史风华, 宋永吉, 罗潇然, 任晓光, 李翠清, 王虹. 六铝酸盐负载CuO催化还原NO性能[J]. 环境化学, 2012, 31(8): 1222-1226.
引用本文: 史风华, 宋永吉, 罗潇然, 任晓光, 李翠清, 王虹. 六铝酸盐负载CuO催化还原NO性能[J]. 环境化学, 2012, 31(8): 1222-1226.
shu
SHI Fenghua, SONG Yongji, LUO Xiaoran, REN Xiaoguang, LI Cuiqing, WANG Hong. Catalytic reduction of NO over CuO/LaAl12O19 catalysts[J]. Environmental Chemistry, 2012, 31(8): 1222-1226.
Citation: SHI Fenghua, SONG Yongji, LUO Xiaoran, REN Xiaoguang, LI Cuiqing, WANG Hong. Catalytic reduction of NO over CuO/LaAl12O19 catalysts[J]. Environmental Chemistry, 2012, 31(8): 1222-1226.
shu

六铝酸盐负载CuO催化还原NO性能

  • 1.

    北京石油化工学院, 北京, 102617;

  • 2.

    北京化工大学, 北京, 100029

  • 基金项目:

    国家自然科学基金资助项目(21076025)资助.

Catalytic reduction of NO over CuO/LaAl12O19 catalysts

  • 1.

    Beijing Institute of Petrochemical Technology, Beijing, 102617, China;

  • 2.

    Beijing University of Chemical Technology, Beijing, 100029, China

  • Fund Project:

  • 摘要: 采用共沉淀法制备了LaAl12O19六铝酸盐载体,采用等体积浸渍法制备了不同负载量的CuO/LaAl12O19催化剂,并对其进行了XRD、H2-TPR和BET表征,考察了催化剂对CH4选择催化还原NO的性能.结果表明,CuO的负载并未改变六铝酸盐载体的结构,Cu在载体上以Cu2+的形式存在,活性组分CuO与载体LaAl12O19之间存在协同作用; CuO/LaAl12O19催化剂对CH4选择催化还原NO表现出良好活性,所制备的催化剂均能使NO的转化率达到99%;其中负载量为1.0 wt%的CuO/LaAl12O19催化剂的活性最好,完全反应温度T99%为560℃,且在80 h稳定性试验中表现出了良好的高温活性和热稳定性.
    Abstract: LaAl12O19 hexaaluminate was prepared as the support by co-precipitation method. CuO was loaded on the support by using aqueous solution of copper nitrate as precursor and then the samples were calcinated to obtain the catalysts. The catalysts were characterized by means of XRD, H2-TPR and BET technique. And NO selective catalytic reduction activities were studied over the synthesized samples with the CH4 as reducer. The results showed that the structure of LaAl12O19 was unchanged after CuO loading and the active component existed as the Cu2+ state. There was synergistic reaction between the active component(CuO) and the support(LaAl12O19). The results also indicated that all the samples showed high catalytic activity, and the conversion of NO over all the catalysts reached 99%. The 1.0 wt% CuO/LaAl12O19 catalyst possessed the highest catalytic activity, over which the 99% NO conversion temperature was 560℃. It also showed thermal activity and stability during the 80 h stability test at 560℃.
  • 加载中
  • [1] Ferreira A P, Capela S, Da Costa P, et al. Air Pollution Abatement Catalysis (APAC) Symposium CH4-SCR of NO over Co and Pd ferrierite catalysts: Effect of preparation on catalytic performance [J]. Catalysis Today, 2007, 119(1-4): 156-165
    [2] 孙红.蜂窝状金属丝网催化剂的制备及其贫燃条件下选择催化还原NOx的研究. 辽宁:大连理工大学博士学位论文,2007
    [3] 钟秦. 燃煤烟气脱硫脱硝技术及工程实例(第二版)[M]. 北京:化学工业出版社,2007:332
    [4] 赵清森, 孙路石,向军,等. CuO/γ-Al2O3催化剂选择性催化还原NO[J].燃烧科学与技术,2009,15(5):429-43
    [5] Xue Xuye, Lu Guanzhong, Guo Yun,et al. Effect of pretreatment method of activated carbon on the catalytic reduction of NO by carbon over CuO[J]. Applied Catalysis B: Environmental, 2008,79(3):262-269
    [6] 董国君,韩成喜,张浩,等. 堇青石蜂窝陶瓷载CuO选择催化还原NO的研究[J].工业催化,2007,15(3):62-65
    [7] 肖文德,吴志泉. 二氧化硫脱除与回收[M]. 北京:化学工业出版社,2001:27
    [8] Masato Maehida, Koiehi Eguchi, Hiromiehi Arai. Effect of additives on the surface area of oxide supports for catalytic combustion[J]. Journal of Catalysis, 1987, 103:385-393
    [9] 官芳,卢晗锋,黄海凤,等. 六铝酸盐作涂层的蜂窝陶瓷型La0.8Sr0.2MnO3催化剂热稳定性[J].高等化学工程学报,2008,22(6):954-959
    [10] Svensson E E, Boutonnet M, Järäs S G. Stability of hexaaluminate-based catalysts for high-temperature catalytic combustion of methane[J].Applied Catalysis B: Environmental, 2008, 84(1-2): 241-250
    [11] Tian M, Wang A Q, Wang X D, et al. Effect of large cations (La3+ and Ba2+) on the catalytic performance of Mn-substituted hexaaluminates for N2O decomposition[J].Applied Catalysis B: Environmental, 2009, 92(3-4): 437-444
    [12] 宋永吉,董留涛,李翠清,等. 不同方法制备LaCu0.8Zn0.2Al11O19-δ催化剂及其催化分解N2O活性研究[J].环境污染与防治, 2009, 31(9):19-22
    [13] 董留涛,宋永吉,李翠清,等. LaCuxZn1-xAl11O19-δ六铝酸盐催化剂分解N2O的催化性能[J].环境化学,2009,28(2):238-241
    [14] Bukhtiyarova M V, IvanovaA S, Plyasova L M, et al. Selective catalytic reduction of nitrogen oxide by ammonia on Mn(Fe)-substituted Sr(La) aluminates[J].Applied Catalysis A: General, 2009, 357(2):193-205
    [15] Groppi G, Assandri F, Bellotto M, et al. The crystal structure of Ba-β-alumina materials for high-temperature catalytic combustion[J]. Journal of Solid State Chemistry, 1995, 114(2):326-336
    [16] 任晓光,任超,李晓燕.过渡金属离子复合掺杂的六铝酸盐催化剂的脱硝性能[J].环境污染与防治,2011,33(9):6-7
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  699
  • HTML全文浏览数:  668
  • PDF下载数:  382
  • 施引文献:  0
出版历程
  • 收稿日期:  2011-05-24
史风华, 宋永吉, 罗潇然, 任晓光, 李翠清, 王虹. 六铝酸盐负载CuO催化还原NO性能[J]. 环境化学, 2012, 31(8): 1222-1226.
引用本文: 史风华, 宋永吉, 罗潇然, 任晓光, 李翠清, 王虹. 六铝酸盐负载CuO催化还原NO性能[J]. 环境化学, 2012, 31(8): 1222-1226.
shu
SHI Fenghua, SONG Yongji, LUO Xiaoran, REN Xiaoguang, LI Cuiqing, WANG Hong. Catalytic reduction of NO over CuO/LaAl12O19 catalysts[J]. Environmental Chemistry, 2012, 31(8): 1222-1226.
Citation: SHI Fenghua, SONG Yongji, LUO Xiaoran, REN Xiaoguang, LI Cuiqing, WANG Hong. Catalytic reduction of NO over CuO/LaAl12O19 catalysts[J]. Environmental Chemistry, 2012, 31(8): 1222-1226.
shu

六铝酸盐负载CuO催化还原NO性能

  • 1.  北京石油化工学院, 北京, 102617;
  • 2.  北京化工大学, 北京, 100029
  • 收稿日期:  2011-05-24
基金项目:

国家自然科学基金资助项目(21076025)资助.

摘要: 采用共沉淀法制备了LaAl12O19六铝酸盐载体,采用等体积浸渍法制备了不同负载量的CuO/LaAl12O19催化剂,并对其进行了XRD、H2-TPR和BET表征,考察了催化剂对CH4选择催化还原NO的性能.结果表明,CuO的负载并未改变六铝酸盐载体的结构,Cu在载体上以Cu2+的形式存在,活性组分CuO与载体LaAl12O19之间存在协同作用; CuO/LaAl12O19催化剂对CH4选择催化还原NO表现出良好活性,所制备的催化剂均能使NO的转化率达到99%;其中负载量为1.0 wt%的CuO/LaAl12O19催化剂的活性最好,完全反应温度T99%为560℃,且在80 h稳定性试验中表现出了良好的高温活性和热稳定性.
