硅基微/介孔材料吸附二硫化碳(CS2)的性能

,  ,  ,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

谢遵园, 谢倩, 李军平, 王峰, 彭伟才, 赵宁, 肖福魁, 魏伟, 孙予罕. 硅基微/介孔材料吸附二硫化碳(CS2)的性能[J]. 环境化学, 2010, 29(6): 1048-1053.
引用本文: 谢遵园, 谢倩, 李军平, 王峰, 彭伟才, 赵宁, 肖福魁, 魏伟, 孙予罕. 硅基微/介孔材料吸附二硫化碳(CS2)的性能[J]. 环境化学, 2010, 29(6): 1048-1053.
shu
XIE Zunyuan, XIE Qian, LI Junping, WANG Feng, PENG Weicai, ZHAO Ning, XIAO Fukui, WEI Wei, SUN Yuhan. THE ADSORPTION PROPERTY OF CARBON DISULFIDENE (CS2) ONTO SiO2-BASED MICRO/MESOPOROUS MATERIALS[J]. Environmental Chemistry, 2010, 29(6): 1048-1053.
Citation: XIE Zunyuan, XIE Qian, LI Junping, WANG Feng, PENG Weicai, ZHAO Ning, XIAO Fukui, WEI Wei, SUN Yuhan. THE ADSORPTION PROPERTY OF CARBON DISULFIDENE (CS2) ONTO SiO2-BASED MICRO/MESOPOROUS MATERIALS[J]. Environmental Chemistry, 2010, 29(6): 1048-1053.
shu

硅基微/介孔材料吸附二硫化碳(CS2)的性能

  • 1.

    中国科学院山西煤炭化学研究所煤转化国家重点实验室, 太原, 030001;

  • 2.

    中国科学院研究生院, 北京, 100049;

  • 3.

    聊城大学材料科学与工程学院, 聊城, 252059

  • 基金项目:

    国家青年自然科学基金(20803089)资助项目

    太原市科技项目创业创新专项(09122060)

THE ADSORPTION PROPERTY OF CARBON DISULFIDENE (CS2) ONTO SiO2-BASED MICRO/MESOPOROUS MATERIALS

  • 1.

    State Key Laboratory of Coal Couversiou, Iustitute of Coal Chemistry, Chinese Academy of Sciences, Taiyuau, 030001，China;

  • 2.

    Graduate School of the Chinese Academy of Sciences, Beijing, 100049, China;

  • 3.

    College of Materials Science and Engineering, Liaocheng Univeisity, Liaocheng, 252059, China

  • Fund Project:

  • 摘要: 以聚甲基含氢硅氧烷(PMHS)和正硅酸乙酯(TEOS)为原料,在不同的PMHS:TEOS质量比条件下合成了一系列具有微/介孔硅基材料.N2吸/脱附表征显示该材料具有微/介孔双孔分布的结构特征和较高的比表面积,并且随着PMHS:TEOS质量比的变化而变化.其中,当PMHS:TEOS质量比为1:3时硅基微/介孔材料具有最大的比表面积,达到783m2·g-1.XRD表征结果显示,该材料是无定形材料.材料对二硫化碳(CS2)的吸附性能的研究结果表明,PMHS:TEOS质量比为1:3合成的硅基微/介孔材料对CS2的吸附量最大,静态吸附量达到762.76mg·g-1,动态吸附穿透时间达到35min.再生实验表明材料再生性良好,可重复使用.
    Abstract: Micro/mesoporous SiO2-based materials were synthesized with polymethylhydrosiloxane (PMHS) and tetraethoxysilane (TEOS) with different PMHS/TEOS mass ratios. The materials were characterized by N2 adsorption/desorption. The micropore volume was calculated by t-Plot method, and the miropore size distributions was calculated by DFT method. The characterization revealed that the synthesized materials had large specific surface area. The specific surface area changed with the PMHS/TEOS mass ratio. When the PMHS/TEOS mass ratio is 1:3, the materials reached the largest specific surface area of 783m2·g-1. Meanwhile, it was found that the SiO2-based materials had the bimodal pore structures (mircoporous and mesoporous). The XRDdiffraction patterns indicate that the micro/mesoporous SiO2-based materials are amorphous materials. The adsorption properties of the materials were investigated with carbon disulfide (CS2) as a probe molecule. The static adsorption results indicated that M3 had the highest adsorption capacity which was synthesized with the PMHS/TEOS mass ratio of 1:3. The equilibrium adsorption capacity of M3 reached 762.76 mg·g-1. Moreover, the dynamic adsorption properties of the materials were also investigated. Among these materials, M3 had the best dynamic adsorption property. The breakthrough time of M3 was 35min. Regeneration experiments indicated that the material had a good regeneration property.
  • 加载中
  • [1] Yegiazarov Yu, Clark J, Potapova L, et al. Adsorption-catalytic process for carbon disulfide removal from air[J]. Catal Today, 2005, 102:242-247
    [2] Guo Bo, Chang Liping, Xie Kechang. Study of the behavior of adsorbing CS2 by activated carbon[J]. Fuel Prccess Technol, 2006, 87:873-881
    [3] Yang Ji, Juan Peng, Shen Zhemin. Removal of carbon disulfide (CS2) from water via adsorption on active carbon fiber (ACF) [J]. Carbon, 2006, 44(8):1367-1375
    [4] Zhao X S, Ma Q, (Max) Lu G Q. VOC removal: comparison of MCM-41 with hydrophobic zeolites and activated carbon[J]. Energy & Fuels, 1998, 12:1051-1054
    [5] Chu Y H, Kim H J, Keun Young Song, et al. Preparation of mesoporous silica fiber matrix for VOC removal[J]. Catalysis Today, 2002, 74:249-256
    [6] 王亚宁, 熊春华, 王槐三. 树脂吸附法取出水及空气中的CS2[J]. 化工环保, 2006, 26(3):174-177
    [7] Davis M E. Ordered porous materials for emerging applications[J]. Nature, 2002 (417):813-821
    [8] 王连洲, 施剑林, 禹剑,等. 介孔氧化硅材料的研究进展[J]. 无机材料学报, 1999, 14:333-342
    [9] 雷杰, 余承忠, 范杰,等. 色谱固定相的介孔氧化硅球材料的合成[J]. 化学学报, 2005, 63:739-744
    [10] 赵东元,余承忠. 功能分子筛的合成设计与生命科学[J]. 浙江化工, 2001, 32:109-113
    [11] 陈逢喜, 黄莤丹, 李全芝. 中孔分子筛研究进展[J]. 科学通报, 1999, 44:1905-1911
    [12] 张兆荣, 索继栓, 张小明,等. 介孔硅基分子筛研究新进展[J]. 化学进展,1999, 58:11-20
    [13] Serrano D P, Calleja G, Botas J A, et al. Adsorption and hydrophobic properties of mesostructured MCM-41 and SBA-15 materials for volatile organic compound removal[J]. Ind Eng Chem Res, 2004, 43:7010-7018
    [14] Shim W G, Lee J W, Moon H. Adsorption equilibrium and column dynamics of VOCs on MCM-48 depending on pelletizing pressure[J]. Microporous and Mesoporous Materials, 2006, 88:112-125
    [15] Lee J W, Shim W G, Moon H. Adsorption equilibrium and kinetics for capillary condensation of trichloroethylene on MCM-41 and MCM-48[J]. Microporous and Mesoporous Materials, 2004, 73:109-119
    [16] Yang Dongjiang, Li Junping, Xu Yao, et al. Direct formation of hydrophobic silica-based micro/mesoporous hydrids from polymethylhydrosiloxane and tetraethoxysilane[J]. Microporous and Mesoporous Mater, 2006, 95:180-186
    [17] 常文明, 李军平, 赵宁,等. 新型SiO2基微/介孔材料的合成及其对集成电路生产中VOCs废气的吸附研究[J]. 化工新型材料, 2009, 37(2):26-28
    [18] Lee Jae Wook, Lee Joog Won, Shim Wang Geun, et al. Adsorption of chlorinated volatile organic compounds on MCM-48[J]. J Chem Eng Date, 2003, 48(2):381-387
    [19] Tanev P T, Chlbwe M, Pinnavaia T J. Titanium-containing mesoporous molecular sieves for catalytic oxidation of aromatic compounds [J]. Nature, 1994, 368:321-323
    [20] Wei Y, Jin D L, Ding T Z, et al, A non-surfactant templating route to mesoporous silica materials[J]. Adv Mater, 1998, 10(4):313-316
    [21] Cheng S, Wei Y, Feng Q W, et al, Synthesis of nanocomposite materials and their biological applications [J]. Chem Mater, 2003, 15, 1560-1566
    [22] Katsunori Kosuge, Shiori Kubo, Nobuyuki Kikukawa. Effect of pore structure in mesoporous silicas on VOC dynamic adsorption/desorption performance[J]. Langmuir, 2007, 23(6):3095-3102
    [23] Serrano D P, Calleja G, Abotas J,et al. Adsorption and hydrophobic properties of mesostructured MCM-41 and SBA-15 materials for volatile organic compound removal[J]. Ind Eng Chem Res, 2004, 43:7010-7018
    [24] 谢遵园, 李军平, 赵宁,等. 活性炭纤维(ACF)吸附二硫化碳(CS2)的研究[J].新型炭材料, 2009, 24(3):260-264
