不同填料潮汐流人工湿地处理SBR尾水的对比

,  ,  ,

downloadPDF

上一篇

下一篇

孔令华, 施春红, 马方曙, 周北海. 不同填料潮汐流人工湿地处理SBR尾水的对比[J]. 环境工程学报, 2017, 11(1): 379-385. doi: 10.12030/j.cjee.201508147
引用本文: 孔令华, 施春红, 马方曙, 周北海. 不同填料潮汐流人工湿地处理SBR尾水的对比[J]. 环境工程学报, 2017, 11(1): 379-385. doi: 10.12030/j.cjee.201508147
shu
KONG Linghua, SHI Chunhong, MA Fangshu, ZHOU Beihai. Comparison of treatment on SBR tail water in tidal flow constructed wetlands with different packing[J]. Chinese Journal of Environmental Engineering, 2017, 11(1): 379-385. doi: 10.12030/j.cjee.201508147
Citation: KONG Linghua, SHI Chunhong, MA Fangshu, ZHOU Beihai. Comparison of treatment on SBR tail water in tidal flow constructed wetlands with different packing[J]. Chinese Journal of Environmental Engineering, 2017, 11(1): 379-385. doi: 10.12030/j.cjee.201508147
shu

不同填料潮汐流人工湿地处理SBR尾水的对比

  • 1.

    北京科技大学土木与环境工程学院, 北京, 100083

  • 2.

    北京科技大学工业典型污染物废物资源化处理北京市重点实验室, 北京, 100083

  • 基金项目:

  • 中图分类号: X703

Comparison of treatment on SBR tail water in tidal flow constructed wetlands with different packing

  • 1.

    School of Civil and Environmental Engineering, Beijing University of Science and Technology, Beijing 100083, China

  • 2.

    Beijing Key Laboratory of Resource-oriented Treatment of Industrial Pollutants, Beijing University of Science and Technology, Beijing 100083, China

  • Fund Project:

