前置回流式反硝化-硝化组合反应器(UBF-BAF)处理高氨氮制药废水

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

张文艺, 姚立荣, 闫刚, 赵婷婷, 陆丽巧, 李定龙. 前置回流式反硝化-硝化组合反应器(UBF-BAF)处理高氨氮制药废水[J]. 环境化学, 2011, 30(6): 1168-1174.
引用本文: 张文艺, 姚立荣, 闫刚, 赵婷婷, 陆丽巧, 李定龙. 前置回流式反硝化-硝化组合反应器(UBF-BAF)处理高氨氮制药废水[J]. 环境化学, 2011, 30(6): 1168-1174.
shu
ZHANG Wenyi, YAO Lirong, YAN Gang, ZHAO Tingting, LU Liqiao, LI Dinglong. TREATMENT OF PHARMACEUTICAL WASTEWATER OF HIGH NH3-N CONCENTRATION WITH PRE-BACKFLOW TYPE DENITRIFICATION AND NITRIFICATION COMBINED REACTOR (UBF/BAF)[J]. Environmental Chemistry, 2011, 30(6): 1168-1174.
Citation: ZHANG Wenyi, YAO Lirong, YAN Gang, ZHAO Tingting, LU Liqiao, LI Dinglong. TREATMENT OF PHARMACEUTICAL WASTEWATER OF HIGH NH3-N CONCENTRATION WITH PRE-BACKFLOW TYPE DENITRIFICATION AND NITRIFICATION COMBINED REACTOR (UBF/BAF)[J]. Environmental Chemistry, 2011, 30(6): 1168-1174.
shu

前置回流式反硝化-硝化组合反应器(UBF-BAF)处理高氨氮制药废水

  • 1.

    常州大学环境与安全工程学院, 常州, 213164

  • 基金项目:

    江苏省自然科学基金项目(SBK200930405)

    "十一五"国家科技重大专项(2008ZX07101-007-01)资助.

TREATMENT OF PHARMACEUTICAL WASTEWATER OF HIGH NH3-N CONCENTRATION WITH PRE-BACKFLOW TYPE DENITRIFICATION AND NITRIFICATION COMBINED REACTOR (UBF/BAF)

  • 1.

    School of Environmental and Safety Engineering, Changzhou University, Changzhou, 213164, China

  • Fund Project:

