磁性Fe3O4/Ag3PO4复合光催化剂催化降解染料废水中的孔雀石绿

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

夏阁遥, 陈男, 胡伟武, 冯传平, 郭旭, 张振亚. 磁性Fe3O4/Ag3PO4复合光催化剂催化降解染料废水中的孔雀石绿[J]. 环境工程学报, 2015, 9(8): 3821-3827. doi: 10.12030/j.cjee.20150838
引用本文: 夏阁遥, 陈男, 胡伟武, 冯传平, 郭旭, 张振亚. 磁性Fe3O4/Ag3PO4复合光催化剂催化降解染料废水中的孔雀石绿[J]. 环境工程学报, 2015, 9(8): 3821-3827. doi: 10.12030/j.cjee.20150838
shu
Xia Geyao, Chen Nan, Hu Weiwu, Feng Chuanping, Guo Xu, Zhang Zhenya. Photocatalytic degradation of malachite green in dye wastewater by magnetical Fe3O4/Ag3PO4 composite photocatalysts[J]. Chinese Journal of Environmental Engineering, 2015, 9(8): 3821-3827. doi: 10.12030/j.cjee.20150838
Citation: Xia Geyao, Chen Nan, Hu Weiwu, Feng Chuanping, Guo Xu, Zhang Zhenya. Photocatalytic degradation of malachite green in dye wastewater by magnetical Fe3O4/Ag3PO4 composite photocatalysts[J]. Chinese Journal of Environmental Engineering, 2015, 9(8): 3821-3827. doi: 10.12030/j.cjee.20150838
shu

磁性Fe3O4/Ag3PO4复合光催化剂催化降解染料废水中的孔雀石绿

  • 1.

    中国地质大学(北京)水资源与环境学院, 北京 100083

  • 2.

    中国地质大学(北京)期刊中心, 北京 100083

  • 3.

    中国地质调查局天津地质调查中心, 天津 300170

  • 4.

    日本筑波大学生命与环境科学研究科, 筑波 3058572 日本

  • 基金项目:

  • 中图分类号: X703

Photocatalytic degradation of malachite green in dye wastewater by magnetical Fe3O4/Ag3PO4 composite photocatalysts

  • 1.

    School of Water Resources and Environment, China University of Geosciences (Beijing), Beijing 100083, China

  • 2.

    The Journal Center of China University of Geosciences (Beijing), Beijing 100083, China

  • 3.

    Tianjin Center, China Geological Survey, Tianjin 300170, China

  • 4.

    Life and Environmental Sciences, University of Tsukuba, Tsukuba 3058572, Japan

  • Fund Project:

