净水污泥为载体的生物膜法在印染废水处理中的应用

,  ,  ,  ,

downloadPDF

上一篇

下一篇

刘晴, 杨兰, 王东田, 王炼, 徐知雄. 净水污泥为载体的生物膜法在印染废水处理中的应用[J]. 环境工程学报, 2017, 11(1): 188-196. doi: 10.12030/j.cjee.201508208
引用本文: 刘晴, 杨兰, 王东田, 王炼, 徐知雄. 净水污泥为载体的生物膜法在印染废水处理中的应用[J]. 环境工程学报, 2017, 11(1): 188-196. doi: 10.12030/j.cjee.201508208
shu
LIU Qing, YANG Lan, WANG Dongtian, WANG Lian, XU Zhixiong. Application of water purification sludge as biofilm carrier in dyeing wastewater treatment[J]. Chinese Journal of Environmental Engineering, 2017, 11(1): 188-196. doi: 10.12030/j.cjee.201508208
Citation: LIU Qing, YANG Lan, WANG Dongtian, WANG Lian, XU Zhixiong. Application of water purification sludge as biofilm carrier in dyeing wastewater treatment[J]. Chinese Journal of Environmental Engineering, 2017, 11(1): 188-196. doi: 10.12030/j.cjee.201508208
shu

净水污泥为载体的生物膜法在印染废水处理中的应用

  • 1.

    苏州科技学院环境科学与工程学院, 苏州, 215009

  • 2.

    苏州科技学院化学生物与材料工程学院, 苏州, 215009

  • 基金项目:

    国家自然科学基金资助项目（51178283）

    江苏省“六大人才高峰”资助项目

    苏州科技学院研究生科研创新计划项目（SKCX13S-054）

  • 中图分类号: X703.1

Application of water purification sludge as biofilm carrier in dyeing wastewater treatment

  • 1.

    School of Environmental Science and Engineering, Suzhou University of Science and Technology, Suzhou 215009, China

  • 2.

    School of Chemistry Biology and Material Engineering, Suzhou University of Science and Technology, Suzhou 215009, China

  • Fund Project:

  • 摘要: 以净水污泥制备的柱状颗粒为载体，采用上流式曝气生物滤柱（BAF）对污水厂经厌氧处理后的印染废水进行好氧处理。通过对净水污泥柱状颗粒的破碎实验、热重分析、BET、EDX、XRD、SEM和ICP-AES等表征分析表明，制备净水污泥柱状颗粒载体的最佳焙烧温度为600℃。在BAF对污染物的去除过程中，并且结构稳定。研究了COD、NH3-N、色度和SS等生化特性随BAF高度的沿程变化情况以及水力负荷、气水比对BAF处理效能的影响。结果表明，在气水比为4：1、水力负荷为0.03~0.06 m3·（m2·h）-1的最优条件下，BAF对COD、NH3-N、色度及SS的去除分别集中在填料层60 cm以下、60 cm以下、45 cm以上及15 cm以上。
    Abstract: Dyeing wastewater pretreated with an anaerobic process was aerobically treated using an up-flow biological aerated filter (BAF) column, which is a carrier for water purification sludge (WPS) particles prepared through granulation and calcinations. The WPS particles were characterized by a crushing test, thermogravimetric analysis, a BET-specific surface area test, an energy dispersive X-ray fluorescence spectrometer, X-ray diffraction, a scanning electron microscope, and inductively coupled plasma-atomic emission spectrometry, and the results revealed that the optimal calcination temperature was 600℃. The WPS carriers did not release secondary pollutants, such as heavy metals, and their granular structure was retained during the BAF wastewater treatment process. The removal rates of COD, NH3-N, chroma, and SS were investigated along with the optimal BAF height for each. The effects of hydraulic loading and air-water ratio on the efficiency of the BAF were also studied in detail, and their optimal values were from 0.03 to 0.06 m3·(m2·h)-1 and 4:1, respectively. The effective height of the BAF for the removal of COD and NH3-N was below 60 cm, whereas it was 15 cm and above 45 cm for the removal of SS and chroma, respectively.
  • 加载中
  • [1] 刘辉, 张玉先. 自来水厂的污泥处置与综合利用[J]. 给水排水, 2001, 27(11):15-18
    [2] 张玉妹, 韩乙萱, 魏杰, 等. 碱改性净水污泥对水中氨氮的吸附效能研究[J]. 环境科学学报, 2014, 34(10):2484-2490
    [3] HOVSEPYAN A, BONZONGO J C J. Aluminum drinking water treatment residuals (Al-WTPs) as sorbent for mercury:Implications for soil remediation[J]. Journal of Hazardous Materials, 2009, 164(1):73-80
    [4] KIM Y, KIM C, CHOI I, et al. Arsenic removal using mesoporous alumina prepared via a templating method[J]. Environmental Science & Technology, 2012, 38(3):924-931
    [5] BABATUNDE A O, HAO Y Q. Equilibrium and kinetic analysis of phosphorus adsorption from aqueous solution using waste alum sludge[J]. Journal of Hazardous Materials, 2010, 184(1/2/3):746-752
    [6] MONTEIRO S N, ALEXANDRE J, MARGEM J I, et al. Incorporation of sludge waste from water treatment plant into red ceramic[J]. Construction and Building Materials, 2008, 22(6):1281-1287
    [7] 陆洪宇, 马文成, 张梁, 等. 曝气生物滤池深度处理混合印染废水[J]. 环境工程学报, 2013, 7(7):2409-2413
    [8] 陆继来, 任洪强, 夏明芳, 等. 新排放标准的印染废水深度处理技术进展[J]. 工业水处理, 2009, 29(7):7-10
    [9] 冯栩, 廖银章, 李旭东. 印染废水生物处理技术的进展[J]. 印染2010(15):48-51
    [10] JOU C G, HUANG G C. A pilot study for oil refinery wastewater treatment using a fixed-film bioreactor[J]. Advanced in Environmental Research, 2003, 7(2):463-469
    [11] YANG Lei, LAI C T, SHIEH W K. Biodegradation of dispersed diesel fuel under high salinity conditions[J]. Water Research, 2000, 34(13):3303-3314
    [12] 国家环境保护局. 水和废水监测分析方法[M]. 4版. 北京:中国环境科学出版社, 2002:210-284
    [13] WANG Changhui, GAO Sijia, WANG Tianxiao, et al. Effectiveness of sequential thermal and acid activation on phosphorus removal by ferric and alum water treatment residuals[J]. Chemicals Engineering Journal, 2011, 172(2/3):885-891
    [14] SU Delin, WANG Jianlong, LIU Kaiwen, et al. Kinetic performance of oil-field produced water treatment by biological aerated filter[J]. Chinese Journal of Chemical Engineering, 2007, 15(4):591-594
    [15] 田晴, 陈季华. BAC生物活性炭法及其在水处理中的应用[J]. 环境工程, 2006, 24(1):84-86
    [16] 王琳, 窦娜莎. Biostyr曝气生物滤池处理城市污水的沿程生化特性[J]. 环境工程学报, 2013, 7(8):2942-2946
    [17] 严子春, 何强, 龙腾瑞, 等. 折流曝气生物滤池的特征与处理效能试验研究[J]. 环境工程学报, 2008, 2(10):1327-1331
    [18] 田晴. 印染碱减量废水二级出水生物活性炭法深度处理工艺的研究[D]. 上海:东华大学, 2006
    [19] 刘明坤, 郑俊, 汪荣. 曝气生物滤池的调试及运行[J]. 中国给水排水, 2008, 24(4):100-102
    [20] 王琳, 窦娜莎. Biostyr曝气生物滤池处理城市污水的影响因素[J]. 中国给水排水, 2013, 29(15):55-58
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1988
  • HTML全文浏览数:  1655
  • PDF下载数:  449
  • 施引文献:  0
出版历程
  • 收稿日期:  2015-12-02
  • 刊出日期:  2017-01-05
刘晴, 杨兰, 王东田, 王炼, 徐知雄. 净水污泥为载体的生物膜法在印染废水处理中的应用[J]. 环境工程学报, 2017, 11(1): 188-196. doi: 10.12030/j.cjee.201508208
引用本文: 刘晴, 杨兰, 王东田, 王炼, 徐知雄. 净水污泥为载体的生物膜法在印染废水处理中的应用[J]. 环境工程学报, 2017, 11(1): 188-196. doi: 10.12030/j.cjee.201508208
shu
LIU Qing, YANG Lan, WANG Dongtian, WANG Lian, XU Zhixiong. Application of water purification sludge as biofilm carrier in dyeing wastewater treatment[J]. Chinese Journal of Environmental Engineering, 2017, 11(1): 188-196. doi: 10.12030/j.cjee.201508208
Citation: LIU Qing, YANG Lan, WANG Dongtian, WANG Lian, XU Zhixiong. Application of water purification sludge as biofilm carrier in dyeing wastewater treatment[J]. Chinese Journal of Environmental Engineering, 2017, 11(1): 188-196. doi: 10.12030/j.cjee.201508208
shu

净水污泥为载体的生物膜法在印染废水处理中的应用

  • 1.  苏州科技学院环境科学与工程学院, 苏州, 215009
  • 2.  苏州科技学院化学生物与材料工程学院, 苏州, 215009
  • 收稿日期:  2015-12-02
基金项目:

国家自然科学基金资助项目（51178283）

江苏省“六大人才高峰”资助项目

苏州科技学院研究生科研创新计划项目（SKCX13S-054）

摘要: 以净水污泥制备的柱状颗粒为载体，采用上流式曝气生物滤柱（BAF）对污水厂经厌氧处理后的印染废水进行好氧处理。通过对净水污泥柱状颗粒的破碎实验、热重分析、BET、EDX、XRD、SEM和ICP-AES等表征分析表明，制备净水污泥柱状颗粒载体的最佳焙烧温度为600℃。在BAF对污染物的去除过程中，并且结构稳定。研究了COD、NH3-N、色度和SS等生化特性随BAF高度的沿程变化情况以及水力负荷、气水比对BAF处理效能的影响。结果表明，在气水比为4：1、水力负荷为0.03~0.06 m3·（m2·h）-1的最优条件下，BAF对COD、NH3-N、色度及SS的去除分别集中在填料层60 cm以下、60 cm以下、45 cm以上及15 cm以上。
