无机碳强化处理焦化废水EGSB反应器运行效能

,  ,  ,

downloadPDF

上一篇

下一篇

董春娟, 潘青业, 孙亚全, 汪艳霞. 无机碳强化处理焦化废水EGSB反应器运行效能[J]. 环境工程学报, 2017, 11(6): 3518-3524. doi: 10.12030/j.cjee.201603186
引用本文: 董春娟, 潘青业, 孙亚全, 汪艳霞. 无机碳强化处理焦化废水EGSB反应器运行效能[J]. 环境工程学报, 2017, 11(6): 3518-3524. doi: 10.12030/j.cjee.201603186
shu
DONG Chunjuan, PAN Qingye, SUN Yaquan, WANG Yanxia. Operational characteristic of EGSB reactor treating coking wastewater after adding inorganic carbon[J]. Chinese Journal of Environmental Engineering, 2017, 11(6): 3518-3524. doi: 10.12030/j.cjee.201603186
Citation: DONG Chunjuan, PAN Qingye, SUN Yaquan, WANG Yanxia. Operational characteristic of EGSB reactor treating coking wastewater after adding inorganic carbon[J]. Chinese Journal of Environmental Engineering, 2017, 11(6): 3518-3524. doi: 10.12030/j.cjee.201603186
shu

无机碳强化处理焦化废水EGSB反应器运行效能

  • 1.

    太原学院环境工程系, 太原 030032

  • 2.

    太原理工大成工程有限公司, 太原 030024

  • 3.

    中国市政工程中南设计研究总院有限公司, 武汉 430010

  • 基金项目:

    山西省2015科技攻关项目（20150313002-1）

  • 中图分类号: X703

Operational characteristic of EGSB reactor treating coking wastewater after adding inorganic carbon

  • 1.

    Department of Environmental Engineering, Taiyuan University, Taiyuan 030032, China

  • 2.

    Taiyuan University of Technology Da-Cheng Co. LTD, Taiyuan 030024, China

  • 3.

    Central and Southern China Municipal Engineering Design & Research Institute Co. Ltd., Wuhan 430010, China

  • Fund Project:

