西安冬、夏季PM2.5中水溶性无机离子的变化特征

,  ,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

杨素霞, 曹军骥, 沈振兴, 刘随心, 张婷, 王启元, 强娟, 李文韬. 西安冬、夏季PM2.5中水溶性无机离子的变化特征[J]. 环境化学, 2012, 31(8): 1179-1188.
引用本文: 杨素霞, 曹军骥, 沈振兴, 刘随心, 张婷, 王启元, 强娟, 李文韬. 西安冬、夏季PM2.5中水溶性无机离子的变化特征[J]. 环境化学, 2012, 31(8): 1179-1188.
shu
YANG Suxia, CAO Junji, SHEN Zhenxing, LIU Suixin, ZHANG Ting, WANG Qiyuan, QIANG Juan, LI Wentao. Variations of water-soluble ions in PM2.5 at Xi'an between summer and winter[J]. Environmental Chemistry, 2012, 31(8): 1179-1188.
Citation: YANG Suxia, CAO Junji, SHEN Zhenxing, LIU Suixin, ZHANG Ting, WANG Qiyuan, QIANG Juan, LI Wentao. Variations of water-soluble ions in PM2.5 at Xi'an between summer and winter[J]. Environmental Chemistry, 2012, 31(8): 1179-1188.
shu

西安冬、夏季PM2.5中水溶性无机离子的变化特征

  • 1.

    中国科学院地球环境研究所, 黄土与第四纪地质国家重点实验室, 西安, 710075;

  • 2.

    中国科学院研究生院, 北京, 100049;

  • 3.

    西安交通大学全球环境变化研究院, 西安, 710049;

  • 4.

    西安交通大学环境科学与工程系, 西安, 710049;

  • 5.

    陕西省西安市环境监测站, 西安, 710054

  • 基金项目:

    国家自然科学基金项目(NSFC40925009)资助.

Variations of water-soluble ions in PM2.5 at Xi'an between summer and winter

  • 1.

    Institute of Earth Environment, Chinese Academy of Sciences, Xi'an, 710075, China;

  • 2.

    Graduate University of Chinese Academy of Sciences, 100049, China;

  • 3.

    The Academy of Global Environmental Change, Xi'an Jiaotong University, Xi'an, 710049, China;

  • 4.

    School of Environmental Science and Engineering, Xi'an Jiaotong University, Xi'an, 710049, China;

  • 5.

    The Environmental Monitoring Station of Xi'an, Xi'an, 710054, China

  • Fund Project:

  • 摘要: 为探讨西安市冬、夏季水溶性无机离子的季节和空间变化特征,2010年1月和7月分别在西安城区4个站点及上风区高陵(GL)和下风区黑河(HH)连续采集2周的PM2.5样品,使用离子色谱仪分析样品中水溶性无机离子成分.结果表明,PM2.5质量浓度冬季明显高于夏季,空间变化表现为:城区站点浓度均值(172.6 μg·m-3)>上风区点GL(98.9 μg·m-3)>下风区点HH(81.0 μg·m-3).水溶性无机离子浓度总和占PM2.5质量浓度的41.8%,其中SO42-、NO3-和NH4+是水溶性离子的主要成分,分别占总离子质量浓度的35.1%、22.6%和12.2%.Na+、Ca2+和Mg2+在冬、夏季浓度相差不大,而SO42-、NO3-、NH4+以及K+、Cl-等均明显表现为冬季浓度高于夏季.SO42-、NO3-和NH4+在冬、夏季空间变化均表现为城区站点>GL>HH,这3种离子夏季在大气中的主要存在方式为NH4HSO4和NH4NO3,而冬季主要以(NH4)2SO4、NH4NO3和NH4Cl形式存在.NO3-/SO42-的比值为0.64,表明西安市固定源仍是主要污染贡献源,但是移动源所占比例较之前研究有所上升,应采取一定措施控制机动车数量并加强排放监控.
    Abstract: To investigate the seasonal and temporal variations of water-soluble ions in Xi'an,PM2.5 samples were collected in January and July of 2010 at four urban sites and two rural sites: GaoLing (GL) and HeiHe (HH). Five cations (NH4+, K+, Ca2+, Mg2+ and Na+) and three anions(SO42-, NO3- and Cl-) were determined by ion chromatography. The average concentration of PM2.5 was 172.6 μg·m-3 at the urban sites, 98.2 μg·m-3 at GL, and 81.0 μg·m-3 at HH. PM2.5 mass had a higher concentration in the winter than summer. Total ions accounted for 41.8% of the PM2.5 mass, and SO42-, NO3-, and NH4+ were the most abundant components of the ions, which accounted for 35.1%, 22.6%, and 12.2% of the total ions, respectively. Na+, Ca2+ and Mg2+ had a considerable level in both summer and winter, but the concentration of other ions were higher in the winter. K+ and Ca2+ had a peaked concentration at the two rural sites (GL and HH) in the winter which were different from the summer, while the other ions were higher at the urban sites in both summer and winter. The correlation among ions suggested that principal water-soluble ions existed in the form of NH4HSO4 and NH4NO3 in the summer while (NH4)2SO4, NH4NO3 and NH4Cl in the winter. The ratio of NO3-/SO42- in Xi'an was 0.64, indicating that coal combustion was still the main pollution in Xi'an.
  • 加载中
  • [1] 滕恩江. 中国四城市空气中粗细颗粒物元素组成特征 [J]. 中国环境科学, 1999, 19(3):238-242
    [2] Appel B R, Tokiwa Y, Hsu J, et al. Visibility as ralated to atmospheric aerosol constituents [J]. Atmospheric Environment, 1985, 19(9):1525-1534
    [3] U. S. Environmental Protection Agency. Air quality criteria for particulate matter[S]. Research Triangle Park, NC: National Center for Environmental Assessment-RTP Office; Report No. EPA/600/P-99/OOa2F,2004
    [4] 杨复沫,贺克斌,马永亮,等. 北京PM2.5浓度的变化特征及其与PM10、TSP的关系 [J]. 中国环境科学, 2002, 22(6):506-510
    [5] Ye B M, Ji X L, Yang H Z, et al. Concentration and chemical composition of PM2.5 in Shanghai for a 1-year period [J]. Atmospheric Environment, 2003, 37(4):499-510
    [6] 王荟,王格慧,黄鹉鸣,等. 南京市大气中PM10、PM2.5日污染特征 [J]. 重庆环境科学, 2003, 25(5):54-59
    [7] Zhang X Y, Cao J J, Li L M, et al. Characterization of atmospheric aerosol over Xi'an in the south margin of the Loess Plateau, China [J]. Atmospheric Environment, 2002, 36(26):4189-4199
    [8] Cao J J, Chow J C, Lee S C, et al. Characterization and source apportionment of atmospheric organic and elemental carbon during fall and winter of 2003 in Xi'an, China [J]. Atmospheric Chemistry and Physics, 2005, 5:3127-3137
    [9] Hu M, He L Y, Zhang Y H, et al. Seasonal variation of ionic species in fine particles at Qingdao, China [J]. Atmospheric Environment, 2002, 36(38):5853-5859
    [10] Ho K F, Lee S C, Cao J J, et al. Seasonal variations and mass closure analysis of particulate matter in Hong Kong [J]. Science of the Total Environment, 2006,355(1-3):276-287
    [11] Cao J J, Lee S C, Chow J C, et al. Spatial and seasonal distributions of carbonaceous aerosols over China [J]. Journal of Geophysical Research-Atmospheres, 2007, 112(D22S11):1-9
    [12] Shen Z X, Arimoto R, Cao J J, et al. Seasonal variations and evidence for the effectiveness of pollution controls on water-soluble inorganic species in total suspended particulates and fine particulate matter from Xi'an, China [J]. Journal of the Air & Waste Management Association, 2008, 58(12):1560-1570