  • 摘要: 通过构建室内潮汐流沸石-石灰石混合填料和沸石填料人工湿地装置，探讨了不同基质人工湿地对SBR尾水中污染物的去除效果。结果表明，沸石对NH4+-N的吸附能力强，且潮汐间歇运行方式使系统一直保持高效的去除NH4+-N的能力，石灰石中Ca、Mg含量高，对P有较好的吸附。潮汐流沸石-石灰石混合填料、沸石填料人工湿地对NH4+-N的去除率分别为99.8%、96.7%，对TP的去除率分别为59.6%、24.9%。石灰石呈中性偏碱性，有利于水中硝化菌、反硝化菌和某些异养菌群的生长。潮汐流沸石-石灰石混合填料、沸石填料人工湿地对TN的去除率分别为43.0%、28.0%，对COD的去除率分别为43.4%、36.7%。沸石-石灰石混合填料人工湿地上层基质中微生物量最高，达到20.45 nmol·g-1填料（相当于E.coli大小的细胞2.0×109个）。2组系统中微生物量具有较明显的分层现象，且上层高于下层，这与污染物随水流推流方向的浓度变化一致。
    Abstract: Two tidal flow constructed wetlands (TFCW), one with zeolite-limestone-mixed packing and one with zeolite-only packing, were set up on a lab scale to explore the impact of purification performance on SBR tidal water. Results showed that zeolite had strong adsorption affinity for NH4+-N, and the tidal intermittent operation mode removed NH4+-N with high efficiency. The Ca and Mg content was high in the limestone, therefore the limestone adsorbed P well. In the zeolite-limestone-mixed packing and zeolite-only packing TFCWs, the removal rates for NH4+-N were 99.8% and 96.7%, respectively, and for P were 59.6% and 24.9%, respectively, in the plateau stage. The limestone was weakly alkaline, which was beneficial for the growth of nitrifying bacteria, denitrifying bacteria, and some heterotrophic bacteria in the water. In the zeolite-limestone-mixed packing and zeolite-only packing TFCWs, the removal rates for TN were 43.0% and 28.0%, respectively, and for COD were 43.4% and 36.7%, respectively, in the plateau stage. The upper layer of the zeolite-limestone-mixed packing TFCW had the most bacteria, with 20.45 nmol·g-1 packing, amounting to 2.0×109 cells (as they are the same size as E. coli). From microbial quantity, it was determined that the upper layer was further along than the lower layer, which was consistent with the change in pollutant concentration as well as water flow direction.
  • 加载中
  • [1] ROUSSEAUA D P L, LESAGE E, STORY A, et al. Constructed wetlands for water reclamation[J]. Desalination, 2008, 218(1/2/3):181-189
    [2] WU Shubiao, ZHANG Dongxiao, AUSTIN D, et al. Evaluation of a lab-scale tidal flow constructed wetland performance:Oxygen transfer capacity, organic matter and ammonium removal[J]. Ecological Engineering, 2011, 37(11):1789-1795
    [3] SUN G, GRAY K R, BIDDLESTONE A J, et al. Treatment of agricultural wastewater in a pilot-scale tidal flow reed bed system[J]. Environmental Technology, 1999, 20(2):233-237
    [4] 黄逸群, 张民, 徐玉新. 人工湿地填料净化生活污水级配优化研究[J]. 环境科学与技术, 2009, 32(3):130-134
    [5] 吕涛, 吴树彪, 柳明慧, 等. 潮汐流及水平潜流人工湿地污水处理效果比较研究[J]. 农业环境科学学报, 2013, 32(8):1618-1624
    [6] 张军, 周琪, 何蓉. 表面流人工湿地中氮磷的去除机理[J]. 生态环境, 2004, 13(1):98-101
    [7] 尹炜, 李培军, 傅金祥, 等. 潜流人工湿地不同基质除磷研究[J]. 沈阳建筑大学学报(自然科学版), 2006, 22(6):985-988
    [8] 徐丽花, 周琪. 不同填料人工湿地处理系统的净化能力研究[J]. 上海环境科学, 2002, 21(10):603-605
    [9] 于鑫, 张晓健, 王占生. 饮用水生物处理中生物量的脂磷法测定[J]. 城市给排水, 2002, 28(5):1-5
    [10] 周金娥, 唐立峰. 人工湿地系统的除污机理及影响因素探讨[J]. 土壤, 2009, 41(4):520-524
    [11] 杜新, 施春红, 马方曙. 有机负荷对潮汐流人工湿地净化农村生活污水的影响[J]. 生态与农村环境学报, 2015, 31(3):380-384
    [12] SCHOLZ M, LEE B H. Constructed wetlands:A review[J]. International Journal of Environmental Studies, 2005, 62(4):421-447
    [13] 张自杰. 排水工程:下册[M].4版. 北京:中国建筑工业出版社, 2000
    [14] 李圭白, 张杰. 水质工程学[M]. 北京:中国建筑工业出版社, 2005
    [15] VYMAZAL J. Horizontal sub-surface flow and hybrid constructed wetlands systems for wastewater treatment[J]. Ecological Engineering, 2005, 25(5):478-490
    [16] PAREDES D, KUSCHK P, MBWETTE T S A, et al. New aspects of microbial nitrogen transformations in the context of wastewater treatment:A review[J]. Engineering in Life Science, 2007, 7(1):13-25
    [17] LEE C G, FLETCHER T D, SUN Guangzhi. Nitrogen removal in constructed wetland systems[J]. Engineering in Life Sciences, 2009, 9(1):11-22
    [18] SASIKALA S, TANAKA N, WAHWAHH S Y, et al. Effects of water level fluctuation on radial oxygen loss, root porosity, and nitrogen removal in subsurface vertical flow wetland mesocosms[J]. Ecological Engineering, 2009, 35(3):410-417
    [19] PENG Zhaoxu, PENG Yongzhen, GUI Lijuan, et al. Competition for single carbon source between denitrification and phosphorus release in sludge under anoxic condition[J]. Chinese Journal of Chemical Engineering, 2010, 18(3):472-477
    [20] 徐亚同. pH值、温度对反硝化的影响[J]. 中国环境科学, 1994, 14(4):308-313
    [21] MARTÍN M, GARGALLO S, HERNÁNDEZ-CRESPO C, et al. Phosphorus and nitrogen removal from tertiary treated urban wastewaters by a vertical flow constructed wetland[J]. Ecological Engineering, 2013, 61:34-42
    [22] ZHAO Yongjun, LIU Bo, ZHANG Wenguang, et al. Performance of pilot-scale vertical-flow constructed wetlands in responding to variation in influent C/N ratios of simulated urban sewage[J]. Bioresource Technology, 2010, 101(6):1693-1700
    [23] SUNDBERG C, TONDERSKI K, LINDGREN P E. Potential nitrification and denitrification and the corresponding composition of the bacterial communities in a compact constructed wetland treating landfill leachates[J]. Water Science and Technology, 2007, 56(3):159-166
    [24] 付融冰, 杨海真, 顾国维, 等. 人工湿地基质微生物状况与净化效果相关分析[J]. 环境科学研究, 2005, 18(6):44-49
