微波-Cu(Ⅱ)-Fenton氧化法处理间硝基苯胺废水

,  ,  ,

downloadPDF

上一篇

下一篇

王楠楠, 郑彤, 张广山, 王鹏. 微波-Cu(Ⅱ)-Fenton氧化法处理间硝基苯胺废水[J]. 环境工程学报, 2015, 9(11): 5149-5154. doi: 10.12030/j.cjee.20151103
引用本文: 王楠楠, 郑彤, 张广山, 王鹏. 微波-Cu(Ⅱ)-Fenton氧化法处理间硝基苯胺废水[J]. 环境工程学报, 2015, 9(11): 5149-5154. doi: 10.12030/j.cjee.20151103
shu
Wang Nannan, Zheng Tong, Zhang Guangshan, Wang Peng. Treatment of m-nitroaniline wastewater by microwave-Cu(Ⅱ)-Fenton oxidation[J]. Chinese Journal of Environmental Engineering, 2015, 9(11): 5149-5154. doi: 10.12030/j.cjee.20151103
Citation: Wang Nannan, Zheng Tong, Zhang Guangshan, Wang Peng. Treatment of m-nitroaniline wastewater by microwave-Cu(Ⅱ)-Fenton oxidation[J]. Chinese Journal of Environmental Engineering, 2015, 9(11): 5149-5154. doi: 10.12030/j.cjee.20151103
shu

微波-Cu(Ⅱ)-Fenton氧化法处理间硝基苯胺废水

  • 1.

    哈尔滨工业大学市政环境工程学院, 哈尔滨 150090

  • 2.

    城市水资源与水环境国家重点实验室, 哈尔滨 150090

  • 基金项目:

    国家自然科学基金委员会创新研究群体科学基金资助项目(51121062)

    水质水量联合调控与应急处置关键技术研究与运行示范项目(2012ZX07205-005-05)

  • 中图分类号: X703.1

Treatment of m-nitroaniline wastewater by microwave-Cu(Ⅱ)-Fenton oxidation

  • 1.

    School of Municipal and Environmental Engineering, Harbin Institute of Technology, Harbin 150090, China

  • 2.

    State Key Laboratory of Urban Water Resource and Environment, Harbin 150090, China

  • Fund Project:

  • 摘要: 为了强化MW-Fenton法有机废水处理技术,向MW-Fenton体系中加入Cu(Ⅱ),组成MW-Cu(Ⅱ)-Fenton体系,并以间硝基苯胺(m-NA)为底物,对该体系进行了研究。首先考察了包括MW-Cu(Ⅱ)-Fenton体系在内的6种污水处理方法对m-NA配水的处理效果,并对其进行了准一级动力学对比。结果表明:MW-Cu(Ⅱ)-Fenton氧化法具有最大的反应速率常数(0.379 min-1),是MW-Fenton法(0.279 min-1)的1.36倍;Fe(Ⅱ)为MW-Cu(Ⅱ)-Fenton氧化法中的核心催化剂,Cu(Ⅱ)为辅助催化剂。在此基础上考察了pH,nH2O2/nFe(Ⅱ)和对MW-Cu(Ⅱ)-Fenton体系的影响,并进行了优化,根据实验结果,确定最佳条件为:pH=3.0,=0.20 mmol/L,nH2O2/nFe(Ⅱ)=80,=0.3 mg/L。最后,利用荧光分光度法测定了6种氧化体系中羟基自由基(·OH)的相对生成量,对比结果表明Cu(Ⅱ)是通过加快MW-Fenton体系中·OH的生成速率而起作用的。
    Abstract: In order to enhance the microwave-Fenton(MW-Fenton) process, Cu(Ⅱ) was added into the process to form MW-Cu(Ⅱ)-Fenton process. m-nitroaniline(m-NA) was chosen as the target pollutant. Firstly, the treatment effects of m-NA in six wastewater treatment methods respectively(MW-Cu(Ⅱ)-Fenton process included) were examined via the pseudo first-order kinetics comparison. The results show that MW-Cu(Ⅱ)-Fenton process has the largest reaction rate constant(0.379 min-1) which is 1.36 times larger than that in MW-Fenton process(0.279 min-1). Fe(Ⅱ) is the core catalyst in MW-Cu(Ⅱ)-Fenton process while Cu(Ⅱ) is the assistant one. Next, the effects of four parameters(pH,[Fe(Ⅱ)],nH2O2/nFe(Ⅱ),[Cu(Ⅱ)]) on MW-Cu(Ⅱ)-Fenton process were studied and optimized. According to the results, the optimal conditions were pH=3.0,=0.20 mmol/L, nH2O2/nFe(Ⅱ)=80 and=0.3 mg/L. Finally, the relative generation amount of hydroxyl radicals(·OH) was measured and compared by fluorescence spectrophotometry. The results reveal that the assistant catalyzed function of Cu(Ⅱ) is performed by accelerating the generation rate of·OH in MW-Cu(Ⅱ)-Fenton process.
  • 加载中
  • [1] 纪仲光, 王军, 栾兆坤. 微波辅助水处理研究应用进展. 给水排水, 2013, 39(增刊): 400-404 Ji Zhongguang, Wang Jun, Luan Zhaokun. Application progress of microwave assisted water treatment. Water & Wastewater Engineering, 2013, 39(S1): 400-404(in Chinese)
    [2] 冯文煊, 施文健, 刘剑青, 等. 微波技术在污水处理中的研究进展和应用. 环境污染与防治, 2014, 36(1): 73-79 Feng Wenxuan, Shi Wenjian, Liu Jianqing, et al. Application and research progress of microwave technology in sewage treatment. Environmental Pollution and Control, 2014, 36(1): 73-79(in Chinese)
    [3] 任伯帜, 侯保林, 陈文文, 等. 微波辐射对污水处理厂动态流活性污泥性能的影响研究. 环境科学学报, 2013, 33(6): 1624-1628 Ren Bozhi, Hou Baolin, Chen Wenwen, et al. Impact on properties of the sewage treatment plant dynamic flow activated sludge by microwave radiation. Acta Scientiae Circumstantiae, 2013, 33(6): 1624-1628(in Chinese)
    [4] Li Nan, Wang Peng, Zuo Chen, et al. Microwave-enhanced fenton process for DMSO-containing wastewater. Environmental Engineering Science, 2010, 27(3): 271-280
    [5] Wang Yujing, Zhao Hongying, Gao Junxia, et al. Rapid mineralization of azo-dye wastewater by microwave synergistic electro-fenton oxidation process. Journal of Physical Chemistry C, 2012, 116(13): 7457-7463
    [6] Liu Bo, Li Song, Zhao Yongjun, et al. Enhanced degradation of 4-nitrophenol by microwave assisted Fe/EDTA process. Journal of Hazardous Materials, 2010, 176(1-3): 213-219
    [7] 张德莉, 黄应平, 罗光富, 等. Fenton及Photo-Fenton反应研究进展. 环境化学, 2006, 25(2): 121-127 Zhang Deli, Huang Yingping, Luo Guangfu, et al. Research progress of Fenton and photo-Fenton reaction. Environmental Chemistry, 2006, 25(2): 121-127(in Chinese)
    [8] 戴清, 胡新林, 袁春伟. Photo-Fenton反应产生的羟自由基的研究. 东南大学学报, 1998, 28(2): 41-45 Dai Qing, Hu Xinlin, Yuan Chunwei. Study on hydroxyl free radicals from Photo-Fenton reaction. Journal of Southeast University, 1998, 28(2): 41-45(in Chinese)
    [9] 王其仓, 原野. Fenton反应机理的研究新发现. 化工中间体, 2013,(6): 23-26 Wang Qicang, Yuan Ye. The new found of Fenton reagent reaction mechanism. Chemical Intermediate, 2013,(6): 23-26(in Chinese)
    [10] 段冬, 吴德礼, 马鲁铭. 新型类Fenton催化剂用于酸性红B染料废水处理的研究. 环境工程学报, 2010, 4(11): 2413-2418 Duan Dong, Wu Deli, Ma Luming. Treatment of acid red B wastewater by a novel Fenton-like catalyst. Chinese Journal of Environmental Engineering, 2010, 4(11): 2413-2418(in Chinese)
    [11] 国家环境保护总局, 《水和废水检测分析方法》编委会. 水和废水监测分析方法(第4版). 北京: 中国环境科学出版社, 2002
    [12] Yu Jiaguo, Wang Wenguang, Cheng Bei, et al. Enhancement of photocatalytic activity of mesporous TiO2 powders by hydrothermal surface fluorination treatment. The Journal of Physical Chemistry C, 2009, 113(16): 6743-6750
    [13] 苗肖君, 王楠楠, 赵珊珊, 等. 微波辅助Cu(Ⅱ)-Fenton体系催化氧化处理对硝基苯酚废水. 环境工程学报, 2014, 8(6): 2299-2305 Miao Xiaojun, Wang Nanna, Zhao Shanshan, et al. Treatment of PNP wastewater by microwave assisted Cu(Ⅱ)-Fenton catalytic oxidation process. Chinese Journal of Environmental Engineering, 2014, 8(6): 2299-2305(in Chinese)
    [14] Wang Nannan, Zheng Tong, Jiang Jiping, et al. Pilot-scale treatment of p-nitrophenol wastewater by microwave-enhanced Fenton oxidation process: Effects of system parameters and kinetics study. Chemical Engineering Journal, 2014, 239: 351-359
    [15] 吕永为, 郭祥群. 荧光分光光度法测定两种中药对羟基自由基的清除作用. 厦门大学学报(自然科学版), 2004, 43(2): 208-212 Lü Yongwei, Guo Xiangqun. Evaluation of the scavenging effect of baitouweng, banzhilian to hydroxyl radical by fluorescence spectrophotometry. Journal of Xiamen University(Natural Science), 2004, 43(2): 208-212(in Chinese)