  • 摘要: 为实现处理焦化废水的颗粒污泥的快速培养，进而高效处理焦化废水，在22~27 ℃环境温度下，平行运行2个EGSB反应器，用焦化废水驯化处理啤酒废水颗粒污泥，对微氧运行（与厌氧对比），有机营养物添加（厌氧、微氧运行）、无机碳营养添加（厌氧、微氧运行）3种情况时的污染物质（COD）去除效果进行实验研究。研究结果表明：与厌氧相比，微氧运行能够明显强化焦化废水中毒性污染物质的去除。在焦化废水驯化初期，多次水质冲击（1 500 mg·L-1COD， 220 mg·L-1氨氮→2 000 mg·L-1COD，70 mg·L-1氨氮→700 mg·L-1COD，104~220 mg·L-1氨氮），微氧运行时COD平均去除率为24.8%（厌氧运行时仅为5.16%）。微氧运行虽然保证了污泥床的有效膨胀，但COD去除率的提高仍然有限。有机营养物的添加并没有使得COD去除率大幅提高，厌氧时为22.8%，微氧时为37.5%。无机碳营养（碳酸氢钠）的添加能够大幅提高焦化废水中COD去除率，厌氧时提高到53.8%；微氧时提高到75.4%，增幅分别达到31.0%和37.4%。微氧运行条件与无机碳营养的耦合作用能强化焦化废水中COD的去除，快速驯化培养处理焦化废水颗粒污泥。通过给处理焦化废水微氧EGSB反应器内添加碳酸氢钠，40 d就能完成高活性颗粒污泥的培养，高效处理焦化废水中各种污染物质。进水COD、酚类、氰化物和硫氢化物分别为54.8-1 927 mg·L-1，10.1-154.3 mg·L-1，0.9-57.8 mg·L-1和66.7-340.4 mg·L-1、进水流量1.2 L·h-1、HRT10 h 时，COD去除率达到78%~86%，酚类、氰化物、硫氢化物的平均去除率分别高达98.9%、93.1%和97.5%。
    Abstract: To rapidly acclimate granules and efficiently treat the actual coking wastewater, the granules that treat brewery wastewater were acclimated with the actual coking wastewater at 22-27℃ (operating two EGSB reactors in parallel).The COD removal efficiencies were investigated in the following three operation stages:the micro-aerobic operation condition (compared with the anaerobic operation condition), addition of organic nutrients (anaerobic and micro-aerobic operation), and addition of inorganic carbon substances (anaerobic and micro-aerobic operation).The results showed that, compared with the anaerobic operation, the micro-aerobic operation could distinctly enhance the removal of toxic pollutants in the actual coking wastewater.In the initial stage of acclimatization with actual coking wastewater, the COD average removal was 24.8% for micro-aerobic operation (only 5.16% for anaerobic operation), undergoing such water quality shocks as 1 500 mg·L-1COD, 220 mg·L-1 ammonia→2 000 mg·L-1 COD, 70 mg·L-1 ammonia→700 mg·L-1 COD, and 104~220 mg·L-1 ammonia.Though micro-aerobic operation could keep full expansion of granules sludge bed, the enhancement to COD removal was very limited.The addition of organic nutrients could not distinctly improve the COD removal efficiency at only 22.8% for anaerobic operation and 37.5% for micro-aerobic operation.However, the addition of inorganic carbon nutrients (bicarbonate) could enhance the COD removal efficiency considerably.The COD average removal efficiencies were high at 53.8% and 75.4% for the anaerobic and micro-aerobic operation (with 31.0% and 37.4% increased range), respectively.The coupling of micro-aerobic operation conditions and inorganic carbon could enhance the COD removal in the actual coking wastewater and then rapidly acclimate the granules that treat actual coking wastewater.Through the supplement of bicarbonate, the high activity granules in the EGSB reactor could be acclimated within 40 d and then could efficiently treat pollutants in the actual coking wastewater.Under the conditions of 54.8-1 927 mg·L-1, 10.1-154.3 mg·L-1, 0.9-57.8 mg·L-1 and 66.7-340.4 mg·L-1 of COD, phenol, cyanide and thiocyanate influent concentrations, respectively, a 1.2 L·h-1 influent flow,10 h HRT, the COD removal efficiency was 78%-86%, and the average removal efficiencies of phenol, cyanide and thiocyanate were 98.9%, 93.1% and 97.5%, respectively.
  • 加载中
  • [1] GU Qiyuan, SUN Tichang, WU Gen, et al.Influence of carrier filling ratio on the performance of moving bed biofilm reactor in treating coking wastewater[J].Bioresource Technology, 2014,166:72-78
    [2] WANG Feng, HU Yiru, GUO Chen, et al.Enhanced phenol degradation in coking wastewater by immobilized laccase on magnetic mesoporous silica nanoparticles in a magnetically stabilized fluidized bed[J].Bioresource Technology, 2012,110:120-124
    [3] LI Bing, SUN YingLan, LI Yuying.Pretreatment of coking wastewater using anaerobic sequencing batch reactor (ASBR)[J].Journal of Zhejiang University SCIENCE,2005,6B (11):1115-1123
    [4] 陆洪宇,孙亚全,董春娟,等.焦化废水中COD、挥发酚和硫氰化物同步高效去除[J].环境工程学报, 2014,8(7):2848-2852
    [5] 董春娟, 王海会,陈素云,等.EGSB反应器处理焦化废水的启动试验研究[J].中国给水排水,2011,27(9):91-94
    [6] LI Huosheng, ZHOU Shaoqi, MA Weihao, et al.Fast start-up of ANAMMOX reactor:Operational strategy and some characteristics as indicators of reactor performance[J].Desalination,2012, 286(2):436-441
    [7] MONTALVO S, GUERRERO L, ROBLES M, et al.Start-up and performance of UASB reactors using zeolite for improvement of nitrate removal process[J].Ecological Engineering, 2014,70(9):437-445
    [8] GOBERNA M, GADERMAIER M, FRANKE-WHITTLE I H, et al.Start-up strategies in manure-fed biogas reactors:Process parameters and methanogenic communities[J].Biomass and Bioenergy, 2015, 75(5):46-56
    [9] JEONG Y S, CHUNG J S.Simultaneous removal of COD, thiocyanate, cyanide and nitrogen from coal process wastewater using fluidized biofilm process[J].Process Biochemistry,2006, 41:1141-1147
    [10] KIM Y M, PARK D, LEE D S, er al.Sudden failure of biological nitrogen and carbon removal in the full-scale predenitrification process treating cokes wastewater[J].Bioresource Technology,2009, 100:4340-4347
    [11] CHAKRABORTY S, VEERAMANI H.Effect of HRT and recycle ratio on removal of cyanide, phenol,thiocyanate and ammonia n anaerobic-anoxic-aerobic continuous system[J].Process Biochemistry,2006,41:96-105
    [12] SAHARIAH B P, CHAKRABORTY S W.Kinetic analysis of phenol, thiocyanate and ammonia-nitrogen removals in an anaerobic-anoxic-aerobic moving bed bioreactor system[J].Journal of Hazardous Materials,2011, 190:260-267
    [13] XU P, HAN H, ZHUANG H, et al.Advanced treatment of biologically pretreated coal gasification wastewater by a novel integration of heterogeneous Fenton oxidation and biological process[J].Bioresource Technology,2015,182:389-392
    [14] 景雪.利用共基质代谢提高活性污泥法处理焦化废水COD的效率[J].广州环境科学,2009,24(3):11-14
    [15] 国家环保总局.水和废水监测分析方法[M].北京:中国环境科学出版社,2004
    [16] American Water Works Assocoation.Standard Methods for the Examination of Water and Wastewater[M].22 nd ed.Washington DC:American Public Health Association, 1999:4500-CN-M
    [17] KIM Y M, PARK D, LEE D S, er al.Inhibitory effects of toxic compounds on nitrification process for cokes wastewater treatment[J].Journal of Hazardous Materials,2008,152:915-921
    [18] VÁZQUEZ I, RODRÍGUEZ J, MARADIEN E,et al.Simultaneous removal of phenol, ammonium and thiocyanate from coke wastewater by aerobic biodegradation[J].Journal of Hazardous Materials,2006,137:1773-1780
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1668
  • HTML全文浏览数:  1394
  • PDF下载数:  586
  • 施引文献:  0
出版历程
  • 收稿日期:  2016-04-27
  • 刊出日期:  2017-06-23
董春娟, 潘青业, 孙亚全, 汪艳霞. 无机碳强化处理焦化废水EGSB反应器运行效能[J]. 环境工程学报, 2017, 11(6): 3518-3524. doi: 10.12030/j.cjee.201603186
引用本文: 董春娟, 潘青业, 孙亚全, 汪艳霞. 无机碳强化处理焦化废水EGSB反应器运行效能[J]. 环境工程学报, 2017, 11(6): 3518-3524. doi: 10.12030/j.cjee.201603186
shu
DONG Chunjuan, PAN Qingye, SUN Yaquan, WANG Yanxia. Operational characteristic of EGSB reactor treating coking wastewater after adding inorganic carbon[J]. Chinese Journal of Environmental Engineering, 2017, 11(6): 3518-3524. doi: 10.12030/j.cjee.201603186
Citation: DONG Chunjuan, PAN Qingye, SUN Yaquan, WANG Yanxia. Operational characteristic of EGSB reactor treating coking wastewater after adding inorganic carbon[J]. Chinese Journal of Environmental Engineering, 2017, 11(6): 3518-3524. doi: 10.12030/j.cjee.201603186
shu

