湘江底泥重金属污染特征与生态风险评价
Characteristics and ecological risk assessment of heavy metals contamination in sediments of the Xiangjiang River
-
摘要: 本研究于湘江共采集了29个典型重金属污染断面底泥样品,测定了底泥中重金属Cd、Pb、Cr、Cu、Mn和Zn的含量及其有效态含量,并采用改进潜在生态风险指数法评价了底泥重金属的潜在生态风险.研究结果表明,湘江底泥存在主要由重金属Cd、Pb、Cr、Cu、Mn和Zn构成的复合污染,其含量范围依次为2.83—29.15 mg·kg-1、8—1784 mg·kg-1、10.00—4884.28 mg·kg-1、9—674 mg·kg-1、744.83—16246.22 mg·kg-1和61.50—3771.11 mg·kg-1;参考土壤环境质量Ⅲ级标准的断面超标率依次为100%、10.34%、6.90%、3.54%、100%和24.14%;有效态百分含量范围依次为25.04%—66.63%、8.75%—50.00%、1.14%—35.08%、3.70%—39.00%、1.99%—65.79%和7.48%—47.96%;生态风险评价结果表明, Cd的潜在生态风险最高,其次是Pb和Mn,潜在生态风险指数贡献率(MRI)依次为90.37%、4.17%、3.03%,干流的潜在生态风险高于支流的生态风险,达到极强危害水平的采样断面占72.41%,主要集中于永州、衡阳、株洲、湘潭、长沙和郴州.Abstract: This study investigated the pollution characteristics and ecological risk of heavy metals in the sediments from the Xiangjiang River. Twenty nine sediment samples were collected from the typical monitoring sections of the Xiangjiang River. The contents and bioavailability of six heavy metals (Cd、Pb、Cr、Cu、Mn、Zn) in these sediment samples were analyzed. And the ecological risk of the heavy metals was further assessed by the modified potential ecological risk index (MRI) method. Results showed that heavy metal combined pollution existed in the sediments of the Xiangjiang River, in which the content of Cd、Pb、Cr、Cu、Mn and Zn were 2.83—29.15 mg·kg-1, 8—1784 mg·kg-1, 10.00—4884.28 mg·kg-1, 9—674 mg·kg-1, 744.83—16246.22 mg·kg-1, 61.50—3771.11 mg·kg-1, respectively. According to the environmental quality standards for soils, approximately 100%, 10.34%, 6.90%, 3.54%, 100%, and 24.14% of the heavy metal concentrations in sediment samples exceed the third grade standard for Cd, for Pb, Cr, Cu, Mn, and Zn, respectively. The corresponding range of bioavailability fractions were 25.04%—66.63%, 8.75%—50.00%, 1.14%—35.08%, 3.70%—39.00%, 1.99%—65.79%, 7.48%—47.96%, respectively. The results of ecological risk assessment indicated that the ecological risk was dominantly caused by Cd with the contribution to MRI counting for 90.37%, followed by 4.17% for Pb and 3.03% for Mn. Meanwhile, compared with tributary, the ecological risk of sediments in main stream was more serious. About 72.41% of sampling sections in main stream reached extremely strong risk level, and the high-risk sections were mainly located in Yongzhou, Zhuzhou, Xiangtan, Changsha and Chenzhou district.
-
Key words:
- Xiangjiang River /
- sediments /
- heavy metals /
- risk assessment code /
- ecological risk.
-
-
[1] 刘耀驰, 高栗, 李志光, 等. 湘江重金属污染现状、污染原因分析与对策探讨[J]. 环境保护科学, 2010, 36(4): 26-29. LIU Y C, GAO L, LI Z G, et al. Analysis on heavy metals pollution status and reasons in Xiangjiang River and discussion on its countermeasures[J]. Environmental Protection Science, 2010, 36(4): 26-29(in Chinese).
