严一超, 张耀斌. O3/H2O2深度处理印染废水二级出水[J]. 环境工程学报, 2015, 9(11): 5281-5287. doi: 10.12030/j.cjee.20151124
引用本文: 严一超, 张耀斌. O3/H2O2深度处理印染废水二级出水[J]. 环境工程学报, 2015, 9(11): 5281-5287. doi: 10.12030/j.cjee.20151124
shu
Yan Yichao, Zhang Yaobin. Advanced treatment of bio-treated textile wastewater using O3/H2O2[J]. Chinese Journal of Environmental Engineering, 2015, 9(11): 5281-5287. doi: 10.12030/j.cjee.20151124
Citation: Yan Yichao, Zhang Yaobin. Advanced treatment of bio-treated textile wastewater using O3/H2O2[J]. Chinese Journal of Environmental Engineering, 2015, 9(11): 5281-5287. doi: 10.12030/j.cjee.20151124
shu

O3/H2O2深度处理印染废水二级出水

  • 1.

    大连理工大学环境学院, 大连 112004

  • 基金项目:

    国家"水体污染控制与治理"科技重大专项(2012ZX07202006-003)

  • 中图分类号: X703.1

Advanced treatment of bio-treated textile wastewater using O3/H2O2

  • 1.

    School of the Environment, Dalian University of Technology, Dalian 112004, China

  • Fund Project:

  • 摘要: 采用O3/H2O2高级氧化工艺深度处理印染废水二级出水,考察了不同反应条件对O3/H2O2工艺的影响,并且对污水二级出水有机物(EfOM)的性质和去除行为进行了表征分析。结果表明,在pH=9,臭氧进气流量0.2 L/min,臭氧浓度116 mg/L,反应时间100 min,H2O2投加量9.79 mmol/L时,COD和色度去除率分别为82.2%、96.9%,B/C(BOD5/COD)由初始的0.10提升到0.32。此外,三维荧光光谱(3DEEM)、相对分子质量分布(MWD)以及亲疏水性分布分析表明,处理后EfOM的荧光特性发生变化,低分子量物质大量增加,亲疏水性分布也有所改变。
    Abstract: A textile wastewater after bio-treated was further treated by O3/H2O2 process in this study. The influences of operating conditions on its performance were investigated, properties of effluent organic matter(EfOM) and its removal behavior were characterized as well. The results showed that the removal rates of COD and chroma were up to 82.2% and 96.9%, respectively, B/C(BOD5/COD) increased from 0.10 initially to 0.32, under the following optimal conditions including pH of 9, gas flow of 0.2 L/min, ozone concentration of 116 mg/L, reaction time of 100 min and H2O2 dosage of 9.79 mmol/L. After the treatment, three dimension fluorescence excitation-emission matrix(3DEEM), relative molecular weight distribution(MWD) and hydrophilicity/hydrophobicity demonstrated that both fluorescence characteristics and hydrophobic/hydrophilic properties of EfOM changed. Besides, low-MW substances increased abundantly.
  • 加载中
  • [1] 邓一荣, 赵璐, 傅翔, 等. 印染废水的高级氧化脱色深度处理中试. 中国给水排水, 2012, 28(23): 114-116 Deng Yirong, Zhao Lu, Fu Xiang, et al. Advanced oxidation process for decoloration treatment of printing and dyeing wastewater. China Water & Wastewater, 2012, 28(23): 114-116(in Chinese)
    [2] Turhan K., Turgut Z. Decolorization of direct dye in textile wastewater by ozonization in a semi-batch bubble column reactor. Desalination, 2009, 242(1-3): 256-263
    [3] Shon H. K., Vigneswaran S., Snyder S. A. Effluent organic matter(EfOM) in wastewater: Constituents, effects, and treatment. Critical Reviews in Environmental Science and Technology, 2006, 36(4): 327-374
    [4] Shon H. K., Vigneswaran S., Kim I. S., et al. Fouling of ultrafiltration membrane by effluent organic matter: A detailed characterization using different organic fractions in wastewater. Journal of Membrane Science, 2006, 278(1-2): 232-238
    [5] Huang Haiou. Microfiltration membrane fouling in water treatment: Impact of chemical attachments. Baltimore, Maryland: Doctor Dissertation of Johns Hopkins University, 2006
    [6] 贾瑞平, 陈烨璞. 臭氧联合氧化技术在污水处理方面的新进展. 工业水处理, 2007, 27(5): 4-9 Jia Ruiping, Chen Yepu. Current progress of ozone combined with other oxidation technique in wastewater treatment. Industrial Water Treatment, 2007, 27(5): 4-9(in Chinese)
    [7] 朱洪涛. 臭氧-微滤工艺处理二级出水过程中的膜污染及控制机理. 北京: 清华大学博士学位论文, 2009 Zhu Hongtao. Characteristics and mechanism of membrane fouling in the treatment of secondary effluent with ozonation-microfiltration process. Beijing: Doctor Dissertation of Tsinghua University, 2009(in Chinese)
    [8] 孙迎雪, 吴乾元, 田杰, 等. 污水中溶解性有机物组分特性及其氯消毒副产物生成潜能. 环境科学, 2009, 30(8): 2282-2287 Sun Yingxue, Wu Qianyuan, Tian Jie, et al. Characteristics and chlorinated disinfection by-products formation potential of dissolved organic matter fractions in treated wastewater. Environmental Science, 2009, 30(8): 2282-2287(in Chinese)
    [9] Gong Jianli, Liu Yongdi, Sun Xianbo. O3 and UV/O3 oxidation of organic constituents of biotreated municipal wastewater. Water Research, 2008, 42(4-5): 1238-1244
    [10] Popiel S., Nalepa T., Dzierz·ak D., et al. Rate of dibutylsulfide decomposition by ozonation and the O3/H2O2 advanced oxidation process. Journal of Hazardous Materials, 2009, 164(2-3): 1364-1371
    [11] Elovitz M. S.,Von Gunten U. Hydroxyl radical/ozone ratios during ozonation processes. I. The Rct concept. Ozone: Science & Engineering: The Journal of the International Ozone Association, 1999, 21(3): 239-260
    [12] 陈英, 张浩, 钟理, 等. 苯酚的O3/H2O2化学氧化反应动力学研究. 化学反应工程与工艺, 2001, 17(1): 55-60 Chen Ying, Zhang Hao, Zhong Li, et al. The reaction kinetics of phenol chemical oxidation by the O3/H2O2 process. Chemical Reaction Engineering and Technology, 2001, 17(1): 55-60(in Chinese)
    [13] Jiao Weizhou, Liu Youzhi, Liu Wenli, et al. Degradation of nitrobenzene-containing wastewater with O3 and H2O2 by high gravity technology. China Petroleum Processing and Petrochemical Technology, 2013, 15(1): 85-94
    [14] Suh J. H., Mohseni M. A study on the relationship between biodegradability enhancement and oxidation of 1,4-dioxane using ozone and hydrogen peroxide. Water Research, 2004, 38(10): 2596-2604
    [15] Zhao Weirong, Shi Huixiang, Wang Dahui. Ozonation of cationic red X-GRL in aqueous solution: Degradation and mechanism. Chemosphere, 2004, 57(9): 1189-1199
    [16] 陈岚. 除草剂2,4-D的O3、O3/H2O2高级氧化技术研究. 杭州: 浙江大学博士学位论文, 2004 Chen Lan. Oxidation of herbicides 2,4-D by ozone and ozone combined with hydrogen peroxide. Hangzhou: Doctor Dissertation of Zhejiang University, 2004(in Chinese)
    [17] He Zhiqiao, Song Shuang, Xia Min, et al. Mineralization of C. I. reactive yellow 84 in aqueous solution by sonolytic ozonation. Chemosphere, 2007, 69(2): 191-199
    [18] 马军, 石枫华. O3/H2O2氧化工艺去除水中硝基苯的研究. 环境科学, 2002, 23(5): 67-71 Ma Jun, Shi Fenghua. Study on removal of nitrobenzene in water by O3/H2O2. Environmental Science, 2002, 23(5): 67-71(in Chinese)
    [19] Laabs C. N., Amy G. L., Jekel M. Understanding the size and character of fouling-causing substances from effluent organic matter(EfOM) in low-pressure membrane filtration. Environment Science & Technology, 2006, 40(14): 4495-4499
    [20] Yang Wenlan, Li Xuchun, Pan Bingcai, et al. Effective removal of effluent organic matter(EfOM) from bio-treated coking wastewater by a recyclable aminated hyper-cross-linked polymer. Water Research, 2013, 47(13): 4730-4738
    [21] Baker A., Tipping E., Thacker S. A., et al. Relating dissolved organic matter fluorescence and functional properties. Chemosphere, 2008, 73(11): 1765-1772
    [22] 龚剑丽, 刘勇弟, 孙贤波, 等. 生化出水中各类有机污染物的特性及在混凝处理过程中的行为. 华东理工大学学报(自然科学版), 2008, 34(1): 91-95 Gong Jianli, Liu Yongdi, Sun Xianbo, et al. Characterization of residual organic pollutants in secondary effluent and their behavior during coagulation process. Journal of East China University of Science and Technology(Natural Science Edition), 2008, 34(1): 91-95(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1842
  • HTML全文浏览数:  1355
  • PDF下载数:  539
  • 施引文献:  0
出版历程
  • 收稿日期:  2014-09-20
  • 刊出日期:  2015-11-18
严一超, 张耀斌. O3/H2O2深度处理印染废水二级出水[J]. 环境工程学报, 2015, 9(11): 5281-5287. doi: 10.12030/j.cjee.20151124
引用本文: 严一超, 张耀斌. O3/H2O2深度处理印染废水二级出水[J]. 环境工程学报, 2015, 9(11): 5281-5287. doi: 10.12030/j.cjee.20151124
shu
Yan Yichao, Zhang Yaobin. Advanced treatment of bio-treated textile wastewater using O3/H2O2[J]. Chinese Journal of Environmental Engineering, 2015, 9(11): 5281-5287. doi: 10.12030/j.cjee.20151124
Citation: Yan Yichao, Zhang Yaobin. Advanced treatment of bio-treated textile wastewater using O3/H2O2[J]. Chinese Journal of Environmental Engineering, 2015, 9(11): 5281-5287. doi: 10.12030/j.cjee.20151124
shu

O3/H2O2深度处理印染废水二级出水

  • 1. 大连理工大学环境学院, 大连 112004
  • 收稿日期:  2014-09-20
基金项目:

国家"水体污染控制与治理"科技重大专项(2012ZX07202006-003)

摘要: 采用O3/H2O2高级氧化工艺深度处理印染废水二级出水,考察了不同反应条件对O3/H2O2工艺的影响,并且对污水二级出水有机物(EfOM)的性质和去除行为进行了表征分析。结果表明,在pH=9,臭氧进气流量0.2 L/min,臭氧浓度116 mg/L,反应时间100 min,H2O2投加量9.79 mmol/L时,COD和色度去除率分别为82.2%、96.9%,B/C(BOD5/COD)由初始的0.10提升到0.32。此外,三维荧光光谱(3DEEM)、相对分子质量分布(MWD)以及亲疏水性分布分析表明,处理后EfOM的荧光特性发生变化,低分子量物质大量增加,亲疏水性分布也有所改变。