无机碳强化处理焦化废水EGSB反应器运行效能

  • 1. 太原学院环境工程系, 太原 030032
  • 2. 太原理工大成工程有限公司, 太原 030024
  • 3. 中国市政工程中南设计研究总院有限公司, 武汉 430010
  • 收稿日期:  2016-04-27
基金项目:

山西省2015科技攻关项目（20150313002-1）

摘要: 为实现处理焦化废水的颗粒污泥的快速培养，进而高效处理焦化废水，在22~27 ℃环境温度下，平行运行2个EGSB反应器，用焦化废水驯化处理啤酒废水颗粒污泥，对微氧运行（与厌氧对比），有机营养物添加（厌氧、微氧运行）、无机碳营养添加（厌氧、微氧运行）3种情况时的污染物质（COD）去除效果进行实验研究。研究结果表明：与厌氧相比，微氧运行能够明显强化焦化废水中毒性污染物质的去除。在焦化废水驯化初期，多次水质冲击（1 500 mg·L-1COD， 220 mg·L-1氨氮→2 000 mg·L-1COD，70 mg·L-1氨氮→700 mg·L-1COD，104~220 mg·L-1氨氮），微氧运行时COD平均去除率为24.8%（厌氧运行时仅为5.16%）。微氧运行虽然保证了污泥床的有效膨胀，但COD去除率的提高仍然有限。有机营养物的添加并没有使得COD去除率大幅提高，厌氧时为22.8%，微氧时为37.5%。无机碳营养（碳酸氢钠）的添加能够大幅提高焦化废水中COD去除率，厌氧时提高到53.8%；微氧时提高到75.4%，增幅分别达到31.0%和37.4%。微氧运行条件与无机碳营养的耦合作用能强化焦化废水中COD的去除，快速驯化培养处理焦化废水颗粒污泥。通过给处理焦化废水微氧EGSB反应器内添加碳酸氢钠，40 d就能完成高活性颗粒污泥的培养，高效处理焦化废水中各种污染物质。进水COD、酚类、氰化物和硫氢化物分别为54.8-1 927 mg·L-1，10.1-154.3 mg·L-1，0.9-57.8 mg·L-1和66.7-340.4 mg·L-1、进水流量1.2 L·h-1、HRT10 h 时，COD去除率达到78%~86%，酚类、氰化物、硫氢化物的平均去除率分别高达98.9%、93.1%和97.5%。