    [13] Shen Z X, Cao J J, Arimoto R, et al. Ionic composition of TSP and PM2.5 during dust storms and air pollution episodes at Xi'an, China [J]. Atmospheric Environment, 2009, 43(18):2911-2918
    [14] Roosli M, Theis G, Kunzli N, et al. Temporal and spatial variation of the chemical composition of PM10 at urban and rural sites in the Basel area, Switzerland [J]. Atmospheric Environment, 2001, 35 (21):3701-3713
    [15] 张西振. 汽车排放影响因素及微观排放模型研究. 西安:长安大学硕士学位论文, 2007
    [16] 王启元, 曹军骥, 甘小凤,等. 成都市灰霾与正常天气下大气PM2.5的化学元素特征 [J]. 环境化学, 2010, 29(4):644-648
    [17] 王琳琳, 王淑兰, 王新锋,等. 北京市2009 年8 月大气颗粒物污染特征 [J]. 中国环境科学, 2011, 31 (4):553-560
    [18] Wang G H, Huang L M, Gao S X, et al. Characterization of water-soluble species of PM10 and PM2.5 aerosols in urban area in Nanjing, China [J]. Atmospheric Environment, 2002, 36(8):1299-1307
    [19] Wang Y, Zhuang G S, Tang A H, et al. The ion chemistry and the source of PM2.5 aerosol in Beijing [J]. Atmospheric Environment, 2005, 39 (21):3771-3784
    [20] Shen Z X, Cao J J, Arimoto R, et al. Chemical characteristics of fine particles (PM1) from Xi'an, China [J]. Aerosol Science and Technology, 2010, 44 (6):461-472
    [21] 张婷,曹军骥,吴枫,等. 西安春夏季气体及PM2.5中水溶性组分的污染特征[J]. 中国科学院研究生院学报,2007, 24 (5): 643-646
    [22] Sachio Ohta, Toshiichi Okita, A chemical characterization of atmospheric aerosol in Sapporo [J]. Atmospheric Environment. Part A. General Topics, 1990, 24 (4):815-822
    [23] 郭兆冰,陈天蕾,陈天,等. 香河地区大气气溶胶中水溶性离子观测及分析 [J].环境化学, 2010, 29 (4):764-765
    [24] 唐孝炎,张远航. 大气环境化学 [M]. 高等教育出版社, 1990:345-347
    [25] Zhang T, Cao J J, Tie X X, et al. Water-soluble ions in atmospheric aerosols measured in Xi'an, China: Seasonal variations and sources [J]. Atmospheric Research, 2011, 102 (1-2):110-119
    [26] Gao X M, Yang L X, Cheng S H, et al. Semi-continuous measurement of water-soluble ions in PM2.5 in Jinan, China: Temporal variations and source apportionments [J]. Atmospheric Environment, 2011, 45(33):6048-6056
    [27] Wang Y, Zhuang G S, Zhang X Y, et al.The ion chemistry, seasonal cycle, and sources of PM2.5 and TSP aerosol in Shanghai [J]. Atmospheric Environment, 2006, 40(16): 2935-2952
    [28] 陶俊,张仁健,董林,等. 夏季广州城区PM2.5和PM1.0中水溶性无机离子特征 [J]. 环境科学, 2010, 31 (7):1417-1425
    [29] Lai S C, Zou S C, Cao J J, et al. Characterizing ionic species in PM2.5 and PM10 in four Pearl River Delta cities, South China [J]. Journal of Environmental Science, 2007, 19(8):939-947
    [30] 沈振兴, 李丽珍, 杜娜, 等. 西安市春季大气细粒子的质量浓度及其水溶性组分的特征 [J]. 生态环境, 2007, 16(4): 1193-1198
    [31] Watson J G, Chow J C, Houck J E, PM2.5 chemical source profiles for vehicle exhaust, vegetative burning, geological material, and coal burning in Northwestern Colorado during 1995 [J]. Chemosphere, 2001, 43 (8):1141-1151
    [32] Kato N. Analysis of structure of energy consumption and dynamics of emission of atmospheric species related to the global environmental change (SOx, NOx, and CO2) in Asia [J]. Atmospheric Environment, 1996, 30 (5):757-785
    [33] 赵普生,张小玲,孟伟,等.京津冀区域气溶胶中无机水溶性离子污染特征分析 [J]. 环境科学,2011,32(6):1546-1550
    [34] Xiao H Y, Liu C Q. Chemical characteristics of water-soluble components in TSP over Guiyang, SW China, 2003 [J]. Atmospheric Environment, 38(37):6297-6306
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  667
  • HTML全文浏览数:  529
  • PDF下载数:  319
  • 施引文献:  0
出版历程
  • 收稿日期:  2011-10-19
杨素霞, 曹军骥, 沈振兴, 刘随心, 张婷, 王启元, 强娟, 李文韬. 西安冬、夏季PM2.5中水溶性无机离子的变化特征[J]. 环境化学, 2012, 31(8): 1179-1188.
引用本文: 杨素霞, 曹军骥, 沈振兴, 刘随心, 张婷, 王启元, 强娟, 李文韬. 西安冬、夏季PM2.5中水溶性无机离子的变化特征[J]. 环境化学, 2012, 31(8): 1179-1188.
shu
YANG Suxia, CAO Junji, SHEN Zhenxing, LIU Suixin, ZHANG Ting, WANG Qiyuan, QIANG Juan, LI Wentao. Variations of water-soluble ions in PM2.5 at Xi'an between summer and winter[J]. Environmental Chemistry, 2012, 31(8): 1179-1188.
Citation: YANG Suxia, CAO Junji, SHEN Zhenxing, LIU Suixin, ZHANG Ting, WANG Qiyuan, QIANG Juan, LI Wentao. Variations of water-soluble ions in PM2.5 at Xi'an between summer and winter[J]. Environmental Chemistry, 2012, 31(8): 1179-1188.
shu

