合成条件对粉煤灰合成沸石除磷特性的影响

,  ,  ,  ,

downloadPDF

上一篇

下一篇

柯瑶瑶, 冀晓东, 李亚伟, 赵宁, 宋祎楚. 合成条件对粉煤灰合成沸石除磷特性的影响[J]. 环境工程学报, 2016, 10(3): 1492-1499. doi: 10.12030/j.cjee.20160378
引用本文: 柯瑶瑶, 冀晓东, 李亚伟, 赵宁, 宋祎楚. 合成条件对粉煤灰合成沸石除磷特性的影响[J]. 环境工程学报, 2016, 10(3): 1492-1499. doi: 10.12030/j.cjee.20160378
shu
Ke Yaoyao, Ji Xiaodong, Li Yawei, Zhao Ning, Song Yichu. Effect of synthetic conditions on characters of phosphorus removal using synthetic zeolite from fly ash[J]. Chinese Journal of Environmental Engineering, 2016, 10(3): 1492-1499. doi: 10.12030/j.cjee.20160378
Citation: Ke Yaoyao, Ji Xiaodong, Li Yawei, Zhao Ning, Song Yichu. Effect of synthetic conditions on characters of phosphorus removal using synthetic zeolite from fly ash[J]. Chinese Journal of Environmental Engineering, 2016, 10(3): 1492-1499. doi: 10.12030/j.cjee.20160378
shu

合成条件对粉煤灰合成沸石除磷特性的影响

  • 1.

    北京林业大学水土保持国家林业局重点实验室, 北京 100083

  • 2.

    水利部综合事业局, 北京 100053

  • 3.

    黄河流域水资源保护局, 郑州 450003

  • 基金项目:

    北京林业大学科技创新计划团队项目(TD2011-01)

  • 中图分类号: X705

Effect of synthetic conditions on characters of phosphorus removal using synthetic zeolite from fly ash

  • 1.

    Key Laboratory of Soil and Water Conservation State Forestry Administration, Beijing Forestry University, Beijing 100083, China

  • 2.

    Bureau of Comprehensive Development of Ministry of Water Resources, Beijing 100053, China

  • 3.

    Yellow River Water Resource Protection Bureau, Zhengzhou 450003, China

  • Fund Project:

  • 摘要: 利用不同钙含量的3种粉煤灰采用碱熔融-水热法合成沸石,研究了不用合成条件对3种粉煤灰合成沸石除磷性能的影响,并分析了除磷机理。3种粉煤灰合成沸石中沸石的种类各不相同,低钙粉煤灰合成沸石主要以NaP1型沸石为主,中钙粉煤灰合成沸石主要以一种无名沸石为主,高钙粉煤灰合成沸石则主要以加藤石为主,沸石含量几乎为零。碱灰比、熔融时间、熔融温度、固液比、结晶时间等合成因素中,对3种粉煤灰合成沸石固磷能力影响相对较大的是碱灰比和熔融时间。3种合成沸石的除磷能力顺序依次为高钙粉煤灰合成沸石> 中钙粉煤灰合成沸石> 低钙粉煤灰合成沸石,并且3种沸石的固磷能力与初始原料粉煤灰中的CaO含量成正比。固磷机理是合成沸石溶于水后向水中释放Ca2+,释放出来的Ca2+即可与磷酸根生成磷酸钙沉淀,从而达到固磷的目的。合成的沸石最大固磷能力为92.24 mg/g。
    Abstract: An alkaline fusion method was adopted to synthesize zeolites from low-calcium, middle-calcium, and high-calcium fly ashes. The effects of different synthesis conditions on the phosphorus immobilization capacity of the synthesized zeolites were studied, and the phosphorus immobilization mechanism was also analyzed. The main crystals of the three synthesized zeolites from low-calcium, middle-calcium, and high-calcium fly ashes are NaP1 zeolite, Na6(AlSiO4)6·4H2O, and katoite, respectively. The effects of the NaOH/fly-ash mass ratio and the melting time on the phosphorus uptake of the synthesized zeolites are relatively larger than the solid-liquid ratio, melting temperature, and crystallization time. The phosphorus uptake capacity of the three synthesized zeolites is in the following order:high-calcium zeolite> middle-calcium zeolite> low-calcium zeolite. The capacity of synthetic the synthesized zeolites for phosphorus removal is proven to be proportional to the calcium content of the different raw materials. After the synthesized zeolites were added into the solution, the Ca2+ in the zeolite was leached into the solution and its was then precipitated with PO3-4 to produce calcium phosphate. The maximum adsorption capacity for phosphorus obtained is 92.24 mg/g.
  • 加载中
  • [1] Guo L. Doing battle with the green monster of Taihu Lake. Science, 2007, 317(5842):1166
    [2] Yang Min, Yu Jianwei, Li Zonglai, et al. Taihu Lake not to blame for Wuxi's woes. Science, 2007, 319(5860):158
    [3] 张传光, 张乃明, 于秀芳. 热改性斜发沸石对富营养化水体的脱氮除磷效果. 环境工程学报, 2013, 7(5):1666-1670 Zhang Chuanguang, Zhang Naiming, Yu Xiufang. Effect of denitrification and dephosphorization of thermal modified clinoptilolite for eutrophic water. Chinese Journal of Environmental Engineering, 2013, 7(5):1666-1670(in Chinese)
    [4] Schindler D. W., Hecky R. E., Findlay D. L., et al. Eutrophication of lakes cannot be controlled by reducing nitrogen input:Results of a 37-year whole-ecosystem experiment. Proceedings of the National Academy of Sciences of the United States of America, 2008, 105(32):11254-11258
    [5] Yang Xiaofang, Wang Dongsheng, Sun Zhongxi, et al. Adsorption of phosphate at the aluminum (hydr) oxides-water interface:Role of the surface acid-base properties. Colloids and Surfaces A:Physicochemical and Engineering Aspects, 2007, 297(1-3):84-90
    [6] Li Yanzhong, Liu Changjun, Luan Zhaokun, et al. Phosphate removal from aqueous solutions using raw and activated red mud and fly ash. Journal of Hazardous Materials, 2006, 137(1):374-383
    [7] Tanaka Y., Yatagai A., Masujima H., et al. Autotrophic denitrification and chemical phosphate removal of agro-industrial wastewater by filtration with granular medium. Bioresource Technology, 2007, 98(4):787-791
    [8] Rodrigues L. A., Pinto Da Silva M. L. C. An investigation of phosphate adsorption from aqueous solution onto hydrous niobium oxide prepared by co-precipitation method. Colloids and Surfaces A:Physicochemical and Engineering Aspects, 2009, 334(1-3):191-196
    [9] Mulkerrins D., Dobson A. D. W., Colleran E. Parameters affecting biological phosphate removal from wastewaters. Environment International, 2004, 30(2):249-259
    [10] 唐朝春, 刘名, 陈惠民, 等. 吸附除磷技术的研究进展. 水处理技术, 2014, 40(9):1-7 Tang Chaochun, Liu Ming, Chen Huimin, et al. Research progress of phosphorus removal from wastewater by adsorption technology. Technology of Water Treatment, 2014, 40(9):1-7(in Chinese)
    [11] 杨利香,施钟毅."十一五"我国粉煤灰综合利用成效及其未来技术方向和发展趋势.粉煤灰,2012, (4):4-9 Yang Lixiang, Shi Zhongyi. "Eleventh Five" fly ash comprehensive utilization achievements, future technology orientation and development tendency in our country. Coal Ash, 2012, (4):4-9(in Chinese)
    [12] 鲁晓勇, 朱小燕. 粉煤灰综合利用的现状与前景展望. 辽宁工程技术大学学报, 2005, 24(2):295-298 Lu Xiaoyong, Zhu Xiaoyan. Present situation and developing prospect of comprehensive utilization of fly ashes. Journal of Liaoning Technical University, 2005, 24(2):295-298(in Chinese)
    [13] 冯俊杰, 张瑞芳, 龚伦伦, 等. 基于粉煤灰的多孔无机保温材料的研制. 材料科学与工程学报, 2014, 32(5):638-642 Fen Junjie, Zhang Ruifang, Gong Lunlun, et al. Preparation of porous thermal insulation material using fly ash. Journal of Materials Science and Engineering, 2014, 32(5):638-642(in Chinese)
    [14] 赵智, 唐泽军, 宋满刚, 等. 粉煤灰和PAM改良沙土物理性质的田间试验. 水土保持学报, 2013, 27(3):178-183 Zhao Zhi, Tang Zejun, Song Mangang, et al. An field trial of polyacrylamide and fly ash for modifying physical properties of sandy soil. Journal of Soil and Water Conservation, 2013, 27(3):178-183(in Chinese)
    [15] Chen Jiangang, Kong Hainan, Wu Deyi, et al. Removal of phosphate from aqueous solution by zeolite synthesized from fly ash. Journal of Colloid and Interface Science, 2006, 300(2):491-497
    [16] 赵统刚, 吴德意, 陈建刚, 等. 粉煤灰合成沸石同步脱氨除磷特性的研究. 环境科学, 2006, 27(4):696-700 Zhao Tonggang, Wu Deyi, Chen Jiangang, et al. Study on characteristics of simultaneous removal of ammonium and phosphate from waste water by zeolitized fly ash. Environmental Science, 2006, 27(4):696-700(in Chinese)
    [17] 王将军, 孙立军. 高钙粉煤灰的界定. 粉煤灰综合利用, 2002, (5):27-29 Wang Jiangjun, Sun Lijun. The definition of high-calcium-flyash. Fly Ash Comprehensive Utilization, 2002, (5):27-29(in Chinese)
    [18] Juan R., Hernández S., Andrés J. M., et al. Synthesis of granular zeolitic materials with high cation exchange capacity from agglomerated coal fly ash. Fuel, 2007, 86(12-13):1811-1821
    [19] Molina A., Poole C. A comparative study using two methods to produce zeolites from fly ash. Minerals Engineering, 2004, 17(2):167-173
    [20] 罗富金. 城市污水处理升级改造中化学除磷原理及费用. 山西建筑, 2010, 36(29):174-175 Luo Fujin. Chemical phosphorus removal principles in the upgrading reform of urban wastewater treatment and the cost. Shanxi Architecture, 2010, 36(29):174-175(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1512
  • HTML全文浏览数:  1106
  • PDF下载数:  513
  • 施引文献:  0
出版历程
  • 收稿日期:  2015-04-01
  • 刊出日期:  2016-03-18
柯瑶瑶, 冀晓东, 李亚伟, 赵宁, 宋祎楚. 合成条件对粉煤灰合成沸石除磷特性的影响[J]. 环境工程学报, 2016, 10(3): 1492-1499. doi: 10.12030/j.cjee.20160378
引用本文: 柯瑶瑶, 冀晓东, 李亚伟, 赵宁, 宋祎楚. 合成条件对粉煤灰合成沸石除磷特性的影响[J]. 环境工程学报, 2016, 10(3): 1492-1499. doi: 10.12030/j.cjee.20160378
shu
Ke Yaoyao, Ji Xiaodong, Li Yawei, Zhao Ning, Song Yichu. Effect of synthetic conditions on characters of phosphorus removal using synthetic zeolite from fly ash[J]. Chinese Journal of Environmental Engineering, 2016, 10(3): 1492-1499. doi: 10.12030/j.cjee.20160378
Citation: Ke Yaoyao, Ji Xiaodong, Li Yawei, Zhao Ning, Song Yichu. Effect of synthetic conditions on characters of phosphorus removal using synthetic zeolite from fly ash[J]. Chinese Journal of Environmental Engineering, 2016, 10(3): 1492-1499. doi: 10.12030/j.cjee.20160378
shu

