响应面法分析Fenton氧化处理采油废水的过程

,  ,  ,  ,

downloadPDF

上一篇

下一篇

朱米家, 田伟, 刘瑞平, 原志敏, 姚俊. 响应面法分析Fenton氧化处理采油废水的过程[J]. 环境工程学报, 2016, 10(3): 1217-1222. doi: 10.12030/j.cjee.20160334
引用本文: 朱米家, 田伟, 刘瑞平, 原志敏, 姚俊. 响应面法分析Fenton氧化处理采油废水的过程[J]. 环境工程学报, 2016, 10(3): 1217-1222. doi: 10.12030/j.cjee.20160334
shu
Zhu Mijia, Tian Wei, Liu Ruiping, Yuan Zhimin, Yao Jun. Application of response surface methodology to treatment of oil recovery wastewater processing using Fenton oxidation[J]. Chinese Journal of Environmental Engineering, 2016, 10(3): 1217-1222. doi: 10.12030/j.cjee.20160334
Citation: Zhu Mijia, Tian Wei, Liu Ruiping, Yuan Zhimin, Yao Jun. Application of response surface methodology to treatment of oil recovery wastewater processing using Fenton oxidation[J]. Chinese Journal of Environmental Engineering, 2016, 10(3): 1217-1222. doi: 10.12030/j.cjee.20160334
shu

响应面法分析Fenton氧化处理采油废水的过程

  • 1.

    北京科技大学土木与环境工程学院, 北京 100083

  • 基金项目:

    中国博士后基金资助项目(2012M510322)

  • 中图分类号: X131.2

Application of response surface methodology to treatment of oil recovery wastewater processing using Fenton oxidation

  • 1.

    School of Civil and Environmental Engineering, University of Science and Technology Beijing, Beijing 100083, China

  • Fund Project:

  • 摘要: 采用Fenton氧化对采油废水进行研究,选取双氧水与二价铁离子的摩尔比、初始pH值和反应时间为自变量,以废水的COD去除率为响应值,通过Box-Behnken设计方法进行实验设计,进行了3因素3水平共15个实验点的实验。使用响应面分析法对实验结果进行模拟及分析,建立了响应值与3个自变量的二次多项式方程模型。Fenton氧化的优化工艺条件:n(H2O2):n(Fe2+)=0.8,pH=3.0以及反应时间60 min。在该优化条件下,废水的COD去除率可达72.8%,经实验验证,实际值与模型预测值拟合性好,偏差仅为0.5%。实验结果证实了该模型分析采油废水处理运行参数的准确性。优化工艺后的处理水质COD值完全满足油田废水达标排放的要求。通过总离子色谱图和质谱检索分析原油中的成分变化情况,证实Fenton方法对原油组分的降解效果。
    Abstract: Fenton oxidation was employed to treat oil recovery wastewater. The H2O2/Fe2+ mole ratio, initial pH value, and reaction time were selected as independent variables; COD removal rate of wastewater was selected as the response value. A Box-Behnken design was employed for the experimental design, of which an experimental matrix of three-factorial, three-level experimental design consisting of 15 experimental runs was conducted. Experimental results were simulated and analyzed by response surface methodology. A quadratic polynomial equation was constructed to describe the relationship between COD removal rate and three variables. The optimum conditions of Fenton oxidation were determined to be a H2O2/Fe2+ mole ratio of 0.8, initial pH value of 3.0, and reaction time of 60 min. The removal rate of COD was up to 72.8% under the optimal conditions. The actual value agreed with the predicted value from the model equation with only 0.5% deviation. The results confirmed that the proposed models were accurate and reliable for the analysis of the variables of wastewater treatment. Furthermore, the COD of the treated water could meet the discharge standard in oilfields. The change of organic composition was reflected in the total ion chromatogram and mass spectrometry, which can be used to confirm the degradation effect of oil by the Fenton method.
  • 加载中
  • [1] 周奇彬, 戎晓坤, 赵志军, 等. 采油废水中多环芳烃的生态风险评价. 环境污染与防治, 2012, 34(6):37-41 Zhou Qibin, Rong Xiaokun, Zhao Zhijun, et al. Ecological risk assessment of polycyclic aromatic hydrocarbons in petroleum wastewater. Environmental Pollution and Control, 2012, 34(6):37-41(in Chinese)
    [2] 陈进富. 油田采出水处理技术与进展. 环境工程, 2000, 18(1):18-20 Chen Jinfu. Treatment technique of oil field produced water and its progress. Environmental Engineering, 2000, 18(1):18-20(in Chinese)
    [3] 傅剑锋, 武秋立. 响应面法分析Fenton氧化垃圾渗滤液的过程. 化工进展, 2006, 25(12):1493-1495 Fu Jianfeng, Wu Qiuli. Application of response surface methodology to treatment of landfill leachate processing using Fenton's oxidation. Chemical Industry and Engineering Progress, 2006, 25(12):1493-1495(in Chinese)
    [4] 陈学政, 李辉, 王羽. 油田含油污水Fenton氧化处理方法的研究. 环境保护科学, 2010, 36(4):30-32 Chen Xuezheng, Li Hui, Wang Yu. Study on oily sewage treatment by Fenton oxidation. Environmental Protection Science, 2010, 36(4):30-32(in Chinese)
    [5] Tabaraki R., Nateghi A., Ahmady-Asbchin S. Biosorption of lead (II) ions on Sargassum ilicifolium:Application of response surface methodology. International Biodeterioration & Biodegradation, 2014, 93:145-152
    [6] Boubakri A., Hafiane A., Bouguecha S. A. T. Application of response surface methodology for modeling and optimization of membrane distillation desalination process. Journal of Industrial and Engineering Chemistry, 2014, 20(5):3163-3169
    [7] 郭训文, 汪晓军. Fenton氧化深度处理稠油废水. 油田化学, 2013, 30(2):276-279 Guo Xunwen, Wang Xiaojun. Advanced treatment of heavy oil wastewater by Fenton oxidation. Oilfield Chemistry, 2013, 30(2):276-279(in Chinese)
    [8] Saldaña-Robles A., Guerra-Sánchez R., Maldonado-Rubio M. I., et al. Optimization of the operating parameters using RSM for the Fenton oxidation process and adsorption on vegetal carbon of MO solutions. Journal of Industrial and Engineering Chemistry, 2014, 20(3):848-857
    [9] Li Yongmei, Zhang Ai. Removal of steroid estrogens from waste activated sludge using Fenton oxidation:Influencing factors and degradation intermediates. Chemosphere, 2014, 105:24-30
    [10] Wang Jingang, Guo Yunleiyu, Guo Peiquan, et al. Degradation of reactive brilliant red K-2BP in water using a combination of swirling jet-induced cavitation and Fenton process. Separation and Purification Technology, 2014, 130:1-6
    [11] Merayo N., Hermosilla D., Cortijo L., et al. Optimization of the Fenton treatment of 1,4-dioxane and on-line FTIR monitoring of the reaction. Journal of Hazardous Materials, 2014, 268:102-109
    [12] Oliveira C., Alves A., Madeira L. M. Treatment of water networks (waters and deposits) contaminated with chlorfenvinphos by oxidation with Fenton's reagent. Chemical Engineering Journal, 2014, 241:190-199
    [13] Lin S. H., Lo C. C. Fenton process for treatment of desizing wastewater. Water Research, 1997, 31(8):2050-2056
    [14] 王娟, 杨再福. Fenton氧化在废水处理中的应用. 环境科学与技术, 2011, 34(11):104-108 Wang Juan, Yang Zaifu. Application of Fenton oxidation technology in wastewater treatment. Environmental Science & Technology, 2011, 34(11):104-108(in Chinese)
    [15] Chen Sheng, Sun Dezhi, Chung J. S. Treatment of pesticide wastewater by moving-bed biofilm reactor combined with Fenton-coagulation pretreatment. Journal of Hazardous Materials, 2007, 144(1-2):577-584
    [16] Meriç S., Kaptan D., Ölmez T. Color and COD removal from wastewater containing Reactive Black 5 using Fenton's oxidation process. Chemosphere, 2004, 54(3):435-441
    [17] 郦和生, 陈新芳, 刘伟, 等. Fenton试剂处理含油废水的实验研究. 北京化工大学学报, 2007, 34(3):238-240 Li Hesheng, Chen Xinfang, Liu Wei, et al. Treatment of oily wastewater with Fenton's reagent. Journal of Beijing University of Chemical Technology, 2007, 34(3):238-240(in Chinese)