西安冬、夏季PM2.5中水溶性无机离子的变化特征

  • 1.  中国科学院地球环境研究所, 黄土与第四纪地质国家重点实验室, 西安, 710075;
  • 2.  中国科学院研究生院, 北京, 100049;
  • 3.  西安交通大学全球环境变化研究院, 西安, 710049;
  • 4.  西安交通大学环境科学与工程系, 西安, 710049;
  • 5.  陕西省西安市环境监测站, 西安, 710054
  • 收稿日期:  2011-10-19
基金项目:

国家自然科学基金项目(NSFC40925009)资助.

摘要: 为探讨西安市冬、夏季水溶性无机离子的季节和空间变化特征,2010年1月和7月分别在西安城区4个站点及上风区高陵(GL)和下风区黑河(HH)连续采集2周的PM2.5样品,使用离子色谱仪分析样品中水溶性无机离子成分.结果表明,PM2.5质量浓度冬季明显高于夏季,空间变化表现为:城区站点浓度均值(172.6 μg·m-3)>上风区点GL(98.9 μg·m-3)>下风区点HH(81.0 μg·m-3).水溶性无机离子浓度总和占PM2.5质量浓度的41.8%,其中SO42-、NO3-和NH4+是水溶性离子的主要成分,分别占总离子质量浓度的35.1%、22.6%和12.2%.Na+、Ca2+和Mg2+在冬、夏季浓度相差不大,而SO42-、NO3-、NH4+以及K+、Cl-等均明显表现为冬季浓度高于夏季.SO42-、NO3-和NH4+在冬、夏季空间变化均表现为城区站点>GL>HH,这3种离子夏季在大气中的主要存在方式为NH4HSO4和NH4NO3,而冬季主要以(NH4)2SO4、NH4NO3和NH4Cl形式存在.NO3-/SO42-的比值为0.64,表明西安市固定源仍是主要污染贡献源,但是移动源所占比例较之前研究有所上升,应采取一定措施控制机动车数量并加强排放监控.