  • 摘要: 利用离子交换法制备了可磁性分离并具有高效可见光催化活性的Fe3O4/Ag3PO4复合光催化剂,对制备的样品进行了粉末X射线衍射(XRD)表征。同时,用孔雀石绿溶液模拟染料废水,考察了孔雀石绿溶液的初始浓度、催化剂投加量及溶液初始pH值对复合光催化剂催化降解孔雀石绿效果的影响,并探讨了Fe3O4/Ag3PO4磁性复合光催化剂的回收及循环利用特性。结果表明,该复合光催化剂在可见光照射下表现出较高的催化活性;当孔雀石绿溶液浓度为5 mg/L、复合催化剂投加量为200 mg/L、溶液初始pH=3.0、可见光照20 min时,Fe3O4/Ag3PO4复合光催化剂对孔雀石绿的去除率可达96%;反应结束后,磁性复合光催化剂在外加磁场作用下,易于从反应体系中分离,循环使用3次后,其光催化效率仍可达到60%。实验表明,制备的复合光催化剂对染料废水中孔雀石绿有较高的降解效率,并具有优良的回收利用性。
    Abstract: The magnetically recoverable Fe3O4/Ag3PO4 composite photocatalysts with enhanced photocatalytic activity in visible light irradiation were synthesized by ion exchange method. The as-prepared samples were characterized by powder X-ray diffraction (XRD). Meanwhile, in the present study, we investigated the effect of initial solution concentration, dosage of photocatalysts and initial pH of reaction system on the degradation process using simulating dye wastewater with malachite green. Furthermore, the magnetically recyclability and reusability of Fe3O4/Ag3PO4 composite photocatalysts were also studied. As a result, the as-achieved photocatalysts exhibited high catalytic activity under visible light illumination, and the degradation efficiency of malachite green reached 96% within 20 min of irradiation (Initial solution concentration = 5 mg/L; dosage of composite photocatalyst=200 mg/L; initial solution pH=3.0). The Fe3O4/Ag3PO4 composite photocatalysts could be collected easily from photocatalytic system in a magnetic field, and the degradation efficiency could be maintained at 60% after 3 cycles. The research indicated the as-prepared composite photocatalysts showed high degradation efficiency towards malachite green and posed excellent reusability.
  • 加载中
  • [1] Chen Yijie, Zhang Yaqin, Chen Liu, et al. Photodegradation of malachite green by nanostructured Bi2WO6 visible light-induced photocatalyst. International Journal of Photoenergy, 2012, 2012: Article ID 510158, doi: 10.1155/2012/510518
    [2] Sridewi N., Lee Y. F., Sudesh K. Simultaneous adsorption and photocatalytic degradation of malachite green using electrospun P(3HB)-TiO2 nanocomposite fibers and films. International Journal of Photoenergy, 2011, 2012: Article ID 597854, doi: 10.1155/2011/597854
    [3] 刘永红, 张馨, 李大塘, 等. BiPO4/Ag3PO4新 型 可 见 光 催 化 剂 的制 备 及 其 性 能 研 究. 湖南科技大学学报(自然科学版), 2013, 28(1): 98-101 Liu Yonghong, Zhang Xin, Li Datang, et al. A study on preparation of BiPO4/Ag3PO4 novel visible light responsible photocatalysts and their photocatalytic performance. Journal of Hunan University of Science & Technology (Nature Science Edition), 2013, 28(1): 98-101 (in Chinese)
    [4] 刘素芹, 梁英, 刘华俊, 等. Ag3PO4/TiO2纳米管阵列的制备及其可见光光催化活性. 硅酸盐学报, 2012, 40(9): 1242-1246 Liu Suqin, Liang Ying, Liu Huajun, et al. Fabrication and visible-light photocatalytic activity of Ag3PO4/TiO2 nanotube arrays. Journal of the Chinese Ceramic Society, 2012, 40(9): 1242-1246 (in Chinese)
    [5] Chen Suhua, Yin Zhen, Luo Shenglian, et al. Preparation of magnetic Fe3O4/SiO2/Bi2WO6 microspheres and their application in photocatalysis. Materials Research Bulletin, 2013, 48(2): 725-729
    [6] Yi Zhiguo, Ye Jinhua, Kikugawa N., et al. An orthophosphate semiconductor with photooxidation properties under visible-light irradiation. Natural Materials, 2010, 9(7): 559-564
    [7] Dorniani D., Bin Hussein M. Z., Kura A. U., et al. Preparation of Fe3O4 magnetic nanoparticles coated with gallic acid for drug delivery. International Journal of Nanomedicine, 2012, 2012: 5745-5756
    [8] Wei Xiao, Xie Tengfeng, Peng Linlin, et al. Effect of heterojunction on the behavior of photogenerated charges in Fe3O4@Fe2O3nanoparticle photocatalysts. Journal of Physical Chemistry C, 2011, 115(17): 8637-8642