[2] 柳德新. 湘江保护, 饮用水源先行[N]. 湖南日报, 2013-11-05. LIU D X. "The Xiangjiang river protection, drinking water first"[N]. Hunan Daily, 2013-11 -05(in Chinese).
[3] 雷丹. 湖南重金属污染现状分析及其修复对策[J]. 湖南有色金属, 2012, 28(1): 57-60. LEI D. Analysis on heavy metals pollution status in Hunan Province and its remediation strategy[J]. Hunan Nonferrous Metals, 2012, 28(1): 57-60(in Chinese).
[4] 吕明军, 周立耘, 颜珂, 等. 祛多年沉疴还一江清水 [N]. 人民日报, 2015-01-26. LV M J, ZHOU L Y, YAN K, et al. "Qu duonian chenke huan yijiang qingshui"[N]. People's Daily, 2015-01 -26(in Chinese).
[5] 贺广华, 曹昌. 拯救湘江 [N].中国经济周刊, 2009-04-27, 16. HE G H, CAO C. "Zhenjiu Xianhjiang"[N]. China Economic Weekly, 2009 -04-27, 16(in Chinese).
[6] PENG J F, SONG Y G, YUAN P. The remediation of heavy metals contaminated sediment[J]. J Hazard Mater, 2009, 161(4): 633-640. [7] 储金宇, 张金萍, 周晓红, 等. 镇江市古运河河岸沉积物重金属分布特征及潜在生态风险评价[J]. 环境化学, 2015, 34(4): 763-771. CHU J Y, ZHANG J P, ZHOU X H, et al. Distribution characteristics and ecological risk evaluation of heavy metals in riverside sediments of Zhenjiang Canal[J]. Environmental Chemistry, 2015, 34(4): 763-771(in Chinese).
[8] CALMANO W, HONG J, FOERSTNER U. Binding and mobilization of heavy metals in contaminated sediments afected by pH and redox potential[J]. Water Sci Technol, 1993, 29(8): 223-235. [9] [10] KUNWAR P S, DINESH M, VINOD K. S, et al. Studies on distribution and fractionation of heavy metals in Gomti river sediments: A tributary of the Ganges, India[J]. Journal of Hydrology, 2005, 312(1-4): 14-27. [11] WANG L F, YANG L Y, KONG L G, et al. Spatial distribution, source identification and pollution assessment of metal content in the sediments of Nansi Lake, China[J]. Joutnal of Geochemical Exploration 2014, 140(3): 87-95. [12] HAKANSONL. An ecological risk index for aquatic pollution control a sedimentological approach[J]. Water Research, 1980, 14(8): 975-1001. [13] 刘强, 梁雷, 王峰源, 等. 辽河干流消落区沉积物重金属污染特征研究[J]. 中国环境科学, 2013, 33(12): 2220-2227. LIU Q, LIANG L, WANG F Y, et al. Characteristics of heavy metals pollution in sediments of the hydro-fluctuation belt in the Liao River of Liaoning province, Northeast China[J]. China Environmental Science, 2013, 33(12): 2220-2227(in Chinese).
[14] YAN J P, HE Y, HUANG H. Characteristics of heavy metals and their evaluation in sediments from middle and lower reaches of the huaihe river[J]. Journal of China University of Mining & Technology, 2007, 17(3): 414-417. [15] FARKAS A, ERRATICO C, VIGANO L. Assessment of the environmental significance of heavy metal pollution in surficial sediments of the River Po.[J]. Chemosphere, 2007, 68(4): 761-768. [16] CHOU H T, AHN J S, JUNG M C. Seasonal variations and chemical forms of heavy metals in soi ls and dusts f rom the satellite cities of Seoul, Korea[J]. Environment Geochemical Health, 1998, 20(2): 77-86. [17] 王岚, 王亚平, 许春雪, 等. 长江水系表层沉积物重金属污染特征及生态风险性评价[J]. 环境科学, 2012, 33(8): 2599-2606. WANG L, WANG Y P, XU C X, et al. Pollution Characteristics and Ecological Risk Assessment of Heavy Metals in the Surface Sediments of the Yangtze River[J]. Environmental Science, 2012, 33(8): 2599-2606(in Chinese).
