、输出电压、功率密度与进水浓度之间的关系，反硝化在NO3--N高于4 000 mg/L时才能被完全抑制。AD-MFC适用于处理不同浓度的硝酸盐废水，并对高浓度硝酸盐废水具有较好的耐受性。
    Abstract: To investigate the influence of nitrate and COD concentrations on the nitrogen removal and power production performance of AD-MFC,variations of denitrification rate and electricity production were monitored by stepwisely elevating the influent wastewater concentration and the experimental data were fitted with several kinetic models.Power generation was closely related to denitrification rate.Both the denitrification rate and electricity production capacity were enhanced as the initial NO3--N concentration increased from 50 mg/L to 2 000 mg/L,with a maximum nitrate removal rate of (1.26±0.01)kg N/(m3·d) and maximum voltage output of (1 016.75±4.74)mV.Further increase of influent concentration led to decrease of denitrification rate and electricity production capacity.The kinetic behavior of the AD-MFC could be described well with Han-Levenspiel model,through which the relationships among the substrates removal,power generation and wastewater concentrations were established.Denitrification would be completely inhibited at a NO3--N concentration more than 4 000 mg/L,which suggested that AD-MFC was suitable to treat various concentrations of nitrate wastewater and tolerant to high nitrate concentration wastewater.
  • 加载中
  • [1] 赵正权,徐冬,张浩,等.中国污水处理电耗分析和节能途径.科技导报,2010,28(22):43-47 Zhao Zhengquan,Xu Dong,Zhang Hao,et al.Power consumption of wastewater treatment and the measures of energy saving.Science & Technology Review,2010,28(22):43-47(in Chinese)
    [2] Oh S.T.,Kim J.R.,Premier G.C.,et al.Sustainable wastewater treatment:How might microbial fuel cells contribute.Biotechnology Advances,2010,28(6):871-881
    [3] McCarty P.L.,Bae J.,Kim J.Domestic wastewater treatment as a net energy producer:Can this be achieved?.Environmental Science & Technology,2011,45(17):7100-7106
    [4] Logan B.E.,Rabaey K.Conversion of wastes into bioelectricity and chemicals by using microbial electrochemical technologies.Science,2012,337(6095):686-690
    [5] Puig S.,Serra M.,Coma M.,et al.Simultaneous domestic wastewater treatment and renewable energy production using microbial fuel cells(MFCs).Water Science and Technology,2011,64(4):904-909
    [6] Pant D.,Van Bogaert.G.,Diels L.,et al.A review of the substrates used in microbial fuel cells(MFCs)for sustainable energy production.Bioresource Technology,2010,101(6):1533-1543
    [7] Morris J.M.,Fallgren P.H.,Jin S.,et al.Enhanced denitrification through microbial and steel fuel-cell generated electron transport.Chemical Engineering Journal,2009,153(1):37-42.
    [8] 张吉强,郑平,张萌,等.AD-MFC中甲醇与硝酸盐的偶合过程与作用机制.化工学报,2013,64(9):3404-3411 Zhang Jiqiang,Zheng Ping,Zhang Meng,et al.Coupling process and mechanism of methanol oxidation coupled to nitrate reduction in an anodic denitrification microbial fuel cell(AD-MFC).Journal of Chemical Industry and Engineering (China),2013,64(9):3404-3411(in Chinese)
    [9] Shen J.,He R.,Han W.,et al.Biological denitrification of high-nitrate wastewater in a modified anoxic/oxic-membrane bioreactor (A/O-MBR).Journal of Hazardous Materials,2009,172(2-3):595-600
    [10] Tang C.J.,Zheng P.,Chen T.T.,et al.Enhanced nitrogen removal from pharmaceutical wastewater using SBA-ANAMMOX process.Water Research,2011,45(1):201-210
    [11] 国家环境保护总局.水和废水监测分析方法(第4版).北京:中国环境科学出版社,2002
    [12] Foglar L.,Briki F.Wastewater denitrification process-the influence of methanol and kinetic analysis.Process Biochemistry,2003,39(1):95-103
    [13] Clauwaert P.,Rabaey K.,Aelterman P.,et al.Biological denitrification in microbial fuel cells.Environmental Science & Technology,2007,41(9):3354-3360
    [14] McCarthy P.L.,Beck L.,Amant P.Biological denitrification of wastewaters by addition of organic materials//Proceedings of the 24th Industrial Waste Conference.Indiana,1969:1271-1285.
    [15] Logan B.E.,Hamelers B.,Rozendal R.,et al.Microbial fuel cells:Methodology and technology.Environmental Science & Technology,2006,40(17):5181-5192
    [16] Madigan M.T.,Martinko J.M.,Stahl D.,et al.Brock Biology of Microorganisms.San Francisco:Pearson/Benjamin Cummings,2010
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1546
  • HTML全文浏览数:  879
  • PDF下载数:  760
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-10-16
  • 刊出日期:  2014-09-28
张吉强, 郑平, 何崭飞, 季军远, 张萌, 陈慧, 谢作甫. 废水中硝氮和COD浓度对AD-MFC脱氮产电性能的影响[J]. 环境工程学报, 2014, 8(10): 4508-4514.
引用本文: 张吉强, 郑平, 何崭飞, 季军远, 张萌, 陈慧, 谢作甫. 废水中硝氮和COD浓度对AD-MFC脱氮产电性能的影响[J]. 环境工程学报, 2014, 8(10): 4508-4514.
shu
Zhang Jiqiang, Zheng Ping, He Zhanfei, Ji Junyuan, Zhang Meng, Chen Hui, Xie Zuofu. Influence of nitrate and COD concentrations on nitrogen removal and power production performance of AD-MFC[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4508-4514.
Citation: Zhang Jiqiang, Zheng Ping, He Zhanfei, Ji Junyuan, Zhang Meng, Chen Hui, Xie Zuofu. Influence of nitrate and COD concentrations on nitrogen removal and power production performance of AD-MFC[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4508-4514.
shu

废水中硝氮和COD浓度对AD-MFC脱氮产电性能的影响

  • 1.  浙江大学环境工程系, 杭州 310058
  • 2.  中国海洋大学环境科学与工程学院, 青岛 266100
  • 3.  浙江科技学院, 杭州 310023
  • 收稿日期:  2013-10-16
基金项目:

国家自然科学基金资助项目（31070110）

高等学校博士学科点专项科研基金资助项目（20110101110078）

浙江省自然科学基金重点项目（Z5110094）

摘要: 为探明废水中硝氮和COD浓度对阳极反硝化微生物燃料电池（AD-MFC）工作性能的影响，在批式操作下逐步提高进水浓度考察了AD-MFC反硝化速率和产电性能的变化，并以多个动力学模型对此过程进行拟合。结果表明，废水浓度可通过污染物降解速率来影响产电性能，硝氮浓度从50 mg/L升高至 2 000 mg/L时，反硝化速率和输出电压逐渐达到最大值（（1.26±0.01）kg N/（m3·d）和（1 016.75±4.74）mV），但硝氮浓度继续提高会抑制反硝化速率和产电性能。Han-Levenspiel模型可较好地表征AD-MFC的污染物降解和产电动力学行为，以该模型为基础建立了污染物去除速率、输出电压、功率密度与进水浓度之间的关系，反硝化在NO3--N高于4 000 mg/L时才能被完全抑制。AD-MFC适用于处理不同浓度的硝酸盐废水，并对高浓度硝酸盐废水具有较好的耐受性。