    [9] Polshettiwar V., Luque R., Fihri A., et al. Magnetically recoverable nanocatalysts. Chemical Reviews, 2011, 111(5): 3036-3075
    [10] Lv Baoliang, Xu Yao, Tian Hong, et al. Synthesis of Fe3O4＼SiO2＼Ag nanoparticles and its application in surface-enhanced Raman scattering. Journal of Solid State Chemistry, 2010, 183(12): 2968-2973
    [11] Guo Xu, Chen Nan, Feng Chuanping, et al. Performance of magnetically recoverable core-shell Fe3O4@Ag3PO4/AgCl for photocatalytic removal of methylene blue under simulated solar light. Catalyst Communication, 2013, 38: 26-30
    [12] Chen Guodong, Sun Meng, Wei Qin, et al. Ag3PO4/graphene-oxide composite with remarkably enhanced visible-light-driven photocatalytic activity toward dyes in water. Journal of Hazardous Materials, 2013, 244-245: 86-93
    [13] 张维强, 程乐华, 鲁文胜. 磁性纳米Fe3O4@TiO2 颗粒的制备及在污水治理中的应用. 巢湖学院学报, 2013, 15(3): 78-81 Zhang Weiqiang, Cheng Lehua, Lu Wensheng. The preparation of magnetic Fe3O4 @TiO2 nanoparticles and its application in sewage disposal. Journal of Chaohu College, 2013, 15(3): 78-81 (in Chinese)
    [14] Lu C. S., Wu Y. T., Mai F., et al. Degradation efficiencies and mechanisms of the ZnO-mediated photocatalytic degradation of Basic Blue 11 under visible light irradiation. Journal of Molecular Catalysis A: Chemical, 2009, 310(1-2): 159-165
    [15] 田菲, 董社英, 马彩莲, 等. Mg掺杂TiO2光催化降解孔雀绿染料的研究. 应用化工, 2011, 40(11): 1878-1881 Tian Fei, Dong Sheying, Ma Cailian, et al. Photodegradation of malachite green dye by Mg-doped TiO2. Applied Chemical Industry, 2011, 40(11): 1878-1881 (in Chinese)
    [16] An Changhua, Ming Xijuan, Wang Jizhuang, et al. Construction of magnetic visible-light-driven plasmonic Fe3O4@SiO2@AgCl: Ag nanophotocatalyst. Journal of Materials Chemistry, 2012, 22(11): 5171-5176
    [17] Lei Yongqian, Wang Guanhua, Guo Pengran, et al. Silver phosphate based plasmonic photocatalyst: highly active visible-light-enhanced photocatalytic property and photosensitized degradation of pollutants. Functional Materials Letters, 2012, 5(4): 1250047, doi: 10.1142/S1793604712500476
    [18] 温艳媛, 丁旵明. Ag@AgCl修饰的锐钛矿相TiO2纳米管的制备及其光催化性能. 催化学报, 2011, 32(1): 36-45 Wen Yanyuan, Ding Chanming. Preparation and photocatalytic activity of Ag@AgCl modified anatase TiO2 nanotubes. Chinese Journal of Catalysis, 2011, 32(1): 36-45 (in Chinese)
    [19] 徐荣, 葛骁, 郭海宁, 等. 银钛共负载型光催化材料降解甲基橙废水. 环境工程学报, 2014, 8(1): 150-156 Xu Rong, Ge Xiao, Guo Haining, et al. Photocatalytic degradation of methyl orange wastewater by co-deposited(Ag+-TiO2-EP) material. Chinese Journal of Environmental Engineering, 2014, 8(1): 150-156 (in Chinese)
    [20] Saha S., Wang J. M., Pal A. Nano silver impregnation on commercial TiO2 and a comparative photocatalytic account to degrade malachite green. Separation and Purification Technology, 2012, 89: 147-159
    [21] Afshar S., Jahromi H. S., Jafari N., et al. Degradation of malachite green oxalate by UV and visible lights irradiation using Pt/TiO2/SiO2 nanophotocatalyst. Scientia Iranica, 2011, 18(3): 772-779
    [22] Liu Y. G., Ohkob Y., Zhang R. Q., et al. Degradation of malachite green on Pd/WO3 photocatalysts under simulated solar light. Journal of Hazardous Materials, 2010, 184(1-3): 386-391
    [23] Ju Yongming, Yang Shaogui, Ding Youchao, et al. Microwave-assisted rapid photocatalytic degradation of malachite green in TiO2 suspensions: Mechanism and pathways. Journal of Physical Chemistry A, 2008, 112(44): 11172-11177
    [24] Chen C. C., Lu C. S., Chung Y. C., et al. UV light induced photodegradation of malachite green on TiO2 nanoparticles. Journal of Hazardous Materials, 2007, 141(3): 520-528