[18] ZHU H N, YUAN X Z, ZENG G M, et al. Ecological risk assessment of heavy metals in sediments of Xiawan Port based on modified potential ecological risk index [J]. Transactions of Nonferrous Metals Society of China, 2012, 22(6): 1470-1477. [19] 漆燕, 向仁军, 刘湛, 等. 典型河流表层底泥重金属污染现状与评价[J]. 环境科学与技术, 2012, 35(12J): 91-95. Qi Y, Xiang R J, Liu Z, et al. Circumstance and assessment upon heavymetals pollution in surface sediment of typical river[J]. Environmental Science &Technology, 2012, 35(12J): 91-95(in Chinese).
[20] 王鸣宇, 秦延文, 张雷, 等. 湘江衡阳段表层沉积物重金属污染评价研究[J]. 环境科学与技术, 2011, 34(6G): 271-275. WANG M Y, QIN Y W, ZHANG L, et al. Analysis and assessment on pollution of heavy metal in the surface sediment of the Xiangjiang River in Hengyang section. [J]. Environmental Science &Technology, 2011, 34(6G): 271-275(in Chinese).
[21] 王鸣宇, 张雷, 秦延文, 等. 湘江表层沉积物重金属的赋存形态及其环境影响因子分析[J]. 环境科学学报, 2011, 31(11): 2447-2458. Wang M Y, Zhang L, Qin Y W, et al. Speciation of heavy metals in sediments from Xiang River and analysis of their environmental factors[J]. Acta Scientiae Circumstantiae, 2011, 31(11): 2447-2458(in Chinese).
[22] 唐文清, 刘利, 冯泳兰, 等. 河流底泥重金属污染现状分析及评价——以湘江衡阳段为例[J]. 衡阳师范学院学报, 2008, 29(6): 55-59. TANG W Q, LIU L, FENG Y L, et al. Analysis and assessment on pollution status of heavy metal in the fluvial sediment —A case study on the Hengyang section of Xiang River[J]. Journal of Hengyang Normal University, 2008, 29(6): 55-59(in Chinese).
[23] 李军. 湘江长株潭段底泥重金属污染分析与评价[D]. 长沙: 湖南大学, 2008. LI J. Analyses and investigation on heavy metal contamination in sediment of Xiangjiang River section flowing through Changsha, Zhuzhou, Xiangtan[D].Changsha: Hunan University, 2008(in Chinese). [24] 关小敏. 湘江长株潭段水体重金属污染特征及污染源解析[D]. 长沙: 湖南大学, 2011. GUAN X M. The characteristics and source apptionment of heavy metals contamination in "Changsha-Zhuzhou-Xiangtan" section of Xiangjiang River, [D].Changsha: Hunan University, 2008(in Chinese). [25] TESSIER A, CAMPBELL PGC, BISSON M, et al. Sequential extraction procedure for the speciation of particulate trace metals [J]. Analytical Biochemistry 1979, 51(7): 844-851. [26] [27] 张大文, 罗林广, 张莉, 等. 鄱阳湖表层沉积物中砷及重金属赋存形态及其潜在生态风险[J]. 长江流域资源与环境, 2014, 23(8): 1132-1138. ZHANG D W, LUO L G, ZHANG L, et al. Speciation and potential ecological risk assessment of As and heavy metals in surface sediments of Poyang Lake[J]. Resources and Environment in the Yangtze River, 2014, 23(8): 1132-1138(in Chinese).
[28] 曾北危, 潘佑民, 黄璋. 湘江沉积物污染初步评价[J]. 环境化学, 1982, 1(5): 352-358. ZENG B W, PANG Y M, HUANG Z. Preliminary evaluation of the Xiangjiang River sediment pollution[J]. Environmental Chemistry, 1982, 1(5): 352-358(in Chinese).
-