合成条件对粉煤灰合成沸石除磷特性的影响

  • 1. 北京林业大学水土保持国家林业局重点实验室, 北京 100083
  • 2. 水利部综合事业局, 北京 100053
  • 3. 黄河流域水资源保护局, 郑州 450003
  • 收稿日期:  2015-04-01
基金项目:

北京林业大学科技创新计划团队项目(TD2011-01)

摘要: 利用不同钙含量的3种粉煤灰采用碱熔融-水热法合成沸石,研究了不用合成条件对3种粉煤灰合成沸石除磷性能的影响,并分析了除磷机理。3种粉煤灰合成沸石中沸石的种类各不相同,低钙粉煤灰合成沸石主要以NaP1型沸石为主,中钙粉煤灰合成沸石主要以一种无名沸石为主,高钙粉煤灰合成沸石则主要以加藤石为主,沸石含量几乎为零。碱灰比、熔融时间、熔融温度、固液比、结晶时间等合成因素中,对3种粉煤灰合成沸石固磷能力影响相对较大的是碱灰比和熔融时间。3种合成沸石的除磷能力顺序依次为高钙粉煤灰合成沸石> 中钙粉煤灰合成沸石> 低钙粉煤灰合成沸石,并且3种沸石的固磷能力与初始原料粉煤灰中的CaO含量成正比。固磷机理是合成沸石溶于水后向水中释放Ca2+,释放出来的Ca2+即可与磷酸根生成磷酸钙沉淀,从而达到固磷的目的。合成的沸石最大固磷能力为92.24 mg/g。
