表流-水平流复合人工湿地对高污染河水的净化

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

熊家晴, 杜晨, 郑于聪, 葛媛, 王怡雯, 王晓昌. 表流-水平流复合人工湿地对高污染河水的净化[J]. 环境工程学报, 2015, 9(11): 5167-5172. doi: 10.12030/j.cjee.20151106
引用本文: 熊家晴, 杜晨, 郑于聪, 葛媛, 王怡雯, 王晓昌. 表流-水平流复合人工湿地对高污染河水的净化[J]. 环境工程学报, 2015, 9(11): 5167-5172. doi: 10.12030/j.cjee.20151106
shu
Xiong Jiaqing, Du Chen, Zheng Yucong, Ge Yuan, Wang Yiwen, Wang Xiaochang. Purification of highly polluted river water using surface-horizontal subsurface flow hybrid constructed wetlands[J]. Chinese Journal of Environmental Engineering, 2015, 9(11): 5167-5172. doi: 10.12030/j.cjee.20151106
Citation: Xiong Jiaqing, Du Chen, Zheng Yucong, Ge Yuan, Wang Yiwen, Wang Xiaochang. Purification of highly polluted river water using surface-horizontal subsurface flow hybrid constructed wetlands[J]. Chinese Journal of Environmental Engineering, 2015, 9(11): 5167-5172. doi: 10.12030/j.cjee.20151106
shu

表流-水平流复合人工湿地对高污染河水的净化

  • 1.

    西安建筑科技大学环境与市政工程学院, 西北水资源与环境生态教育部重点实验室, 西安 710055

  • 基金项目:

    国家"水体污染控制与治理"科技重大专项(2012ZX07308-001-08)

  • 中图分类号: X522

Purification of highly polluted river water using surface-horizontal subsurface flow hybrid constructed wetlands

  • 1.

    Key Laboratory of Northwest Water Resource, Environment and Ecology of Ministry of Education, School of Environmental and Municipal Engineering, Xi'an University of Architecture and Technology, Xi'an 710055, China

  • Fund Project:

  • 摘要: 为了研究表流-水平流复合人工湿地对高污染河水的净化效果及植物对复合湿地中二级潜流湿地的影响作用,实验构建了表流+芦苇水平潜流和表流+无植物水平潜流复合人工湿地。在相同的水力负荷下连续运行一年的结果表明,复合人工湿地对高污染河水中TN、NH3-N、TP、COD、BOD5和SS的去除率分别为57.3%~63.1%、65.7%~68.1%、69.4%~82.7%、85.3%~86.3%、96.7%~96.9%和97.9%~98.2%,种有植物的二级潜流湿地具有更好的脱氮和除磷效果;表流湿地作为复合湿地的第一级能够有效去除大部分的有机污染物和悬浮物,进而避免二级潜流湿地的堵塞,并利于二级潜流湿地的脱氮除磷的进行;复合湿地对有机物和悬浮物的去除不受季节性波动的影响,但是其脱氮效果受季节波动的影响较大。
    Abstract: In order to investigate the pollutants removal efficiencies of the surface-horizontal subsurface flow(HF) hybrid constructed wetland(HCW) treating the highly polluted river and the roles of the plants in the second stage HFCW, two hybrid constructed wetlands which were composed of FWS+HF(with Phragmites) and FWS+HF(without plants) were constructed and operated under the same hydraulic loading. During one year's experiment, the average removal rates of TN, NH3-N, TP, COD, BOD5 and SS were 57.3%-63.1%, 65.7%-68.1%, 69.4%-82.7%, 85.3%-86.3%, 96.7%-96.9% and 97.9%-98.2%, respectively. The removal efficiencies of nitrogen and phosphorus in the planted HF were higher than the unplanted HF. As the first stage of the HCW, FWS removed most of organic and SS which avoided the clogging of the HF and improved the removal of the nitrogen and phosphorus in the second stage wetland. The removal of organic pollutants and suspended solids in the HCW were not affected by seasonal fluctuation, but the removal of nitrogen was influenced by seasonal fluctuation significantly.
  • 加载中
  • [1] 夏军, 翟金良, 占车生. 我国水资源研究与发展的若干思考. 地球科学进展, 2011, 26(9): 905-915 Xia Jun, Zhai Jinliang, Zhan Chesheng. Some reflections on the research and of development water resources in China. Advances in Earth Science, 2011, 26(9): 905-915(in Chinese)
    [2] 熊家晴, 杨洋, 郑于聪, 等. 表面流人工湿地对高含量有机污染河水的去除效果研究. 水处理技术, 2013, 39(7): 69-72 Xiong Jiaqing, Yang Yang, Zheng Yucong, et al. Treatment of high organic pollutants river wastewater by surface flow constructed wetland. Technology of Water Treatment, 2013, 39(7): 69-72(in Chinese)
    [3] 余志敏, 袁晓燕, 崔理华, 等. 复合人工湿地对城市受污染河水的净化效果. 环境工程学报, 2010, 4(4): 741-745 Yu Zhimin, Yuan Xiaoyan, Cui Lihua, et al. Removal efficiency of integrated constructed wetlands for treating polluted river water. Chinese Journal of Environmental Engineering, 2010, 4(4): 741-745(in Chinese)
    [4] 邢奕, 钱大益, 应高祥. 应用耐冷菌株改善寒冷地区冬季人工湿地系统生物脱氮效果. 北京科技大学学报, 2007, 29(S2): 53-57 Xing Yi, Qian Dayi, Ying Gaoxiang. Application of psychrotrophses in improving bio-treatment efficiency of nitrogen in constructed wetland in cold area during winter. Journal of University of Science and Technology Beijing, 2007, 29(S2): 53-57(in Chinese)
    [5] Saeed T., Sun Guangzhi. A review on nitrogen and organics removal mechanisms in subsurface flow constructed wetlands: Dependency on environmental parameters, operating conditions and supporting media. Journal of Environmental Management, 2012, 112: 429-448
    [6] 谢飞, 黄磊, 高旭, 等. 潜流人工湿地对微污染河水的净化效果. 环境工程学报, 2013, 7(1): 65-71 Xie Fei, Huang Lei, Gao Xu, et al. Purification efficiencies of subsurface horizontal flow constructed wetland treating slightly polluted river water. Chinese Journal of Environmental Engineering, 2013, 7(1): 65-71(in Chinese)
    [7] 赵建, 朱伟, 赵联芳. 人工湿地对城市污染河水的净化效果及机理. 湖泊科学, 2007, 19(1): 32-38 Zhao Jian, Zhu Wei, Zhao Lianfang. Efficiency and mechanism of treating the polluted river water with constructed wetland. Journal of Lake Science, 2007, 19(1): 32-38(in Chinese)
    [8] 钟林, 郑蕾, 丁爱中, 等. 人工湿地在我国污染河水治理中的应用及去除效果统计分析. 北京师范大学学报(自然科学版), 2012,48(1): 66-73 Zhong Lin, Zheng Lei, Ding Aizhong, et al. Reconstructed wetlands to treat polluted river-pollutant removal efficiency in China. Journal of Beijing Normal University(Natural Science), 2012, 48(1): 66-73(in Chinese)
    [9] 王文东, 王小刚, 高榕, 等. 表流-潜流人工湿地处理北方城市景观水体研究. 水处理技术, 2013, 39(10): 76-79, 84 Wang Wendong, Wang Xiaogang, Gao Rong, et al. Study on the treatment of urban landscape water by using the surface and subsurface flow constructed wetland in northern China. Technology of Water Treatment, 2013, 39(10): 76-79, 84(in Chinese)
    [10] 刘树元, 阎百兴, 王莉霞. 潜流人工湿地中植物对氮磷净化的影响. 生态学报, 2011, 31(6): 1538-1546 Liu Shuyuan, Yan Baixing, Wang Lixia. The effect of two wetland plants on nitrogen and phosphorus removal from the simulated paddy field runoff in two small-scale subsurface flow constructed wetlands. Acta Ecologica Sinica, 2011, 31(6): 1538-1546(in Chinese)
    [11] Liu Shuyuan, Yan Baixing, Wang Lixia. The layer effect in nutrient removal by two indigenous plant species in horizontal flow constructed wetlands. Ecological Engineering, 2011, 37(12): 2101-2104
    [12] 国家环境保护总局. 水和废水监测分析方法. 北京: 中国环境科学出版社, 2002
    [13] Vymazal J. The use of hybrid constructed wetlands for wastewater treatment with special attention to nitrogen removal: A review of a recent development. Water Research, 2013, 47(14): 4795-4811
    [14] Tanner C. C. Plants as ecosystem engineers in subsurface-flow treatment wetlands. Water Science and Technology, 2001, 44(11-12): 9-17
    [15] Erler D. V., Tait D., Eyre B. D., et al. Observations of nitrogen and phosphorus biogeochemistry in a surface flow constructed wetland. Science of the Total Environment, 2011, 409(24): 5359-5367
    [16] Herouvim E., Akratos C. S., Tekerlekopoulou A., et al. Treatment of olive mill wastewater in pilot-scale vertical flow constructed wetlands. Ecological Engineering, 2011, 37(6): 931-939
    [17] Yang Lei, Chang Huiting, Huang M. N. L. Nutrient removal in gravel-and soil-based wetland microcosms with and without vegetation. Ecological Engineering, 2001, 18(1): 91-105
    [18] Kuschk P., Wieβner A., Kappelmeyer U., et al. Annual cycle of nitrogen removal by a pilot-scale subsurface horizontal flow in a constructed wetland under moderate climate. Water Research, 2003, 37(17): 4236-4242
    [19] Tanner C. C., Kadlec R. H., Gibbs M. M., et al. Nitrogen processing gradients in subsurface-flow treatment wetlands-influence of wastewater characteristics. Ecological Engineering, 2002, 18(4): 499-520