  • 摘要: 针对常州市某生化制药公司高浓度氨氮制药废水SBR处理工艺,改用前置回流式UBF-BAF组合工艺进行了试验研究.结果表明,在厌氧生物膜的作用下,前置式UBF反应器内不仅依次发生了有机物分解的水解酸化和产甲烷的碳化反应,而且还同步发生了含氮化合物的反硝化和厌氧氨氧化反应,表现出COD、氨氮、亚硝酸盐氮和总氮浓度同步降低.BAF承接经UBF厌氧处理后的出水,与SBR相比具有较高的同步脱碳、脱氮性能,其对氨氮和总氮去除率分别高达84.08%和68.15%.从UBF-BAF反应器中分离出了厌氧氨化细菌和好氧反硝化细菌,从微生物角度进一步表明了UBF-BAF组合反应器具有较强的脱氮能力.UBF-BAF适宜的运行参数:pH值为6.4—7.0,水力负荷为0.16—0.39 m3·m-2·h-1.当进水TKN、NH3-N和COD浓度分别为61.18—91.34 mg·L-1、37.9—56.05 mg·L-1和379.04—802.4 mg·L-1时,COD和NH3-N的去除率均高于80%,各项指标均达到了生物工程类制药工业新建企业水污染物排放限值(GB21907—2008).
    Abstract: SBR(Sequencing Batch Reactor Activated Sludge Process) was employed to treat the wastewater of high NH3-N concentration from a pharmaceutical company in Changzhou City, but the effluent water did not meet the discharge standards. So UBF/BAF combined reactor was used to replace SBR to treat the wastewater. The results showed that the UBF reactor not only had the carbonation reaction, but also had ANAMMOX and denitrification reaction simultaneously under the action of anaerobic biomembrane. Compared with SBR, BAF had a higher performance of decarbonization and denitrification simultaneously. The removal rate of NH3-N reached 84.08%, the removal rate of TN reached 68.15%. Two strains were isolated from UBF/BAF combined reactor, and were identified as Proteus and Pseudomonas by morphological observations and physiological test. The best treatment parameters of UBF/BAF: pH=6.4—7.0, and hydraulic loading=0.16—0.39 m3·m-2·h-1. When the concentration of TKN, NH3-N were 61.18—91.34 mg·L-1, 37.9—56.05 mg·L-1 , respectively in the influent water, the removal rate of COD and NH3-N both exceeded 80%. The effluent water met discharge standards of water pollutants for pharmaceutical industry Bio-pharmaceutical category (GB21907—2008).
  • 加载中
  • [1] 祈佩时,李欣,韩洪彬,等.复合式厌氧-好氧反应器处理制药废水的试验研究[J].哈尔滨工业大学学报,2004,36(12):1721-1723
    [2] 李勇智,彭永臻,王淑滢,等.采用序批式反应器短程生物脱氮工艺处理高氨氮制药废水[J].现代化工,2004,23(增刊):163-166
    [3] Huseyin Tekin,Okan Bilkay,Selale S Ataberk,et al.Use of fenton oxidation to improve the biodegradability of a pharmaceutical wastewater[J]. Journal of Hazardous Materials,2006,136(2):258-265
    [4] 万兴,黄海燕,尚美彦.保健药制药废水处理工程设计[J].中国给水排水,2009,24(12):57-59
    [5]
    [6] Chen Zhaobo,Ren Nanqi,Wang Aijie,et al.A novel application of TPAD-MBR system to the pilot treatment of chemical synthesis-based pharmaceutical wastewater[J]. Water Research,2008,42(13):3385-3392
    [7] 黎永坚,胡晓东,熊紫娟,等.高浓度氨氮对SBR工艺处理制药废水的影响[J].中国给水排水,2009,25(13):92-94
    [8] 汤琪,罗固源.MAP法和SBR法处理垃圾渗滤液的研究[J].环境化学,2008,27(5):639-643
    [9] Rezania B,Oleszkiewicz J A, Cicek N. Hydrogen-dependent denitrification of water in an anaerobic submerged membrance bioreactor coupled with a novel hydrogen delivery system[J]. Water Research,2007,41(5):1074-1080
    [10] Chamchoi N,Nitisoravut S, Schmidt J E. Inactivation of ANAMMOX communities under concurrent operation of anaerobic ammonium oxidation (ANAMMOX) and denitrification[J]. Bioresource Technology,2008,99(9):3331-3336
    [11] Sarti A,Pozzi E,Chinalia F A,et al. The performance of an anaerobic sequencing batch biofilm reactor treating domestic sewage colonized by anoxygenic phototrophic bacteria[J]. Chemosphere,2006,62(9):1437-1443
    [12] 赵爽.对产甲烷细菌的分析与研究[J].山西建筑,2009,35(28):167-168
    [13]
    [14] Chen Huihui,Liu Sitong,Yang Fenglin,et al. The development of simultaneous partial nitrification,ANAMMOX and denitrification(SNAD) process in a single reactor for nitrogen removal[J]. Bioresource Technology,2009,100(4):1548-1554
    [15] 赵昕,倪晋仁.曝气生物滤池处理采油废水过程中有机物的降解[J].环境化学,2007,26(3):376-379
    [16] 国家环保局编.水和废水监测分析方法(第4版)[M].北京: 中国环境科学出版社,2003
    [17] 东秀珠,蔡妙英.常见细菌系统鉴定手册[M].北京: 科学出版社,2001
    [18] 布坎南R E,吉本斯N E.伯杰细菌鉴定手册(第8版)[M].北京: 科学出版社,1984
    [19] 张文艺,翟建平,郑明东,等.BAF工艺处理焦化废水研究[J].给水排水,2005,31(7):52-54
    [20] 刘寅,杜兵,司亚安,等.厌氧氨氧化菌的培养与推流式反应器氨厌氧工艺[J].环境科学,2005,26(2):137-141
    [21] 李金,徐凤花,王玥婷,等.厌氧蛋白质氨化细菌筛选及对酸化液pH的影响[J].东北农业大学学报,2009,40(6):45-49
    [22] 朱杰,付永胜.生物脱氮处理过程中氮素转化规律的研究[J].环境化学,2006,25(5):624-628
    [23] 胡宏博,韩洪军,张凌瀚,等.BIOFOR生物滤池的反硝化/厌氧氨氧化协同脱氮研究[J].中国给水排水,2009,25(11):12-14
    [24] 姚敬博,李亚峰,王勋,等.SBBR工艺脱氮除磷理论及影响因素[J].工业安全与环保,2009,35(8):18-19
    [25] Zhang W Y, Zhao T T, Tan Fangyuan, et al. Isolation and identification of ammonibacteria and ammoniation characteristic analyse. Qiqihaer: 2010 International Conference on Future Biomedical Information Engineering (FBIE), 2010, 2:277-280
    [26] 岳秀萍,李亚新,付梅红,等.吸附-厌氧序批式反应器对有机物的去除[J].中国环境科学,2008, 28(9):861-864
    [27] Liu Yao Xing,Ou Yang Tong,Yuan Dong Xing,et al. Study of municipal wastewater treatment with oyster shell as biological aerated filter medium[J]. Desalination,2010,254(1/3):149-153
    [28] 徐峥勇.单级序批式生物膜反应器(SBBR)多途径生物脱氮的研究[J].环境科学,2007,28(10):2326-2331
    [29] 张文艺,陆丽巧,姚立荣,等.BAF反应器好氧反硝化细菌的筛选分离及反硝化特性研究[J].中国农村水利水电,2011,(1): 59-64
    [30] 张文艺,夏绍凤,董清玉,等.上向流曝气生物滤池中有机氮沿程转化规律与生物特性研究[J].农业工程学报,2008,24(6):234-238
